MOUNTING REQUIREMENTS

2-M4

DATA ALLOCATION

Interval timed Response (X)
0
RX (n+0) F - RX (n+0) 0
F
Unused
1F
I/O DATA DESCRIPTIONS
■ DISCRETE I/O
15
COMMUNICATION CABLE WIRING
■ MASTER CONNECTION
Master module
blue
DA
white
DB
*1 Terminating
yellow
DG
Resistor
SLD
FG
*1. Turn on the terminator DIP switch to activate the internal terminating resistor.
unit: mm (inch)
125 [4.92]
0
R7F4HC
DA
DB
DG
SLD
FG
5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: +81(6)6659-8201 Fax: +81(6)6659-8510 E-mail: info@m-system.co.jp
Refresh Data (Y)
0
Unused
F
RY (n+1) F - RY (n+1) 0
1F
Input 0 (Output 0) 0: OFF / 1: ON
Input 1 (Output 1) 0: OFF / 1: ON
Input 2 (Output 2) 0: OFF / 1: ON
Input 3 (Output 3) 0: OFF / 1: ON
:
Input 15 (Output 15) 0: OFF / 1: ON
R7F4HC
DA
DB
DG
SLD
FG
R7F4HC-DAC32C-K
*1 Terminating
Resistor
