Summary of Contents for Pico Macom PFAM550
-
Page 1: Operation Manual
PFAM550 Manual.qxd 7/29/03 2:10 PM Page 1 PFAM550 550MHz Agile A/V Modulator Installation and Operation Manual Operation www.picomacom.com Ph: 800-421-6511 Manual Rev. 07/03... -
Page 2: Product Inspection
To insure proper installation and operation, take a moment to read this guide before proceeding with the installation. If you have any questions or comments about the PFAM550 Agile A/V Modulator, please contact your dealer or have him contact the PICO MACOM Service Center at these phone numbers: 800-421-6511, 818-493-4300. - Page 3 PFAM550 Manual.qxd 7/29/03 2:10 PM 11. Power Sources: This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supplied to your home, consult your appli- ance dealer or local power company.
- Page 4 Its SAW filter provides superior sideband filtering, adjacent channel compatibility and spurious free output. The PFAM550 provides 57±2 dBmV output over 82 channels from CATV channel 2 to 78 accommodating HRC and IRC offset frequencies. The unit features a composite audio-video IF loop, which provides compatibility with encoders, ghost cancellers, and video-override applications.
-
Page 5: Specifications
PFAM550 Manual.qxd 7/29/03 2:11 PM PFAM550 550MHz Agile A/V Modulator POWER RF OUT Video Channels: Frequency Range: Output Level: Output Impedance: Output Return Loss: Audio/Video Ratio: Frequency Stability: Spurious Output: C/N (In-band): C/N (Out-of-Band): Fv+6 MHz (Upper Adj. Reject): Fv-1.5 MHz (Lower Adj. Reject):... -
Page 6: Operation And Controls
PFAM550 Manual.qxd 7/29/03 2:11 PM Operation and Controls PFAM550 PFAM550 550MHz Agile A/V Modulator POWER Front Panel Control Power On LED: Indicates power is on when lit. Video/Audio Ratio Adjustment: Used to set level of audio carrier. Audio Modulation LED: Indicates aural over modulation level when lit. -
Page 7: Installation Procedure
Measure the video and aural carrier level of the PFAM550 and adjacent channels. 15. Adjust the Output level of the PFAM550 to match the video and audio carrier levels of adjacent channels by adjusting the OUTPUT LEVEL adjustment on the front panel of the PFAM550. -
Page 8: Limited Warranty
We will issue an invoice for the List Price of the loaner unit plus shipping costs. When you receive the loaner unit, pack the failed unit in the loaner unit’s box and ship it freight prepaid to Pico Macom for repair. When you receive the repaired unit, a new RMA number will be provided in the box. Carefully pack the loaner unit and affix the new RMA number on the box and ship it back to us for full credit excluding shipping costs.
