Page 1: Installation And
VSS-52R 5X2 Matrix Switch Installation and Operation Manual Operation www.picomacom.com Ph: 800-421-6511 Manual Rev. 07/03... - Page 2 To insure proper installation and operation, take a moment to read this guide before proceeding with the installation. If you have any questions or comments about the VSS-52R Matrix Switch, please contact your dealer or have him contact the PICO MACOM Service Center at these phone numbers: 800-421-6511, 818-493-4300.
- Page 3 21. Outdoor Antenna Grounding: Before attempting to install this product, be sure the antenna or cable system is grounded so as to VSS-52R provide some protection against voltage surges and built-up static charges.
- Page 4 Rev. 07/03 VSS-52R 5X2 Matrix Switch The VSS-52R matrix switch is ideal for use with a security monitoring centers or school television production where on-the-fly switching between sources is required. The included remote control allows the user to switch any of five input sources independently between two separate outputs, providing an output for recording and one for monitoring.
-
Page 5: Specifications
5x RCA-Audio (Left and Right) Outputs: Video: 2x S-video, RCA-Composite Audio: 2x RCA-Audio (Left and Right) Impedance (In/Out): Video: Audio: Ordering Information VSS-52R VSS-52R VSS-52R 5X2 Matrix Switch SOURCE Front View A/V 1 A/V 2 A/V 3 A/V 4 A/V 5... -
Page 6: Operation And Controls
Operation and Controls VSS-52R STANDBY Front Panel Controls Standby: This indicator will illuminate when the unit has been turned off (no source will be routed to either output). Infrared Detector This is the location the remote control IR signal must reach. -
Page 7: Installation Procedure
If you are not able to obtain a picture, see Troubleshooting Information. Remote Control Operation 1. When using the remote control always aim towards the VSS-52R. 2. The standby LED is lit when plugged in. 3. On the remote control depress the power button and the standby led will distinguish and the power and a device LED will illuminate. -
Page 8: Limited Warranty
We will issue an invoice for the List Price of the loaner unit plus shipping costs. When you receive the loaner unit, pack the failed unit in the loaner unit’s box and ship it freight prepaid to Pico Macom for repair. When you receive the repaired unit, a new RMA number will be provided in the box. Carefully pack the loaner unit and affix the new RMA number on the box and ship it back to us for full credit excluding shipping costs.
