SPLIT-TYPE, HEAT PUMP AIR CONDITIONERS
SPLIT-TYPE, AIR CONDITIONERS
SERVICE MANUAL
Indoor unit
[Model Name]
PSA-RP71KA
PSA-RP100KA
PSA-RP125KA
PSA-RP140KA
[Service Ref.]
PSA-RP71KA
PSA-RP100KA
PSA-RP125KA
PSA-RP140KA
Model name
indication
Revision:
• Some descriptions have been
modified.
OCH528 REVISED EDITION-A
is void.
Notes:
• This manual describes only
service data of the indoor
units.
CONTENTS
1. REFERENCE MANUAL .................................. 2
2. SAFETY PRECAUTION .................................. 3
3. PARTS NAMES AND FUNCTIONS ................ 5
4. SPECIFICATIONS ........................................... 7
5. NOISE CRITERION CURVES ......................... 9
6. OUTLINES AND DIMENSIONS ..................... 10
7. WIRING DIAGRAM ........................................ 11
8. REFRIGERANT SYSTEM DIAGRAM ........... 12
9. TROUBLESHOOTING ................................... 13
10. SPECIAL FUNCTION .................................... 23
11. DISASSEMBLY PROCEDURE ...................... 26
PARTS CATALOG (OCB528)
September 2018
No. OCH528
REVISED EDITION-B
