Step 18
H A R D WA R E
G
Screw M 10 x 33.5 mm
C O M P O N E N T S
12
Rear Drawer Board
13
Left Drawer Board
14
Right Drawer Board
15
Drawer Support Board
Step 19
H A R D WA R E
I
Cam Lock Ø12 mm
N
Cam Cover Ø12 mm
C O M P O N E N T S
11
Front Drawer Board
12
Rear Drawer Board
13
Left Drawer Board
14
Right Drawer Board
15
Drawer Support Board
16
Bottom Drawer Board
x15
x5
x5
x5
x5
x15
x10
x5
x5
x5
x5
x5
x5
C
A
PAGE 13 OF 17
