Summary of Contents for Ark Vision Systems AVS-SplitUnit FHD
- Page 1 AVS-SplitUnit FHD Ark Vision Systems...
- Page 2 Produktvarianten / Product variants 3050020 AVS-SplitUnit FHD Dual Ansicht Split View ▪ ▪ Key Facts Video input 2x M12 Male 4pole Videoeingang 2x M12 Stecker 4polig ▪ ▪ (1080p/720p/CVBS) (1080p/720p/CVBS) Videoausgänge 1x M12 Buchse 4polig Video output 1x M12A Female 4pole ▪...
- Page 3 Stromversorgung / Power supply Kameraeingang / Camera input Monitorausgang / Monitor output Lieferumfang / Scope of Delivery Steuereinheit Control unit ▪ ▪ Triggerkabel Trigger wire ▪ ▪ Cinchkabel Cinch cable ▪ ▪ Stromkabel Power cable ▪ ▪ Bedienungsanleitung Manual ▪ ▪...
- Page 4 Einstellungen / Settings Einstellung via Taster Setting via button ▪ Change camera view: ▪ Kameraansicht ändern: Press button for one second: Taste für eine Sekunde betätigen: Switches between camera 1, camera 2 and Schaltet zwischen Kamera 1, Kamera 2 und Split-mode Split-Mode durch ▪...
- Page 5 Systemskizze / System drawing AVS-Monitor 7“ FHD AVS-Camera- KU 90° FHD AVS-SplitUnit FHD AVS-Cable AVS-Cable 10-32V DC 10-32V DC AVS-Monitor 10“ Quad- ArkPack-Wireless Set 1 AVS-Camera- KU 90° FHD AVS-SplitUnit 10-32V DC AVS-Cable AVS-Cable 23.3 ArkPack-AH Ark-Battery M12-Male-A-5p Ø 4-6mm AVS-Monitor 10“...
- Page 6 Ark Vision Systems GmbH & Co. KG Tel: +49 (0) 6471-5087020 14. März 2022 Limburger Str. 51 E-Mail: info@ark-vision-systems.com Rev.: 01/2022 35799 Merenberg-Allendorf Homepage: www.ark-vision-systems.com © Ark Vision Systems 2022 Germany...
