Husqvarna 140 Workshop Manual

Husqvarna 140 Workshop Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Workshop manual
135, 135e, 135e TrioBrake
140
English

Advertisement

Table of Contents
loading

Related Manuals for Husqvarna 140

Summary of Contents for Husqvarna 140

  • Page 1 Workshop manual 135, 135e, 135e TrioBrake English...

  • Page 3: Table Of Contents

    Safety equipment ..........16 Repair instructions ..........24 Carburettor ............33 Troubleshooting........... 53 Husqvarna AB has a policy of continuous product development and therefore reserves the right to modify the design and appearance of products without prior notice. English –...

  • Page 4: Index

    Index Index Symbols in the Workshop Manual 9 Symbols on the saw 9 Bar bolt 52 Structure 7 Replacing the bar bolt 52 Target group 7 Tools 7 Carburettor 33 Assemble on the saw 40 Oil pump and screen 31 Assembly 38 Assembling the oil pump and screen 32 Carburettor adjustment 41...
  • Page 5 Index Trouble shooting 54 Trouble-shooting methods 55 Vibration damping system 43 Assembly 43 Cleaning and inspection 43 Dismantling 43 English –...

  • Page 6: Introduction And Safety Instructions

    Introduction and safety instructions 2 Introduction and safety instructions Contents General ...........................7 Safety ..........................7 Target group ........................7 Changes ..........................7 Tools ..........................7 Structure .........................7 Numbering ........................7 General instructions ......................8 Special instructions ......................8 2.10 Symbols on the saw .......................9 2.11 Symbols in the Workshop Manual ..................9 –...
  • Page 7 Workshop Manual. Usage is evident from respective sections. Some sections include a Description of the actual unit in order to increase the basic understanding. Always use Husqvarna’s original: • Spare parts 2.7 Numbering • Service tools Position references to components inside the figu- res are designated A, B, etc.
  • Page 8 Introduction and safety instructions 2.8 General instructions 2.9 Special instructions The workshop where chain saw repairs are to be The fuel that is used in a chainsaw poses the fol- done must be equipped with safety equipment as lowing hazards: set out in local provisions.
  • Page 9 Introduction and safety instructions 2.10 Symbols on the saw 2.11 Symbols in the Workshop Manual The symbols below are embedded on the chain saw. This symbol warns of personal injury Choke lever when the instructions are not followed Use protective gloves. Refuelling Use protective goggles.

  • Page 10: Technical Data

    1,5 / 2,0 / 9 000 135e TB: 40,9 / 2,25 41 / 1,61 31 / 1,22 1,5 / 2,0 / 9 000 140: 40,9 / 2,49 41 / 1,61 31 / 1,22 1,6 / 2,1 / 9 000 Spark plug gap...
  • Page 11 Spark plug 135: 2 900 4 300 NGK BPMR 7A Champion RCJ 7Y 135e: 2 900 4 300 Husqvarna HQT-1 135e TB: 2 900 4 300 140: 2 900 4 300 Fuel tank capacity Oil pump capacity at Oil tank capacity...

  • Page 12: Service Tools

    Special tools 4 Special tools – English...
  • Page 13 Special tools Item Description Used for Order no. Clutch tool Centrifugal clutch 530 03 11-12 Piston stop Locking the crankshaft 504 91 06-05 Fuel filter hook Withdrawing the fuel filter 502 50 83-01 Allen key, 4mm For M5 bolts 502 50 87-01 Allen key, 4mm For M5 bolts 502 50 18-01...

  • Page 14: Service Data

    Service data 5 Service data The numbers by bolted components represent the tightening torque in Nm. Lubricate chain saw oil. Lubricate with grease. – English...
  • Page 15 Service data 23Nm 13mm 2.5Nm 2.5Nm English –...

  • Page 16: Safety Equipment

    Safety equipment 6 Safety equipment Contents Dismantling the chain brake ...................17 Chain brake - reassembly ....................18 Silencer - removal ......................19 Silencer - refitting ......................19 Chain catcher - replacement ..................20 Dismantling the start/stop control ...................20 Stop switch - resistance measurement ................21 Assembling the start/stop control ..................21 Throttle lock, throttle trigger and return spring - removal ..........22 6.10...

  • Page 17: Safety Equipment

    Safety equipment 6 Safety equipment 6.1 Dismantling the chain brake Release the brake by moving the front hand guard backward. Loosen the bar nut and remove the clutch cover, chain and bar (see figure 1). Fig 1 Carefully tighten the clutch housing in a vice. Release the brake by using the saw's front hand guard (A) as a tool.

  • Page 18: Chain Brake - Reassembly

    Safety equipment 6.2 Chain brake – reassembly Bolt the elbow joint to the brake band (see figure 5) and tighten to a torque of 1–1.5 Nm. Locate the elbow joint and connected brake band in their recesses in the clutch cover. Lubricate the recess for the spring with grease (see figure 6).

  • Page 19: Silencer - Removal

    Safety equipment Operating test: The engine must not be running during the test. Guide bar length Height 15"-20” 50 cm/20" • Hold the chainsaw over a firm surface. The height of the guide bar above the surface is given in the table above. •...

  • Page 20: Chain Catcher - Replacement

    Safety equipment 6.5 Chain catcher – replacement If the chain catcher is worn it must be replaced with a new one. Release the brake by pushing the kickback guard backwards. Undo the guide bar bolts and remove the clutch cover, chain and guide bar. Remove the chain catcher and replace it with a new one.

  • Page 21: Stop Switch - Resistance Measurement

    Safety equipment 6.7 Stop switch – resistance measurement Clean the mating surfaces and check the resis- tance as follows: Measure the resistance by connecting a multime- ter to the ignition coil. NOTE! The switch must be in the “on” (A) position to give the correct reading (see figure 14).

  • Page 22: Throttle Lock, Throttle Trigger And Return Spring - Removal

    Safety equipment 6.9 Throttle lock, throttle trigger and return spring – removal Loosen the throttle actuator rod on the carburettor, the fuel hose and the suction hose to the fuel pump. Dismantle the tank unit from the engine unit by loosening the screws A (see figure 17) Fig 17 Dismantle the handle insert (B) by loosening the...

  • Page 23: Throttle Lock, Throttle Trigger And Return Spring - Refitting

    Safety equipment Cleaning and inspection • Clean and inspect all parts carefully. If there are any cracks or other defects replace the dama- ged parts with new ones. Always use original parts. Check that the spring is not broken and has not •...

  • Page 24: Repair Instructions

    Repair instructions 7 Repair instructions Contents Starter assembly - removal .....................25 Changing a broken or worn starter cord .................26 Tensioning the recoil spring ....................26 Replacing a worn recoil spring ..................27 Starter assembly - refitting ....................27 Ignition module - testing ....................27 Ignition module and flywheel - removal ................28 Ignition module and flywheel - refitting ................29 Centrifugal clutch - removal ....................30...

  • Page 25: Repair Instructions

    Repair instructions 7 Repair instructions 7.1 Starter assembly – removal Undo the four bolts that fasten the starter assembly to the crankcase and lift off the starter assembly. (see figure 1) Fig 1 Pull out about 30 cm of the cord and fasten it in the notch in the pulley rim.

  • Page 26: Changing A Broken Or Worn Starter Cord

    Repair instructions 7.2 Changing a broken or worn starter cord When the starter cord is worn and must be replaced, the tension on the return spring must be released. Pull the cord out about 30 cm and lift it into the notch on the outside of the starter pulley.

  • Page 27: Replacing A Worn Recoil Spring

    Repair instructions 7.4 Replacing a worn recoil spring WARNING! Make sure the recoil spring does not fly out and cause injury. Wear eye protection.. Remove the bolt from the centre of the pulley and lift off the pulley and spring cassette. Replace the defective spring cassette with a new one.

  • Page 28: Ignition Module And Flywheel - Removal

    Repair instructions 7.7 Ignition module and flywheel – removal Remove the cylinder cover. Disconnect the HT lead, remove the spark plug and fit piston stop 502 54 15- 01. in its place. Take off the starter assembly, release the leads from the cable guide and remove it (see figure 8).

  • Page 29: Ignition Module And Flywheel - Refitting

    Repair instructions 7.8 Ignition module and flywheel – refitting Fit the flywheel on the crankshaft journal. Turn the flywheel so that the key lines up with the keyway in the shaft. Fit the nut on the shaft and tighten to a torque of 25-30 Nm (see figure 11).

  • Page 30: Centrifugal Clutch - Removal

    Repair instructions 7.9 Centrifugal clutch – removal Remove the cylinder cover. Disengage the chain brake by pushing the kickback guard backwards. Undo the bar nut and remove the clutch cover, bar and chain (see figure 13). Disconnect the HT lead. Remove the spark plug and fit piston stop 502 54 15-01 (A) in its place (see figure 14).

  • Page 31: Centrifugal Clutch - Refitting

    Repair instructions 7.10 Centrifugal clutch – refitting Insert the clutch springs in the shoes. Screw the clutch (anti-clockwise) until it stops. Now tighten using tool 530 03 11-12 and a suitable socket wrench or combination spanner. Tightening torque min. 20 Nm. Remove the piston stop.

  • Page 32: Assembling The Oil Pump And Screen

    Repair instructions 7.12 Assembling the oil pump and screen 7.14 Assembling the intake system Fit the chain guide plate with tightening torque Fit the intake manifold (A) and the partition walls 1–1.5 Nm. (B and C) on the cylinder using tool 502 50 87-01 (see figure 21).

  • Page 33: Carburettor

    Repair instructions 7.15 Carburettor WARNING! The fuel used in the chainsaw has the following hazardous properties: 1. The fluid and its fumes are poisonous. 2. Can cause skin irritation. 3. Is highly inflammable. Description The drawings accompanying this description do not correspond with the carburettor on the chainsaw.
  • Page 34 Repair instructions Function The carburettor operates differently in the following modes: • Cold start mode • Idling mode • Part throttle mode • Full throttle mode In the cold start mode (see figure) the choke valve (H) is fully closed. This increases the vacuum in the carburettor so that fuel is sucked more easily from all the diffuser jets (D, E and F).
  • Page 35 Repair instructions Dismantling the carburettor 1. Dismantle the cylinder cover and the air filter. 2. Disassemble the handle holder (see figure 29). Fig 29 3. Push the throttle actuator rod out of the han- dle part. Unhook it from the carburettor (see figure 30).
  • Page 36 Repair instructions 6. Disassemble the pump cover (G) over the measuring chamber cover (R) and carefully remove the control diaphragm (H) with gasket (J). 7. Unscrew the screw (K) and remove the needle valve (L) with lever (M), shaft (N) and spring (P).
  • Page 37 Repair instructions 5. That the tips of the high (V) and low jet screws Cleaning and inspection (W) are not damaged (see figure 34). Clean all units in clean petrol. 6. That the intake manifold (R2) is undamaged Use compressed air to dry the petrol on the com- (see figure 33).
  • Page 38 Repair instructions Assembly Maintain a high level of cleanliness when assem- bling the carburettor. The slightest contamination can result in running problems. 1. If the throttle and choke valves, together with levers and springs were removed, they should be refitted. The spring is tensioned 1-2 turns. Lubricate the shaft bearings with light oil.
  • Page 39 Repair instructions Pressure testing the carburettor Pressure testing should be carried out with the car- burettor fully assembled. Testing should always be carried out after the carburettor has been repaired, but it can also be carried out as trouble shooting before dismantling the carburettor.
  • Page 40 Repair instructions Assemble on the saw 1. Press the carburettor down towards the parti- tion wall. Make sure that it gets into the correct position. 2. Fit the filter holder by hooking the choke con- trol into the choke lever (A). 3.
  • Page 41 Repair instructions Carburettor adjustment Conditions during adjustment • The air filter should be clean and the cylinder cover fitted when adjustments are made. Ad- justing the carburettor with a dirty air filter will give a too lean fuel mixture the next time the air filter is cleaned.

  • Page 42: Tank Unit

    Repair instructions 7.16 Tank unit WARNING! The fuel used in the chain saw has the following hazardous properties: The fluid and its vapour are poisonous. Can cause skin irritation. Is highly inflammable. Dismantling 1. Drain the fuel from the tank. 2.

  • Page 43: Vibration Damping System

    Repair instructions Assembly 1. If the throttle lock has been removed, this must be assembled before the tank unit and engine unit are assembled. 2. Lift the engine unit above the tank unit and insert the fuel hose (in J), return hose (in H) in the bottom of the carburettor compartment (see figure 48).

  • Page 44: Replacing The Fuel Filter

    Repair instructions 7.19 Replacing the fuel filter NOTE! Do not use knurled pliers to disconnect or reconnect the fuel hose. This could dam- age the hose and lead to leakage or frac- ture. First remove the old fuel filter from the tank unit using special tool 502 50 83-01.

  • Page 45: Piston And Cylinder - Removal

    Repair instructions 7.22 Piston and cylinder – removal Remove: • cylinder cover • carburettor (see “Carburettor – removal”) • silencer • spark plug • fuel unit Undo the four cylinder bolts from the underside and lift the cylinder off carefully (see figure 52). Fig 53 Cover the opening in the crankcase (see figure 54).
  • Page 46 Repair instructions Check the following: • The surface coating of the cylinder is not worn through, especially in the upper part of the cylinder. • The cylinder is free from score marks and areas of wear. • The piston is free from score marks. Small scratches can be polished out with fine emery paper.

  • Page 47: Piston And Cylinder - Refitting

    Repair instructions Faults and causes Score marks on the piston (A) 1. Incorrect carburettor setting. Too high over- speed. 2. Too low octane fuel. 3. Too low or incorrect oil in the fuel. Carbon build-up (B) 1. Incorrect carburettor setting. Too low over- speed.
  • Page 48 Repair instructions Inlet manifold The intake system has two intakes. 1. The lower intake leads the fuel and air mixture from the carburettor to the cylinder. 2. The upper intake leads air to the cylinder. Assembling the intake system Mount the intake manifold (A) and the partition walls (B and C) on the cylinder using tools 502 50 87-01 (see figure 62).

  • Page 49: Cylinder - Pressure Testing

    Repair instructions 7.24 Cylinder – pressure testing Remove: • cylinder cover • carburettor • spark plug Mount cover plate 504 63 93-01 (see figure 63). Fig 63 Loosen the screws on the muffler and press the rubber sheet 502 54 11-02 between the muffler and cylinder.

  • Page 50: Crankshaft Complete - Dismantling

    Repair instructions 7.25 Crankshaft complete - dismantling Remove the following: • chain and bar • clutch cover • cylinder cover • starter assembly* • centrifugal clutch* • carburettor* • silencer* • handle system • hand guard • piston and cylinder* Fig 66 * See special instructions.

  • Page 51: Crankshaft Complete - Reassembly

    Repair instructions 7.27 Crankshaft complete – reassembly Fit the crankshaft complete in the crankcase. Refit the following parts: • piston and cylinder* • handle system • hand guard • silencer* • carburettor* • centrifugal clutch* • starter assembly* • cylinder cover •...

  • Page 52: Replacing The Bar Bolt

    Repair instructions 7.29 Replacing the bar bolt Replacing the front bar guide. Drain the oil tank. Knock through the old guide bar bolt so that it falls into the oil tank. Remove the bolt from the oil tank. Secure steel wire to the outer part of the bar bolt (A), thread the steel wire through the oil tank and Fig 70 out through the bolt hole in the crankcase (see...

  • Page 53: Troubleshooting

    Troubleshooting 8 Troubleshooting Contents Troubleshooting ......................54 Troubleshooting methods ....................55 English –...
  • Page 54 Troubleshooting 8.1 Troubleshooting The various faults that can affect a chainsaw are divided into four groups. In each group the likely symptoms are given on the left and possible causes are listed on the right. The most likely faults are given first, and so on.
  • Page 55 Troubleshooting High rpm Acceleration och retardation Will not run at Adjust H screw Does not Adjust L screw accelerate Adjust H screw full throttle Blocked air filter Blocked air filter Blocked fuel tank vent Blocked fuel tank vent Blocked fuel filter Blocked fuel filter Fuel line blocked Fuel line blocked...
  • Page 56 115 55 08-26 2013W07...
