Cooper Lighting Halo L5056 Stasis Specification

DESCRIPTION
A series of understated, balanced lampholders that come in a variety of
lamp types. The Stasis family of lampholders feature die cast and extruded
bodies with elegant free flowing lines. Ideal for accent and display lighting
applications. This Ceramic Metal Halide T6 lampholder is perfect for those
applications where performance is required from a discreet source.
SPECIFICATION FEATURES
A ... Quick-Lock Adapter
Die cast adapter attaches
electrically and mechanically
anywhere along track. Includes
discreet locking tab that locks
lampholder on track and allows for
easy removal and repositioning.
Two position conductor allows use
in single circuit and either circuit of
two circuit track.
B ... Lockable Aiming
Lampholder tilt and rotation can be
locked in place easily with the
included 1.5mm allen wrench.
C ... Switch
On-off switch allows power to be
turned off during lamp
replacement on individual
lampholders.
D ... Ballast Housing
Die cast and extruded aluminum
housing incorporates the lamp
control circuit.
A
39W
5-5/8"
[143mm]
70W
6-3/4"
[171mm]
C
B
L 5
Track Lamp Type Series
L=Halo Track 5=Metal 05=Stasis
Halide
E ... Lamp Housing
Aluminum die cast lamp housing
has an integral reflector and
adjustable light center optic
allowing the light beam to be
adjusted from spot-to-flood.
F ... Lampholder Arm
Arm allows the lamp housing tilt to
adjust +/-90°. It also pivots +/-90°
around the ballast housing. This
enables the ballast housing to
remain static on the track creating
a clean look, while providing full
aiming capabilities. The arm
employs graduations every 15° for
precise and repeatable tilt aiming.
Indicator mark on the bottom
ensures perfect lamp housing
alignment with track.
F
B
2-3/8"
[60mm]
H
05 6
Lamp Wattage
6 =T6 CMH 39 = 39W T6 CMH
(Lamp Not 70 = 70W T6 CMH
Included)
Specifications and Dimensions subject to change without notice.
Consult your representative for additional options and finishes.
Catalog #
Project
Comments
Prepared by
G ... Beam Focus Knob
Knob rotates 90° providing infinite
beam adjustment from
spot-to-flood. A cool-to-the-touch
silicone cover allows convenient,
hot aiming capabilities. The
silicone cover has an embossed
graphic indicating turn direction
for desired beam.
H ... Bezel
Removable front bezel features
positive threaded engagement and
holds the containment lens with a
threaded media ring. The bezel
accepts L275 cube cell louver and
L200 media, including color filters
and beam modifying lenses. Bezel
accepts a total two pieces of
media.
Labels
UL/c-UL Listed for use with Halo
Power-Trac and Lazer Track.
D
G
E
7-7/16"
[189mm]
4-13/16"
[106mm]
Finish
Accessories
P=White L200=Series Lenses
MB=Black
L275 =Cube Cell Louver
AH =Aluminum
Haze
HALO
®
Type
Date
L5056
Stasis
39 and 70W Ceramic Metal Halide
T6
Power-Trac
Energy Data
Input Power: 39W: 45W
70W: 77W
> 0.95
Power Factor:
Input Current: 39W: 0.37A
70W: 0.65A
Harmonic Distortion: <10%
ADV070779
11/06/2007 5:13:50 PM
