modway MOD-7082 Assembly Instructions Manual page 10

Step 13
H A R D WA R E
A Cam Lock Ø15 mm
C Cam Cover Ø17 mm
R Screw M 4 x 10 mm
C O M P O N E N T S
3
Left Side Board
5
Rear Board (Top and Bottom)
7
Top Support
8
Drawer Support
9
Drawer Support (Front)
Step 14
H A R D WA R E
A Cam Lock Ø15 mm
C Cam Cover Ø17 mm
G Screw M 10 x 33.5 mm
C O M P O N E N T S
2
Bottom Board
3
Left Side Board
4
Right Side Board
5
Rear Board (Bottom)
C
x10
x10
x2
x1
x1
x1
x4
x4
x2
x2
x4
x1
x1
x1
x1
A
A
C
PAGE 10 OF 17
