Installation; Unpacking - Telecor TMS-MA Installation Manual

Once you have unpacked and inspected your TMS-MA, your next step is to install the unit in a
standard 19" equipment rack and then connect the power, audio cable harness, and optional
(provided by customer) antenna.
B.1 Unpacking
The following equipment is included with your TMS-MA:
• Telecor Media Source Model A (TMS-MA)
• Cable harness for connecting TMS-MA to T2/XL (CHAP-TMS-MA)
• 2A DC 5V Power Adapter
When you receive your TMS-MA you should unpack it carefully to verify that you have received
all the parts. If you are missing any parts notify Telecor immediately. Also inspect for any damage
which could have occurred during shipping. If you discover any damaged items, contact the
shipping company immediately.
1
If the TMS-MA is ordered with a rack, the cable harness will be pre-installed in the rack.
TMS-MA Telecor Media Source Model A Installation Manual
