PLASMA DISPLAY SYSTEM
PRO-110FD
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Model
Type
PRO-110FD
KUCXC
This service manual should be used together with the following manual(s).
Model No.
PDP-5010FD
CONTENTS
1. CONTRAST OF MISCELLANEOUS PARTS ...................................................................... 2
1.1 CONTRAST TABLE ....................................................................................................... 2
1.2 CONTRAST OF PCB ASSEMBLIES........................................................................... 11
2. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM ............................................................ 14
2.1 OVERALL CONNECTION DIAGRAM (1/2) ................................................................. 14
2.2 OVERALL CONNECTION DIAGRAM (2/2) ................................................................. 16
2.3 HNM BLOCK DIAGRAM.............................................................................................. 18
2.4 CONNECTOR PIN DESCRIPTION ............................................................................. 19
2.5 HN MODULE ASSY (1/6) [8620 BLOCK] .................................................................... 20
2.6 HN MODULE ASSY (2/6) [8620_DDR BLOCK] .......................................................... 24
2.7 HN MODULE ASSY (3/6) [ETHERNET BLOCK]......................................................... 26
2.8 HN MODULE ASSY (4/6) [HNM_USB BLOCK] .......................................................... 28
2.9 HN MODULE ASSY (5/6) [HNM_IO BLOCK] .............................................................. 30
2.10 HN MODULE ASSY (6/6) [HNM_POWER BLOCK] .................................................. 32
3. PCB CONNECTION DIAGRAM ........................................................................................ 34
3.1 HN MODULE ASSY..................................................................................................... 34
4. DIAGNOSIS ...................................................................................................................... 36
4.1 DIAGNOSIS FLOWCHART ......................................................................................... 36
5. SERVICE MODE............................................................................................................... 39
5.1 DETAILS OF FACTORY MENU ................................................................................... 39
6. DISASSEMBLY ................................................................................................................. 40
6.1 DISASSEMBLY AND REASSEMBLY PRECAUTIONS FOR SPEAKER SYSTEM ..... 40
PIONEER CORPORATION
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2007
Power Requirement
AC 120 V
Order No.
ARP3455
EXPLODED VIEWS, BLOCK DIAGRAM, ADJUSTMENT, etc
4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
ARP3469
Remarks
Remarks
T-ZZS-001 AUG. 2007 Printed in Japan
ORDER NO.
