Step 16
H A R D WA R E
B
Cam Bolt Ø7.5 x 32 mm
D
Plastic Dowel Ø6 x 30 mm
C O M P O N E N T S
11
Front Drawer Board
12
Rear Drawer Board
Step 17
H A R D WA R E
D
Plastic Dowel Ø6 x 30 mm
C O M P O N E N T S
13
Left Drawer Board
14
Right Drawer Board
15
Drawer Support Board
x15
x20
x5
x5
x30
x5
x5
x5
PAGE 12 OF 17
