- Page 1 MPCM45 Universal-Chassis Single Channel A/V Mini-Modulator Installation and Operation Manual Operation www.picomacom.com Ph:800-421-6511 Manual Rev. 04/03...
-
Page 2: Product Inspection
To insure proper installation and operation, take a moment to read this guide before proceeding with the installation. If you have any questions or comments about the MPCM45 modulator, please contact your dealer or have him contact the PICO MACOM Service Center at these phone numbers: 800-421-6511, 818-493-4300. -
Page 3: Note To The Catv System Installer
21. Outdoor Antenna Grounding: Before attempting to install this product, be sure the antenna or cable system is grounded so as to MPCM45 provide some protection against voltage surges and built-up static charges. - Page 4 The unit’s phase- locked loop (PLL) circuitry and unique multi-stage output bandpass filtering ensure accurate and spurious-free output. In addition, the MPCM45 uses SAW filtering with FCC group delay correction circuitry to provide superior adjacent channel selectivity.
-
Page 5: Specifications
General Power Input: Operating Temperature: Dimensions: Weight: Connectors: Power: Ordering Information MPCM45 – Channel Ph:800-421-6511 www.picomacom.com 1 V p-p min for 87.5% mod. 75 Ohms 0.5 V to 1.5 V p-p <5% (10 to 90% APL) <5° (10 to 90% APL) +12 VDC, +5 VDC -10°... -
Page 6: Operation And Controls
Operation and Controls MPCM45 PICO MACOM AUDIO VIDEO RATIO Panels Front, Rear and Side Panels Audio Level Control: Use this control to adjust the audio modulation level (volume). Video Level Control: Use this control to adjust the video modulation level (picture quality). -
Page 7: Installation Procedure
• Do not use solvents or harsh detergents. • Do not use this product for purposes other than intended. HEADEND/DISTRIBUTION INTERFACE PICO MACOM recommends connecting the headend components in the following manner: Each of the modulators, signal processors or strip amplifiers output are connected to a combining network. -
Page 8: Warranty
We will issue an invoice for the List Price of the loaner unit plus shipping costs. When you receive the loaner unit, pack the failed unit in the loaner unit’s box and ship it freight prepaid to Pico Macom for repair. When you receive the repaired unit, a new RMA number will be provided in the box. Carefully pack the loaner unit and affix the new RMA number on the box and ship it back to us for full credit excluding shipping costs.
