EM MALIBU
OWNER'S HANDBOOK

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Malibu EM 2015 and is the answer not in the manual?

Questions and answers

Related Manuals for HOLDEN Malibu EM 2015

Summary of Contents for HOLDEN Malibu EM 2015

  • Page 1 EM MALIBU OWNER’S HANDBOOK...
  • Page 2 GM Holden Ltd, ABN 84 006 893 232 (hereinafter Holden) Change of name, address or ownership If you drive a pre-owned Holden, have moved house or changed any of your details, we’d like to hear from you! Holden uses your details to keep your vehicle’s factory provided Roadside Assistance and Warranty details up to date.
  • Page 3 2015 Holden Malibu Owner Manual In Brief ......1-1 Storage ..... . . 4-1 Climate Controls .
  • Page 4 2015 Holden Malibu Owner Manual Towing ..... . 10-55 Appearance Care ... 10-56 Service and Maintenance .
  • Page 5 Introduction We thank you for choosing Holden and want to assure you of our continuing interest in your driving pleasure and satisfaction. This handbook applies to the current Malibu model. Therefore, due to different models and options, you may fi nd reference in this Handbook to some equipment not fi...
  • Page 6 Danger indicates a hazard with a with all the necessary information to to, GM, the GM logo, HOLDEN, the high level of risk which will result enable you to drive your vehicle HOLDEN Emblem, MALIBU, and safely and efficiently.
  • Page 7 Introduction information relating to a specific : Engine Coolant Temperature Caution component, control, message, : Exterior Lamps gauge, or indicator. Text marked Caution provides : Fog Lamps : This symbol is shown when information on possible damage you need to see the owner manual : Fuel Gauge to the vehicle.
  • Page 8 In Brief In Brief In Brief Vehicle Features Steering Wheel Controls ..1-14 Cruise Control ....1-14 Driver Information Instrument Panel Centre (DIC) ....1-15 Instrument Panel .
  • Page 9 In Brief Instrument Panel...
  • Page 10 In Brief 1. Infotainment System Controls. 10. Ultrasonic Parking Assist on 20. Data Link Connector (Out of See Overview on page 7-1. page 9-22. View). See Malfunction Indicator Lamp on page 5-11. 2. Storage Area. See Instrument Traction Control System (TCS) Panel Storage on page 4-1.
  • Page 11 In Brief Initial Drive Door Locks Information To lock or unlock the doors from the outside: This section provides a brief Press on the Remote overview about some of the Keyless Entry (RKE) transmitter. important features that may or may See Remote Keyless Entry not be on your specific vehicle.
  • Page 12 In Brief Push the door lock snib on the The power windows only operate Seat Adjustment top of the door to lock that with the ignition in ACC/ door only. Manual Seats ACCESSORY or ON/RUN/START, or when Retained Accessory Power Pull the door handle once to (RAP) is active.
  • Page 13 In Brief Seat Height Adjuster Power Seats Lumbar Adjustment If available, press and hold the top To adjust a power seat, if equipped: To adjust the lumbar support, or bottom of the switch to raise or if available: Move the seat forward or lower the seat.
  • Page 14 In Brief Reclining Seatbacks 3. Push and pull on the seatback to Power Reclining Seatbacks make sure it is locked. Manual Reclining Seatbacks To return the seatback to the upright position: 1. Lift the lever fully without applying pressure to the seatback, and the seatback will return to the upright position.
  • Page 15 In Brief Second Row Seats Head Restraint Press to heat the driver or passenger seat cushion and Adjustment The rear seatbacks can be folded seatback. Indicator lights on the down to increase cargo space. Do not drive until the head restraints button show the current setting.
  • Page 16 In Brief Seat Belts Mirror Adjustment Interior Mirror Adjustment Exterior Mirrors Hold the rear view mirror in the centre and move it to view the area behind the vehicle. Manual Rear view Mirror Pull the tab rearward for daytime use and push it forward for night-time use to avoid glare from the headlamps from behind.
  • Page 17 In Brief 1-10 Steering Wheel Interior Lighting Reading Lamps Adjustment Dome Lamps There are reading lamps in the overhead console To adjust the steering wheel: The interior lamps control in the : Press the button near overhead console controls both the 1.
  • Page 18 1-11 In Brief Exterior Lighting Windscreen Wiper/ : Turns on the park lamps including all lamps, except the Washer headlamps. : Turns on the headlamps together with the park lamps and instrument panel lights. See: Exterior Lamp Controls on page 6-1 With the ignition in ACC/ Front Fog Lamps on page 6-3 ACCESSORY or ON/RUN/START,...
  • Page 19 In Brief 1-12 Climate Controls The heating, cooling, and ventilation for the vehicle can be controlled with this system. INT: Move the lever down to INT for intermittent wipes, then turn INT band down for more frequent wipes or up for less frequent wipes.
  • Page 20 1-13 In Brief Transmission Driver Shift Control (DSC) To use this feature: 1. Move the shift lever from D (Drive) rearward to M (Manual). 2. Press the + (plus) end of the button on the top of the shift lever to upshift, or push the (minus) end of the button to downshift.
  • Page 21 In Brief 1-14 Vehicle Features Cruise Control : Press to decline an incoming call, or to end a current call. Press to silence the vehicle Steering Wheel Controls speakers while using the infotainment system. Press again to turn the sound on. : Press to select an audio source.
  • Page 22 1-15 In Brief RES/+: Move the thumbwheel up Rear Vision briefly to make the vehicle resume Camera (RVC) to a previously set speed or hold upwards to accelerate. If cruise The RVC displays a view of the control is already active, use to area behind the vehicle when the increase vehicle speed.
  • Page 23 In Brief 1-16 Keep the sensors on the vehicle's Performance and Electronic Stability rear bumper clean to ensure proper Control (ESC) Maintenance operation. The Electronic Stability Control See Ultrasonic Parking Assist on Traction Control system assists with directional page 9-22. control of the vehicle in difficult System (TCS) driving conditions.
  • Page 24 1-17 In Brief Engine Oil Life System Driving for Better Fuel (Diesel) Economy The engine oil life system calculates Driving habits can affect fuel usage. engine oil life based on vehicle use Here are some driving tips to get the and displays the CHANGE ENGINE best fuel economy possible.
  • Page 25 Keys, Doors, and Windows Keys, Doors, and Exterior Mirrors Keys and Locks Convex Mirrors ....2-12 Windows Power Mirrors ....2-13 Keys Folding Mirrors .
  • Page 26 Keys, Doors, and Windows Remote Keyless Entry (RKE) System Do not make changes or modifications to the RKE. This could void authorisation to use this equipment. If there is a decrease in the RKE operating range: Check the distance. The transmitter may be too far from the vehicle.
  • Page 27 Keys, Doors, and Windows Remote Keyless Entry (Lock): Press to lock all doors. (Unlock): Press to unlock the driver door or all doors. See (RKE) System Operation The turn signal indicators may flash Remote Lock/Unlock/Start under and/or the horn may sound on the The Keyless Access system allows Vehicle Personalisation on second press to indicate locking...
  • Page 28 Keys, Doors, and Windows vehicle has this feature, there will be Keyless Unlocking/Locking from a button on the outside front door the Passenger Doors handles. When the doors are locked and the The Keyless Access can be RKE transmitter is within range of the door handle, pressing the lock/ programmed to unlock all doors on unlock button on a passenger door...
  • Page 29 1. Place the transmitter in the automatically lock when exiting the rearmost cupholder in the Starting the Vehicle with a Low vehicle, see Remote Lock/Unlock/ console with the Holden logo Transmitter Battery Start under Vehicle Personalisation facing upwards. If the transmitter battery is weak on page 5-27.
  • Page 30 Keys, Doors, and Windows 2. With the vehicle in P (Park) or Door Locks N (Neutral), press the brake pedal and the ENGINE START/ Danger STOP button. See Starting the Engine on page 9-5. Unlocked doors can be Replace the transmitter battery dangerous.
  • Page 31 Keys, Doors, and Windows There are several ways to lock and Power Door Locks Door Open Reminder unlock the vehicle. A chime will sound and the From the outside: appropriate door message will display on the Driver Information Turn the key in the driver door Centre (DIC) if one of the doors is lock anticlockwise to lock the not fully closed.
  • Page 32 Keys, Doors, and Windows The power door unlock function can Doors be personalised using the Vehicle Settings Menu. See Vehicle Boot Personalisation on page 5-27 for more information. Danger Safety Locks Exhaust gases can enter the The vehicle has rear door security vehicle if it is driven with the boot locks to prevent passengers from open, or with any objects that...
  • Page 33 Keys, Doors, and Windows Danger (Continued) Adjust the climate control system to a setting that brings in only outside air and set the fan speed to the highest setting. For more information about carbon monoxide, see Engine Close the boot by pulling the handle Exhaust on page 9-8.
  • Page 34 2-10 Keys, Doors, and Windows Vehicle Security On Solid: Vehicle is secured Caution during the delay to arm the system. This vehicle has theft-deterrent Fast Flash: Vehicle is unsecured. Do not use the emergency boot features; however, they do not make A door, the bonnet, or the boot release handle as a tie-down or the vehicle impossible to steal.
  • Page 35 Keys, Doors, and Windows 2-11 will bypass the 30-second delay Disarming the Alarm System Immobiliser Operation and immediately arm the alarm Do one of the following to disarm This vehicle has a passive system. the alarm system or turn off the theft-deterrent system.
  • Page 36 2-12 Keys, Doors, and Windows The system has one or more If the vehicle does not start with the Exterior Mirrors transmitters matched to an other transmitter or when the immobiliser control unit in the transmitter is in the transmitter Convex Mirrors vehicle.
  • Page 37 Keys, Doors, and Windows 2-13 Power Mirrors Folding Mirrors Interior Mirrors Manual Folding Mirrors Manual Rear View Mirror The mirrors can be folded inward To adjust the inside rear view mirror, toward the vehicle to prevent hold the rear view mirror in the damage when going through an centre and move it to view the area automatic car wash.
  • Page 38 2-14 Keys, Doors, and Windows Windows The vehicle aerodynamics are Pressing or pulling the switch part of designed to improve fuel economy the way will open or close the performance. This may result in a window as long as the switch is Danger pulsing sound when a window is operated.
  • Page 39 Keys, Doors, and Windows 2-15 Programming the Power 4. Continue holding the switch up Express Window Anti-Pinch for approximately 2 seconds Windows Override after the window is completely If the battery on the vehicle has closed. Warning been recharged or disconnected, The window is now reprogrammed.
  • Page 40 2-16 Keys, Doors, and Windows Window Lockout Sun Visors Pull the sun visor down to block glare. Detach the sun visor from the centre mount to pivot to the side window, or to extend along the rod, This feature prevents the rear if available.

  • Page 41: Table Of Contents

    Seats and Restraints Seats and Lap-Shoulder Belt ... . 3-11 Adding Equipment to the Seat Belt Use During Airbag-Equipped Vehicle . . . 3-22 Restraints Pregnancy ....3-13 Airbag System Check .

  • Page 42: Seats And

    Seats and Restraints Head Restraints Adjust the head restraint so that the Pull and push on the head restraint top of the restraint is at the same after the button is released to make height as the top of the occupant's sure that it is locked in place.
  • Page 43 Seats and Restraints The height of the head restraint can Front Seats be adjusted. Pull the head restraint up to raise it. Try to move the head Seat Adjustment restraint to make sure that it is locked in place. Warning To lower the head restraint, press the button, and push the head Do not adjust the driver's seat...
  • Page 44 Seats and Restraints Seat Height Adjuster Lumbar Adjustment To adjust a power seat, if equipped: Move the seat forward or If available, press and hold the top To adjust the lumbar support, rearward by sliding the control or bottom of the switch to raise or if available: forward or rearward.
  • Page 45 Seats and Restraints Reclining Seatbacks Warning To avoid reducing the effectiveness of seat belts, seatbacks should only be upright or at most semi-reclined when the vehicle is moving. The shoulder belt will not be against your body. Instead, it will be in front of you.
  • Page 46 Tilt the top of the control Do not fit any seat cover rearward to recline. (including genuine Holden Tilt the top of the control forward accessory covers) to heated to raise. seats.
  • Page 47 Seats and Restraints Press the button once for the Rear Seats Caution highest setting. With each press of the button, the heated seat will Folding the Seatback Do not trap the seat belt when change to the next lower setting, returning the seatback or seat and then to the off setting.
  • Page 48 Seats and Restraints Raising the Seatback To raise a seatback: 1. Lift the seatback up and push it Warning rearward to lock it in place. Make sure the seat belt is in the If either seatback is not locked, it retainer clip and is not twisted or could move forward in a sudden caught in the seatback.

  • Page 49: Rear Seat Armrest

    Seats and Restraints Rear Seat Armrest Seat Belts Warning (Continued) This section of the manual Care should be taken to avoid describes how to use seat belts contamination of the webbing with properly. It also describes some polishes, oils and chemicals, and things not to do with seat belts.

  • Page 50: Seat Belts

    3-10 Seats and Restraints This vehicle has indicators as a you stop over a longer distance and, is provided, all occupants still reminder to buckle the seat belts. when worn properly, your strongest have to wear seat belts to get See Seat Belt Reminders on bones take the forces from the seat the most protection.

  • Page 51: Lap-Shoulder Belt

    Seats and Restraints 3-11 There are important things to know 1. Adjust the seat, if the seat is Danger about wearing a seat belt properly. adjustable, so you can sit up straight. To see how, see Seats Sit up straight and always keep You can be seriously injured, in the Index.
  • Page 52 3-12 Seats and Restraints If the webbing locks in the latch 3. Push the latch plate into the 4. To make the lap part tight, pull plate before it reaches the buckle until it clicks. up on the shoulder belt. buckle, tilt the latch plate flat to Pull up on the latch plate to unlock.

  • Page 53: Seat Belt Use During

    Seats and Restraints 3-13 To unlatch the belt, push the button They can help tighten the safety on the buckle. The belt should belts during the early stages of a return to its stowed position. moderate to severe frontal, near-frontal, or rear crash if the Before a door is closed, be sure the threshold conditions for pretensioner seat belt is out of the way.

  • Page 54: Safety System Check

    They can rip apart under impact have been stressed or damaged. forces. If a belt is torn or frayed, See your dealer to have the seat contact a Holden dealer belt assemblies inspected or immediately. replaced. Make sure the seat belt reminder New parts and repairs may be light is working.
  • Page 55 Seats and Restraints 3-15 Have the seat belt pretensioners Airbag System Warning checked if the vehicle has been in a crash, or if the airbag readiness light Airbags are part of the stays on after you start the vehicle supplemental restraint system or while you are driving.
  • Page 56 3-16 Seats and Restraints The vehicle has the following For seat-mounted side impact Danger (Continued) airbags: airbags, the word AIRBAG is on the side of the seatback closest to A frontal airbag for the driver. In some crashes seat belts are the door.
  • Page 57 Seats and Restraints 3-17 Danger (Continued) Danger seriously injured or killed. Do not Children who are up against, sit unnecessarily close to any or very close to, any airbag when airbag, as you would be if sitting it inflates can be seriously injured on the edge of the seat or leaning or killed.

  • Page 58: Where Are The Airbags

    3-18 Seats and Restraints Where Are the Airbags? Side Airbag System Warning Front Airbag System Warning The horn pad must not be covered with adhesive or any Do not fit unauthorised seat other material. covers as they may impair the The driver should adjust the seat deployment of the Side Impact as far rearward as possible while...

  • Page 59: When Should An Airbag

    Seats and Restraints 3-19 Curtain Airbag System airbags to inflate and help restrain the occupants. The vehicle has electronic frontal sensors that help Warning the airbag system determine the severity of the impact. Deployment Do not position your body or any thresholds can vary with specific object (including pillows) in the vehicle design.

  • Page 60: What Makes An Airbag

    3-20 Seats and Restraints Frontal airbags are not intended to impacts. A curtain airbag is intended can contact the steering wheel or inflate during vehicle rollovers, in to inflate on the side of the vehicle the instrument panel. In moderate to rear impacts, or in many side that is struck.
  • Page 61 Seats and Restraints 3-21 quickly that some people may not lamps, and turn off the hazard Warning (Continued) even realise an airbag inflated. warning flashers by using the Curtain airbags may still be at least controls for those features. asthma or other breathing trouble. partially inflated for some time after To avoid this, everyone in the they inflate.

  • Page 62: Adding Equipment To The Airbag-Equipped Vehicle

    3-22 Seats and Restraints In many crashes severe enough to Servicing the Adding Equipment to the inflate the airbag, windscreens are Airbag-Equipped Vehicle Airbag-Equipped Vehicle broken by vehicle deformation. Additional windscreen breakage Airbags affect how the vehicle Adding accessories that change the may also occur from the front should be serviced.

  • Page 63: Replacing Airbag System

    Seats and Restraints 3-23 Child Restraints Caution Danger (Continued) Older Children If an airbag covering is damaged, protect you and your opened, or broken, the airbag passenger(s) in a crash, resulting may not work properly. Do not in serious injury or even death. To Warning open or break the airbag help make sure the airbag...
  • Page 64 3-24 Seats and Restraints Buckle the lap-shoulder belt. Danger (Continued) Does the shoulder belt rest on the shoulder? If yes, continue. over the abdomen, which could If no, then return to the cause severe or even fatal booster seat. internal injuries in a crash. Does the lap belt fit low and snug on the hips, touching the thighs? If yes, continue.

  • Page 65: Infants And Young

    Seats and Restraints 3-25 Warning (Continued) Danger (Continued) can be crushed together and seriously injured by not wearing seriously injured. A seat belt must the lap-shoulder belt properly. In a be used by only one person at crash, the child would not be a time.
  • Page 66 3-26 Seats and Restraints Danger Danger Warning Children can be seriously injured Never hold an infant or a child WARNING EXTREME or strangled if a shoulder belt is while riding in a vehicle. Due to HAZARD! wrapped around their neck and crash forces, an infant or a child Do not use a rearward facing the seat belt continues to tighten.

  • Page 67: Child Restraint Systems

    Seats and Restraints 3-27 Selection of a particular restraint Child Restraint Systems Warning (Continued) should take into consideration not We recommend a child restraint only the child's weight, height, and shoulders. Infants should always system that is tailored specifically to age but also whether or not the be secured in rear-facing child the vehicle.
  • Page 68 Holden strongly recommends that Warning Remember that it is safest for you refer to your specific State or children to be seated in the rear...

  • Page 69: Where To Put The Restraint

    Seats and Restraints 3-29 They are able to stay seated like backbone, which is still very weak, evenly spread over the baby's back, this for the entire trip. is under less strain in the event of with minimal jarring to the an accident.

  • Page 70: Top Tether Anchor Fittings

    Australian States and Territories station or a Holden Dealer. Top Tether Anchor Fittings and New Zealand have laws restricting the seating of children Top Tether Anchor in the front passenger seat.
  • Page 71 Seats and Restraints 3-31 The child restraint may have a Top Tether Anchor Fitting To assist in locating the top tether single tether (1) or a dual tether (3). Locations anchor fittings, the top tether anchor Either will have a single fitting symbol is on the cover.
  • Page 72 3-32 Seats and Restraints Warning Danger (Continued) Danger Accident statistics show that secure the restraint following the Children can be seriously injured children are safer when properly instructions that came with the or strangled if a shoulder belt is secured in a rear seat in the child restraint and the instructions wrapped around their neck and correct child restraint for their...
  • Page 73 Seats and Restraints 3-33 1.2. Route, attach, and tighten Caution (Continued) the top tether according to the child restraint Do not fold the empty rear seat instructions and the with a seat belt buckled. This following instructions: could damage the seat belt or the seat.

  • Page 74: Isofix Child Restraint

    3-34 Seats and Restraints New parts and repairs may be Note: Ensure that seat belt buckles Do not secure a child seat in a necessary even if the top tether are placed out of the way of the position without a top tether anchor anchor fittings were not being used child seat.

  • Page 75: Securing Child Restraints

    Seats and Restraints 3-35 tether. See Top Tether Anchor Fittings on page 3-30 for more information. 6. Push and pull the child restraint in different directions to be sure it is secure. To remove the child restraint, unbuckle the vehicle seat belt and let it return to the stowed position.
  • Page 76 3-36 Seats and Restraints tether, see Top Tether Anchor Danger Fittings on page 3-30 for top tether anchor locations. A child in a forward-facing child When using the lap-shoulder belt to restraint can be seriously injured secure the child restraint in this or killed if the front passenger position, follow the instructions that airbag inflates and the passenger...
  • Page 77 Seats and Restraints 3-37 To remove the child restraint, unbuckle the vehicle seat belt and let it return to the stowed position. If a top tether is attached to the top tether anchor fitting, disconnect it. 4. Push the latch plate into the 5.
  • Page 78 3-38 Seats and Restraints NOTES...

  • Page 79: Instrument Panel Storage

    Storage Storage Storage Compartments Storage Compartments Instrument Panel Storage Instrument Panel Storage ..4-1 Glovebox ..... 4-1 Cupholders .

  • Page 80: Cupholders

    Storage Cupholders Rear Seat Sunglasses Storage Centre Console Lower the armrest to access the Push on the cover and release to cupholders. open the compartment. Push down on the cover handle and slide the cover forward to access the cupholders. The cupholders can be removed for cleaning.

  • Page 81: Additional Storage Features

    Storage Centre Console Storage Additional Storage Features Cargo Tie-Downs Press the button and lift to open. The centre console has storage under the armrest. There is a USB port and a power outlet inside. See There are cargo tie-downs in the Power Outlets on page 5-5.
  • Page 82 Storage NOTES...
  • Page 83 Instruments and Controls Instruments and Malfunction Lamps On Reminder ..5-18 Indicator Lamp ... . . 5-11 Cruise Control Light ..5-18 Controls Service Vehicle Soon Door open warning light .

  • Page 84: Instruments And Controls

    Instruments and Controls Starting the Vehicle Controls Do not adjust the steering wheel Messages ....5-26 while driving. Transmission Messages ..5-26 Steering Wheel Steering Wheel Controls Vehicle Reminder...

  • Page 85: Horn

    Instruments and Controls vehicle speakers while using the Windscreen Wiper/ INT: (Intermittent Wipes): Move infotainment system. Press again to the lever down to INT for Washer turn the sound on. intermittent wipes, then turn INT band down for more (Thumbwheel Control): frequent wipes or up for less Press to select an audio source.
  • Page 86 Instruments and Controls If the ignition is put in OFF while the The wiper operations return to wipers are performing wipes due to normal when the transmission is no windscreen washing, the wipers longer in N (Neutral) or the vehicle continue to run until they reach the speed has increased.

  • Page 87: Clock

    Instruments and Controls Clock Setting the 12/24 Hour Format: turning off the vehicle. See Retained Accessory Power (RAP) on 1. Press the CONFIG button. The infotainment system controls page 9-5. are used to access the time and 2. Rotate the MENU/TUNE knob to Open the protective cover to use the date settings through the menu select Time and Date.

  • Page 88: Warning Lights, Gauges, And Indicators

    Instruments and Controls Warning Lights, Warning lights come on when there When one of the warning lights could be a problem with a vehicle comes on and stays on while Gauges, and function. Some warning lights come driving, or when one of the gauges on briefly when the engine is started shows there may be a problem, Indicators...

  • Page 89: Instrument Cluster

    Instruments and Controls Instrument Cluster...

  • Page 90: Speedometer

    Instruments and Controls Speedometer Fuel Gauge Here are four things that some owners ask about. These are The speedometer shows the normal and do not indicate a vehicle's speed in kilometres per problem with the fuel gauge: hour (km/h). At the petrol station, the petrol pump shuts off before the gauge Odometer reads full.

  • Page 91: Engine Coolant Temperature

    Instruments and Controls Engine Coolant Seat Belt Reminders Passenger Seat Belt Reminder Light Temperature Gauge Driver Seat Belt Reminder The vehicle may also have a Light passenger seat belt reminder light. There is a driver seat belt reminder light on the instrument cluster. When the vehicle is started, this light flashes and a chime may come When the vehicle is started, this...

  • Page 92: Airbag Readiness Light

    5-10 Instruments and Controls The front passenger seat belt Charging System Light warning light and chime may turn on if an object is put on the seat such as a briefcase, handbag, grocery bag, laptop, or other electronic device. To turn off the warning light and/or chime, remove the object The airbag readiness light comes on from the seat or buckle the...

  • Page 93: Malfunction

    Instruments and Controls 5-11 Malfunction To prevent more serious damage to Caution (Continued) the vehicle: Indicator Lamp Reduce vehicle speed. Modifications made to the engine, This light comes on when the transmission, exhaust, intake, Avoid hard accelerations. ignition is turned on, as a check to or fuel system of the vehicle can show it is working.

  • Page 94: Service Vehicle Soon

    5-12 Instruments and Controls Service Vehicle Soon If the warning light comes on, there Warning (Continued) is a brake problem. Have the brake Light system inspected right away. the road and carefully stopped, have the vehicle towed for service. If the light comes on while driving, a chime sounds.

  • Page 95: Electric Parking Brake

    Instruments and Controls 5-13 Electric Parking Brake Antilock Brake System Light (ABS) Warning Light For vehicles with the EPB, the parking brake warning light should come on briefly when the engine is started. If it does not come on, have This light should come on briefly as This light comes on briefly when the the vehicle serviced by your dealer.

  • Page 96: Traction Off Light

    5-14 Instruments and Controls light is also on, the vehicle does not Traction Off Light See Traction Control System (TCS) have antilock brakes and there is a on page 9-16 and Electronic problem with the regular brakes. Stability Control (ESC) on See Brake System Warning Light on page 9-18.

  • Page 97: Electronic Stability Control

    Instruments and Controls 5-15 vehicle might need service. When (TCS) is also off, and wheel spin is For more information, see Starting this warning light is on, the ESC is not limited. If the ESC is off, the the Engine on page 9-5. off and does not limit wheel spin.

  • Page 98: Engine Oil Pressure Light

    5-16 Instruments and Controls traffic situations permit. The Low Fuel Warning Light Caution (Continued) indicator goes off as soon as the soot particles are at normal levels. the oil level is within the operating If the engine is shut off while the range and the oil pressure is still DPF indicator is on or flashing, low, have the vehicle serviced.

  • Page 99: Security Light

    Instruments and Controls 5-17 Security Light For information regarding this light reduced. If this light stays on, see and the vehicle's security system, your dealer as soon as possible for see Vehicle Alarm System on diagnosis and repair. page 2-10. High-Beam On Light Reduced Engine Power Light...

  • Page 100: Lamps On Reminder

    5-18 Instruments and Controls The light goes out when the fog The light goes out when the cruise Information Displays lamps are turned off. See Front Fog control is turned off. See Cruise Lamps on page 6-3 for more Control on page 9-20 for more Driver Information information.
  • Page 101 Instruments and Controls 5-19 DIC Buttons Trip/Fuel Menu Items Timer Available on some vehicles, this Press MENU on the turn signal display can be used as a timer. To lever until Trip/Fuel Menu is start the timer, press SET/CLR while displayed.
  • Page 102 5-20 Instruments and Controls Navigation km/h. The average speed can L/100 km. The fuel be reset by pressing SET/CLR while economy can be reset by pressing On vehicles with a Navigation the Average Vehicle Speed display SET/CLR while the Average Fuel system, this display shows the is showing.

  • Page 103: Vehicle Messages

    Instruments and Controls 5-21 current oil life remains. On some Battery Voltage Vehicle Messages models, this display is shown as This display, available on some DIC messages display when the vehicles, shows the current battery status of the vehicle has changed When the remaining oil life is low, voltage.

  • Page 104: Brake System Messages

    5-22 Instruments and Controls system starts reducing features of RELEASE PARKING BRAKE STEP ON BRAKE TO the vehicle that may be noticed. At RELEASE PARK BRAKE This message is displayed if the the point that features are disabled, electric parking brake is on while the This message is displayed if you this message displays.

  • Page 105: Engine Cooling System

    Instruments and Controls 5-23 BOOTLID OPEN COOLANT LEVEL LOW ADD Engine Oil Messages COOLANT This message will display when the CHANGE ENGINE OIL SOON boot is open. Close the boot This message will display if the This message displays on diesel completely.

  • Page 106: Engine Power Messages

    5-24 Instruments and Controls of the low oil pressure has been Fuel System Messages amount. Continued driving is corrected. Check the oil as soon as mandatory to prevent the filter from FUEL LEVEL LOW possible and have the vehicle clogging. See Diesel Particulate serviced by your dealer.

  • Page 107: Lamp Messages

    Instruments and Controls 5-25 USE TRANSMITTER POCKET Object Detection System message is displayed, the system will not limit wheel spin. Adjust your TO START Messages driving accordingly. See your dealer This message displays when the for service. PARK ASSIST OFF battery in the Remote Keyless Entry SERVICE ESP (RKE) transmitter needs to be...
  • Page 108 5-26 Instruments and Controls SERVICE POWER STEERING Starting the Vehicle SHIFT DENIED Messages This message displays if there is a This message displays when problem with the electric power attempting to use the automatic TURN STEERING WHEEL steering system. Take the vehicle to transmission manual mode to shift START VEHICLE AGAIN your dealer for service.
  • Page 109 Instruments and Controls 5-27 Vehicle Reminder Window Messages Vehicle Messages Personalisation OPEN THEN CLOSE DRIVER WINDOW ICE POSSIBLE DRIVE The audio system controls are used WITH CARE to access the personalisation This message is displayed when the window needs to be reprogrammed. menus for customising vehicle This message displays when ice If the vehicle's battery has been...
  • Page 110 5-28 Instruments and Controls 2. Rotate the TUNE/MENU knob to Climate and Air Quality Press TUNE/MENU when Auto highlight Vehicle Settings. Demist is highlighted to select On or Select the Climate and Air Quality Off. A checkmark indicates the 3. Press the centre of the TUNE/ menu and the following may be feature is turned on.
  • Page 111 Instruments and Controls 5-29 Press TUNE/MENU when Chime Lighting 30 Seconds, 1 Minute, or 2 Minutes. Volume is highlighted. Rotate the Press TUNE/MENU to confirm and Select the Lighting menu and the TUNE/MENU knob to select Normal go back to the last menu. following will be displayed: or High.
  • Page 112 5-30 Instruments and Controls Relock Remotely Unlocked Auto Door Lock Remote Door Unlock Doors This allows selection of whether the This allows selection of what doors Passive Door Unlock doors will automatically lock when are unlocked when pressing the vehicle is shifted out of P (Park). Passive Door Lock the RKE transmitter.
  • Page 113 Instruments and Controls 5-31 Press TUNE/MENU when Passive A checkmark indicates the feature is Door Unlock is highlighted. Rotate turned on. Press Back to move back the TUNE/MENU knob to select All to the last menu. Doors or Driver Door Only. Press Return to Factory Settings? Back to move back to the last menu.
  • Page 114 5-32 Instruments and Controls NOTES...

  • Page 115: Exterior Lamp Controls

    Lighting Lighting Exterior Lighting (Park Lamps): Turns on the park lamps including all lamps, except the headlamps. Exterior Lamp Controls Exterior Lighting (Headlamps): Turns on the Exterior Lamp Controls ..6-1 headlamps together with the park Exterior Lamps Off lamps and instrument panel lights.

  • Page 116: Headlamp Flash

    Lighting Lights On with Wipers If the windscreen wipers are activated in daylight with the engine on, and the exterior lamp control is in AUTO, the headlamps, park lamps, and other exterior lamps This indicator light turns on in the come on.

  • Page 117: Turn And Lane-Change

    Lighting Raise or lower the lever until the Front Fog Lamps (Hazard Warning Flasher): arrow starts to flash to signal a lane Press this button on the centre change. Hold it there until the lane stack to make the front and rear turn change is completed.

  • Page 118: Interior Lighting

    Lighting If the front fog lamps are turned on Interior Lighting Courtesy Lamps while the exterior lamp control is in The courtesy lamps come on the AUTO position, the park lamps Instrument Panel automatically when any door is come on automatically. Illumination Control opened and the dome lamp is in the (Front Fog Lamps): Press to...

  • Page 119: Reading Lamps

    Lighting Lighting Features The exit lighting feature can be (Door): Turns the lamps on changed. See Vehicle when any door is opened. Personalisation on page 5-27. Entry Lighting (On): Keeps the lamps on all the time. Battery Load Some exterior lamps and most of the interior lights turn on briefly Management Reading Lamps...
  • Page 120 Lighting The battery can be discharged at Normally, these actions occur in idle if the electrical loads are very steps or levels, without being high. This is true for all vehicles. noticeable. In rare cases at the This is because the generator highest levels of corrective action, (alternator) may not be spinning fast this action may be noticeable to the...
  • Page 121 Infotainment System Infotainment Navigation Symbols ..7-38 Introduction Destination ....7-40 System Configure Menu ... . . 7-50 Overview Global Positioning System (GPS) .

  • Page 122: Infotainment System

    Infotainment System Set up the audio by pre-setting The vehicle has Retained Danger favourite stations, setting the Accessory Power (RAP). With RAP, tone, and adjusting the the audio system can be played Taking your eyes off the road for speakers. even after the ignition is turned off.
  • Page 123 Infotainment System Radio without Navigation (Clock) (Play/Pause) 11. CD Slot SEEK 13. CONFIG (Configure) 14. TONE 15. INFO (Information) 1. VOL/ (Volume/Power) (Phone/Mute) 2. FAV (Favourite Pages 1 6) 6. BACK (Home) 7. TUNE/MENU Knob 4. SOURCE (Eject)
  • Page 124 Infotainment System Radio with Navigation (Phone) 2. SRCE (Source) 3. HOME (Home Page) 4. NAV (Navigation) 5. DEST (Destination) 6. RPT (Repeat) 7. VOL/ (Volume/Power) 8. FAV (Favourite Pages 1 6) (Eject) 10. Preset Buttons (1 6) (Clock) (Play/Pause) SEEK 14.
  • Page 125 Infotainment System Continue pressing to cycle Infotainment Control Buttons button on the Home Page, then through the full map and split touching Radio Settings, and then The buttons on the faceplate are screens. touching Number of Favorite Pages. used to start primary functions while DEST (Destination): (Eject): Press to eject a disc using the infotainment system.

  • Page 126: Steering Wheel Controls

    Infotainment System CD, USB, Bluetooth Audio: Turn to manually change the CONFIG (Configuration Menu): Press and hold to fast forward radio station. Press to adjust features for through a track. Release the Languages, Time and Date, Radio Steering Wheel Controls button to return to playing Settings, Phone Settings, Display speed.

  • Page 127: Using The System

    Infotainment System Using the System Touch Screen Buttons (Mute/End Call): Press to decline an incoming call, or to end a The Home Page allows access to The infotainment system is current call. Press to silence the many of the features. controlled by touching the screen vehicle speakers while using the and by using the knobs and other...
  • Page 128 Infotainment System Home Page Customisation 2. Touch an icon to switch with Touch the Now Playing screen another icon. button to display the active source page. The sources available are 3. Select the icon to swap with. AM, FM, CD, USB/iPod, Pandora, 4.
  • Page 129 Infotainment System Touch the Destination screen button Touch the Config screen button to Touch the FM screen button to to display the Destination Entry display the Config main page. From display the FM main page and play home page or the Destination Menu. this display, adjust features such as the current or last tuned FM station.
  • Page 130 7-10 Infotainment System Touch the Pandora screen button to Touch the CD screen button to Touch the iPod screen button to display the Pandora home page and display the CD main page and play display the iPod main page and play stream personalised radio stations the current or last CD track the current or last track selected.
  • Page 131 Infotainment System 7-11 clean. Never use window cleaners or solvents. Periodically hand wash the microfibre cloth separately, using mild soap. Do not use bleach or fabric softener. Rinse thoroughly and air dry before next use. Touch the AUX screen button to Touch the Quick Info screen button Caution access any connected auxiliary...

  • Page 132: Am-Fm Radio

    7-12 Infotainment System Radio 10 minutes. Opening the driver door To adjust the settings: will not turn the radio off when Bass: Touch + or to change pressing the power button. AM-FM Radio the level. Some radios may stay on longer Mid (Midrange): Touch + or Playing the Radio and reset the time for 10 minutes if...
  • Page 133 Infotainment System 7-13 Finding a Station the faceplate or SRC on the steering wheel controls, or say 1. Touch the AM screen button on Press SOURCE or SRCE on the Tune FM or FM through voice the Home Page or select AM by faceplate or SRC on the steering recognition.

  • Page 134: Radio Data System (Rds)

    7-14 Infotainment System In the AM or FM main page, To scroll through the pages, press causes the radio features to work touch one of the preset screen FAV or the Fav screen button on the improperly. If this happens, contact buttons to go to the selected top bar.

  • Page 135: Backglass Antenna

    Infotainment System 7-15 automatically works to reduce Backglass Antenna Caution (Continued) interference, some static can occur, The AM-FM antenna is integrated especially around tall buildings or not be covered by the vehicle with the rear window demister in the hills, causing the sound to fade in warranty.

  • Page 136: Quick Info

    7-16 Infotainment System ® On a BlackBerry phone, go to Quick Info Pandora Internet Radio the BlackBerry App World ® Pandora is a free Internet radio search for Pandora. service that streams personalised ® ® On an iPhone , iPad , or iPod radio stations based on artists, ®...
  • Page 137 Infotainment System 7-17 2. To launch, do one of the If the Please See Device message Press and say Tune following: is shown, the login screen may Pandora. display on the device. Launch the application on After Pandora has been launched, the device.
  • Page 138 7-18 Infotainment System Using a BlackBerry Phone If the Please See Device message Touch a user-created station to play is shown, the login screen may from the displayed list. The phone must be unlocked. To display on the device. launch Pandora service: Pandora Features If the Please Unlock the Phone or 1.
  • Page 139 Infotainment System 7-19 should not play on this station. This Pandora voice control will not work Pandora Troubleshooting feature is only available on until Pandora is launched the first Unable to Connect Device to user-created stations. time during that ignition cycle. Vehicle (Thumbs Up): When touched, Pandora Skip Limit...
  • Page 140 7-20 Infotainment System For iPhone, iPod touch, or iPad Connection between phone and If touching OK does not clear the devices, check that the USB radio lost. issue on the phone, see "Please cable is connected to the USB Unlock the Phone or Restart the If any iPhone, iPod touch, port and the screen is unlocked.

  • Page 141: Stitcher Internet Radio

    Infotainment System 7-21 Unlock the phone and check that latest version is installed on the pop-up displays if the latest Home Page is shown on the phone/ device and the volume on the application is installed on the device. device is turned up. device.
  • Page 142 7-22 Infotainment System After Stitcher has been launched, Using an Android Phone If the Please See Device message press SOURCE or SRCE on the is shown, the login screen may 1. Pair the Android phone using faceplate, or SRC on the steering display on the device.
  • Page 143 Infotainment System 7-23 Select and store programs as (Play/Pause): Touch on the favourites on the device. Favourite radio to pause playback. Touch station lists can be created to again to resume. include favourite shows which can Stitcher Advertisement be accessed through My On Demand Stations.
  • Page 144 7-24 Infotainment System Close Stitcher on the device and The volume is too low. Turn up 2. Open and close the driver door, launch again. Devices that allow the volume on the device. wait about 30 seconds, and try multitasking may require an to connect the device again.

  • Page 145: Audio Players

    Infotainment System 7-25 Do not apply labels to discs. The Please See Device: When not Audio Players labels could get caught in the logged in or when authentication player. failed, see the device. Touch OK to CD Player continue. Disconnect the phone Insert only one disc at a time.
  • Page 146 7-26 Infotainment System Press and hold to fast forward On the CD main page, the track Press to eject a disc from the through a track. Release the number displays and the Song, CD player. If the disc is not removed button to return to playing Artist, and Album information within a short period of time, it is...

  • Page 147: Usb

    Infotainment System 7-27 There was a problem while Unprotected WMA Normalization: Normalization helps burning the disc. to improve the voice recognition Unprotected AAC accuracy for titles that sound similar. The label is caught in the CD Other formats may be supported. It also helps group long lists of player.
  • Page 148 7-28 Infotainment System Cover Art: The Gracenote Use the touch screen or voice USB MP3 Player and USB Drives embedded database contains cover recognition to access the Playlist The USB MP3 players and USB art or album art information for the menu.
  • Page 149 Infotainment System 7-29 Press and hold to reverse To play a USB device, do one of the The radio supports plugging a quickly through playback. following: mobile phone in as a USB drive as Release to return to playing long as the mobile phone supports Connect the USB and it begins speed.
  • Page 150 7-30 Infotainment System Delete Automatic Playlist: Touch 2. Select the album to view a list of present. The radio displays the file to delete a More Like this playlist. all songs on the album. name as the track name if the song information is not available.
  • Page 151 Infotainment System 7-31 To connect an iPod: iPod Menu 2. The radio will show "Indexing" and continue playing the 1. Connect one end of the standard current song. iPod USB cable to the iPod's dock connector. Delete Automatic Playlist: Touch to delete a More Like This playlist.
  • Page 152 7-32 Infotainment System Albums: 2. Select the song from the list to Playing from an iPhone or iPad begin playback. 1. Touch to view the albums on This feature supports the following the iPod. Podcast: iPhone or iPad models: ® 2.

  • Page 153: Auxiliary Devices

    Infotainment System 7-33 USB troubleshooting Auxiliary Devices If an auxiliary device has already been connected, but a different If the device is not being recognised This vehicle has an auxiliary input source is currently active, do one of or the music is missing screen jack in the front console.
  • Page 154 7-34 Infotainment System 2. Music can be launched by doing on the phone. Check the phone playback. This may happen one of the following: manufacturer's information for depending on how the device notification support. communicates over Bluetooth. Touch the Bluetooth Audio screen button on the Some phones support sending Bluetooth Audio Menu...

  • Page 155: Using The Navigation

    Infotainment System 7-35 Navigation The touch-sensitive buttons Touch Heading Indicator to display available are: the Map View. There are three indicator settings: Using the Navigation 2D North Up: Displays North at System the top of the map screen Use the NAV button on the regardless of the direction the vehicle is travelling.
  • Page 156 7-36 Infotainment System Touch to change the view of the Touch to display a search list of Switch Route Time/Destination maps while using the navigation nearby POIs. Select the Touch to customise the arrival/travel function. The system offers a variety desired POI.

  • Page 157: Maps

    Infotainment System 7-37 Press NAV on the faceplate to Map Adjustments The map scale bar times out if exit map scrolling and return to the zoom level is not changed The system lets you adjust the scale the current vehicle location on within a few seconds.

  • Page 158: Navigation Symbols

    7-38 Infotainment System Detailed Areas The waypoint symbol marks one or more set waypoints. Road network attributes are A waypoint is a stopover destination contained in the map database for point added to the planned route. detailed areas. Attributes include information such as street names, The estimated time and distance to street addresses, and turn...
  • Page 159 Infotainment System 7-39 Touch this screen symbol to change to 3D mode. The 3D symbol is the same as the Heading up symbol, but the map is in 3D. This symbol indicates that the map This symbol on the right of the map view is North up: North up displays screen displays the speed limit North at the top of the map screen...

  • Page 160: Destination

    7-40 Infotainment System Driving on a Route Destination Alpha-Numeric Keyboard Urgent Manoeuvre Alert The system will give an indication that the next manoeuver is close. Letters of the alphabet, symbols, If route guidance is not active, touch punctuation, and numbers, when the Destination Entry screen button available, display on the navigation on the Home Page to access the...
  • Page 161 Infotainment System 7-41 Delete: Touch to delete an counter with a number of incorrect character that has been available streets. Touch to view selected. the list and select the street. 3. Enter the house number. Address Entry 4. Touch the Done screen button at any time and the system tries to resolve a destination based on the entered information, then...
  • Page 162 7-42 Infotainment System Points of Interest (POI) Entering by POI name: Touch the Points of Interest screen 7. Touch the Start Guidance screen button on the Destination Entry button and the route calculates. page. Several options can be 1. Select to search By Name. selected to plan a route.
  • Page 163 Infotainment System 7-43 Address Book If a destination is already saved to 4. To customise the address book the address book, touch Destination entry, select Name, Number, Entry on the Home Page to display or Icon. the Address Book screen button. Latitude/Longitude Choose a destination by selecting Coordinates...
  • Page 164 7-44 Infotainment System To enter the location as coordinates, Adding a Favorite Route: 3. Scroll and select a favourite latitude and longitude: route. 1. Touch the Home Page 1. Touch Destination on the Home Destination Entry button to 4. Touch the Start Guidance screen Page.
  • Page 165 Infotainment System 7-45 4. Using the keypad, enter Select from Map Travel Guide the name. 5. Touch the Done screen button. The new name will be in the Favorite Routes Menu. My Home Touch the Home Page Touch the Travel Guide screen Destination Entry button to button on the Destination Entry display the Select from Map...
  • Page 166 7-46 Infotainment System Entering by POI Category 3. Select any of the line options Entering by POI name: such as Nearby. 4. Select Category from the POI Selection menu to access the POI List. 1. Select Category from the POI 1.
  • Page 167 Infotainment System 7-47 Destination Confirmation destination is already stored in the address book, Edit will show as the Multiple options are available on the menu item. destination confirmation screen: Route Options Start Guidance: Touch to start a route calculation to the displayed destination.
  • Page 168 7-48 Infotainment System Eco: This calculates for the most Menu with Route Guidance Destination List fuel efficient route based on speed Active and distance. Under the Route Options menu, there are route preferences that by default are all enabled. A checkmark placed next to each preference indicates this.
  • Page 169 Infotainment System 7-49 avoid a segment of roads. Waypoints To delete a waypoint: A maximum of eight avoided Up to three waypoints can be added 1. From the Destination menu, segments are allowed. to the current route. The waypoints touch Destination List. can be sorted (moved) or deleted.

  • Page 170: Configure Menu

    7-50 Infotainment System 4. Select the location to move the languages. Select the desired waypoint to. language. English is the only available language. Instead of deleting individual waypoints, select Delete All Time and Date Settings Waypoints to delete all waypoints at the same time.
  • Page 171 Infotainment System 7-51 Touch the Back screen button to Gracenote Options: Touch to Navigation Settings save the adjustments. enable/disable Normalization used Touch the Config button on the to improve voice recognition and Home Page to enter the setup Radio Settings media groupings.

  • Page 172: Global Positioning

    7-52 Infotainment System Map Display: Touch to change the can affect the navigation system's screen background. ability to determine the accurate position of the vehicle. The Automatic setting adjusts the screen background The GPS shows the current position automatically depending on the of the vehicle using signals sent by exterior lighting conditions.

  • Page 173: Vehicle Positioning

    Infotainment System 7-53 The vehicle changes directions Vehicle Positioning Problems with Route more than once, or the vehicle is Guidance At times, the position of the vehicle turning on a turn table in a on the map could be inaccurate due parking lot.

  • Page 174: If The System Needs

    7-54 Infotainment System The route prohibits the entry of a If the System Needs Database Coverage vehicle due to a regulation by Service Explanations time or season or any other regulation which may be given. If the navigation system needs Coverage areas vary with respect to service and the steps listed here the level of map detail available for...

  • Page 175: Voice Recognition

    Infotainment System 7-55 Voice Recognition 2. Clearly speak one of the (frequency), saying Tune FM commands listed later in this 87.7 or Tune FM are both Voice recognition allows for section. valid commands. hands-free operation of the When the command is Press twice on the steering infotainment system features.
  • Page 176 7-56 Infotainment System volume knob of the radio, Voice Recognition Help Voice Recognition Commands or press the volume steering To enter the help playback session, The following list shows the voice wheel control. If the volume is clearly speak one of the help commands available for the adjusted during a voice commands.
  • Page 177 Infotainment System 7-57 Phone Commands Delete Device: Instructs the Play Album (album title): Instructs system to delete a paired device. the system to play a specific album. Dial or Call (phone number or Read Text Messages or Read SMS Play Song (song title): Instructs contact): Instructs the system to Messages: Instructs the system to the system to play a specific song.
  • Page 178 7-58 Infotainment System Search Genre (genre name): Search Podcast (podcast name): Go Back, Back, Previous: Instructs the system to show a list of Instructs the system to show a list of Instructs the system to go back to a all songs for a specific genre. For all tracks in a specific podcast.
  • Page 179 Infotainment System 7-59 Navigation Commands (If Address or Destination: Allows the POI categories and an address to be stated as a sub-categories in the system by Equipped) one-shot method. The system will touching Destination from the Home To activate the navigation voice recognise the address if stated all at Page or DEST on the faceplate, recognition:...

  • Page 180: Bluetooth Phone/Devices

    7-60 Infotainment System Help: The system plays back more Store Bluetooth Phone/ specific help commands associated My Number Devices with Navigation or a Navigation Minutes sub-feature. Bluetooth Store Last Number Cancel Guidance or Cancel Route: Instructs the system to (Digit | Number) Dial Overview cancel guidance.
  • Page 181 Infotainment System 7-61 Bluetooth-enabled phones. Infotainment System Controls Audio System Available features and functions For information about how to Sound comes through the vehicle's may be dependent on the device. navigate the menu system using the front audio system speakers and On a current phone call screen, an infotainment controls, see Overview overrides the audio system.
  • Page 182 7-62 Infotainment System Pairing Information Pairing a Phone/Device system recognises the new connected phone after the A Bluetooth-enabled phone and 1. Press the CONFIG button or pairing process is complete. an audio playback device can be paired to the system at the 7.
  • Page 183 Infotainment System 7-63 Deleting a Paired Phone/Device Pairing with Voice Recognition to enter the PIN or to confirm the four or six-digit code matches. 1. Press the CONFIG button. A Bluetooth-enabled mobile phone The system responds must be paired and then connected 2.
  • Page 184 7-64 Infotainment System If another mobile phone is 3. The system responds with: To The radio will display the first 1,000 not found, the original phone delete a device, please select its contacts and the phone numbers for remains connected. name from the list.
  • Page 185 Infotainment System 7-65 3. Select the Incoming Calls, Using the Infotainment Controls Call Waiting Using Steering Outgoing Calls, or Missed Wheel Controls Turn the TUNE/MENU knob to Calls list. Answer or Decline and press the Call waiting must be supported on 4.
  • Page 186 7-66 Infotainment System wireless service carrier to work. This Muting a Call To Transfer Audio to the Bluetooth feature is only supported when the System from a Cell Phone During a call, all sounds from inside vehicle is not moving. Use the audio transfer feature on the vehicle can be muted so that the To start a conference while in a...

  • Page 187: Text Messaging

    Infotainment System 7-67 Clearing the System The text messaging feature can also Android: Accept and activate be initiated via voice recognition. Message Access Profile (MAP) if Unless information is deleted out of requested. the vehicle Bluetooth system, it will Using Text Messaging be retained.
  • Page 188 7-68 Infotainment System an incoming message. Not all 2. Touch Send to send the phones support the sending of message. messages. Alternatively, touch Back to cancel and return to the previous Replying to Text Messages screen. Incoming Text Messages 3. View the message. The message view screen is not available while the vehicle is in motion.
  • Page 189 Infotainment System 7-69 Touch View to view the Touch Manage Predefined Text Messaging Settings message. The message view Messages to create a user screen is not available while the defined message that can be vehicle is in motion. used later to reply to a text message.

  • Page 190: Trademarks And Licence Agreements

    7-70 Infotainment System Trademarks and Gracenote ® Licence Agreements Gracenote , Gracenote logo and logotype, and the "Powered by Gracenote" logo are either a registered trademark or a trademark of Gracenote, Inc. in the United States and/or other countries. Manufactured under license from Dolby Laboratories.
  • Page 191 Climate Controls Climate Controls Climate Control Systems Automatic Climate Control System Climate Control Systems Automatic Climate Control The heating, cooling, and ventilation for the vehicle can be controlled with System ..... . 8-1 this system.
  • Page 192 Climate Controls Automatic Operation Manual Operation (Bi-Level): Air is directed to the instrument panel outlets and the The system automatically controls Temperature Control: Turn the floor outlets. the fan speed, air delivery, air knob clockwise or anticlockwise to conditioning, and recirculation in increase or decrease the driver or (Floor): Air is directed to the order to heat or cool the vehicle to...
  • Page 193 Climate Controls Press AUTO to return to automatic The heated outside rear view Sensors operation and the air conditioner mirrors turn on with the rear window The solar sensor on top of the runs as needed. When the indicator demister and help to clear fog or instrument panel near the light is on, the air conditioner runs frost from the surface of the mirror.
  • Page 194 Climate Controls Dual Automatic Climate Control System When the indicator light is on, the system is in full automatic operation. The heating, cooling, and ventilation for the vehicle can be controlled with If the air delivery mode or fan this system. setting is manually adjusted, the auto indicator turns off and displays will show the selected settings.
  • Page 195 Climate Controls SYNC: Press to link all climate (Floor): Air is directed to the (Recirculation): Press to turn zone settings to the driver settings. floor outlets. on recirculation. An indicator light The SYNC indicator light will turn comes on. Air is recirculated to (Demist): Air is directed to the on.
  • Page 196 Climate Controls Rear Window Demister Sensors Air Vents (Rear Window Demister): The solar sensor on top of the Centre Air Vents Press to turn the rear window instrument panel near the demister on or off. windscreen monitors the solar heat. The rear window demister turns off The climate control system uses the automatically after about...
  • Page 197 Climate Controls Side Air Vents Rear Air Vents Maintenance Air vents are located at the rear of the centre console. Passenger Compartment Air Filter Operation Tips Keep all outlets open whenever The filter removes dust, pollen, and possible for best system other airborne irritants from outside performance.
  • Page 198 Climate Controls NOTES...
  • Page 199 Driving and Operating Driving and Engine Exhaust Driver Assistance Systems Engine Exhaust ....9-8 Ultrasonic Parking Assist ..9-22 Operating Diesel Particulate Filter ..9-8 Side Blind Zone Running the Vehicle While Alert (SBZA) .

  • Page 200: Driving And Operating

    Driving and Operating Driving Information Once the power assist is used up, it See specific vehicle steering can take longer to stop and the messages under Vehicle Messages brake pedal will be harder to push. on page 5-21. Control of a Vehicle Hydraulic Power Steering Steering Braking, steering, and accelerating...

  • Page 201: Starting And Operating

    Driving and Operating Starting and The transmitter must be in the Caution (Continued) vehicle for the system to operate. Operating If the pushbutton start is not Follow this breaking-in working, the vehicle may be near a guideline every time you get New vehicle running-in strong radio antenna signal causing new brake linings.
  • Page 202 Driving and Operating message SHIFT TO PARK in the If the vehicle must be shut off in an Warning Driver Information Centre (DIC). emergency: See Transmission Messages on 1. Brake using a firm and steady Turning off the vehicle while page 5-26 for more information.

  • Page 203: Starting The Engine

    Driving and Operating The ignition will switch from ACC/ The instruments and audio systems 4. Press the engine START/STOP ACCESSORY to OFF after will operate as they do in ON/RUN, button. The green LED will five minutes to prevent battery but the vehicle will not be able to be illuminate and the engine will rundown.

  • Page 204: Shifting Into Park

    Driving and Operating The radio continues to work until the Leaving the Vehicle with the is set before leaving it. After moving driver door is opened. the shift lever into P (Park), hold the Engine Running regular brake pedal down. Then, All these features operate when the see if the shift lever can be moved key is in ON/RUN or ACC/...
  • Page 205 Driving and Operating out of P (Park), unless the ignition is 3. Move the shift lever to the 2. Release the shift lever trim from in ON/RUN and the brake pedal is desired position. the centre console at the rear, applied.

  • Page 206: Parking On Flammable

    Driving and Operating Parking On Flammable Engine Exhaust Warning (Continued) Surfaces There are holes or openings Warning in the vehicle body from Warning damage or aftermarket Engine exhaust contains carbon modifications that are not monoxide (CO), which cannot be Things that can burn could touch completely sealed.
  • Page 207 Driving and Operating runs automatically during driving Cleaning takes place quickest at soon as possible. flashes when without any notification. The filter is high engine speeds and loads. Do diesel particle filter has reached the cleaned by periodically burning off not switch off the engine until the maximum filling level.

  • Page 208: Running The Vehicle While

    9-10 Driving and Operating Running the Vehicle Automatic Warning While Parked Transmission It is dangerous to get out of the It is better not to park with the vehicle if the shift lever is not fully engine running. in P (Park) with the parking brake If the vehicle is left with the engine firmly set.

  • Page 209: Manual Mode

    Driving and Operating 9-11 of P (Park), ease pressure on the D (Drive): This position is for Warning shift lever and push the shift lever normal driving. It provides good fuel all the way into P (Park) as you economy when pushing the Shifting into a drive gear while the maintain brake application.

  • Page 210: Antilock Brake

    9-12 Driving and Operating The transmission will not allow 2. Press the + (plus) end of the Brakes shifting to the next lower gear if button on the top of the shift the vehicle speed or engine rpm lever to upshift, or push the Antilock Brake is too high.

  • Page 211: Electric Parking Brake

    Driving and Operating 9-13 If driving safely on a wet road and it close to the vehicle in front of you, Electric Parking Brake becomes necessary to slam on the there will not be enough time to brakes and continue braking to apply the brakes if that vehicle avoid a sudden obstacle, a suddenly slows or stops.
  • Page 212 9-14 Driving and Operating The system has a parking brake drive the vehicle if the parking brake If the parking brake warning light is status light and a parking brake status light is flashing. See your on, the EPB has detected an error warning light.

  • Page 213: Brake Assist

    Driving and Operating 9-15 EPB Release power brake system under Caution conditions where the driver has To release the EPB, place the quickly and forcefully applied the ignition in the ACC/ACCESSORY or Driving with the parking brake on brake pedal in an attempt to quickly ON/RUN position, apply and hold can overheat the brake system stop or slow down the vehicle.

  • Page 214: Ride Control Systems Traction Control

    9-16 Driving and Operating drive off. After the driver completely Ride Control Systems The system may be heard or felt stops and holds the vehicle in a while it is working, but this is complete standstill on a grade, HSA normal.
  • Page 215 Driving and Operating 9-17 It is recommended to leave the Traction Control Operation Caution (Continued) system on for normal driving Traction control limits wheel spin by conditions, but it may be necessary reducing engine power to the may not be covered by the to turn the system off if the vehicle wheels (engine speed management) vehicle warranty.

  • Page 216: Electronic Stability

    9-18 Driving and Operating The traction control system may traction and stability control systems activate on dry or rough roads or and helps the driver maintain under conditions such as heavy directional control of the vehicle in acceleration while turning or abrupt most driving conditions.
  • Page 217 Driving and Operating 9-19 If the vehicle is in cruise control is stuck in sand, mud, ice or snow, when the system begins to assist and you want to rock the vehicle to the driver maintain directional attempt to free it. control of the vehicle, the ESC/TCS ESC may also turn off automatically light will flash and the cruise control...

  • Page 218: Cruise Control

    9-20 Driving and Operating Cruise Control Warning The cruise control lets the vehicle Cruise control can be dangerous maintain a speed of about 40 km/h where you cannot drive safely at or more without keeping your foot a steady speed. Do not use on the accelerator.
  • Page 219 Driving and Operating 9-21 accelerate. If cruise control is Resuming a Set Speed Reducing Speed While Using already active, use to increase Cruise Control If the cruise control is set at a vehicle speed. desired speed and then the brakes If the cruise control system is SET/ (Set/Coast): Move the are applied, the cruise control is...

  • Page 220: Driver Assistance Systems

    9-22 Driving and Operating Using Cruise Control on Hills Press Driver Assistance How well the cruise control works Systems Press to turn the cruise on hills depends upon the vehicle control system off completely. speed, load, and the steepness of The cruise control cannot be Ultrasonic Parking Assist the hills.
  • Page 221 Driving and Operating 9-23 Turning the System On and Off When the System Does Not Danger (Continued) Seem to Work Properly The UPA system can be turned on and off using the park assist button prevent injury, death, or vehicle The following messages may be next to the shift lever.

  • Page 222: Side Blind Zone

    9-24 Driving and Operating weather. The message may not SBZA Detection Zones Danger clear until the frost or ice has The SBZA sensor covers a zone of melted. approximately one lane over from SBZA does not detect vehicles An object was hanging out of the both sides of the vehicle, or 3.5 m.

  • Page 223: Rear Vision

    Driving and Operating 9-25 Vehicle Personalisation on cleaning the rear bumper corners, page 5-27. If SBZA is disabled by see your dealer. This message may the driver, the SBZA mirror displays also be displayed when driving near will not light up. sites where the SBZA system could cause interference.
  • Page 224 9-26 Driving and Operating To return to the previous screen The RVC system has a guideline Warning sooner, do one of the following: overlay that can help the driver align the vehicle when backing into a Press a button on the The RVC system does not display parking spot.
  • Page 225 Driving and Operating 9-27 To turn the symbols and guidelines Rear Vision Camera Error The area displayed by the camera is on or off: Messages limited. 1. Shift into P (Park). SERVICE REAR VISION CAMERA It does not display objects that are SYSTEM: This message can close to either corner or under the 2.

  • Page 226: Fuel

    It is dark. unless specified by Holden. The sun or the beam of Under no circumstances should headlamps is shining directly fuel containing the manganese into the camera lens.

  • Page 227: Fuel For Petrol Engines

    Holden may affect your New injury. Purchasing your fuel from a Prohibited Fuels Vehicle Voluntary Warranty to the reputable fuel retailer may reduce...

  • Page 228: Fuel For Diesel Engines

    Warranty. In no event will GM diesel fuels, such as rape seed oil Keep sparks, flames, and Holden be responsible or bear or bio diesel containing more than smoking materials away any liability for any damage or 5% FAME.
  • Page 229 Driving and Operating 9-31 The fuel cap is behind the fuel door Warning (Continued) Warning on the driver side of the vehicle. If equipped, the fuel door is locked Fuel can spray out if the fuel If a fire starts while you are when the vehicle doors are locked.

  • Page 230: Filling A Portable Fuel

    Remove the container from section. the vehicle or boot before filling. A Holden Dealer will assist with supply and installation of towing Place the container on the equipment. ground. Place the nozzle inside the fill...
  • Page 231 The maximum unbraked towing capacity for all vehicles is 750 kg. New Vehicle Voluntary Warranty, to the extent that Holden considers the overloading or missing equipment to Warning (Continued) have affected the specifications or Warning quality of the vehicle.
  • Page 232 Ensure the weight of the packed carbon monoxide, see Engine trailer is not greater than the towing Exhaust on page 9-8. capacity of the Holden approved tow bar package fitted to the A trailer hitched to a vehicle places vehicle.
  • Page 233 Towing and loading equipment Tow load Mandatory equipment Up to 1,200 kg Holden 1,200 kg rated tow bar Holden trailer wiring harness Brakes on the trailer if the aggregate trailer mass (ATM) is more than 750 kg Vehicles handle differently when Use a lower gear and the towing.

  • Page 234: Conversions And Add-Ons

    9-36 Driving and Operating If a tow bar is removed, have Running-in when towing Conversions and any mounting holes in the It is recommended that a new Add-Ons underbody sealed to prevent vehicle be driven for at least entry of exhaust fumes, dust and 1,500 km before towing.
  • Page 235 Vehicle Care 10-1 Vehicle Care Headlamp Aiming Tyre Rotation ....10-35 When It Is Time for New Headlamp Aiming ..10-22 Tyres .

  • Page 236: Vehicle Care

    10-2 Vehicle Care General Information Damage to vehicle components Vehicle Checks resulting from modifications or the For service and parts needs, visit installation or use of non-GM Doing Your Own your dealer. You will receive certified parts, including control Service Work genuine parts and trained and module or software modifications, is supported service people.

  • Page 237: Bonnet

    Vehicle Care 10-3 Keep a record with all parts receipts To close the bonnet: and list the kilometres and the date 1. Before closing the bonnet, be of any service work performed. sure all the filler caps are properly installed. Caution 2.
  • Page 238 10-4 Vehicle Care Engine Compartment Overview 2.0L L4 Diesel Engine...
  • Page 239 Vehicle Care 10-5 1. Engine Air Cleaner/Filter on 5. Engine Oil Fill Cap. See When 8. Battery on page 10-21. page 10-11. to Add Engine Oil under Engine 9. Engine Compartment Fuse Oil on page 10-7. 2. Brake Fluid Reservoir. See Block on page 10-27.
  • Page 240 10-6 Vehicle Care 2.4L L4 Petrol Engine...

  • Page 241: Engine Oil

    Vehicle Care 10-7 1. Engine Air Cleaner/Filter on Engine Oil Checking Engine Oil page 10-11. It is a good idea to check the engine To ensure proper engine 2. Brake Fluid Reservoir. See oil level at each fuel fill. In order to performance and long life, careful Brakes on page 10-19.
  • Page 242 10-8 Vehicle Care 2. Pull out the dipstick and clean it use. For engine oil crankcase Add enough oil to put the level with a paper towel or cloth, then capacity, see Capacities and somewhere in the proper operating push it back in all the way. Specifications on page 12-5.
  • Page 243 Vehicle Care 10-9 temperatures. When selecting an oil of the appropriate viscosity grade, always select an oil of the correct specification. See Specification earlier in this section. Selecting the Right Engine Oil (Diesel Engines) Caution Caution Selecting the right engine oil Use only engine oil that is Use only engine oil that is depends on both the proper oil...

  • Page 244: Engine Oil Life System

    10-10 Vehicle Care temperatures. When selecting an oil containing used engine oil. See the to work properly, the system must of the appropriate viscosity grade, manufacturer's warnings about the be reset every time the oil is always select an oil of the correct use and disposal of oil products.

  • Page 245: Automatic Transmission

    Vehicle Care 10-11 oil change. Remember to reset the The system is reset when the procedure is difficult, this should be oil life system whenever the oil is CHANGE ENGINE OIL SOON done at the dealer. Contact your changed. message is off and the REMAINING dealer for additional information.

  • Page 246: Cooling System

    10-12 Vehicle Care Cooling System Warning (Continued) The cooling system allows the Keep hands, clothing, and tools engine to maintain the correct away from any under bonnet working temperature. electric fan. Warning Heater and radiator hoses, and other engine parts, can be very 2.4L L4 Petrol Engine hot.

  • Page 247: Engine Coolant

    Vehicle Care 10-13 What to Use Use a 50/50 mixture of clean, Caution drinkable water and DEX-COOL coolant. If using this mixture, Warning Using coolant other than nothing else needs to be added. ® DEX-COOL can cause This mixture: Adding only plain water or some premature engine, heater core, other liquid to the cooling system Gives freezing protection down...
  • Page 248 10-14 Vehicle Care Check to see if coolant is visible in How to Add Coolant to the Caution (Continued) the coolant surge tank. If the coolant Coolant Surge Tank inside the coolant surge tank is damaged. Too much water in the boiling, do not do anything else until Warning mixture can freeze and crack...
  • Page 249 Vehicle Care 10-15 1. Remove the coolant surge tank 4. With the coolant surge tank Warning pressure cap when the cooling pressure cap off, start the system, including the coolant engine and let it run until the Steam and scalding liquids from a surge tank pressure cap and upper radiator hose can be felt hot cooling system can blow out...

  • Page 250: Engine Overheating

    10-16 Vehicle Care Engine Overheating If Steam is Coming from the If No Steam is Coming from Engine Compartment the Engine Compartment There is an engine coolant If an engine overheat warning is temperature gauge on the vehicle Warning displayed but no steam can be seen instrument cluster to warn of engine or heard, the problem may not be overheating.

  • Page 251: Power Steering Fluid

    Vehicle Care 10-17 If the coolant temperature gauge is Power Steering Fluid How to Check Power Steering (Diesel Engine Only) no longer in the overheat zone, the Fluid vehicle can be driven. Continue to Check the level when the engine drive the vehicle slowly for about is cool.

  • Page 252: Washer Fluid

    10-18 Vehicle Care 5. Remove the cap again and look Washer Fluid Open the cap with the washer at the fluid level on the dipstick. symbol on it. Add washer fluid until What to Use the tank is full. See Engine Compartment Overview on When windscreen washer fluid is page 10-4 for reservoir location.

  • Page 253: Brakes

    Vehicle Care 10-19 pedal travel. This could be a sign Caution (Continued) Caution that brake service might be required. expansion if freezing occurs, Continuing to drive with worn-out which could damage the tank Brake Adjustment brake pads could result in costly if it is completely full.

  • Page 254: Brake Fluid

    10-20 Vehicle Care change in many other ways if the There are only two reasons why the Warning wrong replacement brake parts are fluid level in the reservoir might installed. go down: If too much brake fluid is added, it The fluid level goes down can spill on the engine and burn, Brake Fluid...

  • Page 255: Battery

    Vehicle Care 10-21 Battery Warning Caution (Continued) The original equipment battery is be replaced. Do not let Using brake fluid other than GM maintenance-free. Do not remove someone put in the wrong recommended brake fluid may the cap and do not add fluid. kind of fluid.

  • Page 256: Headlamp Aiming

    10-22 Vehicle Care Headlamp Aiming Warning Warning (Continued) Headlamp aim has been preset and Do not use a match or flame near Battery posts, terminals and should need no further adjustment. a vehicle's battery. If you need related accessories contain lead If the vehicle is damaged in a crash, more light, use a flashlight.

  • Page 257: Bulb Replacement

    Vehicle Care 10-23 Bulb Replacement Headlamps, Front Turn Dipped Beam Headlamp Signal and Park Lamps 1. For the passenger side bulb, For the proper type of replacement remove the windscreen washer bulbs, see Replacement Bulbs on bottle filler neck by firmly pulling page 10-26.
  • Page 258 10-24 Vehicle Care 6. Install a new bulb in the lamp 7. Install the spring clips. assembly. 8. Connect the electrical connector. 7. Install the spring clamp, pressing 9. Replace the cap from the back in on the end and then swing of the headlamp assembly by downward.

  • Page 259: Fog Lamps

    Vehicle Care 10-25 6. For the passenger side, reinstall Number Plate Lamp the windscreen washer bottle To replace one of these bulbs: filler neck by firmly pushing it straight into the bottle. Ensure that the filler neck clip engages into the under bonnet electrical centre retainer.

  • Page 260: Replacement Bulbs

    10-26 Vehicle Care Replacement Bulbs Electrical System If there is a problem on the road and a fuse needs to be replaced, the Bulb same amperage fuse can be Exterior Lamp Electrical System Number borrowed. Choose some feature of Overload the vehicle that is not needed to use Reverse Lamp W16W...

  • Page 261: Fuses

    Vehicle Care 10-27 Although the circuit is protected Fuses of the same amperage can Caution from electrical overload, overload be temporarily borrowed from due to heavy snow or ice may another fuse location, if a fuse goes Spilling liquid on any electrical cause wiper linkage damage.
  • Page 262 10-28 Vehicle Care...
  • Page 263 Vehicle Care 10-29 The vehicle may not be equipped Mini Mini Usage Usage with all of the fuses, relays, and Fuses Fuses features shown. PT Run/Crank Ignition Left Main Beam Mini Usage Fuses SDM Ignition Term 87A Transmission Control Vehicle Air Non Walk 02 Module Battery Purification System...
  • Page 264 10-30 Vehicle Care Mini J-Case Usage Mini Usage Usage Fuses Fuses Relays Canister Vent Sunroof Cooling Fan K1 Solenoid Front Power Window Run/Crank Adaptive Forward PEPS Motor Diesel Fuel Heater Lighting/Headlamp Antilock Brake Window/Mirror Levelling Electric System Pump Demister Anti-Theft Warning Siren Horn Electric Parking Brake Micro...

  • Page 265: Block

    Vehicle Care 10-31 Micro Usage Fuses Usage Relays Right Mirror Turn Signal, Cooling Fan K3 Left Brake Lamp, Right Front Turn Signal, Left Dipped Beam HID/ Rear Turn Signal Left DRL Radio Instrument Panel Fuse Universal Hands-Free Block Phone Front Accessory Power Outlet Instrument Panel Fuse Block Console Bin Power...

  • Page 266: Wheels And Tyres

    10-32 Vehicle Care Wheels and Tyres Fuses Usage Fuses Usage Left Dipped Beam Instrument Panel Cluster Tyres Headlamp, Left Daytime Ignition Switch Running Lamp Every new GM vehicle has Right Dipped Beam high-quality tyres made by a Power Door Locks Headlamp, Right leading tyre manufacturer.

  • Page 267: Tyre Pressure

    Vehicle Care 10-33 Warning (Continued) Warning (Continued) Caution Underinflated tyres pose Worn or old tyres can Neither tyre underinflation nor overinflation is good. the same danger as cause a crash. If the tread overloaded tyres. The is badly worn, Underinflated tyres, or tyres resulting crash could replace them.

  • Page 268: Tyre Inspection

    10-34 Vehicle Care Tyre Placard Do not forget the spare tyre, inflation pressure is high, press if the vehicle has one. on the metal stem in the centre The tyre placard may display the of the tyre valve to release air. tyre size and pressures using the How to Check following icons:...

  • Page 269: Tyre Rotation

    Vehicle Care 10-35 The tread or sidewall is Any time unusual wear is Do not include the spare tyre in cracked, cut, or snagged noticed, rotate the tyres as soon the tyre rotation. deep enough to show cord or as possible, check for proper Adjust the front and rear tyres to fabric.

  • Page 270: When It Is Time For New

    10-36 Vehicle Care tyres, including the spare if Warning (Continued) equipped, be replaced after six years, regardless of tread wear. an emergency, a cloth or a paper towel can be used; however, use Buying New Tyres a scraper or wire brush later to Refer to the tyre placard on the remove all rust or dirt.

  • Page 271: Wheel Replacement

    Replace any wheel that is bent, as the vehicle's insurance policy. suspension, or other vehicle cracked, or badly rusted or Contact a Holden Dealer for advice parts. The area damaged by the corroded. If wheel nuts keep coming on suitable tyres.

  • Page 272: If A Tyre Goes Flat

    10-38 Vehicle Care A rear blowout, particularly on a Warning (Continued) Warning curve, acts much like a skid and may require the same correction as avoid vehicle damage, drive slow All passengers must be out of the used in a skid. Stop pressing the and readjust or remove the vehicle when it is being jacked.
  • Page 273 Vehicle Care 10-39 Warning (Continued) Warning (Continued) Danger (Continued) Do not start or run the engine After installing the spare tyre on level place to change the tyre. To while the vehicle is supported by the vehicle, stop as soon as help prevent the vehicle from the jack.

  • Page 274: Tyre Sealant And Compressor Kit

    10-40 Vehicle Care This vehicle may come with a jack The following information explains Warning and spare tyre or a tyre sealant and how to repair or change a tyre. compressor kit. To use the jacking Overinflating a tyre could cause Tyre Sealant and equipment to change a spare tyre the tyre to rupture and you or...
  • Page 275 Vehicle Care 10-41 If this vehicle has a tyre sealant and The kit includes: compressor kit, there may not be a spare tyre or tyre changing equipment, and on some vehicles there may not be a place to store a tyre. The tyre sealant and compressor can be used to temporarily seal punctures up to 6 mm (0.25 in) in...
  • Page 276 10-42 Vehicle Care There is only enough sealant to seal 1. Remove the tyre sealant one tyre. After usage, the tyre canister (4) and compressor sealant canister must be replaced. from its storage location. See Storing the Tyre Sealant and Using the Tyre Sealant and Compressor Kit on page 10-47.
  • Page 277 Vehicle Care 10-43 If the vehicle only has a cigarette 11. Inflate the tyre to the lighter, use the cigarette lighter. recommended inflation pressure using the pressure Do not pinch the power plug gauge (8). The recommended cord in the door or window. inflation pressure can be found 9.
  • Page 278 10-44 Vehicle Care 14. Turn the sealant/air hose (2) 20. If the flat tyre was able to Caution (Continued) anticlockwise to remove it from inflate to the recommended the tyre valve stem. inflation pressure, remove the the tyre. Remove the power plug maximum speed label from the 15.
  • Page 279 Vehicle Care 10-45 If the tyre pressure has fallen within 150 km of driving to 5. On/Off Button more than 68 kPa (10 psi) have the tyre repaired or 6. Slot on Top of Compressor below the recommended replaced. 7. Pressure Deflation Button inflation pressure, stop driving Using the Tyre Sealant and the vehicle.
  • Page 280 10-46 Vehicle Care See If a Tyre Goes Flat on 6. Plug the power plug (9) into the 9. Inflate the tyre to the page 10-38 for other important accessory power outlet in the recommended inflation pressure safety warnings. vehicle. Unplug all items from using the pressure gauge (8).
  • Page 281 Vehicle Care 10-47 11. Unplug the power plug (9) from Storing the Tyre Sealant Caution the accessory power outlet in and Compressor Kit the vehicle. If the recommended pressure The tyre sealant and compressor kit 12. Turn the air only hose (10) cannot be reached after is located in the boot.

  • Page 282: Tyre Changing

    10-48 Vehicle Care Tyre Changing Removing the Flat Tyre and Installing the Spare Tyre Removing the Spare Tyre and 1. Do a safety check before Tools proceeding. See If a Tyre Goes The equipment you need is located Flat on page 10-38 for more in the boot.
  • Page 283 Vehicle Care 10-49 4. Attach the jack lift assist tool to Caution Warning (Continued) the jack by fitting both ends of the jack and tool over one Make sure that the jack lift head damage, be sure to fit the jack lift another.
  • Page 284 10-50 Vehicle Care Warning (Continued) Warning an emergency, a cloth or a paper Never use oil or grease on bolts towel can be used; however, use or nuts because the nuts might a scraper or wire brush later to come loose. The vehicle's wheel remove all rust or dirt.
  • Page 285 Vehicle Care 10-51 Warning (Continued) Caution after replacing. See Capacities Wheel covers will not fit on the and Specifications on page 12-5 vehicle's compact spare. If you try for original equipment wheel nut to put a wheel cover on the torque specifications.

  • Page 286: Full-Size Spare Tyre

    10-52 Vehicle Care Store the spare or flat tyre as shown Full-Size Spare Tyre Jump Starting below. If this vehicle came with a full-size For more information about the This vehicle has a screw in fastener. spare tyre, it was fully inflated when vehicle battery, see Battery on new;...
  • Page 287 Vehicle Care 10-53 2. Position the two vehicles so that Caution they are not touching. 3. To avoid the possibility of the Ignoring these steps could result vehicles rolling, set the parking in costly damage to the vehicle brake firmly on both vehicles that would not be covered by the involved in the jump start vehicle warranty.
  • Page 288 10-54 Vehicle Care 6. Do not let the other end of the Warning Warning (Continued) red positive (+) cable touch metal. Connect it to the An electric fan can start up even add de ionised water to take care positive (+) terminal of the good when the engine is not running of that first.

  • Page 289: Towing The Vehicle

    Vehicle Care 10-55 8. Connect the other end of the Towing Caution black negative ( ) cable to an unpainted heavy metal engine Towing the Vehicle If the jumper cables are part away from the dead battery, connected or removed in the but not near engine parts wrong order, electrical shorting Caution...

  • Page 290: Appearance Care

    10-56 Vehicle Care Appearance Care Caution Exterior Care Improper use of the tow eye can cause vehicle damage. Use Locks caution and low speeds to prevent damage to the vehicle. Locks are lubricated at the factory. Use a de-icing agent only when absolutely necessary, and have the locks greased after using.
  • Page 291 Vehicle Care 10-57 washed. This could cause damage calcium chloride and other salts, ice Caution (Continued) that would not be covered by the melting agents, road oil and tar, tree vehicle warranty. sap, bird droppings, chemicals from products can be obtained from industrial chimneys, etc., can If using an automatic car wash, your dealer.
  • Page 292 10-58 Vehicle Care The bright metal mouldings on the Cleaning Exterior Lamps/ Caution (Continued) vehicle are aluminium. To prevent Lenses, Emblems, Decals and damage always follow these Stripes may damage it. Use only cleaning instructions: non-abrasive waxes and polishes Use only lukewarm or cold water, a Be sure the moulding is cool to that are made for a basecoat/ soft cloth, and a car washing soap...
  • Page 293 Vehicle Care 10-59 Aftermarket appearance caps or Windscreen and Wiper Blades can be removed by rubbing with a covers while the lamps are clean cloth. See Recommended Clean the outside of the windscreen illuminated, due to excessive Fluids and Lubricants on page 11-3. with glass cleaner.
  • Page 294 10-60 Vehicle Care Steering, Suspension, and Caution Caution (Continued) Chassis Components Chrome wheels and other chrome automatic car wash that uses Visually inspect steering, suspension, and chassis trim may be damaged if the silicone carbide tyre cleaning components for damaged, loose, vehicle is not washed after driving brushes.

  • Page 295: Interior Care

    Vehicle Care 10-61 underbody. Your dealer or an Chemical Paint Spotting Your dealer may have products for underbody car washing system can cleaning the interior. Use cleaners Airborne pollutants can fall upon do this. If not removed, rust and specifically designed for the and attack painted vehicle surfaces corrosion can develop.
  • Page 296 10-62 Vehicle Care Never use a brush with stiff When heavily soiled, use warm Caution bristles. soapy water. Never rub any surface Fabric/Carpet/Suede To prevent scratching, never use aggressively or with excessive abrasive cleaners on automotive Start by vacuuming the surface pressure.
  • Page 297 Vehicle Care 10-63 3. Start on the outside edge of the Cleaning High Gloss Surfaces Instrument Panel, Leather, soil and gently rub toward the and Vehicle Information and Vinyl, Other Plastic Surfaces, centre. Fold the cleaning cloth to Radio Displays Low Gloss Paint Surfaces and a clean area frequently to Natural Open Pore Wood...

  • Page 298: Floor Mats

    10-64 Vehicle Care Care of Seat Belts Use the following guidelines for Caution (Continued) proper floor mat usage: Keep belts clean and dry. The original equipment floor solvents can permanently change mats were designed for your the appearance and feel of Warning vehicle.
  • Page 299 Vehicle Care 10-65 Removing and Replacing the Floor Mats Pull up on the rear of the floor mat to unlock each retainer and remove. Reinstall by lining up the floor mat retainer openings over the carpet retainers and snap into position. Make sure the floor mat is properly secured in place.
  • Page 300 10-66 Vehicle Care NOTES...
  • Page 301 Service and Maintenance 11-1 Service and General Information The required maintenance intervals vary considerably between climates, Maintenance geographical locations, terrain, and Caution driving conditions. The Service/ Warranty booklet provided with the Maintenance intervals, checks, vehicle shows the intervals required General Information inspections, recommended fluids, for the various maintenance General Information .
  • Page 302 11-2 Service and Maintenance The maintenance schedule is for At your dealer, you can be certain Warning vehicles that: that you will receive the highest level of service available. Your Carry passengers and cargo Performing maintenance work can dealer has specially trained service within recommended limits.
  • Page 303 Service and Maintenance 11-3 Recommended Fluids, Lubricants, and Parts Recommended Fluids and Lubricants Usage Fluid/Lubricant Engine Oil Specification (Petrol 5W-30; (dexos1 ) 2.4L L4) Engine Oil Specification (Diesel 5W-30; (dexos2 ) 2.0L L4) ® Engine Coolant Specification 50% clean fresh water and 50% Dexcool anti-freeze coolant, conforming to specification number GM6277M ®...
  • Page 304 11-4 Service and Maintenance NOTES...
  • Page 305 Technical Data 12-1 Technical Data Vehicle Identification Vehicle Identification Vehicle Identification Number (VIN) Vehicle Identification Number (VIN) ....12-1 Identification Plate ... 12-2 Vehicle Data Engine Data .

  • Page 306: Identification Plate

    12-2 Technical Data Identification Plate Engine number location Compliance label Petrol 2.4L L4 Engine Diesel 2.0L L4 Engine The engine number is located inside the engine compartment. The engine serial number is stamped into the metal to the right It is stamped into the metal, This label shows the vehicle make, of the exhaust manifold.

  • Page 307: Vehicle Data

    Technical Data 12-3 Vehicle Data Engine Data Engine type 2.4L Petrol 2.0L Diesel Engine 2384 cc 1956 cc Fuel Petrol Diesel Octane rating (RON) Unleaded regular 91 or higher Ethanol compatibility Vehicle Weight The carrying capacity assumes Overloading is a safety hazard and could also shorten the life of the vehicle. that no accessories are fitted.

  • Page 308: Additional Weights

    12-4 Technical Data Axle loads Example 2: Maximum front and rear axle loads A. Vehicle carrying capacity (example 408 kg) Do not exceed the maximum axle loads, including the weight of any options or accessories fitted to the vehicle. Take the roof rack load into account B.
  • Page 309 Technical Data 12-5 Capacities and Specifications Engine type 2.4L Petrol 2.0L Diesel Refill engine oil including 4.7 L 4.5 L filter (approximately) Coolant (approximately) 7.1 L 6.1 L Fuel tank 73.0 L 73.0 L Wheel Nut Torque...

  • Page 310: Tyre Pressure

    12-6 Technical Data Tyre Pressure Recommended pressure Tyre size Wheel size and profile Normal load Eco normal load Maximum load Spare Front Rear Front Rear Front Rear 225/55 R17 97V 17 X 7 J 245/45 R18 100V 18 X 8 J...
  • Page 311 Customer Information 13-1 Customer Customer Information As a first step, Holden suggests you discuss any concern with the Information relevant Department Manager Customer Satisfaction (Sales Manager or Service Procedure Manager). Customer Information Alternatively, the Dealership Holden Customer Care Customer Satisfaction...
  • Page 312 Written Correspondence Most of this information will be as well as New Zealand found on the Vehicle Identification You can also write to Holden at the Customer Care. Certificate, located inside the front address below: Alternatively, you may prefer to...
  • Page 313 New Zealand. Vehicle model Australia Applicable details for New Zealand Vehicle Identification Number are set out in the Holden Warranty (ISOVIN), refer to the inside front The Holden Customer Assistance and Owner Assistance Information cover of the Service/Warranty...
  • Page 314 13-4 Customer Information NOTES...
  • Page 315 INDEX Airbags Audio System Backglass Antenna ...7-15 Adding Equipment to the Accessories and Vehicle ..... .3-22 Radio Reception .
  • Page 316 INDEX Brake Cleaning Parking, Electric ....9-13 Exterior Care ....10-56 Camera System Warning Light ..5-12 Interior Care .
  • Page 317 INDEX Customer Care Driver Information Engine Offices ......13-3 Centre (DIC) ....5-18 Air Cleaner/Filter .
  • Page 318 INDEX Fuel ......9-28 Gauges (cont'd) Tachometer ....5-8 Additives .
  • Page 319 INDEX Heated Mirrors ....2-13 Lamps (cont'd) Number Plate ....10-25 Heating and Air Conditioning .
  • Page 320 INDEX Lights (cont'd) Messages (cont'd) Front Fog Lamp ....5-17 Service Vehicle ....5-25 Maintenance Schedule Headlamp Flash .
  • Page 321 INDEX Parking Assist Ultrasonic .....9-22 Object Detection System Quick Info ..... 7-16 Passenger Compartment Air Messages .
  • Page 322 INDEX Restraints Seats Shifting Into Park ..... . . 9-6 Where to Put ....3-29 Adjustment, Front .
  • Page 323 INDEX Storing the Tyre Sealant Trailer Tyres (cont'd) Wheel Alignment and and Compressor Kit ..10-47 Towing ......9-32 Sun Visors .
  • Page 324 i-10 INDEX Vehicle (cont'd) Weights Security ..... .2-10 Additional .....12-4 Service Soon Light .

Table of Contents

Save PDF
