Summary of Contents for Hisense HUI66360XCUS

  • Page 1 User manual Dishwasher HUI66360XCUS...

  • Page 2: Table Of Contents

    Contents Your dishwasher ........................Important safety instructions ....................General ............................Child safety ..........................Installation ..........................Overflow guard function ......................Winter storage/transport ......................Packing material ........................Disposal ............................ Symbols ............................ Before washing for the first time ................... Water hardness ......................... Basic settings ........................... Fill up with rinse aid ........................
  • Page 3 Remove blockages ........................Troubleshooting ........................Installation instructions ......................Important safety instructions ....................Tools ............................Before you start ........................1. Placing the dishwasher ......................2. Fit the protective film ......................3. Prepare water supply, drainage and electrical connections ..........4. Adjust the height and slide the dishwasher into place ............5.

  • Page 4: Your Dishwasher

    Your dishwasher Install the dishwasher; see the chapter Installation instructions. Then open the door and press Power. The first time the dishwasher is switched on, it is important that you choose the right settings to ensure good dishwashing results. See the chapter Before washing for the first time. On/Off Program Option...

  • Page 5: Important Safety Instructions

    Important safety instructions SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE WARNING! When using your dishwasher, follow basic precautions, including the following: Read all instructions before using the dishwasher. Use the dishwasher only for its intended purpose. Use only detergents or rinse agents recommended for use in a dishwasher and keep them out of the reach of children.

  • Page 6: Installation

    WARNING! Dishwasher detergents and rinse aids are corrosive, so always keep them out of reach of children. Installation See the chapter Installation instructions. Overflow guard function The overflow guard starts pumping out the machine and turns off the water supply if the water level in the dishwasher exceeds the normal level.

  • Page 7: Before Washing For The First Time

    Before washing for the first time Water hardness In order to achieve good dishwashing results, the dishwasher needs soft water (water with low mineral content). Hard water leaves a white coating on dishes and the dishwasher. Checking water hardness Contact the local water utility to check the water hardness in your area. This is important to determine how much detergent and rinse aid to use.

  • Page 8: Greener Dishwashing

    Greener dishwashing Save energy and water When using a dishwasher in a residential setting, less energy and water are generally used compared to washing the dishes by hand. Do not rinse under running water Do not rinse the dishes under running water as this will lead to increased energy and water consumption. Simply scrape off large food particles before loading the dishwasher.

  • Page 9: Loading The Dishwasher

    Loading the dishwasher Fragile dishes Some cookware is not dishwasher safe. This can be for several reasons. Some materials cannot withstand high temperatures, others can be damaged by dishwasher detergent. Use caution with, for example, handmade items, China, crystal/glassware, silver, copper, tin, aluminum, wood, and plastic.

  • Page 10: Upper Basket

    Upper basket Place glasses, cups, bowls, side plates, and saucers in the upper basket. Place all soiled surfaces face down. Place wine glasses on the wine glass shelf. Place knives in the knife stand on the right. 3 positions Knife stand Raising and lowering the upper basket 1.

  • Page 11: Lower Basket

    Adjustable plate supports The adjustable plate supports can be folded down to make it easier to load pots, bowls and glasses. Lower basket Place plates, side plates, serving dishes, pots and cutlery (in the cutlery basket) in the lower basket. Adjustable plate supports The adjustable plate supports can be folded down to make it easier to load pots and bowls.

  • Page 12: Typical Load

    Flexible cutlery basket The cutlery basket is flexible and can be separated into two parts, which can then be attached to the side of the lower basket. Typical load Recommended for daily, regular, or typical use. Upper basket The best drying results NOTE! Ensure the upper basket is set to its lowest position.

  • Page 13: Using The Dishwasher

    Using the dishwasher Add detergent Follow the instructions on the detergent packaging. Too much detergent can result in less effective dishwashing and lead to greater environmental impact. Detergent compartment The detergent compartment must be dry when adding detergent. If powder or liquid dishwasher detergent is Prewash detergent Main wash detergent used, add a small amount of the detergent to...

  • Page 14: On/Off

    On/Off Program Option Start/Stop Display Special program NOTE! The control panel only reacts to use when the door is open. On/Off Open the door and press Power. Also turn on the water supply valve if it is turned off. Select program Select a program to suit the type of dishes and how dirty they are.

  • Page 15: Select Option

    Quiet A quieter dishwashing program, suitable for running at night. The program time is extended. Quick A quick program for dishes that have just been used and have no dried leftovers on them. Self Clean Self-cleaning program for the dishwasher tub, spray arms, and spray pipes. This program should be run (with no dishes in the machine) using regular dishwasher detergent or citric acid.

  • Page 16: Start/Stop

    WARNING! The dishwasher door must not be blocked or closed when opened automatically. Doing so may damage the door lock mechanism. Wait at least 5 minutes before closing the door. Start/Stop Press Start. The display will start counting down, indicating that the dishwasher is ready to start. Close the door properly within four seconds, otherwise the dishwasher will not start.

  • Page 17: Once The Program Has Finished

    Once the program has finished The end of the program is indicated by one short signal from the buzzer. The chapter Settings describes how to change this function. Moreover, the end of the program is indicated by the status light turning off. Once the dishwasher door is opened and the program has finished, "End"...

  • Page 19: Settings

    Settings 1. Open the door and press Power. 2. To open the dishwasher's settings menu, press and hold Auto and Delay until SEt is shown on the display. 3. Press Boost to step through the settings menu. 4. Press Auto to step through the alternatives. 5.
  • Page 20 Settings Alternatives (The menu closes automatically after three seconds.)

  • Page 21: Care And Maintenance Instructions

    Care and maintenance instructions Fill up with rinse aid When the rinse aid needs filling up, the above symbol lights on the display. Lift up to open Press to close 1. Open the rinse aid compartment lid. 2. Carefully fill up with rinse aid to the level marked MAX. 3.

  • Page 22: Cleaning The Spray Arms

    3. Refit the fine filter and turn the lock ring clockwise to its stop position. Check that the edges seal properly. Remember to refit the coarse filter! NOTE! Dishwashing results may be affected if the coarse and fine filters are incorrectly fitted. The dishwasher must not be used without the filters in place! Check that the yellow drain pump stop (on the right in the...

  • Page 23: Clean The Outside Of The Dishwasher

    Lower spray arm Pull the lower spray arm straight up to release it. Clean the outside of the dishwasher Door and door seal Open the door. Clean the sides of the door and the door seal regularly with a slightly damp cloth. Clean the door seal at the lower front edge of the dishwasher with a cleaning brush.
  • Page 24 7. Plug the machine in again. Drain pump stop NOTE! Do not forget to reinstall the drain pump stop.

  • Page 25: Troubleshooting

    Troubleshooting Error messages Action Overfilling water Unblocking the drain pump. See the chapter Care and maintenance instructions. If the problem persists, contact your nearest Customer Care Center. Water outlet fault See "Water remains in the dishwasher above the filters" under "Problem"...
  • Page 26 Problem Possible causes Action Press and hold Door Open until the display starts counting down. Wait until the countdown ends (60 seconds). Close the door. Check that the door lock clicks into place and locks. The dishwasher does not start. Start has not been pressed.
  • Page 27 Problem Possible causes Action Detergent is too old. Detergent Avoid large packages. is a perishable product. Dishes loaded incorrectly. Do not cover porcelain with large bowls or the like. Avoid placing very tall glasses in the corners of the baskets. See the chapter Loading the dishwash- Glasses and cups have toppled Load the dishes securely.
  • Page 28 Problem Possible causes Action Spots left after washing. Lipstick and tea can be difficult Use a detergent with a bleach- to wash off. ing agent. Detergent residue in the deter- The detergent compartment The detergent compartment gent compartment after dish- was damp when adding deter- must be dry when adding deter- washing.
  • Page 29 Problem Possible causes Action The dishwasher is connected to Cleaning the garbage disposer a garbage disposer. connected to the dishwasher can eliminate odors. Follow the disposer manufacturer's clean- ing instructions. Grease deposits in the dish- Low temperature programs Select a program with a high washer.

  • Page 30: Installation Instructions

    Installation instructions Inches (mm) Nominal dimensions. Actual measurements may vary. Important safety instructions Connections to electricity, water, and drainage must be performed by a qualified professional. Always follow applicable regulations for water, drainage, and electricity. Take care during installation! Wear protective gloves! There must always be two people! Place a drip tray on the floor beneath the dishwasher to prevent damage from any water leaks.

  • Page 31: Before You Start

    Once your new Hisense dishwasher has been delivered to you, carefully unpack the dishwasher and check for any damage. If the dishwasher has been damaged, do not install the dishwasher, and contact Hisense Customer Service listed on the warranty card.

  • Page 32: Prepare Water Supply, Drainage And Electrical Connections

    NOTE! The surface to which the protective film is fitted must be clean and dry. WARNING! Countertop might be damaged by moist if protective film is not properly installed. 3. Prepare water supply, drainage and electrical connections Slide the dishwasher near desired install location. If connect to power via plug: Pull the drain, plug cord and supply hoses through the opening as the dishwasher is slid into place.

  • Page 33: Screwing The Dishwasher Into Place

    4. Adjust the front feet by turning them clockwise to raise and counterclockwise to lower the dishwasher. 5. Verify there is an air gap of at least 0.1" (3 mm) between the underside of the countertop and the top edge of the dishwasher. 6.

  • Page 34: Electrical Connection

    6. Electrical connection Information about the electrical connection can be found on the serial number plate. This specification must match the electricity supply. Grounding instructions This appliance must be grounded. In the event of a malfunction or breakdown, grounding will reduce the risk of electric shock by providing a path of least resistance for electric current.

  • Page 35: Connection To Water Supply

    3. Connect an external supply cord with its three cable wires, and screw them into place. Also secure the supply cord into place with the strain relief. Tighten the screws to ensure the supply cord is firmly secured. 4. Replace the protective cover of the junction box. 7.

  • Page 36: Dishwasher Toe Kick

    min. 0.6" (14 Max. 37 3/8'' (950 mm) The drain hose can also be connected to a connection nipple on the sink unit's water trap. The connection nipple must have an internal diameter of at least 0.6" (14 mm). The drain hose may be extended by a maximum of 118" (3 m) (the total length of the drain hose must not exceed 177"...

  • Page 37: Completing The Installation

    Fit the toe kick 10. Completing the installation Remove all transport protection on the door and inside the dishwasher. NOTE! At the end, test the dishwasher by running the 1h program with the Boost option. Check that the dishwasher fills with water and drains. Check also that none of the connections leak.

  • Page 38: Service And Warranty

    Service and warranty Read the chapter Troubleshooting before contacting the Customer Care Center. If you have encountered a problem that you cannot resolve, please contact your nearest Customer Care Center for professional help. When making contact, provide the details on the serial number plate. Include the article number (1) and the serial number (2).

  • Page 39: Technical Information

    Technical information Technical data Height: 33.70 - 35.67'' (856 - 906 mm) Width: 23.8'' (605 mm) Depth: 22.67'' (576 mm) Weight: 77 lb (35 kg) Water pressure: 4.2-140 psi (0.03-1.0 MPa) Electrical connection: See serial number plate Rated power: See serial number plate 1) Weight can vary due to different specifications.
  • Page 40 877915-a3 We reserve the right to make changes.
