PDP-507CMX
S
C
ERIAL
This manual provides information for controlling the PDP-507CMX industrial plasma display panel
with an external communication device by using serial commands.
1
About the RS-232C Adjustment ............................................................................ 2
2
Interface .................................................................................................................. 3
3
Combination Connection ...................................................................................... 4
4
ID Assignment ........................................................................................................ 5
5
List of Commands.................................................................................................. 7
6
QUEST Commands ................................................................................................ 15
I
NDUSTRIAL
R
OMMAND
EFERENCE
Released: January 23, 2007
T
ABLE
P
LASMA
M
O
C
F
ONTENTS
D
P
ISPLAY
ANEL
ANUAL
(version 1.0)
Advertisement
Related Manuals for Pioneer PDP-507CMX
Summary of Contents for Pioneer PDP-507CMX
-
Page 1: Table Of Contents
PDP-507CMX ERIAL OMMAND This manual provides information for controlling the PDP-507CMX industrial plasma display panel with an external communication device by using serial commands. About the RS-232C Adjustment ... 2 Interface ... 3 Combination Connection ... 4 ID Assignment ... 5 List of Commands... -
Page 2: About The Rs-232C Adjustment
RS-232C Adjustment RS-232C Adjustment This display has an RS-232C terminal. It is possible to use a PC to make various adjustments and settings. 1 About the RS-232C Adjustment Adjustments using the RS-232C: • The adjustments are written to the same memory area as for the integrator mode (refer to section 5.4.4, “PICTURE, White Balance and SCREEN Position Adjustment Values Memory Area Tables”... -
Page 3: Interface
2 Interface 1) Connector D-sub 9 pins (male/straight) 2) Pin layout Pin No. Signal NC (not connected) TxD (Transmit Data) RxD (Receive Data) NC (not connected) 3) Baud Rate 9 600 bps (standard) (switch-able to 1 200, 2 400, 4 800, 19 200, 38 400 bps) Note The baud rate of this display should be set to match the baud rate of the PC. -
Page 4: Combination Connection
RS-232C Adjustment 3 Combination Connection When controlling/adjusting panels, it is convenient to connect several displays to one PC. By performing a combination connection and assigning IDs to the panels, it is possible to control and adjust several displays at the same time or separately. Connection method: Connect the panels as shown in the figure below. -
Page 5: Id Assignment
4 ID Assignment The ID is assigned from the PC. Commands: <IDC> (ID CLEAR) ... Clears the assigned ID <IDS> (ID SET) ... Assigns an ID IDS is only effective when an ID is not assigned. IDs are assigned starting from the panel closest to the PC. Example: Case of 4 displays (assigning IDs with the PC for the first time) First, connect an RS-232C and combination cables. - Page 6 RS-232C Adjustment Under the connection conditions shown below, use a combination cable for up to 16 panels. 1 Length of RS-232C cable connecting PC to Plasma Display: 5 m Conditions: 2 Combination cable length: 5 m each 3 Wire specifications for linking cable: Mini Din 6-pin straight (7 strand cable) Combination cable 5m Note For details on the number of displays that can be connected in series using the video OUT terminal (INPUT1, 4), refer to...
-
Page 7: List Of Commands
5 List of RS-232C Commands (Command 434CMX = Command 43MXE1 / Command 505CMX = Command 50MXE10 , 50MXE11 , 50MXE1 , 50MXE1-S / Command 425CMX = Command 42MXE10) 7 Normal Operation Related Commands Command Command Command 434CMX 427CMX 425CMX 505CMX 507CMX POWER Turns the power OFF. - Page 8 RS-232C Adjustment Command Command Command 434CMX 427CMX 425CMX 505CMX 507CMX Sets the MULTI SCREEN to PoutP (side by side, 2-L). MSTS06 Sets MULTI SCREEN to SWAP (switches between main – MSTS08 and sub screens). – MSTS09 Sets MULTI SCREEN to PoutP (side by side 2-R). MSTS10 Sets MULTI SCREEN to 2-SCREEN (side by side 3).
- Page 9 Sets the DVI BLACK LEVEL to LOW. – DBLS02 Sets the DVI BLACK LEVEL to HIGH. Note 1: The operation differs between the PDP-434CMX/PDP-505CMX and PDP-425CMX/PDP-507CMX/PDP-427CMX Note 2: EDIS01/02 only operates on the PDP-505CMX 7 “MENU”–“OPTION” related commands Command Command...
- Page 10 RS-232C Adjustment 7 “INTEGRATOR”–“PICTURE” related commands Command Command Command 434CMX 427CMX 425CMX 505CMX 507CMX VIDEO QUALITY Adjusts the contrast. Adjusts the brightness. Adjusts the horizontal enhance. Adjusts the vertical enhance. Adjusts the color. Adjusts the tint. Adjusts the sharpness. WHITE BALANCE Adjusts R.HIGH of the white balance.
- Page 11 7 “INTEGRATOR”–“OPTION” related commands Command Command Command 434CMX 427CMX 425CMX 505CMX 507CMX SCREEN MASK Displays the present set value of SCREEN MASK. FMKS00 Sets SCREEN MASK to OFF. Sets SCREEN MASK to inverse (negative – positive reversed). FMKS02 Sets SCREEN MASK to white mask. FMKS03 FMKS04 Sets SCREEN MASK to red mask.
- Page 12 PTRS06 – Sets sub screen translucence to 70 %. PTRS07 – Sets sub screen translucence to 80 %. PTRS08 Note 1: The operation differs between the PDP-434CMX/PDP-505CMX and PDP-425CMX/PDP-507CMX/PDP-427CMX Number direct Function Effective Minimum Maximum Last Comment memory New, and effective...
- Page 13 Command Command Command 434CMX 427CMX 425CMX 505CMX 507CMX – BPIS01 Sets the BANNER PinP input to INPUT1. Sets the BANNER PinP input to INPUT2. – BPIS02 Sets the BANNER PinP setting to OFF. – BPPS00 – BPPS01 Sets the BANNER PinP setting to TOP3. Sets the BANNER PinP setting to MID-HIGH.
- Page 14 RS-232C Adjustment Command Command Command 434CMX 427CMX 425CMX 505CMX 507CMX – – RMCS26 Remote control key: POINT ZOOM – – RMCS27 Remote control key: ID NO SET – – RMCS28 Remote control key: CLEAR – – RMCS29 Remote control key: FREEZE –...
-
Page 15: Quest Commands
6 QUEST Commands What are QUEST commands? • Quest commands output TXD such as adjustment data from the panel’s microprocessor to a PC. • Adjustment and other data is output in ASCII code. Note Command names are given inside brackets < >. •... - Page 16 RS-232C Adjustment 1) Obtaining QST Status Information Sequence Data Content Command echo-back Generation information Inch information Forwarding Power source state During standby: Standby cause During power supply: main screen signal status During standby or 1 screen display: dummy data During 2-screen display: sub screen signal status Main input function information Sub input function information Main screen size information...
- Page 17 2) <QPI> Obtaining Integrator/PICTURE information Sequence Data Content Command echo-back CONTRAST BRIGHTNESS C,DETAIL R (RED) C,DETAIL Y (YELLOW) C,DETAIL G (GREEN) C,DETAIL C (CYAN) C,DETAIL B (BLUE) C,DETAIL M (MAGENTA) H.ENHANCE V.ENHANCE COLOR TINT SHARPNESS Main input function Main screen size information Check sum Note 1) If the signal type is not confirmed, dummy data is output.
- Page 18 RS-232C Adjustment 5) <QSS> Obtaining SETUP information Sequence Data Content Command echo-back COLOR TEMP. POWER MGT. AUTO POWER OFF MPEG NR PURECINEMA COLOR DECODING COLOR SYSTEM DVI SET UP (PLUG/PLAY) DVI SET UP (BLACK LEVEL) BRT.ENHANCE SUB VOLUME Main input function Main screen size information Check sum Note 1) In the case of set data that cannot be output because of the type of input signal, dummy data is output.
- Page 19 Sequence Data Content PRO USE UNDERSCAN PRO USE IMAGE PROCESS PRO USE SYGNAL TYPE POWER ON MODE INPUT POWER ON MODE MULTI MODE POWER ON MODE MULTI INPUT 1 POWER ON MODE MULTI INPUT 2 POWER ON MODE VOLUME SEAMLESS SW SEAMLESS SW SELECT1 SEAMLESS SW SELECT2 MIRROR MODE...
- Page 20 QAP (fixed) 18 Byte 42 inch: A (North America model): PDP-427CMX******** G (Europe-general model): PDP-42MXE20******* 50 inch: J (Japan model): PDP-507CMX-JP***** A (North America model): PDP-507CMX******** G (Europe-general/CKD model): PDP-50MXE20******* GS (Europe-general/silver model): PDP-50MXE20******* 2 Byte 1 Byte 03hex 4: Wednesday...
- Page 21 7 Table of commands not compatible with PDP-434CMX to PDP-425CMX Ends 232C integrator adjustment mode. Starts 232C integrator adjustment mode. Displays present color off setting. COFS00 Does not set color off. COFS01 Sets color off. Resets still picture movement function. Selects audio output fix.
- Page 22 RS-232C Adjustment 7 Check Sum This is data to which 2-Byte ASCII code is added to a data group returned by a QUEST command. PC side QUEST command 02 (hex) 2 Byte 3 Byte A detailed example is given below. Example) The check sum value that is added when the QUEST command “QAA”...
