Kerosene
User's Manual and
Forced Air Heaters
Operating Instructions
Model #s: PT-45-KFA, PT-70T-KFA,
PT-125T-KFA, PT-175T-KFA, PT-215T-KFA
CONSUMER: Retain this manual for future reference.
IMPORTANT: Read and understand all of the directions in this manual before assembling,
starting, or servicing the heater. Improper use of this heater can cause serious injury. Keep this
manual for future reference.
GENERAL HAZARD WARNING:
DANGER
Be sure to comply with the instructions and warnings provided with this heater, or death,
serious bodily injury and property loss, damage from the hazards of fire, explosion, burn,
asphyxiation, and carbon monoxide poisoning can result.
Only persons who can follow and understand these instructions should use or service this
heater. If you need heater information such as an instruction manual, labels, etcetera, contact
the manufacturer.
Not for use in residential living areas or in non-adequately ventilated enclosed
DANGER
spaces.
Pinnacle Products International, Inc. 668 Stony Hill Road #302 Yardley, PA 19067 USA
Phone: 215-891-8460 Fax: 215-891-8461 Web: www.pinnacleint.com Email: info@pinnacleint.com
701000103-10
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Pinnacle International Protemp PT-175T-KFA
Summary of Contents for Pinnacle International Protemp PT-175T-KFA
- Page 1 If you need heater information such as an instruction manual, labels, etcetera, contact the manufacturer. Not for use in residential living areas or in non-adequately ventilated enclosed DANGER spaces. Pinnacle Products International, Inc. 668 Stony Hill Road #302 Yardley, PA 19067 USA Phone: 215-891-8460 Fax: 215-891-8461 Web: www.pinnacleint.com Email: info@pinnacleint.com 701000103-10...
-
Page 2: Table Of Contents
This is an unvented portable heater. It uses air (oxygen) from the area in which it is used. Adequate combustion and ventilation air must be provided. Refer to VENTILATION on Page 7. -
Page 3: Features
NEVER move or handle heater while still hot. NEVER transport heater with fuel in its tank. If equipped with a thermostat, the heater may start at any time. ALWAYS locate heater on a stable and level surface. ALWAYS keep children and animals away from heater. -
Page 4: Specifications
Pump Pressure PSI Volt/Hz 120VAC/60 Hz Amps Phase Size (L x W x H) Net Weight (Lbs) Specifications subject to change without notice Page 4 Pinnacle Products International, Inc. Kerosene User’s Manual PT-70T-KFA 45,000 70,000 0.35 0.53 120VAC/60 Hz Single Single 30”... -
Page 5: Unpacking
Front Handle Figure 5. Frame components, Models PT-125T/175T/215T-KFA Pinnacle Products International, Inc. Kerosene User’s Manual Check the chart below to be sure that you have all of the parts required to assembly your heater. If you find that any parts are missing, call 215-891-8460 for assistance in receiving the miss- ing components. -
Page 6: Assembly
4. Snap the wheel caps onto the large washers (B). 5. Place heater on the assembled frame, making sure that the air inlet end is by the wheels, and the mounting holes on the tank flange of the heater align with holes in frame. -
Page 7: Fuels
IS HOT OR OPERATING. FIRE OR EXPLOSION COULD RESULT. It is always a good idea to fire the heater outdoors for the fist time. This will allow any oils used in the manufacturing process to be burned off in a safe environment. This initial burn should last... -
Page 8: Operation
Troubleshooting Guide on Page 15. NOTE: The electrical components of this heater are protected by a fuse mounted in the PC board. If the heater fails to fire, check this fuse first, and replace if necessary. Also check the power source to be sure that the proper voltage is being provided to the heater. -
Page 9: Maintenance
Be sure fan blades are dry before re-starting the heater. For Fan removal, see Figure Figure 14. Fan Replacement Pinnacle Products International, Inc. Kerosene User’s Manual NOZZLES: Nozzles should be cleaned or replaced at least once per heating season. - Page 10 Photocell Lens Installing Photocell: 1) Incorrect 2) Correct Figure 17. Photocell Positioning Page 10 Pinnacle Products International, Inc. Kerosene User’s Manual Ignitor Wire Photocell Wire PT-70T-KFA only Figure 18. Photocell Position for PT-45 / 70T-KFA FUEL FILTER: The Fuel Filter should be cleaned at least twice per heating sea- son by rinsing it in clean 1-K kerosene.
-
Page 11: Pump Pressure
For best measurement of pressure, test with full tank of fuel. Optimum pressure occurs when the nose cone is cherry red and there are no extending flames from the heater. Pinnacle Products International, Inc. Kerosene User’s Manual Pump Pressure 3.0 PSI 4.0 PSI 5.0 PSI... -
Page 12: Exploded Parts Drawing
ING OR WHILE CONNECTED TO A POWER SOURCE Exploded Drawing Part Breakdown Figure 21. Exploded View Models PT-45/70T/125T/175T/215T-KFA Page 12 Pinnacle Products International, Inc. Kerosene User’s Manual (PT-125 / 175 / 215T-KFA only) (PT-40 / 70T-KFA only) 5 42 Kerosene... -
Page 13: Replacement Part Listing
Electric Outlet Handle Front Handle Rear Handle Wheel Support Frame Wheel Axle Wheel (Pneumatic) Wheel Cap Hardware Kit Cord Wrap Pinnacle Products International, Inc. Kerosene User’s Manual Part Number for Models: PT-45-KFA PT-70T-KFA 70-002-0100 70-002-0100 – – 70-007-0100 70-007-0100 70-003-0100... -
Page 14: Wiring Diagrams
Kerosene UNATTENDED WHILE BURN- ING OR WHILE CONNECTED Forced Air Heaters TO A POWER SOURCE Wiring Diagrams Figure 23 Model PT-70T-KFA Figure 22 Model PT-45-KFA Figure 24 Model PT-125T/ 175T/ 215T-KFA Page 14 Pinnacle Products International, Inc. Kerosene User’s Manual... -
Page 15: Troubleshooting Guide
Poor Combustion and / or excess soot production Heater does not turn on and the lamp is not lit Pinnacle Products International, Inc. Kerosene User’s Manual Possible Cause 1. Incorrect pump pressure 2. Dirty Input, Output or Lint Filter 3. Dirty Fuel Filter 4. -
Page 16: Limited Warranty
Pinnacle Products International, Inc. will repair or replace and return the item, freight pre-paid. If Pinnacle Products International, Inc. finds the item to be in normal operating condition, or not defective, the item will be returned freight collect.This Limited Warranty is in lieu of all other express warranties.
