Cooper Lighting GEO 80-IP Specification Sheet

NEO-RAY ™
GEO
89-DIP
83-DP
80-IP
D I R E C T- I N D I R E C T ( 8 9 )
D I R E C T ( 8 3 )
I N D I R E C T ( 8 0 )
• Direct – indirect light
distribution.
• The light is continuous and
unbroken.
• Die formed steel housing,
nominal illuminated sections
3', 4', 6' and 8'.
• Rigid 'U' shaped double
formed trim with 3/8"
regress soft lit edge.
• Runs provided to the nearest
foot.
• Housings may be special
ordered custom finished.
• Patterns are formed by
butting standard sections.
• Selection of 4 light diffuser
options.
83-DP additional feature
• Selection of 4 light diffuser
options.
720
COOPER LIGHTING
89-DIP
18"
[457mm]
6-1/4"
[159mm]
6" [153mm]
Construction: 20-gauge steel housing. Nominal 3',
4', 6' or 8' illuminated sections.
End Caps: 20-gauge steel construction.
Shielding: White bold baffle louver. White acrylic
diffuser. Prismatic acrylic lens. Parabolic baffle.
Electrical: 120, 277, 347 or Universal Voltage
electronic ballast. Fixtures and electrical
components certified to UL and CUL standards.
Finish: Durable, low gloss, white, powder coated
acrylic finish.
Mounting: Pendant with single stem (standard) or
single cable. Canopy: Round 5" diameter.
Geo 80IP Geo 83DP
R O W C O N F I G U R AT I O N
8 9 D I P
8 3 D P
8 0 I P
NOTES: For complete product data, refer to the Neo-Ray Specification Binder. Specifications and dimensions subject to change without notice. Products may be
modified for use in international markets. Please contact your Cooper Lighting Sales Representative for availability and ordering information.
ORDERING INFORMATION:
83-DP
Sample number: 89-DIP-2T8-ST40-1EB-SI-S58
Series
89=Geo DIP
Light Output
DIP=Direct-Indirect Pendant (89)
DP=Direct Pendant (83)
IP=Indirect Pendant (80)
80-IP
Number of Lamps (per cross section) (not included)
1=1 Lamp 2=2 Lamps
Lamp Type
T8 T5
Pendant Type
SC=Single Cable
Run Length
Overall Nominal Run Length__ft. (Any combination of 8', 6', 4' and 3'
sections)
Voltage 1
1=120V 2=277V
Ballast
EB=Electronic Ballast (Standard)
Switching
SI=Single Switching
Emergency
EM=Emergency Pack (Consult Factory)
Fusing
GLR GMF
Shielding (*not available for 80 Indirect)
S22=White Acrylic Diffuser
S72=White Bold Baffle
S58=KSH-12 Clear Acrylic Prismatic Lens
S79=Semi-Specular Aluminum Parabolic Baffle
1 Due to various constraints, some options may not be combined with others.
2 Available with 7° or earthquake 45° swivel canopy assembly.
83=Geo DP 80=Geo IP
T5HO
ST=Single Stem 2
3=347V U=Universal
DB=Dimming Ballast
DU=Dual Switching
S22 Acrylic Diffuser S58 Acrylic Lens
S72 Bold Baffle S79 Parabolic Baffle
