Page 1
TABLE OF CONTENTS Adjusting and operating features such as door locks, Before driving mirrors, and steering column. When driving Driving, stopping and safe-driving information. Interior Air conditioning and audio systems, as well as other in- features terior features for a comfortable driving experience. Maintenance Cleaning and protecting your vehicle, performing do-it- and care...
TABLE OF CONTENTS Index 1-6. Theft deterrent system Before driving Engine immobilizer system ... 79 Theft prevention labels (U.S.A.)....... 81 1-1. Key information Keys ........30 1-7. Safety information Correct driving posture ..82 1-2. Opening, closing and SRS airbags ......84 locking the doors Front passenger occupant Wireless remote control ..
Page 3
2-3. Operating the lights and Interior features wipers Headlight switch....148 Windshield wipers and 3-1. Using the air conditioning washer ......151 system and defogger Rear window wiper and Air conditioning system ..236 washer ......153 Rear window defogger ..243 2-4.
Page 4
TABLE OF CONTENTS Index 3-4. Using the hands-free phone Luggage compartment features ......376 system (for cellular phone) Garage door opener ... 379 Hands-free phone system (for cellular phone) ... 313 Compass ......387 Using the hands-free phone system Maintenance and care (for cellular phone) ...
Page 5
When trouble arises Vehicle specifications 5-1. Essential information 6-1. Specifications Emergency flashers .... 466 Maintenance data (fuel, oil level, etc.) ... 512 If your vehicle needs to be towed ......467 Fuel information....523 If you think something Tire information ....526 is wrong ......
Page 6
Pictorial index Exterior Outside rear view mirror illumination lights P. 148 Windshield wipers P. 151 Hood P. 410 Antenna P. 293 Outside rear view mirrors P. 71 Headlights and daytime running lights P. 148, 150 Front turn signal/parking and front side marker lights P.
Page 7
Stop/tail and rear side marker lights P. 148 Fuel filler door P. 76 Access doors P. 38 Side doors P. 35 Tires ●Rotation P. 425 ●Replacement P. 484 ●Inflation pressure P. 433 Rear turn signal lights P. 136 ●Information P.
Page 8
Pictorial index Exterior Glass hatch P. 45 Rear window wiper P. 153 Rear window defogger P. 243 Back door P. 40 Rear view monitor system camera P. 163 License plate lights P. 148 : If equipped...
Page 9
Pictorial index Interior SRS driver airbag P. 84 Seat belts P. 60 Horn P. 139 Head restraints P. 57 Auxiliary box P. 360 Bottle holders P. 359 SRS front passenger airbag P. 84 Rear seats P. 51 Floor mats P. 373 Cup holders P.
Page 10
Pictorial index Interior Sun visors P. 361 Interior lights P. 351 Vanity mirrors P. 362 SRS curtain shield airbags P. 84 Anti-glare inside rear view mirror P. 67 Rear view monitor system P. 163 Microphone P. 300, 319 Garage door opener P.
Page 11
Vehicles without Crawl Control Personal lights P. 352 Vehicles with Crawl Control A-TRAC switch P. 182 RR DIFF LOCK switch P. 187 Personal lights P. 352 Crawl Control switch P. 192 : If equipped...
Page 12
Pictorial index Interior Inside door lock button P. 36 Door lock switch P. 35 Window lock switch P. 74 Power window switches P. 74...
Page 13
Automatic transmission Front-wheel drive control Shift lever P. 132 Cup holders lever P. 179 P. 355 Parking brake lever P. 137 Shift lock override Cup holders P. 355 button P. 498 Manual transmission Four-wheel drive control Shift lever P. 134 ...
Page 14
Pictorial index Instrument panel Headlight switch P. 148 Turn signal lever P. 136 Gauges and meters P. 140 Windshield wipers and washer switch P. 151 Rear window wiper and washer switch P. 153 Accessory meter P. 146 Glove box P.
Page 15
Clock P. 363 Emergency flasher switch P. 466 Audio system P. 244 Security indicator P. 79 Air conditioning system P. 236 Rear window defogger switch P. 243 : If equipped...
Page 16
Pictorial index Instrument panel VSC OFF switch P. 185, 197, 198 RR DIFF LOCK switch P. 187 A-TRAC switch P. 182 Power outlet P. 365 AUX port/USB port P. 270, 278, 289 Intuitive parking assist switch P. 159 ...
Page 17
Engine (ignition) switch P. 129 : If equipped...
Page 18
Pictorial index Instrument panel Telephone switch P. 318 Audio remote control switches P. 290 Talk switch P. 318 Cruise control switch P. 154...
Page 19
Instrument panel light control dial P. 141 Tilt steering lock release lever P. 66 RSCA OFF switch P. 95 CLUTCH START CANCEL switch P. 191 Outside rear view mirror switches P. 71 : If equipped...
Page 20
Pictorial index Luggage compartment Child restraint anchor brackets P. 106 Tie-down hooks P. 376...
Page 21
Shopping bag hooks P. 378 Cargo net hooks P. 377 Jack P. 484 Tools P. 484 Shopping bag hooks P. 378 Cargo net hooks P. 377 Luggage storage P. 375 Power outlet P. 366 : If equipped ...
Page 22
Accessories, spare parts and modification of your Toyota A wide variety of non-genuine spare parts and accessories for Toyota vehicles are currently available in the market. You should know that Toyota does not warrant these products and is not responsible for their performance, repair, or replacement, or for any damage they may cause to, or adverse effect they may have on, your Toyota vehicle.
Page 23
● Anti-lock brake system ● SRS airbag system ● Seat belt pretensioner system Be sure to check with your Toyota dealer for precautionary measures or spe- cial instructions regarding installation of a mobile two-way radio system. Vehicle data recordings Your Toyota is equipped with several sophisticated computers that will record certain data, such as: •...
Page 24
Event data recorder This vehicle is equipped with an event data recorder (EDR). The main pur- pose of an EDR is to record, in certain crash or near crash-like situations, such as an air bag deployment or hitting a road obstacle, data that will assist in understanding how a vehicle’s systems performed.
Page 25
● Disclosure of the EDR data Toyota will not disclose the data recorded in an EDR to a third party except when: • An agreement from the vehicle’s owner (or the lessee for a leased vehicle) is obtained • In response to an official request by the police, a court of law or a govern- ment agency •...
Page 26
CAUTION ■ General precautions while driving Driving under the influence: Never drive your vehicle when under the influ- ence of alcohol or drugs that have impaired your ability to operate your vehi- cle. Alcohol and certain drugs delay reaction time, impair judgment and reduce coordination, which could lead to an accident that could result in death or serious injury.
Page 27
This is a warning against anything which may cause damage to the vehicle or its equipment if the warning is ignored. You are informed about what you must or must not do in order to avoid or reduce the risk of damage to your Toyota and its equipment.
Before driving 1-1. Key information 1-5. Refueling Keys ........30 Opening the fuel tank cap ........76 1-2. Opening, closing and 1-6. Theft deterrent system locking the doors Engine immobilizer Wireless remote control ..32 system ......79 Side doors......35 Theft prevention labels Access doors .....
Keep the plate in a safe place such as your wallet, not in the vehicle. In the event that a key is lost, a new key can be made by your Toyota dealer using the key number plate. (P. 499) ■...
Page 31
1-1. Key information NOTICE ■ To prevent key damage ● Do not subject the keys to strong shocks, expose them to high tempera- tures by placing them in direct sunlight, or get them wet. ● Do not expose the keys to electromagnetic materials or attach any mate- rial that blocks electromagnetic waves to the key surface.
1-2. Opening, closing and locking the doors Wireless remote control The wireless remote control can be used to lock and unlock the vehi- cle from outside the vehicle. Locks all doors Unlocks all doors Pressing the button unlocks the driver’s door. Pressing the button again within 3 seconds unlocks the other doors.
Page 33
When a wireless key (that emits radio waves) is being used nearby ● When the wireless key has been left near an electrical appliance such as a personal computer ■ Customization that can be configured at Toyota dealer Settings (e.g. wireless remote control system) can be changed. (Customizable features P. 537)
Page 34
1-2. Opening, closing and locking the doors ■ Certification for wireless remote control For vehicles sold in the U.S.A. FCC ID: HYQ12BBT FCC ID: HYQ13BBL NOTE: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
1-2. Opening, closing and locking the doors Side doors The vehicle can be locked/unlocked using the wireless remote con- trol, key or door lock switch. ■ Wireless remote control (if equipped) P. 32 ■ Locks all doors Unlocks all doors Turning the key a single time in the driver’s door unlocks the driver’s door,...
Page 36
1-2. Opening, closing and locking the doors Passenger’s door lock switch Locks all doors Unlocks all doors ■ Inside door lock button Locks the door Unlocks the door Pulling the inside handle can open the front door even if the inside door lock button is in the lock position.
Page 37
A buzzer sounds if the driver’s door is opened, while the engine switch is in the ACC or LOCK position to remind you to remove the key. ■ Customization that can be configured at Toyota dealer Settings (e.g. unlocking function using a key) can be changed. (Customizable features P. 537) CAUTION ■...
1-2. Opening, closing and locking the doors Access doors The access door (rear door) can be opened using the inside handle. Open the front door widely Pull (from the outside) or push (from the inside) the inside handle of the access door.
Page 39
1-2. Opening, closing and locking the doors NOTICE ■ When opening or closing the front door and access door The front door and access door could be damaged if they hit each other when being opened or closed.
1-2. Opening, closing and locking the doors Back door The back door can be locked/unlocked using a key, wireless remote control or door lock switch. ■ Wireless remote control (if equipped) P. 32 ■ Unlocks the back door Locks the back door Opens the back door When you turn the key clock- wise and hold it for about 1...
Page 41
1-2. Opening, closing and locking the doors ■ Back door fixing function The back door can be held in the following positions: Half open position Open the back door to the half open position. It cannot be held in this posi- tion when being closed.
Page 42
1-2. Opening, closing and locking the doors Rear step bumper For rear end protection and eas- ier step-up loading. To get on the rear step bumper, use the shaded area in the illus- tration. CAUTION ■ Caution while driving ● Keep the back door closed while driving.
Page 43
1-2. Opening, closing and locking the doors CAUTION ■ Operating the back door Observe the following precautions. Failure to do so may cause parts of the body to be caught, resulting in death or serious injury. ● When opening or closing the back door, thoroughly check to make sure the surrounding area is safe.
Page 44
If a bicycle carrier or similar heavy object is attached to the back door, it may suddenly shut again after being opened, causing someone’s hands, head or neck to be caught and injured. When installing an accessory part to the back door, using a genuine Toyota part is recommended. NOTICE ■...
1-2. Opening, closing and locking the doors Glass hatch The glass hatch can be opened using the key. Turn the key clockwise and hold it for about 1 second. Raise ■ Opening the glass hatch ● The glass hatch opens slightly, after the back door is locked. ●...
Page 46
1-2. Opening, closing and locking the doors CAUTION ■ Caution while driving ● Keep the glass hatch closed while driving. If the glass hatch is left open, it may hit near-by objects while driving or luggage may be unexpectedly thrown out, causing an accident. In addition, exhaust gases may enter the vehicle, causing death or a seri- ous health hazard.
Page 47
Doing so may cause hands to be caught or the glass hatch damper stay to break, causing an accident. ● Do not attach any accessories other than genuine Toyota parts to the glass hatch. Such additional weight on the glass hatch may cause the glass hatch to suddenly shut again after it is opened.
Page 48
Do not touch the damper stay rod with gloves or other fabric items. ● Do not attach any accessories other Damper stay rod than genuine Toyota parts to the glass hatch. ● Do not place your hand on the damper stay or apply lateral forces to it.
1-3. Adjustable components (seats, mirrors, steering wheel) Front seats Seat position adjustment lever Seat cushion angle adjust- ment knob (driver’s side only) Seat height adjustment lever (driver’s side only) Seatback angle adjustment lever Active head restraints When the occupant’s lower back presses against the seatback during a rear-end collision, the head restraint moves slightly for-...
Page 50
1-3. Adjustable components (seats, mirrors, steering wheel) ■ Active head restraints Even small forces applied to the seatback may cause the head restraint to move. Pushing up a locked head restraint forcibly may show the head restraint inner structure. These do not indicate problems. During rear-end collision...
1-3. Adjustable components (seats, mirrors, steering wheel) Rear seats The seatbacks of the rear seats can be folded down. Stow the seat belt buckles and remove the head restraints. Swing the bottom cushion up by pulling the lock release strap.
Page 52
1-3. Adjustable components (seats, mirrors, steering wheel) Push the lock release button and fold down the seatback. Removing rear seat bottom cushions When loading large luggage items, the cushion can be removed. Do not remove the cushion for normal usage. Loosen the bolts with a wrench at first and turn the dials by hand to remove them.
Page 53
1-3. Adjustable components (seats, mirrors, steering wheel) Separate the bottom cushion from the hinge. Fold the hinge as shown in the illustration.
Page 54
1-3. Adjustable components (seats, mirrors, steering wheel) ■ If you cannot raise the seatback Release the seat belt lock by: Pushing on the lower front edge of the seatback to slacken the seat belt. Letting the seat belt retract a little. ■...
Page 55
Have the hexagon head bolts tightened with a torque wrench to 12.5 ft·lbf (17 N·m, 1.7 kgf·m), or have them tightened by your Toyota dealer. Failure to do so may cause the dials to be loosened and the bottom cush-...
Page 56
1-3. Adjustable components (seats, mirrors, steering wheel) NOTICE ■ Before folding down or removing the seats ● The seat belts buckles must be stowed. ● The head restraints must be removed before you fold down the seatback. ■ After returning the seatback and reinstalling the bottom cushion Return the seat belt buckles to their cor- rect position.
1-3. Adjustable components (seats, mirrors, steering wheel) Head restraints Head restraints are provided for all seats. ■ Adjusting the head restraints Front seats Vertical adjustment Pull the head restraints up. Down Push the head restraint down while pushing the lock release Lock release button button.
Page 58
1-3. Adjustable components (seats, mirrors, steering wheel) ■ Removing the head restraints Front seats Pull the head restraint up while pushing the lock release button. Rear seats Pull the head restraint up while pushing the lock release button. ■ Installing the head restraints Front seats Align the head restraint with the installa- tion holes and push it down to the lock...
Page 59
1-3. Adjustable components (seats, mirrors, steering wheel) ■ When installed the rear outboard head restraints to opposite direction Push a flathead screwdriver into the slot. The slot is located on the right side of the right head restraint anchor. While pressing in the screwdriver, pull up the head restraint. ■...
1-3. Adjustable components (seats, mirrors, steering wheel) Seat belts Make sure that all occupants are wearing their seat belts before driv- ing the vehicle. ■ Correct use of the seat belts ● Extend the shoulder belt so that it comes fully over the shoulder, does come into contact with the...
Page 61
1-3. Adjustable components (seats, mirrors, steering wheel) Releasing the belt Press the release button. Release button ■ Adjusting the height of the belt (front seats) Move the height adjuster up as needed until you hear a click. Down Push the lock release button and slide the height adjuster down.
Page 62
1-3. Adjustable components (seats, mirrors, steering wheel) ■ Emergency locking retractor (ELR) The retractor will lock the belt during a sudden stop or on impact. It may also lock if you lean forward too quickly. A slow, easy motion will allow the belt to extend so that you can move around fully.
Page 63
Each seat belt should be used by one person only. Do not use a seat belt for more than one person at once, including children. ● Toyota recommends that children be seated in the rear seat and always use a seat belt and/or an appropriate child restraint system. ●...
Page 64
● Ensure that the belt and tab are locked and the belt is not twisted. If the seat belt does not function correctly, immediately contact your Toyota dealer. ● Replace the seat assembly, including the belts, if your vehicle has been...
Page 65
● Do not attempt to install, remove, modify, disassemble or dispose of the seat belts. Have any necessary repairs carried out by your Toyota dealer. Inappropriate handling of the pretensioner may prevent it from operating properly resulting in death or serious injury.
1-3. Adjustable components (seats, mirrors, steering wheel) Steering wheel The steering wheel can be adjusted to a comfortable position. Hold the steering wheel and pull and hold the lever. Adjust to the ideal position by moving the steering wheel vertically. After adjustment, release the lever to secure the steering wheel.
1-3. Adjustable components (seats, mirrors, steering wheel) Anti-glare inside rear view mirror In automatic mode, sensors are used to detect the headlights of vehicles behind and automatically reduces the reflected light. Type A Turns automatic mode on/off The indicator comes on when automatic mode is turned on.
Page 68
1-3. Adjustable components (seats, mirrors, steering wheel) Type B Turns automatic mode on Turns automatic mode off The indicator comes on when automatic mode is turned on. The mirror will revert to the automatic mode each time the engine switch is turned on. Adjusting the height of rear view mirror Adjust the height of the rear view mirror by moving it up and down.
Page 69
1-3. Adjustable components (seats, mirrors, steering wheel) ■ To prevent sensor error (vehicles with auto anti-glare inside rear view mirror) To ensure that the sensors operate prop- erly, do not touch or cover them. ■ If a sun visor interferes with the mirror Hold and rotate the mirror to adjust the support.
Page 70
1-3. Adjustable components (seats, mirrors, steering wheel) NOTICE ■ When adjusting the support Do not push the mirror horizontally from the side. The mirror could fall off.
1-3. Adjustable components (seats, mirrors, steering wheel) Outside rear view mirrors Mirror angle can be adjusted. Power-adjustable type Select a mirror to adjust. (L: left or R: right) Adjust the mirror up, down, in or out using the switch. Manually adjustable type Adjust the mirror up, down, in or out by pushing the mirror surface.
Page 72
1-3. Adjustable components (seats, mirrors, steering wheel) Folding back the mirrors Push backward to fold the mir- rors. ■ Mirror operating conditions (vehicles with power-adjustable type) The engine switch is in the ACC or ON position. CAUTION ■ When driving the vehicle Observe the following precautions while driving.
Page 73
1-3. Adjustable components (seats, mirrors, steering wheel) NOTICE ■ If ice should jam the mirror Do not operate the control or scrape the mirror face. Use a spray de-icer to free the mirror.
1-4. Opening and closing the windows Power windows The power windows can be opened/closed using the following switches. Driver’s power window switches Closing Opening One-touch opening (driver’s window only) : To stop the window partway, operate the switch in the oppo- site direction.
Page 75
1-4. Opening and closing the windows ■ The power windows can be operated when The engine switch is in the ON position. ■ Operating the power windows after turning the engine switch off The power windows can be operated for approximately 45 seconds even after the engine switch is turned off.
1-5. Refueling Opening the fuel tank cap Perform the following steps to open the fuel tank cap. ■ Before refueling the vehicle Turn the engine switch off and ensure that all the doors, win- dows and glass hatch are closed. ■...
Page 77
1-5. Refueling Closing the fuel tank cap When installing the fuel tank cap, turn it until you hear a click. The cap will turn slightly to the opposite direction when released. ■ Fuel types Use unleaded gasoline. (Octane rating 87 [Research Octane Number 91] or higher) ■...
Page 78
■ When replacing the fuel tank cap Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury.
1-6. Theft deterrent system Engine immobilizer system The vehicle’s keys have built-in transponder chips that prevent the engine from starting if the key has not been previously registered in the vehicle’s on-board computer. Never leave the keys inside the vehicle when you leave the vehicle. The indicator light flashes after the key has been removed from the engine switch to indi-...
Page 80
1-6. Theft deterrent system ■ Certifications for the engine immobilizer system For vehicles sold in the U.S.A. FCC ID: MOZRI-20BTY This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interfer- ence, and (2) this device must accept any interference received, including interference that may cause undesired operation.
1-6. Theft deterrent system Theft prevention labels (U.S.A.) These labels are attached to the vehicle to reduce vehicle theft by facilitating the tracing and recovery of parts from sto- len vehicles. Do not remove under penalty of law.
1-7. Safety information Correct driving posture Drive in a good posture as follows: Sit upright and well back in the seat. (P. 49) Adjust the position of the seat forward or backward to ensure the pedals can be reached easily depressed to the extent required.
Page 83
1-7. Safety information CAUTION ■ While driving ● Do not adjust the position of the driver’s seat while driving. Doing so could cause the driver to lose control of the vehicle. ● Do not place a cushion between the driver or passenger and the seatback. A cushion may prevent correct posture from being achieved, and reduce the effectiveness of the seat belt and head restraint, increasing the risk of death or serious injury to the driver or passenger.
1-7. Safety information SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. Front airbags Driver airbag/front passenger airbag Can help protect the head and chest of the driver and front pas-...
Page 85
1-7. Safety information Airbag system components Front passenger airbag Side and curtain shield air- bag sensors Curtain shield airbags Driver airbag Side airbags RSCA OFF switch Front passenger occupant classification system (ECU Driver’s seat position sen- and sensors) Front passenger’s seat belt Driver’s seat belt buckle buckle switch switch...
Page 86
1-7. Safety information Your vehicle is equipped with ADVANCED AIRBAGS designed based on the US motor vehicle safety standards (FMVSS208). The airbag sensor assembly (ECU) controls airbag deployment based on infor- mation obtained from the sensors etc. shown in the system compo- nents diagram above.
Page 87
1-7. Safety information ■ Operating conditions (front airbags) ● The SRS front airbags will deploy in the event of an impact that exceeds the set threshold level (the level of force corresponding to an approxi- mately 12-18 mph [20-30 km/h] frontal collision with a fixed wall that does not move or deform).
Page 88
1-7. Safety information ■ Conditions under which the SRS airbags may deploy (inflate), other than a collision The SRS front airbags may also deploy if a serious impact occurs to the underside of your vehicle. Some examples are shown in the illustration. ●...
Page 89
1-7. Safety information ■ Types of collisions that may not deploy the SRS airbag (side airbags and curtain shield airbags) The SRS side airbag and curtain shield airbag system may not activate if the vehicle is subjected to a collision from the side at certain angles, or a colli- sion to the side of the vehicle body other than the passenger compartment.
Page 90
1-7. Safety information ■ When to contact your Toyota dealer In the following cases, contact your Toyota dealer as soon as possible. ● Any of the SRS airbags have been inflated. ● The front of the vehicle is damaged or...
Page 91
1-7. Safety information CAUTION ■ SRS airbag precautions Observe the following precautions regarding the airbags. Failure to do so may cause death or serious injury. ● The driver and all passengers in the vehicle must wear their seat belts properly. The SRS airbags are supplemental devices to be used with the seat belts.
Page 92
An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are...
Page 93
1-7. Safety information CAUTION ■ SRS airbag precautions ● Do not sit on the edge of the seat or lean against the dashboard. ● Do not allow a child to stand in front of the SRS front passenger airbag unit or sit on the knees of a front passenger.
Page 94
Wash off any residue as soon as possible to prevent skin irritation. ● If the areas where the SRS airbags are stored, such as the steering wheel pad and front and rear pillar garnishes, are damaged or cracked, have them replaced by your Toyota dealer.
Page 95
Modification and disposal of SRS airbag system components Do not dispose of your vehicle or perform any of the following modifications without consulting your Toyota dealer. The SRS airbags may malfunction or deploy (inflate) accidentally, causing death or serious injury.
Page 96
1-7. Safety information ■ The switch only should be used In a situation where inflation is not desired (such as during extreme off-road driving). ■ Operating conditions when the RSCA OFF indicator is on ● The curtain shield airbag and seat belt pretensioner will not activate in a vehicle rollover.
1-7. Safety information Front passenger occupant classification system Your vehicle is equipped with a front passenger occupant classifica- tion system. This system detects the conditions of the front passen- ger seat and activates or deactivates the devices for front passenger. SRS warning light Front passenger’s seat belt reminder light AIR BAG ON indicator light...
Page 98
1-7. Safety information Condition and operation in the front passenger occupant classification system ■ Adult AIR BAG ON and AIR BAG OFF indicator AIR BAG ON lights Indicator/ SRS warning light warning light Front passenger’s seat belt reminder light Flashing Front passenger airbag Side airbag on the front passenger seat Devices...
Page 99
1-7. Safety information ■ There is a malfunction in the system AIR BAG ON and AIR BAG OFF indicator AIR BAG lights Indicator/ warning light SRS warning light Front passenger’s seat belt reminder light Front passenger airbag Deactivated Side airbag on the front passenger seat Devices Curtain shield airbag in the front passenger side...
Page 100
1-7. Safety information CAUTION ■ Front passenger occupant classification system precautions Observe the following precautions regarding front passenger occupant clas- sification system. Failure to do so may cause death or serious injury. ● Wear the seat belt properly. ● Make sure the front passenger’s seat belt tab has not been left inserted into the buckle before someone sits in the front passenger seat.
Page 101
Do not kick the front passenger seat or subject it to severe impact. Other- wise, the SRS warning light may come on to indicate a malfunction of the detection system. In this case, contact your Toyota dealer immediately. ● Child restraint systems installed on the rear seat should not contact the front seatbacks.
1-7. Safety information Child restraint systems A child restraint system for a small child or baby must itself be prop- erly restrained on the seat with the lap portion of the lap/shoulder belt. The laws of all 50 states of the U.S.A. and Canada now require the use of child restraint systems.
Page 103
1-7. Safety information Forward facing — Convertible seat Booster seat ■ Selecting an appropriate child restraint system ● Use a child restraint system appropriate for the child until the child becomes large enough to properly wear the vehicle’s seat belts. ●...
Page 104
● Toyota strongly urges the use of a proper child restraint system that con- forms to the size of the child, installed on the rear seat. According to acci- dent statistics, the child is safer when properly restrained in the rear seat than in the front seat.
Page 105
1-7. Safety information CAUTION ■ Child restraint precautions ● Make sure you have complied with all installation instructions provided by the child restraint manufacturer and that the system is properly secured. If it is not secured properly, it may cause death or serious injury to the child in the event of sudden braking, sudden swerving or an accident.
1-7. Safety information Installing child restraints Follow the child restraint system manufacturer’s instructions. Firmly secure child restraints to the rear seats using the LATCH anchors or a seat belt. Attach the top tether strap when installing a child restraint. The lap/shoulder belt can be used if your child restraint system is not compatible with the LATCH (Lower Anchors and Tethers for Chil- dren) system.
Page 107
1-7. Safety information Anchor bracket (for top tether strap) Anchor brackets are provided for all rear seats.
Page 108
1-7. Safety information Installation with LATCH system Type A Widen the gap between the seat cushion and seatback slightly. Latch the hooks of the lower straps onto the LATCH anchors tighten the lower straps. If the child restraint has a top tether strap, the top tether strap should be latched...
Page 109
1-7. Safety information Type B Widen the gap between the seat cushion and seatback slightly. Latch the buckles onto the LATCH anchors. If the child restraint has a top tether strap, the top tether strap should be latched onto tether strap anchor. (P.
Page 110
1-7. Safety information Run the seat belt through the child seat and insert the plate into the buckle. Make sure that the belt is not twisted. Fully extend the shoulder belt and then allow it to retract slightly in order to activate the ALR lock mode.
Page 111
1-7. Safety information Run the seat belt through the child seat and insert the plate into the buckle. Make sure that the belt is not twisted. Fully extend the shoulder belt and then allow it to retract slightly in order to activate the ALR lock mode.
Page 112
1-7. Safety information ■ Booster seat Place the booster seat on the seat facing the front of the vehi- cle. Sit the child in the booster seat. Fit the seat belt to the booster seat according to the manufac- turer’s instructions and insert the plate into the buckle.
Page 113
1-7. Safety information Child restraint systems with a top tether strap Secure the child restraint using the LATCH anchors or seat belt, and remove the head restraint. Raise the anchor bracket, latch the hook onto the anchor bracket and tighten the top tether strap. Make sure the top tether strap is securely latched.
Page 114
1-7. Safety information ■ When the anchor bracket is not in use Lower the anchor bracket. The anchor bracket is only designed to secure the top tether strap. Do not use the anchor bracket for any other pur- pose.
Page 115
1-7. Safety information CAUTION ■ When installing a booster seat Do not fully extend the shoulder belt to prevent the belt from going to ALR lock mode. (P. 62) ALR mode causes the belt to tighten only which could cause death or seri- ous injury to the child.
Page 116
1-7. Safety information CAUTION ■ When installing a child restraint system ● Ensure that the belt and tab are securely locked and the seat belt is not twisted. ● Push and pull the child restraint system from side to side and forward to be sure it is secure.
When driving 2-1. Driving procedures Four-wheel drive system (4WD models with a Driving the vehicle.... 118 manual transmission)..176 Engine (ignition) switch ..129 Four-wheel drive system Automatic Transmission... 132 (4WD models with Manual Transmission..134 an automatic Turn signal lever ....136 transmission) ....
2-1. Driving procedures Driving the vehicle The following procedures should be observed to ensure safe driv- ing. ■ Starting the engine (P. 129) ■ Driving Automatic transmission With the brake pedal depressed, shift the shift lever to D. (P. 132) Release the parking brake.
Page 119
2-1. Driving procedures ■ Parking the vehicle Automatic transmission With the shift lever in D, depress the brake pedal. Set the parking brake. (P. 137) Shift the shift lever to P. (P. 132) When parking on a hill, if necessary, block the wheels. Turn the engine switch off to stop the engine.
Page 120
The vehicle is judged to be driving uphill or downhill ● When the accelerator pedal is released ■ Breaking in your new Toyota To extend the life of the vehicle, the following precautions are recommended to observe: ● For the first 200 miles (300 km): Avoid sudden stops.
Page 121
Your vehicle has a drum-in-disc type parking brake system. This type of brake system needs bedding-down of the brake shoes periodically or when- ever the parking brake shoes and/or drum are replaced. Have your Toyota dealer perform the bedding down operation.
Page 122
Have the vehicle inspected by your Toyota dealer immediately. ● On vehicles with an automatic transmission, do not shift the shift lever to P while the vehicle is moving.
Page 123
2-1. Driving procedures CAUTION ■ When driving the vehicle ● Use engine braking (downshift) to maintain a safe speed when driving down a steep hill. Using the brakes continuously may cause the brakes to overheat and lose effectiveness. (P. 133135) ●...
Page 124
2-1. Driving procedures CAUTION ■ When shifting the shift lever Vehicles with an automatic transmission: Be careful not to shift the shift lever with the accelerator pedal depressed. This may lead to unexpected rapid acceleration of the vehicle that may cause an accident and result in death or serious injury.
Page 125
The exhaust should be checked occasionally. If there is a hole or crack caused by corrosion, damage to a joint or abnormal exhaust noise, be sure to have the vehicle inspected and repaired by your Toyota dealer. Failure to do so may allow exhaust gases to enter the vehicle, resulting in death or a serious health hazard.
Page 126
2-1. Driving procedures CAUTION ■ When braking the vehicle ● When the brakes are wet, drive more cautiously. Braking distance increases when the brakes are wet, and may cause one side of the vehicle to brake differently than the other side. Also the parking brake may not securely hold the vehicle.
Page 127
2-1. Driving procedures NOTICE ■ When driving the vehicle Vehicles with an automatic transmission ● Do not depress the accelerator and brake pedals at the same time during driving, as this may restrain driving torque. ● Do not use the accelerator pedal or depress the accelerator and brake pedals at the same time to hold the vehicle on a hill.
Page 128
If you hear a squealing or scraping noise while driving (brake pad wear limit indicators) Have the brake pads checked and replaced by your Toyota dealer as soon as possible. The rotor damage can result if the pads are not replaced when needed.
2-1. Driving procedures Engine (ignition) switch ■ Engine switch LOCK The steering wheel is locked and the key can be removed. (Vehicles with an automatic transmission: The key can be removed only when the shift lever is in P.) Some electrical components such as the audio system can be used.
Page 130
2-1. Driving procedures ■ Turning the key from ACC to LOCK Shift the shift lever to P (auto- matic transmission) or N (man- ual transmission). (P. 132 134) Push in the key and turn to the LOCK position. ■ Steering lock release When starting the engine, the engine switch may seem stuck in the LOCK posi- tion.
Page 131
2-1. Driving procedures NOTICE ■ To prevent battery discharge Do not leave the engine switch in the ACC or ON position for long periods if the engine is not running. ■ When starting the engine ● Do not crank for more than 30 seconds at a time. This may overheat the starter and wiring systems.
2-1. Driving procedures Automatic Transmission Select a shift position appropriate for the driving conditions. ■ Shifting the shift lever While the engine switch is on, depress the brake pedal and move the shift lever. ■ Shift position uses Shift position Function Parking the vehicle or starting the engine Reversing...
Page 133
2-1. Driving procedures ■ Downshifting restrictions The shift lever cannot be downshifted if the following speeds are exceeded. 2WD models Maximum speed Downshifting mph (km/h) 4 3 90 (145) 3 2 59 (95) 2 L 25 (40) 4WD models Maximum speed Downshifting Transfer position mph (km/h)
2-1. Driving procedures Manual Transmission Fully depress the clutch pedal before operating the shift lever, and then release it slowly. : If equipped...
Page 135
2-1. Driving procedures ■ Maximum allowable speed Observe the following maximum allowable speeds in each gear when maxi- mum acceleration is necessary. Maximum speed Shift position Transfer position mph (km/h) H or HL 30 (48) 11 (18) H or HL 58 (93) 22 (35) H or HL...
2-1. Driving procedures Turn signal lever Left turn Right turn Move and hold the lever partway to signal a lane change. The left hand signal will flash until you release the lever. Move and hold the lever partway to signal a lane change.
2-1. Driving procedures Parking brake ■ Set the parking brake Fully set the parking brake while depressing the brake U.S.A. Canada pedal. At this time, the indicator will come on. ■ Release the parking brake Slightly raise the lever Press the button Lower it completely ■...
Page 138
2-1. Driving procedures NOTICE ■ Before driving Fully release the parking brake. Driving the vehicle with the parking brake set will lead to brake components overheating, which may affect braking performance and increase brake wear.
2-1. Driving procedures Horn To sound the horn, press on or close to the mark. ■ After adjusting the steering wheel Make sure that the steering wheel is securely locked. The horn may not sound if the steering wheel is not securely locked. (P.
2-2. Instrument cluster Gauges and meters The following gauges, meters and displays illuminate when the engine switch is in the ON position. Tachometer Displays the engine speed in revolutions per minute. Speedometer Displays the vehicle speed. Voltmeter Displays the charge state. Engine coolant temperature gauge Displays the engine coolant temperature.
Page 141
2-2. Instrument cluster Odometer/trip meter Odometer: Displays the total distance the vehicle has been driven. Trip meter: Displays the distance the vehicle has been driven since the meter was last reset. Trip meters A and B can be used to record and display differ- ent distances independently.
Page 142
2-2. Instrument cluster NOTICE ■ To prevent damage to the engine and its components ● Do not let the indicator needle of the tachometer enter the red zone, which indicates the maximum engine speed. ● The engine may be overheating if the temperature gauge is in the red zone (H).
2-2. Instrument cluster Indicators and warning lights The indicator and warning lights on the instrument cluster and cen- ter panel inform the driver of the status of the vehicle’s various sys- tems. Instrument cluster Center panel...
Page 144
2-2. Instrument cluster ■ Indicators The indicators inform the driver of the operating state of the vehicle’s various systems. Turn signal indicator AUTO LSD indicator (P. 136) (P. 185) (if equipped) Headlight high beam Four-wheel drive indicator (P. 149) indicator(P. 179) (if equipped) Security indicator Center differential lock...
Page 145
There may be a malfunction in a system if a light does not come on, or if the lights do not turn off. Have the vehicle inspected by your Toyota dealer.
2-2. Instrument cluster Accessory meter Compass Displays the direction that the vehicle is heading. (P. 387) Outside temperature Displays the outside air temperature. (P. 364) Clinometer Displays the longitudinal and lateral inclination of the vehicle. SET button This button is used to calibrate the compass. (P. 388) E/M button Outside temperature mode: Switch between English/U.S.
Page 147
2-2. Instrument cluster CAUTION ■ Caution while driving Do not adjust the display. Doing so may cause the driver to mishandle the vehicle and cause an acci- dent, resulting in death or serious injury.
2-3. Operating the lights and wipers Headlight switch The headlights can be operated manually. Type A The daytime running lights turn on. The side marker, park- ing, tail, license plate, outside rear view mir- illumination equipped), daytime running lights instrument panel lights turn on.
Page 149
2-3. Operating the lights and wipers Type B The daytime running lights turn on. The side marker, park- ing, tail, license plate, outside rear view mir- illumination equipped), daytime running lights instrument panel lights turn on. The headlights and all lights listed above...
Page 150
To turn the lights on again, turn the engine switch to the ON position, or turn the headlight switch off once and then back to the position. ■ Customization that can be configured at Toyota dealer Settings (automatic light off system) can be changed. (Customizable features P. 537) NOTICE ■...
2-3. Operating the lights and wipers Windshield wipers and washer Wiper intervals can be adjusted for intermittent operation (when INT is selected). Intermittent windshield wiper operation Low speed windshield wiper operation High speed windshield wiper operation Decreases the intermittent windshield wiper frequency Increases the intermittent windshield wiper frequency...
Page 152
Damage to the washer fluid pump may be caused if the lever is pulled toward you and held continually. ■ When a nozzle becomes blocked In this case, contact your Toyota dealer. Do not try to clear it with a pin or other object. The nozzle will be damaged.
2-3. Operating the lights and wipers Rear window wiper and washer Intermittent window wiper operation. The wiper operates 3 times at normal speed and then moves to intermittent mode. Normal window wiper oper- ation Washer/wiper dual opera- tion Washer/wiper dual opera- tion The rear window wiper oper- ates while the washer squirts.
2-4. Using other driving systems Cruise control Use the cruise control to maintain a set speed without depressing the accelerator pedal. Indicator Cruise control switch ■ Setting the vehicle speed Press the ON-OFF button to activate the cruise control. Cruise control indicator will come on.
Page 155
2-4. Using other driving systems ■ Adjusting the set speed To change the set speed, operate the lever until the desired set speed is obtained. Increases the speed Decreases the speed Fine adjustment: Momentarily move the lever in the desired direction.
Page 156
2-4. Using other driving systems ■ Canceling and resuming the constant speed control Pulling the lever toward you cancels the constant speed control. The speed setting is also can- celed when the brakes are applied or the clutch pedal (manual transmission only) is depressed.
Page 157
If the cruise control speed cannot be set or if the cruise control cancels immediately after being activated, there may be a malfunction in the cruise control system. Have the vehicle inspected by your Toyota dealer. CAUTION ■...
2-4. Using other driving systems Intuitive parking assist The intuitive parking assist assists the driver by communicating the distance to obstacles measured by the sensors via the buzzer when parallel parking or maneuvering into a garage. Always check the sur- rounding area when using this system.
Page 159
2-4. Using other driving systems ■ Intuitive parking assist switch ON/OFF When on, the buzzer sounds to inform the driver that the system is operational. At this time, the indicator will come Press the switch to switch the ON/OFF mode. The distance and buzzer When a sensor detects an obstacle, the buzzer sounds.
Page 160
2-4. Using other driving systems Sensors that operate and detection range The following diagrams show the sensor detection range. Note that sensors may not be able to detect obstacles that are extremely close to the vehicle. ■ Detection range of the sensors Approx.
Page 161
Objects lower than the sensors or thin stakes etc. may be detected ini- tially, but as they draw closer, they may cease to be detected. • A towing hitch is mounted to the vehicle. • A non-genuine Toyota suspension (lowered suspension etc.) is installed. • When attaching a two-way radio antenna.
Page 162
2-4. Using other driving systems ● The shape of the obstacle may prevent a sensor from detecting it. Pay particular attention to the following obstacles: • Wires, fences, ropes, etc. • Cotton, snow and other materials that absorb radio waves •...
2-4. Using other driving systems Rear view monitor system The rear view monitor system assists the driver by displaying guide lines and an image of the view behind the vehicle while backing up, for example while parking. The screen illustrations used in this text are intended as examples, and may differ from the image that is actually displayed on the screen.
Page 164
2-4. Using other driving systems Switching the screen Type A When the screen is displayed, press on the inside rear view mirror to switch the screen ON/OFF mode. Screen ON mode: Screen is displayed and green indicator comes on. Screen OFF mode: Screen is not displayed amber indicator...
Page 165
2-4. Using other driving systems Screen description Guide lines are displayed on the screen. Guide lines shown differ from those shown on the actual screen. Vehicle width extension guide lines (blue) The line indicates a guide path when the vehicle is being backed straight up.
Page 166
2-4. Using other driving systems Rear view monitor system precautions ■ Area displayed on screen The rear view monitor system displays an image of the view from the bumper of the rear area of the vehicle. • The area displayed on the screen may vary according to vehicle orientation conditions.
Page 167
2-4. Using other driving systems ■ Rear view monitor system camera The camera for the rear view monitor system is located to the spare wheel cover. ● Using the camera If the camera lens becomes dirty, it cannot transmit a clear image. If water droplets, snow or mud adhere to the lens, rinse with water and wipe with a soft cloth.
Page 168
2-4. Using other driving systems ● When the ground behind the vehicle slopes up sharply The distance guide lines will appear to be closer to the vehicle than actual distance. Because of this, objects will appear to be farther away than they actually are.
Page 169
2-4. Using other driving systems ● When any part of the vehicle sags When any part of the vehicle sags due to the number of pas- sengers or the distribution of the load, there is a margin of error between the guide lines on the screen actual dis-...
Page 170
2-4. Using other driving systems ● Distance guide lines Visually check the surroundings and the area behind the vehicle. On the screen, it appears that a truck is parking at point B. How- ever, in reality if you back up to point A, you will hit the truck.
Page 171
If you notice any symptoms If you notice any of the following symptoms, refer to the likely cause and the solution, and re-check. If the symptom is not resolved by the solution, have the vehicle inspected by your Toyota dealer. Symptom Likely cause Solution •...
Page 172
Bright spot Have the vehicle The camera position is out of inspected by your alignment. Toyota dealer. If this happens due The guide to these causes, it lines are • The vehicle is tilted (there is a does not indicate a...
Page 173
2-4. Using other driving systems ■ When using the rear view monitor system The anti-glare function of the inside rear view mirror will be canceled. ■ Rear view monitor system settings The following can be adjusted when the engine switch is in the ON position and the shift position is in R.
Page 174
2-4. Using other driving systems CAUTION ■ When using the rear view monitor system The rear view monitor system is a supplemental device intended to assist the driver when backing up. When backing up, be sure to check visually behind and all around the vehicle before proceeding. Observe the following precautions to avoid an accident that could result in death or serious injury.
Page 175
Doing so may result in the camera malfunc- tioning. ● Do not expose the camera to strong impact as this could cause a malfunc- tion. If this happens, have the vehicle inspected by your Toyota dealer as soon as possible.
2-4. Using other driving systems Four-wheel drive system (4WD models with a manual transmission) Use the four-wheel drive control lever to select the following transfer modes. The center differential lock indicator comes on when the LL or HL mode is selected.
Page 177
2-4. Using other driving systems ■ Shifting between H and HL ● You need not to depress the clutch pedal. ● If the center differential lock indicator does not come on when you shift from H to HL, drive straight ahead while accelerating or decelerating. ●...
Page 178
2-4. Using other driving systems NOTICE ■ To prevent damage to the center differential ● For normal driving on dry and hard surface roads, unlock the center differ- ential. ● Shift to H after the wheels are out of the ditch or off the slippery or bumpy surface.
2-4. Using other driving systems Four-wheel drive system (4WD models with an automatic transmission) Use the front-wheel drive control lever to select the following trans- fer modes. The four-wheel drive indicator comes on when the H4, N or L4 mode is selected.
Page 180
2-4. Using other driving systems ■ Shifting between H2 and H4 ● Reduce your speed to less than 50 mph (80 km/h) and shift the front- wheel drive control lever from H2 to H4. If you have trouble shifting in cold weather, reduce your speed or stop the vehicle.
Page 181
2-4. Using other driving systems CAUTION ■ Caution while driving ● Never shift the front-wheel drive control lever from H2 to H4 if the wheels are slipping. Stop the slipping or spinning before shifting. ● For normal driving on dry and hard surface roads, use H2 position. Driving on dry and hard surface roads in H4 or L4 position may cause drive com- ponent oil leakage, seizure, or other problems resulting in an accident.
2-4. Using other driving systems Active traction control system The active traction control system automatically helps prevent the spinning of 4 wheels when the vehicle is started or accelerated on slippery road surfaces. ■ System operation Vehicles with an automatic transmission: Stop the vehicle, shift the shift lever to N and shift the front- wheel drive control lever into L4.
Page 183
2-4. Using other driving systems Vehicles with overhead console Press the A-TRAC switch to activate the system. At this time, the active traction control system indicator will come on. To cancel the system, push the switch again. When the active traction control system is operating If any of the drive wheels spins, the slip indicator flashes to indi- cate that the active traction con-...
Page 184
2-4. Using other driving systems ■ When the rear differential is locked (vehicles with the rear differential lock system) The active traction control system is activated only when the vehicle speed is less than 4 mph (6 km/h). ■ Sounds and vibrations caused by the active traction control system ●...
2-4. Using other driving systems AUTO LSD system (2WD models) The AUTO LSD system aids traction by using the traction control system to control engine performance and braking when one of the rear wheels begins to spin. The system should be used only when wheel spinning occurs in a ditch or rough surface.
Page 186
2-4. Using other driving systems ■ If the engine is turned off and restarted The AUTO LSD system and the indicators are automatically turned off. ■ Reactivation of the VSC system linked to vehicle speed When the AUTO LSD system is turned on, the VSC system will turn on auto- matically if vehicle speed increases.
2-4. Using other driving systems Rear differential lock system The rear differential lock system is provided for use only when wheel spinning occurs in a ditch or on a slippery or rugged surface. The rear differential lock system is effective in case one of the rear wheels is spinning.
Page 188
2-4. Using other driving systems Vehicles with overhead console Press the RR DIFF LOCK switch to lock the rear differen- tial. At this time, the rear differential lock indicator will blink. Wait a few seconds for the system to complete operation. After the rear differential is locked, the indicator will stop blinking and remain on.
Page 189
2-4. Using other driving systems Manual transmission Before using the rear differential lock system. Stop the vehicle or reduce your speed to less than 5 mph (8 km/h). Depress the clutch pedal and shift the four-wheel drive control lever into LL to see if this is sufficient. If this has no effect, additionally use the rear differential lock system.
Page 190
2-4. Using other driving systems CAUTION ■ To avoid an accident ● Do not use the rear differential lock system except when wheel spinning occurs in a ditch or on a slippery or ragged surface. Large steering effort and careful cornering control will be required. ●...
2-4. Using other driving systems Clutch start cancel switch (vehicles with a manual transmission) The switch allows the vehicle to be driven out of difficult situations by cranking the engine with the clutch engaged. Never use the switch for normal engine starting. Be sure to follow the starting procedure.
2-4. Using other driving systems Crawl Control Allows travel on extremely rough off-road surfaces at a fixed low speed without pressing the accelerator or brake pedal. Minimizes loss of traction or vehicle slip when driving on slippery road sur- faces, allowing for stable driving.
Page 193
2-4. Using other driving systems ■ Speed modes The following table shows some typical terrains and the recommended speed modes. Mode Road condition L (Low) Rock, mogul (downhill) and gravel (downhill) Between L and M Mogul (uphill) M (Medium) Snow, mud, gravel (uphill), sand, dirt, Between M and H mogul (uphill) and grass H (High)
Page 194
2-4. Using other driving systems ■ Crawl Control can be operated when ● The engine is running. ● The shift lever is in any position other than P or N. ● The front-wheel drive control lever is in L4. ● The driver’s door is closed.
Page 195
2-4. Using other driving systems CAUTION ■ When using Crawl Control ● Do not overly rely on Crawl Control. This function does not extend the vehicle’s performance limitations. Always check the terrain thoroughly and drive safely. ● The recommended speed modes for the listed terrains (P. 193) are only a reference.
2-4. Using other driving systems Driving assist systems To help enhance driving safety and performance, the following sys- tems operate automatically in response to various driving situations. Be aware, however, that these systems are supplementary and should not be relied upon too heavily when operating the vehicle. ■...
Page 197
2-4. Using other driving systems To disable TRAC and VSC (2WD models and H2 mode [automatic transmission] on 4WD models) If the vehicle gets stuck in fresh snow or mud, TRAC and VSC may reduce power from the engine to the wheels. You may need to turn the system off to enable you to rock the vehicle in order to free it.
Page 198
When the TRAC OFF indicator light comes on even if the VSC OFF switch has not been pressed TRAC and Crawl Control (if equipped) systems cannot be operated. Contact your Toyota dealer. ■ Automatic reactivation of TRAC and VSC Turning the engine switch off after turning off the TRAC and VSC systems...
Page 199
2-4. Using other driving systems ■ Automatic VSC reactivation (2WD models) If only the TRAC system is turned off, VSC OFF and AUTO LSD indicators turn on. The VSC system will turn on when the vehicle speed increases. ■ Automatic TRAC and VSC reactivation If the TRAC and VSC systems are turned off, the systems will not turn on, even when vehicle speed increases.
Page 200
In addition, make sure that the tires are inflated to the appro- priate tire pressure level. The ABS, VSC and TRAC will not function correctly if different tires are fitted on the vehicle. Contact your Toyota dealer for further information when replacing tires or wheels. ■ Handling of tires and suspension Using tires with any kind of problem or modifying the suspension will affect the driving assist systems, and may cause the system to malfunction.
2-5. Driving information Off-road precautions This vehicle belongs to the utility vehicle class, which has higher ground clearance and narrower tread in relation to the height of its center of gravity to make it capable of performing in a wide variety of off-road applications.
Page 202
2-5. Driving information CAUTION ■ Off-road vehicle precautions Always observe the following precautions to minimize the risk of serious per- sonal injury or damage to your vehicle: ● In a rollover crash, an unbelted person is significantly more likely to die than a person wearing a seat belt.
Page 203
2-5. Driving information Off-road driving When driving your vehicle off-road, please observe the following pre- cautions to ensure your driving enjoyment and to help prevent the closure of areas to off-road vehicles. ● Drive your vehicle only in areas where off-road vehicles are permit- ted to travel.
Page 204
2-5. Driving information CAUTION ■ Off-road driving precautions Always observe the following precautions to minimize the risk of serious per- sonal injury or damage to your vehicle: ● Drive carefully when off the road. Do not take unnecessary risks by driving in dangerous places.
Page 205
2-5. Driving information NOTICE ■ To prevent the water damage ● Take all necessary safety measures to ensure that water damage to the engine or other components does not occur. ● Water entering the engine air intake will cause severe engine damage. ●...
2-5. Driving information Cargo and luggage Take notice of the following information about storage precau- tions, cargo capacity and load. ● Stow cargo and luggage in the luggage compartment whenever possible. ● Be sure all items are secured in place. ●...
Page 207
2-5. Driving information (6) If your vehicle will be towing a trailer, load from your trailer will be transferred to your vehicle. Consult this manual to determine how this reduces the available cargo and luggage load capacity of your vehicle. Calculation formula for your vehicle Cargo capacity Total load capacity (vehicle...
Page 208
2-5. Driving information As shown in the above example, if the number of occupants increases, the cargo and luggage load will be reduced by an amount that equals the increased weight due to the additional occupants. In other words, if an increase in the number of occupants causes an excess of the total load capacity (combined weight of occupants plus cargo and luggage load), you must reduce the cargo and luggage on your vehicle.
Page 209
2-5. Driving information CAUTION ■ Storage precautions ● Never allow anyone to ride in the luggage compartment. It is not designed for passengers. They should ride in their seats with their seat belts properly fastened. Otherwise, they are much more likely to suffer death or serious injury, in the event of sudden braking, sudden swerv- ing or an accident.
2-5. Driving information Vehicle load limits Vehicle load limits include total load capacity, seating capacity, TWR (Trailer Weight Rating) and cargo capacity. ■ Total load capacity (vehicle capacity weight): (P. 512) Total load capacity means the combined weight of occupants, cargo and luggage.
2-5. Driving information Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a manner appropri- ate to the prevailing weather conditions. ■ Pre-winter preparations ● Use fluids that are appropriate to the prevailing outside tem- peratures.
Page 212
2-5. Driving information ■ When driving the vehicle Accelerate the vehicle slowly and drive at a reduced speed suit- able to road conditions. ■ When parking the vehicle Park the vehicle and move the shift lever to P (automatic trans- mission) or to 1 or R (manual transmission) without setting the parking brake.
Page 213
NOTICE ■ Repairing or replacing snow tires Request repairs of and obtain replacement snow tires from Toyota dealers or legitimate tire retailers. This is because the removal and attachment of snow tires affects the opera- tion of the tire pressure warning valves and transmitters.
To tow a trailer safely, use extreme care and drive the vehicle in accordance with your trailer’s characteristics and operating condi- tions. Toyota warranties do not apply to damage or malfunction caused by towing a trailer for commercial purposes. Contact your Toyota dealer for further information about additional...
Page 215
2-5. Driving information Towing related terms ■ GCWR (Gross Combination Weight Rating) The maximum allowable gross combination weight. The gross combination weight is the sum of the total vehicle weight (including the occupants, cargo and any optional equipment installed on the vehicle) and the weight of the trailer being towed (including the cargo in the trailer).
Page 216
2-5. Driving information ■ GAWR (Gross Axle Weight Rating) The maximum allowable gross Front GAWR axle weight. The gross axle weight is the load placed on each axle (front and rear). Rear GAWR ■ TWR (Trailer Weight Rating) The maximum allowable gross (With brakes) trailer weight.
Page 217
2-5. Driving information ■ Unbraked TWR (Unbraked Trailer Weight Rating) The trailer weight rating for tow- (Without brakes) ing a trailer without a trailer ser- vice brake system. ■ Tongue Weight The load placed on the trailer hitch ball. (P. 220)
Page 218
2-5. Driving information Weight limits ● The gross trailer weight must never exceed the TWR described in the table. (P. 219) ● The gross combination weight must never exceed the GCWR described in the table. (P. 219) ● The gross vehicle weight must never exceed the GVWR indi- cated Certification...
Page 219
2-5. Driving information GCWR, TWR and Unbraked TWR Confirm that the gross trailer weight, gross combination weight, gross vehicle weight, gross axle weight and tongue weight are all within the limits. ■ GCWR and TWR Driving Model code Engine GCWR system GSJ10L-GKASKA 9200 lb.
Page 220
2-5. Driving information Trailer Tongue Weight ● A recommended tongue weight varies in accordance with the types of trailers or towing as described below. ● To ensure the recommended values shown below, the trailer must be loaded by referring to the following instructions. •...
Page 221
Toyota hitch/bracket for your vehicle. For details, contact your Toyota dealer. ● If you wish to install a trailer hitch, contact your Toyota dealer. ● Use only a hitch that conforms to the gross trailer weight require- ment of your vehicle.
Page 222
2-5. Driving information Selecting trailer ball Use the correct trailer ball for your application. Trailer ball load rating Matches or exceeds the gross trailer weight rating of the trailer. Ball diameter Matches the size of the trailer coupler. Most couplers stamped with the required trailer ball size.
Page 223
2-5. Driving information Positions for towing hitch receiver and hitch ball Weight carrying ball position: 43.3 in. (1100 mm) Hitch receiver pin hole posi- tion: 39.4 in. (1000 mm) Connecting trailer lights Use the wire harness stored in the rear end under body.
Page 224
● Speed limits for towing a trailer vary by state or province. Do not exceed the posted towing speed limit. ● Toyota recommends that the vehicle-trailer speed limit is 65 mph (104 km/h) on a flat, straight, dry road. Do not exceed this limit, the posted towing speed limit or the speed limit for your trailer as set forth in your trailer owner’s manual, whichever is lowest.
Page 225
2-5. Driving information ● Avoid jerky starts or sudden acceleration. ● Avoid jerky steering and sharp turns, and slow down before mak- ing a turn. ● Note that when making a turn, the trailer wheels will be closer than the vehicle wheels to the inside of the turn. Compensate by making a wider than normal turning radius.
Page 226
2-5. Driving information ● Always place wheel blocks under both the vehicle’s and the trailer’s wheels when parking. Apply the parking brake firmly, and put the transmission in P (automatic transmission) or in 1 or R (manual transmission). Avoid parking on a slope, but if unavoid- able, do so only after performing the following: Apply the brakes and keep them applied.
Page 227
2-5. Driving information ■ Matching trailer ball height to trailer coupler height No matter which class of tow hitch applies, for a more safe trailer hookup, the trailer ball setup must be the proper height for the coupler on the trailer. Coupler Trailer ball ■...
Page 228
Break-in schedule If your vehicle is new or equipped with any new power train components (such as an engine, transmission, differential or wheel bearing), Toyota rec- ommends that you do not tow a trailer until the vehicle has been driven for over 500 miles (800 km).
Page 229
2-5. Driving information If you cannot find any problems, the speed at which trailer swaying occurred is beyond the limit of your particular vehicle-trailer combination. Drive at a lower speed to prevent instability. Remember that swaying of the towing vehicle-trailer increases as speed increases. CAUTION ■...
Page 230
■ When towing a trailer Toyota recommends trailers with brakes that conform to any applicable fed- eral and state/provincial regulations. ● If the gross trailer weight exceeds unbraked TWR, trailer brakes are required.
Page 231
2-5. Driving information NOTICE ■ When installing a trailer hitch Use only the position recommended by your Toyota dealer. Do not install the trailer hitch on the bumper; this may cause body damage. ■ Do not directly splice trailer lights Do not directly splice trailer lights.
2-5. Driving information Dinghy towing Your vehicle is not designed to be dinghy towed (with 4 wheels on the ground) behind a motor home. NOTICE ■ To avoid serious damage to your vehicle Do not tow your vehicle with four wheels on the ground.
Interior features ® 3-1. Using the air conditioning 3-3. Using the Bluetooth audio system and defogger system ® Air conditioning system ..236 Bluetooth audio system ......296 Rear window defogger ..243 ® Using the Bluetooth audio system....300 3-2.
Page 235
Interior features 3-5. Using the interior lights 3-7. Other interior features Interior lights list ....350 Sun visors ......361 • Interior lights ....351 Vanity mirrors....362 • Personal lights ....352 Clock ........ 363 Outside temperature 3-6. Using the storage features display......
3-1. Using the air conditioning system and defogger Air conditioning system Outside air or recirculated Air conditioning air mode switch ON/OFF switch Fan speed control dial Temperature control dial Air outlet selection dial Adjusting the settings ■ Adjusting the temperature setting Turn the temperature control dial clockwise (warm) or counter- clockwise (cool).
Page 237
3-1. Using the air conditioning system and defogger ■ Adjusting the fan speed Turn the fan speed control dial clockwise (increase) or counter- clockwise (decrease). Set the dial to OFF to turn the fan off. ■ Selecting the air outlets Set the air outlet selection dial to an appropriate position.
Page 238
3-1. Using the air conditioning system and defogger When the dial is set to , air flows to the feet and the wind- shield defogger operates. The air intake selector is automat- ically set to outside air mode. To return the recirculated air mode, press When the dial is set to , air...
Page 239
3-1. Using the air conditioning system and defogger ■ If the ambient temperature drops while using the recirculated air mode The air intake mode automatically changes from recirculated air mode to outside air mode after a few minutes. To cancel this function: Press and hold for longer than 2 seconds.
Page 240
3-1. Using the air conditioning system and defogger Right and left side outlets Direct air flow to the left or right, up or down. Opening and closing the right and left side outlets Open the vent. Close the vent.
Page 241
There may be a problem in the air conditioning system if the indi- cator continues to flash. Turn the air conditioning system off and have it inspected by your Toyota dealer. ■ Air conditioning odors ●...
Page 242
3-1. Using the air conditioning system and defogger CAUTION ■ To prevent the windshield from fogging up Do not set the air outlet selection dial to during cool air operation in extremely humid weather. The difference between the temperature of the outside air and that of the windshield can cause the outer surface of the windshield to fog up, blocking your vision.
3-1. Using the air conditioning system and defogger Rear window defogger This feature is used to defog the rear window. On/off Press the button to turn on the rear window defogger. The indicator light will come on. The defogger will automatically turn off after 15 to 240 minutes.
3-2. Using the audio system Audio system Type A: CD player with changer controller and AM/FM radio Type B: CD player with changer and AM/FM radio...
Page 245
3-2. Using the audio system Title Page Using the radio P. 248 Using the CD player P. 255 Playing MP3 and WMA discs P. 263 Operating an iPod P. 270 Operating a USB memory P. 278 Optimal use of the audio system P.
Page 246
3-2. Using the audio system ■ Using cellular phones Interference may be heard through the audio system’s speakers if a cellular phone is being used inside or close to the vehicle while the audio system is operating. ■ Certification for the audio system This device complies with part 15 of the FCC Rules and RSS-Gen of the IC Rules.
Page 247
3-2. Using the audio system NOTICE ■ To prevent battery discharge Do not leave the audio system on longer than necessary with the engine off. ■ To avoid damaging the audio system Take care not to spill drinks or other fluids over the audio system.
3-2. Using the audio system Using the radio Power Volume Scanning for Adjusting the frequency receivable stations (AM, FM mode) or channel (SAT mode) Station selector Displaying radio text messages Mute Setting preset button Seeking the frequency AM/FM/SAT mode button Changing the channel category ®...
Page 249
3-2. Using the audio system ® Scanning radio stations (excluding XM Satellite Radio) ■ Scanning the preset radio stations Press and hold until you hear a beep. Preset stations will be played for 5 seconds each. When the desired station is reached, press again.
Page 250
3-2. Using the audio system ® Satellite Radio (if equipped) ® ■ Receiving XM Satellite Radio Press The display changes as follows each time is pressed. AM FM XM Turn to select the desired channel in all the catego- ries or press “”...
Page 251
3-2. Using the audio system ■ ® Scanning XM Satellite Radio channels ● Scanning channels in the current category Press When the desired channel is reached, press again. ● Scanning the preset channels Press and hold until you hear a beep. When the desired channel is reached, press again.
Page 252
3-2. Using the audio system ■ Reception sensitivity ● Cargo loaded on the roof luggage carrier, especially metal objects, may ® adversely affect the reception of XM Satellite Radio. ● Maintaining perfect radio reception at all times is difficult due to the con- tinually changing position of the antenna, differences in signal strength and surrounding objects, such as trains, transmitters, etc.
Page 253
CHECK ANTENNA There is a short-circuit in the antenna or the sur- rounding antenna cable. See a Toyota certified dealer. ® You have not subscribed to XM Satellite Radio. The radio is being updated with the latest encryp- ®...
Page 254
3-2. Using the audio system The channel you selected is no longer available. CHANNEL NOT Wait for about 2 seconds until the radio returns to AVAILABLE the previous channel or “CH001”. If it does not change automatically, select another channel. ®...
Using the CD player Power Volume CD load (type B only) CD eject PWR VOL PWR VOL Searching playback Displaying text messages Selector buttons TOYOTA LOAD SCAN TEXT PWR VOL TUNE SCROLL Selecting a track PUSH SELECT Playback Playback/ PRESET...
Page 256
3-2. Using the audio system ■ Loading multiple CDs (type B only) Press and hold until you hear a beep. When the indicator on the slot turns from amber to green, insert a CD. The indicator on the slot turns to amber when the CD is inserted. When the indicator on the slot turns from amber to green again, insert the next CD.
Page 257
3-2. Using the audio system Selecting a track Turn or press “” or “” on to select the desired track. Fast-forwarding and reversing tracks Press and hold “” or “” on Scanning tracks Press The first ten seconds of each track will be played. To cancel, press again.
Page 258
3-2. Using the audio system Selecting a CD (type B only) ■ Selecting a CD to play Press ) or ■ Scanning loaded CDs Press and hold until you hear a beep. The first ten seconds of the first track on each CD will be played. To cancel, press again.
Page 259
The CD may be dirty, damaged or inserted up-side down. “PLEASE WAIT”: Operation has stopped due to a high temperature inside the player. Wait for a while and then press . Contact your Toyota dealer if the CD still cannot be played back.
Page 260
3-2. Using the audio system ■ Discs that can be used Discs with the marks shown below can be used. Playback may not be possible depending on the recording format or disc features, or due to scratches, dirt or deterioration. CDs with copy-protection features may not be used.
Page 261
3-2. Using the audio system NOTICE ■ CDs and adapters that cannot be used Do not use the following types of CDs. Also, do not use 3 in. (8 cm) CD adapters, DualDiscs or printable discs. Doing so may damage the CD player and/or the CD insert/eject function. ●...
Page 262
3-2. Using the audio system NOTICE ■ CD player precautions Failure to follow the precautions below may result in serious damage to the CDs or the player itself. ● Do not insert anything other than CDs into the CD slot. ●...
3-2. Using the audio system Playing MP3 and WMA discs Power Volume CD eject Searching playback CD load (type B only) Selector buttons Displaying text messages Selecting a file Playback Selecting a folder Playback/pause Selecting a file/ and file fast-forwarding and reversing Loading and ejecting MP3 and WMA discs P.
Page 264
3-2. Using the audio system Selecting and scanning a folder ■ Selecting folders one at a time Press “” or “” on to select the desired folder. ■ Scanning the first file of all the folders Press and hold until you hear a beep. The first ten seconds of the first file in each folder will be played.
Page 265
3-2. Using the audio system Playing and pausing files Press Random playback ■ Playing files from a particular folder in random order Press (RDM). To cancel, press the button twice more. ■ Playing all of the files on a disc in random order Press (RDM) twice.
Page 266
“PLEASE WAIT”: Operation has stopped due to a high temperature inside the player. Wait for a while and then press . Contact your Toyota dealer if the CD still cannot be played. ■ Discs that can be used P. 260 ■...
Page 267
3-2. Using the audio system ■ MP3 and WMA files MP3 (MPEG Audio LAYER3) is a standard audio compression format. Files can be compressed to approximately 1/10 of their original size by using MP3 compression. WMA (Windows Media Audio) is a Microsoft audio compression format. This format compresses audio data to a size smaller than that of the MP3 format.
Page 268
3-2. Using the audio system ● Compatible disc formats The following disc formats can be used. • Disc formats: CD-ROM Mode 1 and Mode 2 CD-ROM XA Mode 2, Form 1 and Form 2 • File formats: ISO9660 Level 1, Level 2, (Romeo, Joliet) MP3 and WMA files written in any format other than those listed above may not play correctly, and their file names and folder names may not be displayed correctly.
Page 269
3-2. Using the audio system ● Extensions If the file extensions .mp3 and .wma are used for files other than MP3 and WMA files, they will be mistakenly recognized and played as MP3 and WMA files. This may result in large amounts of interference and damage to the speakers.
3-2. Using the audio system Operating an iPod Connecting an iPod enables you to enjoy music from the vehicle speakers. ■ Connecting an iPod Open the cover and connect an iPod using an iPod cable. Turn on the power of the iPod if it is not turned on.
Page 271
3-2. Using the audio system ■ Control panel Power Volume Selector buttons Displaying text messages Selector knob Playback Selecting a song/ Playback/pause fast-forwarding and reversing...
Page 272
3-2. Using the audio system Selecting a play mode Press (BROWSE) to select iPod menu mode. Press as corresponds to the desired play mode. Pressing (MORE) to change to the second selection list. ■ Play mode list First Second Third Fourth Play mode selection...
Page 273
3-2. Using the audio system ■ Selecting a list Turn to display the first selection list. Press to select the desired item. Repeat the same procedure to select the desired song name. To return to the previous selection list, press Selecting songs from a song list Press (LIST).
Page 274
3-2. Using the audio system Playing and pausing songs Press Fast-forwarding and reversing songs Press and hold “ ” or “” on Shuffle playback ■ Playing songs from one playlist or album in random order Press (RDM). To cancel, press the button twice. ■...
Page 275
3-2. Using the audio system ■ About iPod ● Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards. ● iPod is a trademark of Apple Inc., registered in the U.S. and other coun- tries.
Page 276
3-2. Using the audio system ■ Compatible models Model Generation Software version iPod 5th generation Ver. 1.2.0 or higher iPod nano 1st generation Ver. 1.3.0 or higher 2nd generation Ver. 1.1.2 or higher 3rd generation Ver. 1.0.0 or higher iPod touch 1st generation Ver.
Page 277
3-2. Using the audio system NOTICE ■ To prevent damage to iPod ● Do not leave iPod in the vehicle. The temperature inside the vehicle may become high, resulting in damage to the player. ● Do not push down on or apply unnecessary pressure to the iPod while it is connected as this may damage the iPod or its terminal.
3-2. Using the audio system Operating a USB memory Connecting a USB memory enables you to enjoy music from the vehicle speakers. ■ Connecting a USB memory Open the cover and connect a USB memory. Turn on the power of the USB memory if it is not turned on.
Page 279
3-2. Using the audio system ■ Control panel Power Volume Searching playback Selector buttons Displaying text messages Selector knob Playback Playback/ pause Selecting a file/ Selecting a folder fast-forwarding and reversing Selecting and scanning a folder ■ Selecting a folder Press “”...
Page 280
3-2. Using the audio system Selecting and scanning files ■ Selecting a file Turn or press “” or “” on to select the desired file. ■ Scanning the files in a folder Press The first ten seconds of each file will be played. To cancel, press again.
Page 281
3-2. Using the audio system Random playback ■ Playing files from a folder in random order Press (RDM). To cancel, press the button twice. ■ Playing all the files from a USB memory in random order Press (RDM) twice. To cancel, press the button again. Repeat play ■...
Page 282
3-2. Using the audio system ■ USB memory functions Depending on the USB memory that is connected to the system, certain functions may not be available. Disconnecting the device and reconnecting it once again may resolve some malfunctions. ■ Error messages “USB ERROR”:This indicates a problem in the USB memory, in the USB box or connection between them.
Page 283
3-2. Using the audio system ● MP3 and WMA files MP3 (MPEG Audio LAYER 3) is a standard audio compression format. Files can be compressed to approximately 1/10 of their original size using MP3 compression. WMA (Windows Media Audio) is a Microsoft audio compression format. This format compresses audio data to a size smaller than that of the MP3 format.
Page 284
3-2. Using the audio system ● File names The only files that can be recognized as MP3/WMA and played are those with the extension .mp3 or .wma. ● ID3 and WMA tags ID3 tags can be added to MP3 files, making it possible to record the track title, artist name, etc.
Page 285
3-2. Using the audio system CAUTION ■ Caution while driving Do not connect a USB memory or operate the controls. NOTICE ■ To prevent damage to a USB memory ● Do not leave a USB memory in the vehicle. The temperature inside the vehicle may become high, resulting in damage to the player.
3-2. Using the audio system Optimal use of the audio system Selector buttons Adjusting the sound quality and ASL Menu button Using the audio control function ■ Changing sound quality modes Press Press (type B only) as corresponds to the desired mode. “BASS”, “MID”...
Page 287
3-2. Using the audio system ■ Adjusting sound quality Turning adjusts the level. Mode Sound qual- Turn to the Turn to the Level displayed ity mode left right BASS Bass -5 to 5 Mid-range -5 to 5 High (type B only) TREB Treble -5 to 5...
Page 288
3-2. Using the audio system ■ Setting the number of preset pages The number of preset pages desired can be set from 1 to 6. The initial setting is 6 pages. Press Press (MORE). Press (PRESET). Press as corresponds to the desired number of preset pages.
3-2. Using the audio system Using the AUX port/USB port This port can be used to connect a portable audio device and listen to it through the vehicle’s speakers. Open the cover and connect the portable audio device. Press ■ Operating portable audio devices connected to the audio system The volume can be adjusted using the vehicle’s audio controls.
3-2. Using the audio system Using the steering wheel audio switches Some audio features can be controlled using the switches on the steering wheel. Increases/decreases vol- Radio mode: Selects radio station CD mode: Selects tracks, files (MP3 and WMA) and discs (type B only) iPod mode: Selects a song memory...
Page 291
3-2. Using the audio system Turning the power on Press when the audio system is turned off. The audio system can be turned off by holding the switch down until you hear a beep. Changing the audio source Press when the audio system is turned on. The audio source changes as follows each time the switch is pressed.
Page 292
3-2. Using the audio system Selecting a track/file or song ® Press to select the CD, iPod, USB memory, Bluetooth audio mode. Press “” or “” on to select the desired track/file or song. Selecting a folder or album ® Press to select the CD, USB memory or Bluetooth audio...
3-2. Using the audio system Antenna The antenna can be removed. ■ Removing the antenna Place the included wrench around the antenna. When not in use, the wrench is stored in glove box. Loosen the antenna with the wrench and remove it.
Page 294
3-2. Using the audio system ■ Installing the antenna Tighten the antenna by one hand until it will not turn any more. Using the wrench, tighten the antenna an additional 1/8th turn (20 to 45 degrees) to secure it in place. After tightening the antenna, remove the wrench.
Page 295
3-2. Using the audio system NOTICE ■ To avoid damage to the antenna Remove the antenna in the following situations. ● When using an automatic carwash. ● When the antenna will touch the ceiling of a garage, etc. ● When covering the vehicle with a car cover. ■...
® 3-3. Using the Bluetooth audio system ® Bluetooth audio system ® The Bluetooth audio system enables you to enjoy music played on a portable digital audio player (portable player) from the vehicle speakers via wireless communication. ® This audio system supports Bluetooth , a wireless data system capable of playing portable audio music without cables.
Page 297
® 3-3. Using the Bluetooth audio system ® ■ About Bluetooth Bluetooth is a registered trademark of Bluetooth SIG. Inc. ■ Compatible models ® ● Bluetooth specifications: Ver. 1.2 ● Following Profiles: • A2DP (Advanced Audio Distribution Profile) Ver. 1.0 •...
Page 298
® 3-3. Using the Bluetooth audio system For vehicles sold in Canada • Vehicles with CD changer IC ID: 2024B-FT0001A MADE IN JAPAN • Vehicles without CD changer IC ID: 775E-K025 MADE IN JAPAN Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, includ- ing interference that may cause undesired operation of the device.
Page 299
® 3-3. Using the Bluetooth audio system CAUTION ■ Caution regarding interference with electronic devices ® ● Your audio unit is fitted with Bluetooth antennas. People with implanted pacemakers or cardiac defibrillators should maintain a reasonable dis- ® tance between themselves and the Bluetooth antennas.
® 3-3. Using the Bluetooth audio system ® Using the Bluetooth audio system ■ Audio unit Display Track title, Artist name, Album name, Elapsed time, “Streaming Audio”, etc. is displayed. Selects items such as menu and number Turn: Selects an item Press: Inputs the selected item Bluetooth-Audio...
Page 301
® 3-3. Using the Bluetooth audio system Operating the system using voice commands By following voice guidance instructions output from the speaker, ® voice commands enable to the operation of the Bluetooth audio sys- tem without the need to check the display or operate ■...
Page 302
® 3-3. Using the Bluetooth audio system Register a portable player name by either of the following methods: a. Select “Record Name” using , and say the name to be registered. b. Press the talk switch and say the name to be registered. A voice guidance instruction to confirm the input is heard.
Page 303
® 3-3. Using the Bluetooth audio system ® Menu list of the Bluetooth audio system Second First menu Third menu Operation detail menu Pair Audio Players Registering a portable player (Pair audio player) Select Audio Selecting a portable player to Player be used Audio...
Page 304
® 3-3. Using the Bluetooth audio system ■ When using a voice command For numbers, say a combination of single digits from zero to nine. Say the command correctly and clearly. ■ Situations that the system may not recognize your voice ●...
3-3. Using the Bluetooth audio system ® Operating a Bluetooth enabled portable player Power Volume PWR VOL PWR VOL Selector buttons Displaying text messages TOYOTA LOAD SCAN TEXT PWR VOL TUNE SCROLL Selector knob PUSH SELECT Playback PRESET RADIO SET UP...
Page 306
® 3-3. Using the Bluetooth audio system Fast-forwarding and reversing tracks Press and hold “ ” or “” on Switching the display Press Each time is pressed, the display changes in the following order: Track title Track title/Artist name Track title/Album name Track title/Elapsed time Using the steering wheel audio switches P.
® 3-3. Using the Bluetooth audio system ® Setting up a Bluetooth enabled portable player ® Registering a portable player in the Bluetooth audio system allows the system to function. The following functions can be used for reg- istered portable players: ■...
Page 308
® 3-3. Using the Bluetooth audio system Selecting a portable player to be used Select “Select Audio Player” using a voice command or Select the portable player to be used by either of the following methods, and select “Confirm” using a voice command or a.
Page 309
® 3-3. Using the Bluetooth audio system Changing the registered name of a portable player Select “Change Name” using a voice command or Select the name of the portable player to be changed by either of the following methods, and select “Confirm” using a voice command or a.
Page 310
® 3-3. Using the Bluetooth audio system Listing the registered portable players Select “List Audio Players” using a voice command or The list of registered portable players will be read aloud. When listing is complete, the system returns to “BT Audio Setup”. Pressing the talk switch while the name of a portable player is being read aloud selects the portable player, and the following functions will become available:...
Page 311
® 3-3. Using the Bluetooth audio system Deleting a registered portable player Select “Delete Audio Player” using a voice command or Select the portable player to be deleted by either of the follow- ing methods and select “Confirm” using a voice command or a.
3-4. Using the hands-free phone system (for cellular phone) Hands-free phone system (for cellular phone) ® This system supports Bluetooth , which allows you to make or receive calls without using cables to connect a cellular phone and the system, and without operating the cellular phone. ■...
Page 314
3-4. Using the hands-free phone system (for cellular phone) Title Page Security and system setup ■ Setting or changing the PIN ■ Locking or unlocking the phone book P. 337 ■ Setting voice guidance volume ■ Initialization Using the phone book ■...
Page 315
3-4. Using the hands-free phone system (for cellular phone) ® ■ About Bluetooth Bluetooth is a registered trademark of Bluetooth SIG. Inc. ■ Certification for the hands-free phone system For vehicles sold in the U.S.A. • Vehicles with CD changer FCC ID: BABFT0001A MADE IN JAPAN •...
Page 316
3-4. Using the hands-free phone system (for cellular phone) CAUTION ■ FCC WARNING Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Radio Frequency Radiation Exposure. This equipment complies with FCC/ IC radiation exposure limits set forth for uncontrolled equipment and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65 and RSS-102 of the IC radio frequency (RF) Exposure rules.
3-4. Using the hands-free phone system (for cellular phone) Using the hands-free phone system (for cellular phone) ■ Audio unit Display A message, name, phone number, etc. is displayed. Lower-case characters and special characters, such as an umlaut, cannot be dis- played.
Page 318
3-4. Using the hands-free phone system (for cellular phone) ■ Steering wheel switches Volume The voice guidance volume cannot be adjusted using this button. Off-hook switch Turns the hands-free sys- tem on/starts a call On-hook switch Turns the hands-free sys- tem off/ends a call/refuses a call Talk switch...
Page 319
3-4. Using the hands-free phone system (for cellular phone) ■ Microphone...
Page 320
3-4. Using the hands-free phone system (for cellular phone) Operating the system by using a voice command By following the voice guidance instructions output from the speaker, voice commands enable the operation of the hands-free phone sys- tem without the need to check the display or operate ■...
Page 321
3-4. Using the hands-free phone system (for cellular phone) Register a phone name either of the following methods. a. Select “Record Name” using , and say a name to be registered. b. Press the talk switch and say a name to be registered. A voice guidance instruction to confirm the input is heard.
Page 322
3-4. Using the hands-free phone system (for cellular phone) Menu list of the hands-free phone system ■ Normal operation Second First menu Third menu Operation detail menu Dialing a number stored in CallBack the incoming call history (Callback) memory Dialing a number stored in Redial the outgoing call history memory...
Page 323
3-4. Using the hands-free phone system (for cellular phone) Second First menu Third menu Operation detail menu Set PIN Setting a PIN code Phonebook Lock Locking the phone book (Phone book Security lock) Phonebook Unlock Unlocking the phone book (Phone book unlock) Registering the cellular Pair Phone...
Page 324
3-4. Using the hands-free phone system (for cellular phone) ■ Using a short cut key First menu Second menu Operation detail Dialing a number registered in Dial XXX (name) the phone book Dial XXX (number) Dialing the input numbers Phone book add Adding a new number entry Phone book change...
Page 325
3-4. Using the hands-free phone system (for cellular phone) ■ Automatic volume adjustment When vehicle speed is 50 mph (80 km/h) or more, the volume automatically increases. The volume returns to the previous volume setting when vehicle speed drops to 43 mph (70 km/h) or less. ■...
3-4. Using the hands-free phone system (for cellular phone) Making a phone call ■ Making a phone call ● Dialing by inputting a number “Dial by Number” ● Dialing by inputting a name “Dial by Name (Dial by name)” ● Speed dialing ●...
Page 327
3-4. Using the hands-free phone system (for cellular phone) Dialing by inputting a number Press the talk switch and say “Dial by Number”. Press the talk switch and say the phone number. Dial by one of the following methods: a. Press the off-hook switch. b.
Page 328
3-4. Using the hands-free phone system (for cellular phone) When receiving a phone call ■ Answering a phone call Press the off-hook switch. ■ Refusing a phone call Press the on-hook switch. Transferring a call A call can be transferred between the cellular phone and system while dialing, receiving a call, or during a call.
Page 329
3-4. Using the hands-free phone system (for cellular phone) Using the call history memory Follow the procedure below to use a number stored in the call history memory: Press the talk switch and say “Redial” (when using a number stored in the outgoing call history memory) or “CallBack” (when using a number stored in the incoming call history memory).
Page 330
3-4. Using the hands-free phone system (for cellular phone) ■ Call history Up to 5 numbers can be stored in each of the outgoing and incoming call his- tory memories. ■ When talking on the phone ● Do not talk at the same time as the other party. ●...
3-4. Using the hands-free phone system (for cellular phone) Setting a cellular phone Registering a cellular phone in the hands-free phone system allows the system to function. The following functions can be used for reg- istered cellular phones: ■ Functions and operation procedures To enter the menu for each function, follow the steps below using a voice command or ●...
Page 332
3-4. Using the hands-free phone system (for cellular phone) Registering a cellular phone Select “Pair Phone” using a voice command or , and per- form the procedure for registering a cellular phone. (P. 320) Selecting the cellular phone to be used Select “Select Phone”...
Page 333
3-4. Using the hands-free phone system (for cellular phone) Changing a registered name Select “Change Phone Name (Change name)” using a voice command or Select the name of the cellular phone to be changed by either of the following methods: a.
Page 334
3-4. Using the hands-free phone system (for cellular phone) Listing the registered cellular phones Selecting “List Phones” using a voice command or causes the list of registered cellular phones to be read aloud. When listing is complete, the system returns to “Phone Setup”. Pressing the talk switch while the name of a cellular phone is being read selects the cellular phone, and the following functions will be available:...
Page 335
3-4. Using the hands-free phone system (for cellular phone) Changing the passkey Select “Set Passkey” using a voice command or Press the talk switch, say a 4 to 8-digit number, and select “Confirm” using a voice command or The number should be input 1 digit at a time. When the entire number to be registered as a passkey has been input, press again.
Page 336
3-4. Using the hands-free phone system (for cellular phone) ■ Turning on the automatic connection Select “Handsfree Power” using a voice command or Select “Turn on” using a voice command or ■ The number of cellular phones that can be registered Up to 6 cellular phones can be registered in the system.
3-4. Using the hands-free phone system (for cellular phone) Security and system setup To enter the menu of each setting, follow the steps below: ■ Security setting items and operation procedure ● Setting or changing the PIN (Personal Identification Number) 1.
Page 338
3-4. Using the hands-free phone system (for cellular phone) Setting or changing the PIN ■ Setting a PIN Select “Set PIN” using a voice command or Enter a PIN using a voice command or When using , input the code 1 digit at a time. ■...
Page 339
3-4. Using the hands-free phone system (for cellular phone) Locking or unlocking the phone book Select “Phonebook Lock (Phone book lock)” or “Phonebook Unlock (Phone book unlock)” using a voice command or Input the PIN by either of the following methods and select “Confirm”...
Page 340
3-4. Using the hands-free phone system (for cellular phone) ® Displaying the Bluetooth device address and name Select “Device Name” using ® Turn to display the Bluetooth device address and name. Select “Go Back” using to return to “System Setup”. Initialization Select “Reset Settings”...
Page 341
3-4. Using the hands-free phone system (for cellular phone) ■ Initialization ● The following data in the system can be initialized: • Phone book • Outgoing and incoming call history • Speed dials • Registered cellular phone data • Security code ●...
3-4. Using the hands-free phone system (for cellular phone) Using the phone book To enter the menu of each setting, follow the steps below: ● Adding a new phone number 1. “Phonebook” 2. “Add Entry” ● Setting speed dial 1.
Page 343
3-4. Using the hands-free phone system (for cellular phone) ■ Adding procedure Select “Add Entry” using a voice command or Use one of the following methods to input a telephone num- ber: Inputting a telephone number using a voice command STEP2-1 Select “By Voice (By voice)”...
Page 344
3-4. Using the hands-free phone system (for cellular phone) Inputting a phone number using STEP2-1 Select “Manual Input” using STEP2-2 Input a phone number using , and press once again. Input the phone number 1 digit at a time. Selecting a phone number from outgoing or incoming call history STEP2-1 Select “Call History”...
Page 345
3-4. Using the hands-free phone system (for cellular phone) Select the name to be registered by either of the following methods, and select “Confirm” using a voice command or a. Press the talk switch and say the desired name. b. Select “Record Name” using , and say the desired name.
Page 346
3-4. Using the hands-free phone system (for cellular phone) Setting speed dials Select “Speed Dial (Set speed dial)” using a voice command Select the data to be registered as a speed dial by either of the following methods: a. Press the talk switch, say desired number, and select “Confirm”...
Page 347
3-4. Using the hands-free phone system (for cellular phone) Changing a registered name Select “Change Name” using a voice command or Select the name to be changed by either of the following methods. a. Press the talk switch, say desired name, and select “Confirm”...
Page 348
3-4. Using the hands-free phone system (for cellular phone) Deleting registered data Select “Delete Entry” using a voice command or Select the data to be deleted by either of the following meth- ods, and select “Confirm” using a voice command or a.
Page 349
3-4. Using the hands-free phone system (for cellular phone) Listing the registered data Selecting “List names” using a voice command causes a list of the registered data to be read aloud. When listing is complete, the system returns to “Phonebook”. Pressing the talk switch while the desired data is being read aloud selects the data, and the following functions will be available.
3-5. Using the interior lights Interior lights list Rear interior light (P. 351) Center interior light (P. 351) Personal lights (P. 352) Engine switch light ■ Illuminated entry system When the interior light switch is in the DOOR position, the interior light and engine switch light automatically turns on/off according to whether the doors are locked/unlocked and whether the doors are open/closed and the engine switch position.
3-5. Using the interior lights Interior lights ■ Customization that can be configured at Toyota dealer Settings (e.g. The time elapsed before lights turn off) can be changed. (Customizable features P. 537) Interior lights Center DOOR position Rear DOOR position...
3-5. Using the interior lights Personal lights Personal lights Type A On/off Type B On/off ■ To prevent the battery from being discharged The personal lights will automatically turn off in about 30 minutes after the key is removed from the engine switch.
3-6. Using the storage features List of storage features Auxiliary box Glove box Bottle holders Cup holders CAUTION ■ Items that should not be left in the storage spaces Do not leave glasses, lighters or spray cans in the storage spaces, as this may result in the following when cabin temperature becomes high: ●...
3-6. Using the storage features Glove box Glove box Pull up the lever. CAUTION ■ Caution while driving Keep the glove box closed. In the event of sudden braking or sudden swerv- ing, an accident may occur due to an occupant being struck by the open glove box or the items stored inside.
3-6. Using the storage features Cup holders (front) Cup holders (front) Vehicles with an automatic transmission...
Page 356
3-6. Using the storage features Cup holders (front) Vehicles with a manual transmission ■ Holding large cups Vehicles with an automatic transmission The adapter can be removed.
Page 357
3-6. Using the storage features Cup holders (front) Vehicles with a manual transmission The adapter can be removed. CAUTION ■ Items unsuitable for the cup holder Do not place anything other than cups or beverage cans in the cup holders. Other items may be thrown out of the holders in the event of an accident or sudden braking and cause injury.
3-6. Using the storage features Cup holders (rear) Cup holders (rear) ■ Removing the mat Pull up. CAUTION ■ Items unsuitable for the cup holder Do not place anything other than cups or beverage cans in the cup holders. Other items may be thrown out of the holders in the event of an accident or sudden braking and cause injury.
3-6. Using the storage features Bottle holders Bottle holders ■ Bottle holders Depending on their size or shape, some bottles may not fit in the holders. NOTICE ■ Items that should not be stowed in the bottle holders Put the cap on before stowing a bottle. Do not place open bottles in the bot- tle holders, or glasses and paper cups containing liquid.
3-6. Using the storage features Auxiliary box Auxiliary box Push the button. Pull up the lid. CAUTION ■ Caution while driving Keep the auxiliary box closed. Items may fall out and cause death or serious injury in case of an accident or sudden stop.
3-7. Other interior features Clock Adjusts the hours Adjusts the minutes Pressing and holding the but- ton will adjust the hours or min- utes. ■ The clock is displayed when The engine switch is in the ACC or ON position. ■...
System and metric. ■ When – –°C or – –°F is displayed The system may be malfunctioning. Take your vehicle to your Toyota dealer. ■ The outside air temperature is displayed when The engine switch is in the ON position.
3-7. Other interior features Power outlet (12V DC) The power outlet can be used for 12V accessories that run on less than 10A. ■ The power outlet can be used when The engine switch is in the ACC or ON position. NOTICE ■...
3-7. Other interior features Power outlet (120V AC) The power outlet can be used for electrical appliances. ■ Operation Main switch To use the power outlet, turn on the main switch. The power supply starts a few seconds after the main switch is pressed.
Page 367
3-7. Other interior features Maximum available capacity of the power outlet ■ While the vehicle is being driven The maximum capacity of the power outlet is always 120V AC/ 100W. ■ When the vehicle is stationary The maximum capacity of the power outlet varies depending on the following conditions.
Page 368
3-7. Other interior features ■ The power outlet can be used when The engine is started. ■ The indicator light changes according the maximum available capacity, as follows: Indicates 120V AC/400W Indicates 120V AC/100W ■ When the power outlet is in operation The sound of the cooling fan may be heard from the right side of the luggage compartment.
Page 369
● Do not modify, disassemble or repair the power outlet or its inverter, in any way. Doing so may result in unexpected malfunctions or accidents, which could cause serious damage or injuries. Contact a Toyota dealer for any necessary repairs.
Page 370
3-7. Other interior features CAUTION ■ To prevent injuries and accidents, securely fix all electric appliances before use and do not use any appliances that may do any of the fol- lowing: ● Distract the driver while driving, or hamper safe driving. ●...
Page 371
If the power outlet is loose when an electrical appliance plug is con- nected Replace the outlet. Contact a Toyota dealer for any necessary replacements. ■ If the power outlet gets dirty Turn the main switch off and use a soft, clean cloth to wipe it gently.
3-7. Other interior features Armrest Adjusting to the desired angle: Lower the armrest from the highest position to the lowest position. Raise the armrest to the desired angle. Unlock the armrest: Lift the armrest to raise it to the highest position. NOTICE ■...
3-7. Other interior features Floor mat Use only floor mats designed specifically for vehicles of the same model and model year as your vehicle. Fix them securely in place onto the carpet. Insert the retaining hooks (clips) into the floor mat eye- lets.
Page 374
When installing the driver’s floor mat ● Do not use floor mats designed for other models or different model year vehicles, even if they are Toyota Genuine floor mats. ● Only use floor mats designed for the driver’s seat. ●...
3-7. Other interior features Luggage storage box (vehicles without sub woofer) Push the lid down and pull it towards you. CAUTION ■ Caution while driving Keep the luggage storage box closed. Injuries may result in the event of an accident or sudden braking.
3-7. Other interior features Luggage compartment features ■ Tie-down hooks Tie-down hooks are provided for securing loose items.
Page 377
3-7. Other interior features ■ Cargo net hooks To hang the cargo net, use the cargo net hooks and tie-down hooks. The cargo net itself is not included as an original equip- ment.
Page 378
3-7. Other interior features ■ Shopping bag hooks To hang the shopping bag, use the cargo net hooks. CAUTION ■ When the tie-down hooks and cargo net hooks are not in use To avoid injury, always return the tie-down hooks and cargo net hooks to their positions when they are not in use.
3-7. Other interior features Garage door opener The garage door opener can be trained to operate garage doors, gates, entry doors, door locks, home lighting systems, security sys- tems, and other devices. The training procedure is displayed on the inside rear view mirror display screen.
Page 380
3-7. Other interior features ■ ® Training the HomeLink Point the remote control trans- mitter for the device 1 to 3 in. (25 ® to 75 mm) from the HomeLink control buttons. Keep indicator ® HomeLink in view while training. Press and hold down one of the ®...
Page 381
3-7. Other interior features Test operation ® HomeLink pressing newly trained button. If training a garage door opener, check to see if the garage door opens and closes. If the garage door does not operate, see if your garage transmitter is of the Rolling Code type.
Page 382
3-7. Other interior features ■ Training a Rolling Code system (for U.S. owners) If your device is Rolling Code equipped, follow the steps under the ® heading “Training the HomeLink ” before proceeding with the steps listed below. Locate the learn button on the ceiling mounted garage door opener motor.
Page 383
HomeLink buttons. ■ Training other devices To train other devices such as home security systems, home door locks and lighting, contact your Toyota dealer for assistance. ■ Retraining a button ® The individual HomeLink buttons cannot be erased but can be ®...
Page 384
3-7. Other interior features ® Operating HomeLink ® ® Press the appropriate HomeLink button. The HomeLink indicator light should come on. ® The HomeLink compatible transceiver in your vehicle continues to send a signal for up to 20 seconds as long as the button is pressed. ®...
Page 385
3-7. Other interior features ■ Before training ● Install a new battery in the remote control transmitter. ● The battery side of the remote control transmitter must be pointed away ® from the HomeLink button. ■ Certification for the garage door opener FCC ID: NZLGHSHL4 For vehicles sold in the U.S.A.
Page 386
3-7. Other interior features ■ If the following message is displayed This message appears when training procedures have not been performed correctly. Follow the instructions on the screen to complete or cancel train- ing. Pattern A Pattern B ■ When support is necessary Visit on the web at www.homelink.com or call 1-800-355-3515.
3-7. Other interior features Compass The compass indicates the direction that the vehicle is heading. ■ Operation The compass points north for about 3 seconds after the engine switch is turned to the ON position, and then indi- cates the actual direction the vehicle facing.
Page 388
3-7. Other interior features Calibrating the compass Samoa: 5 Guam: 8 Saipan: 8 The direction display deviates from the true direction determined by the earth’s magnetic field. The amount of deviation varies according to the geographic position of the vehicle. If you cross over a map boundary shown in illustration, the compass will deviate.
Page 389
3-7. Other interior features After calibration, leave the system for 6 seconds or press the SET button for about 2 seconds. If the display returns to the outside temperature display, the calibra- tion is complete. ■ Circling calibration Stop the vehicle where it is safe to drive in a circle. Press the SET button until the zone number appears on the outside...
Page 390
3-7. Other interior features ■ Conditions unfavorable to correct operation The compass may not show the correct direction in the following conditions: ● The vehicle is stopped immediately after turning. The compass does not adjust while the vehicle is stopped. ●...
Page 391
3-7. Other interior features NOTICE ■ To avoid the compass malfunctions Do not place magnets or any metal objects on or near the accessory meter. Doing this may cause a malfunction of the compass sensor. ■ To ensure normal operation of the compass ●...
Maintenance and care 4-1. Maintenance and care Cleaning and protecting the vehicle exterior..394 Cleaning and protecting the vehicle interior..397 4-2. Maintenance Maintenance requirements ....400 General maintenance..402 Emission inspection and maintenance (I/M) programs......405 4-3. Do-it-yourself maintenance Do-it-yourself service precautions ....
4-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condition. ● Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
Page 395
4-1. Maintenance and care ■ Aluminum wheels (if equipped) ● Remove any dirt immediately by using a neutral detergent. Do not use hard brushes or abrasive cleaners. Do not use strong or harsh chemical cleaners. Use the same mild detergent and wax as used on the paint. ●...
Page 396
4-1. Maintenance and care NOTICE ■ To prevent paint deterioration and corrosion on the body and compo- nents (aluminum wheels etc.) ● Wash the vehicle immediately in the following cases: • After driving near the sea coast • After driving on salted roads •...
4-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle’s interior and keep it in top condition: ■ Protecting the vehicle interior Remove dirt and dust using a vacuum cleaner. Wipe dirty sur- faces with a cloth dampened with lukewarm water.
Page 398
4-1. Maintenance and care ■ Caring for leather areas Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle’s interior. ■ Shampooing the carpets There are several commercial foaming-type cleaners available. Use a sponge or brush to apply the foam.
Page 399
4-1. Maintenance and care NOTICE ■ Cleaning detergents ● Do not use organic substances such as benzene or gasoline, acidic or alkaline solutions, dye, bleach or other detergent. Doing so may discolor the vehicle interior or cause streaks or damage to painted surfaces. ●...
■ Repair and replacement It is recommended that genuine Toyota parts be used for repair to ensure performance of each system. If non-Toyota parts are used in replacement or if a repair shop other than Toyota dealer performs repairs, confirm the war-...
Page 401
000000. If the system fails to reset, the light will continue flashing. ■ Allow inspection and repairs to be performed by a Toyota dealer ● Toyota technicians are well-trained specialists and are kept up to date with the latest service information. They are well informed about the operations of all systems on your vehicle.
“Scheduled Maintenance Guide” or “Owner’s Manual Supplement”. It is recommended that any problem you notice should be brought to the attention of your Toyota dealer or qualified service shop for advice. Engine compartment Items...
Page 403
4-2. Maintenance Vehicle interior Items Check points • Moves smoothly (without uneven Accelerator pedal pedal effort or catching)? • Can the vehicle be held securely Automatic transmission “Park” on an incline with the shift lever in mechanism • Moves smoothly? •...
Page 404
4-2. Maintenance Items Check points • Moves smoothly? Steering wheel • Has correct free play? • No strange noises? Vehicle exterior Items Check points Door • Operate smoothly? Engine hood • The lock system works properly? • Is there any leakage after park- Fluid leaks ing? •...
If the malfunction indicator lamp comes on The OBD system determines that a problem exists somewhere in the emission control system. Your vehicle may not pass the I/ M test and may need to be repaired. Contact your Toyota dealer to service the vehicle. ■...
• SAE J1703 or FMVSS No.116 Brake fluid level (P. 417) DOT 3 brake fluid • Rag or paper towel • “Toyota Super Long Life Coolant” or similar high quality ethylene glycol based non-silicate, non- amine, non-nitrite and non-borate coolant with long-life hybrid organic acid technology.
Page 407
4-3. Do-it-yourself maintenance Items Parts and tools • Bulb with same number and watt- Light bulbs (P. 456) age rating as original • Phillips-head screwdriver • Automatic transmission fluid Power steering fluid level ® DEXRON II or III (P. 419) •...
Page 408
4-3. Do-it-yourself maintenance CAUTION The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized. To avoid death or serious injury observe the following precautions. ■ When working on the engine compartment ● Keep hands, clothing, and tools away from the moving fan and engine drive belt.
Page 409
4-3. Do-it-yourself maintenance NOTICE ■ If you remove the air cleaner Driving with the air cleaner removed may cause excessive engine wear due to dirt in the air. ■ If the fluid level is low or high It is normal for the brake fluid level to go down slightly as the brake pads wear or when the fluid level in the accumulator is high.
4-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood lock release lever. The hood will pop up slightly. Pull up the hood catch lever and lift the hood. CAUTION ■...
Page 412
4-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. ■ Checking the engine oil Park the vehicle on level ground. After warming up the engine and turning it off, wait more than 5 minutes for the oil to drain back into the bottom of the engine.
Page 413
4-3. Do-it-yourself maintenance ■ Adding engine oil If the oil level is below or near the low level mark, add engine oil of the same type as already in the engine. Make sure to check the oil type and prepare the items needed before adding oil.
Page 414
Dispose of used oil and filters only in a safe and acceptable manner. Do not dispose of used oil and filters in household trash, in sewers or onto the ground. Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal.
Page 415
4-3. Do-it-yourself maintenance NOTICE ■ To prevent serious engine damage Check the oil level on regular basis. ■ When replacing the engine oil ● Be careful not to spill engine oil on the vehicle components. ● Avoid overfilling, as the engine could be damaged. ●...
Page 416
If the coolant level drops within a short time after replenishing Visually check the radiator, hoses, reservoir cap, radiator cap, drain cock and water pump. If you cannot find a leak, have your Toyota dealer pressure test the cap and check for leaks in the cooling system. ■...
Page 417
Radiator and condenser Check the radiator and condenser and clear any foreign objects. If either of the above parts are extremely dirty or you are not sure of their condition, have your vehicle checked by your Toyota dealer. CAUTION ■...
Page 418
4-3. Do-it-yourself maintenance ■ Brake fluid can absorb moisture from the air Excess moisture in the fluid can cause a dangerous loss of braking effi- ciency. Use only newly opened brake fluid. CAUTION ■ When filling the reservoir Take care because brake fluid can harm your hands or eyes and damage painted surfaces.
Page 419
4-3. Do-it-yourself maintenance Power steering fluid ■ Fluid level The fluid level should be within the appropriate range. Full (when cold) Add fluid (when cold) Full (when hot) Add fluid (when hot) Hot: Vehicle has been driven around 50 mph (80 km/h) for 20 minutes, or slightly longer in frigid temperatures.
Page 420
4-3. Do-it-yourself maintenance CAUTION ■ Checking the fluid level Take care, as the reservoir may be hot. NOTICE ■ When adding fluid Avoid overfilling, or the power steering may be damaged. ■ After replacing the reservoir cap Check the steering box case, vane pump and hose connections for leaks or damage.
Page 421
4-3. Do-it-yourself maintenance ■ Checking battery fluid Check that the level is between the upper line and the lower line. Upper line Lower line If the fluid level is at or below the lower line, add distilled water. ■ Adding distilled water O.K.
Page 422
4-3. Do-it-yourself maintenance CAUTION ■ Chemicals in the battery A battery contains poisonous and corrosive sulfuric acid and may produce hydrogen gas which is flammable and explosive. To reduce the risk of death or serious injury, take the following precautions while working on or near bat- tery: ●...
Page 423
4-3. Do-it-yourself maintenance NOTICE ■ When recharging the battery Never recharge the battery while the engine is running. Also, be sure all accessories are turned off. ■ When adding distilled water Avoid overfilling. Water spilled during battery recharging may cause corro- sion.
Page 424
4-3. Do-it-yourself maintenance CAUTION ■ When refilling the washer fluid Do not refill the washer fluid when the engine is hot or running, as the washer fluid contains alcohol and may catch fire if spilled on the engine etc. NOTICE ■...
■ The tire pressure warning system Your Toyota is equipped with a tire pressure warning system that uses tire pressure warning valves and transmitters to detect low tire inflation pressure before serious problems arise. (P. 477)
Page 426
ID codes must be registered in the tire pressure warning computer and tire pressure warning system must be initialized. Have tire pressure warning valve and transmitter ID codes registered by your Toyota dealer. (P. 427) Initializing the tire pressure warning system ■...
Page 427
The tire pressure warning valve and transmitter is equipped with a unique ID code. When replacing a tire pressure warning valve and transmitter, it is necessary to register the ID code of tire pressure warning valve and transmitter. Have the ID code registered by your Toyota dealer.
Page 428
● A tire goes flat repeatedly or cannot be properly repaired due to the size or location of a cut or other damage If you are not sure, consult with your Toyota dealer. ■ Replacing tires and wheels If the ID code of the tire pressure warning valve and transmitter is not registered, the tire pressure warning system will not work properly.
Page 429
4-3. Do-it-yourself maintenance ■ Tire types 1 Summer tires Summer tires are high-speed performance tires best suited to highway driving under dry conditions. Since summer tires do not have the same traction performance as snow tires, summer tires are inadequate for driving on snow-covered or icy roads.
Page 430
Initialization can be completed in a few minutes. However, in the follow- ing cases, the settings have not been recorded and the system will not operate properly. If repeated attempts to record tire inflation pressure settings are unsuccessful, have the vehicle inspected by your Toyota dealer. ●...
Page 431
Do not mix tires of different makes, models or tread patterns. Also, do not mix tires of remarkably different treadwear. ● Do not use tire sizes other than those recommended by Toyota. ● Do not mix differently constructed tires (radial, bias-belted or bias-ply tires).
Page 432
When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer or other qualified service shop as soon as possible. Make sure to replace the tire pressure warning valve and transmitter when replacing the tire.
4-3. Do-it-yourself maintenance Tire inflation pressure ■ Tire inflation pressure The recommended cold tire inflation pressure and tire size is dis- played on the tire and loading information label. (P. 521)
Page 434
4-3. Do-it-yourself maintenance ■ Inspection and adjustment procedure Tire valve Tire pressure gauge Remove the tire valve cap. Press the tip of the tire pressure gauge onto the tire valve. Read the pressure using the graduations of the gauge. If the tire inflation pressure is not within the recommended levels, adjust inflate the tire.
Page 435
Reduced driving comfort and tire life ● Reduced safety ● Damage to the drive train If a tire needs frequent refilling, have it checked by your Toyota dealer. ■ Instructions for checking tire inflation pressure When checking tire inflation pressure, observe the following: ●...
Page 436
4-3. Do-it-yourself maintenance CAUTION ■ Proper inflation is critical to save tire performance Keep your tires properly inflated. Otherwise, the following conditions may occur and result in an accident causing death or serious injury. ● Excessive wear ● Uneven wear ●...
● Bent wheels that have been straightened ■ Aluminum wheel precautions (if equipped) ● Use only Toyota wheel nuts and wrench designed for use with your aluminum wheels. ● When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1000 miles (1600 km).
Page 438
4-3. Do-it-yourself maintenance ■ When replacing wheels The wheels of your Toyota are equipped with tire pressure warning valves and transmitters that allow the tire pressure warning system to provide advanced warning in the event of a loss in tire inflation pressure.
Page 439
Because tire repair or replacement may affect the tire pressure warn- ing valves and transmitters, make sure to have tires serviced by your Toyota dealer or other qualified service shop. In addition, make sure to purchase your tire pressure warning valves and transmitters at your Toyota dealer.
4-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be changed regularly to maintain air conditioning efficiency. ■ Removal method Turn the engine switch off. Open the glove box. Slide off the damper. Push in each side of the glove box to disconnect the upper claws.
Page 441
4-3. Do-it-yourself maintenance Remove the filter case. ■ Replacement method Remove the air conditioning filter and replace it with a new one. The“UP” marks shown on the filter should be pointing up. ■ Checking interval Inspect and replace the air conditioning filter according to the maintenance schedule.
Page 442
4-3. Do-it-yourself maintenance NOTICE ■ When using the air conditioning system Make sure that a filter is always installed. Using the air conditioning system without a filter may cause damage to the system.
4-3. Do-it-yourself maintenance Key battery Replace the battery with a new one if it is discharged. ■ You will need the following items: ● Small Phillips-head screwdriver ● Lithium battery CR2016 ■ Replacing the battery Remove the screw and cover. Push the cover in the arrow direction.
Page 444
● The operational range is reduced. ■ Use a CR2016 lithium battery ● Batteries can be purchased at your Toyota dealer, jewelers, or camera stores. ● Replace only with the same or equivalent type recommended by your Toyota dealer. ●...
4-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as necessary. Turn the engine switch off. The fuses are located in the following places. To check the fuses, follow the instructions below.
Page 446
4-3. Do-it-yourself maintenance ■ Under the instrument panel Remove the lid. After a system failure, see “Fuse layout and amperage rat- ings” (P. 449) for details about which fuse to check.
Page 447
4-3. Do-it-yourself maintenance Remove the fuse with the pull- out tool.
Page 448
4-3. Do-it-yourself maintenance Check if the fuse has blown. Type A Normal fuse Blown fuse Replace it with one of an appropriate amperage rating. The amperage rating can be found on the fuse box lid. Type B Normal fuse Blown fuse Replace it with one of an appropriate amperage rating.
Page 449
4-3. Do-it-yourself maintenance Fuse layout and amperage ratings ■ Engine compartment Type A Type B (if equipped)
Page 450
4-3. Do-it-yourself maintenance Fuse Ampere Circuit SPARE 10 A Spare fuse SPARE 15 A Spare fuse TOWING TAIL 15 A Trailer lights RR FOG 10 A No circuit OFFROAD LP 15 A Offroad lamp Stop lights, high mounted stop- light, anti-lock brake system, trac- tion control system, active traction control system, vehicle stability STOP...
Page 451
4-3. Do-it-yourself maintenance Fuse Ampere Circuit Interior light, personal lights, DOME 10 A engine switch light, clock, acces- sory meter, meter and gauge RADIO NO.1 20 A Audio system Air conditioning system, multiplex communication system, SRS air- ECU-B 10 A bag system, front passenger occu- pant classification system, garage door opener, Crawl Control system...
Page 452
4-3. Do-it-yourself maintenance Fuse Ampere Circuit Anti-lock brake system, vehicle sta- bility control system, traction con- ABS MTR 40 A trol system, active traction control system, AUTO LSD system IGN and GAUGE, multiport fuel injection system/sequential multi- 30 A port fuel injection system, starting system Anti-lock brake system, vehicle sta- bility control system, traction con-...
Page 453
4-3. Do-it-yourself maintenance ■ Under the instrument panel 6 7 8 10 11 Fuse Ampere Circuit Multiport fuel injection system/ sequential multiport fuel injection system, anti-lock brake system, vehicle stability control system, 10 A traction control system, active trac- tion control system, AUTO LSD system, SRS airbag system, front passenger occupant classification system...
Page 454
4-3. Do-it-yourself maintenance Fuse Ampere Circuit Anti-lock brake system, vehicle sta- bility control system, traction con- trol system, active traction control system, AUTO LSD system, cruise ECU-IG 10 A control system, back door lock sys- tem, shift lock system, multiplex communication system, tire pres- sure warning system, Crawl Con- trol system...
Page 455
Never use a fuse of a higher amperage rating than indicated, or use any other object in place of a fuse. ● Always use a genuine Toyota fuse or equivalent. Never replace a fuse with a wire, even as a temporary fix. ●...
You may replace the following bulbs yourself. The difficulty level of replacement varies depending on the bulb. If necessary bulb replacement seems difficult to perform, contact your Toyota dealer. For more information about replacing other light bulbs, contact your Toyota dealer.
Page 457
4-3. Do-it-yourself maintenance ■ Rear bulb locations Stop/tail and rear side marker lights Back-up lights Rear turn signal lights License plate lights Replacing light bulbs ■ Headlights and daytime running lights Unplug the connector.
Page 458
4-3. Do-it-yourself maintenance Remove the rubber cover. Release bulb retaining spring. Remove the bulb. To install a new bulb, align the tabs of the bulb with the cutouts of the mounting hole.
Page 459
4-3. Do-it-yourself maintenance ■ Front turn signal/parking and front side marker lights Turn the bulb base counterclock- wise. Remove the light bulb.
Page 460
4-3. Do-it-yourself maintenance ■ Back-up lights, stop/tail and rear side marker and rear turn signal light bulbs ● Removing the sub woofer speaker (vehicles with sub woofer) Remove the speaker cover. Remove the cover. Installing the sub woofer speaker (P. 463) Remove the sub woofer speaker.
Page 461
4-3. Do-it-yourself maintenance ● Removing the back-up, stop/tail and rear side marker and rear turn signal light bulbs Open the back door and remove the cover. Using a flathead screwdriver or equivalent which is wrapped with a cloth. Turn the bulb bases counter- clockwise.
Page 462
Remove the light bulb. ■ Lights other than the above If any of the lights listed below has burnt out, have it replaced by your Toyota dealer. • Outside rear view mirror illumination lights (if equipped) • High mounted stoplight...
Page 463
LED high mounted stoplight The high mounted stoplight consists of a number of LEDs. If any of the LEDs burn out, take your vehicle to your Toyota dealer to have the light replaced. ■ Installing the sub woofer speaker (vehicles with sub woofer) Install the rubber inside the panel as shown in the illustration.
When trouble arises 5-1. Essential information 5-2. Steps to take in an emergency Emergency flashers ..466 If a warning light turns If your vehicle needs on or a warning buzzer to be towed ....467 sounds......474 If you think something If you have a flat tire..
5-1. Essential information Emergency flashers Use the emergency flashers if the vehicle malfunctions or is involved in an accident. Press the switch to flash all the turn signal lights. To turn them off, press the switch once again. NOTICE ■ To prevent battery discharge Do not leave the emergency flashers on longer than necessary when the engine is not running.
If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your Toyota dealer or a commercial towing service, using a lift-type truck or a flat bed truck. Use a safety chain system for all towing, and abide by all state/pro- vincial and local laws.
Page 468
5-1. Essential information ■ Emergency towing procedure The engine switch must be in the ACC (engine off) or the ON (engine running) position. 4WD models with an automatic transmission: Shift the front-wheel drive control lever in H2. 4WD models with a manual transmission: Unlock the center differ- ential.
Page 469
5-1. Essential information Towing with a sling-type truck NOTICE ■ To prevent body damage Do not tow with a sling-type truck, either from the front or rear. Towing with a wheel lift-type truck from the front Use a towing dolly under the rear wheels.
Page 470
5-1. Essential information Towing with a wheel lift-type truck from the rear 2WD models Turn the engine switch to the ACC position. 4WD models Vehicles with an automatic trans- mission: When not using a tow- ing dolly, turn the engine switch to the ACC position, shift the shift lever to N and shift the front- wheel drive control lever in H2.
Page 471
5-1. Essential information Using a flat bed truck If your Toyota is transported by a Front flat bed truck, it should be tied down at the locations shown in the illustration. If you use chains or cables to tie down your vehicle, the angles shaded in black must be 45.
5-1. Essential information If you think something is wrong If you notice any of the following symptoms, your vehicle probably needs adjustment or repair. Contact your Toyota dealer as soon as possible. ■ Visible symptoms ● Fluid leaks under the vehicle (Water dripping from the air conditioning after use is normal.)
5-1. Essential information Fuel pump shut off system To minimize the risk of fuel leakage when the engine stalls or an air- bag inflates upon collision, the fuel pump shut off system stops sup- plying fuel to the engine. Follow the procedure below to restart the engine after the system is activated.
Stop the vehicle immediately. Continuing to drive the vehicle may be dangerous. The following warning indicates a possible problem in the brake sys- tem. Immediately stop the vehicle in a safe place and contact your Toyota dealer. Warning light Warning light/Details Brake system warning light •...
Page 475
Have the vehicle inspected immediately. Failing to investigate the cause of the following warnings may lead to the system operating abnormally and possibly cause an accident. Have the vehicle inspected by your Toyota dealer immediately. Warning light Warning light/Details Malfunction indicator lamp Indicates a malfunction in: (U.S.A.)
Page 476
5-2. Steps to take in an emergency Warning light Warning light/Details SRS warning light Indicates a malfunction in: • The SRS airbag system; • The front passenger occupant classification system; • The seat belt pretensioner system. ABS warning light (U.S.A.) Indicates a malfunction in: •...
Page 477
(Automatic may start the vehicle transmission again. If the light does vehicles) not go off, contact your Toyota dealer. When the light flashes: Have the system Indicates a malfunction in checked by your Toyota the automatic transmis- dealer. sion system.
Page 478
Toyota dealer. When the light comes Have the system on after blinking for 1 checked by your Toyota minute: Malfunction in dealer. the tire pressure warn- ing system (P. 481) Low fuel level warning light Refuel the vehicle.
Page 479
5-2. Steps to take in an emergency Warning light Warning light/Details Correction procedure Maintenance required reminder light Indicates that mainte- nance is required accord- ing to the driven distance on the maintenance schedule. Illuminates for about 3 seconds and then flashes for about 15 seconds If necessary, perform approximately 4500 miles...
Page 480
Is the fuel tank cap loose? If it is, tighten it securely. The light will go off after taking several driving trips. If the light does not go off even after several trips, contact your Toyota dealer as soon as possible. ■...
Page 481
If there is a lot of snow or ice on the vehicle, in particular around the wheels or wheel housings. ● If non-genuine Toyota wheels are used. (Even if you use Toyota wheels, the tire pressure warning system may not work properly with some types of tires.) ●...
Page 482
Check the tires. If the tire is flat, change to the spare tire and have the flat tire repaired by the nearest Toyota dealer. ● Avoid abrupt maneuvering and braking. If the vehicle tires deteriorate, you could lose control of the steering wheel or the brakes.
Page 483
5-2. Steps to take in an emergency CAUTION ■ Maintenance of the tire Please note that the TPMS (tire pressure warning system) is not a sub- stitute for proper tire maintenance, and it is the driver’s responsibility to maintain correct tire pressure, even if under-inflation has not reached the level to trigger illumination of the TPMS low tire pressure telltale (tire pressure warning light).
5-2. Steps to take in an emergency If you have a flat tire Remove the flat tire and replace it with the spare provided. ■ Before jacking up the vehicle ● Stop the vehicle on a hard, flat surface. ● Set the parking brake. ●...
Page 485
5-2. Steps to take in an emergency Taking out the jack and tool bag Remove the cover and loosen the strap. Loosen and remove the jack. Tighten Loosen Taking out the spare tire Remove the bolt cover. Bolt cover...
Page 486
5-2. Steps to take in an emergency Remove the bolt which fixes the spare wheel cover using the wrench in the tool bag (P. 484). Remove the spare wheel cover. Turn the hold-down nuts counter- clockwise with the wheel nut wrench and remove them.
Page 487
5-2. Steps to take in an emergency Replacing a flat tire Chock the tires. Wheel Flat tire chock positions Behind the Left- rear right- hand hand side side tire Front Behind the Right- rear left- hand hand side side tire In front of Left- the front...
Page 488
5-2. Steps to take in an emergency Remove the wheel ornament using the remover as shown. To protect the wheel and wheel ornament, place a rag between the remover and the wheel ornament, as shown in the illustration. Aluminum wheel Steel wheel Slightly loosen the wheel nuts (one turn).
Page 489
5-2. Steps to take in an emergency Assembling the jack handle. Remove the jack handle, jack handle extension bar and jack han- dle bar from the tool bag and assemble by following these steps. Loosen the bolts and the screw using either the jack handle or a screwdriver.
Page 490
5-2. Steps to take in an emergency Position the jack at the correct jack point as shown. Front Rear Make sure the jack is positioned on a level and solid place. Front Raise the vehicle until the tire is slightly raised off the ground. When positioning the jack under the rear axle housing, make sure the groove on the top of...
Page 491
5-2. Steps to take in an emergency Installing the tire Remove any dirt or foreign mat- ter from the wheel contact sur- face. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, and the tire may come off the vehicle.
Page 492
5-2. Steps to take in an emergency Lower the vehicle. Firmly tighten each nut two or three times in the order shown in the illustration. Tightening torque: 83 ft·lbf (113 N·m, 11.5 kgf·m) Reinstall the wheel ornament. Aluminum wheel...
Page 493
5-2. Steps to take in an emergency Steel wheel Stowing the flat tire, jack and all tools Install the flat tire in the reverse order of removal. Tightening torque: 44 ft·lbf (60 N·m, 6.1 kgf·m) Install the spare wheel cover in the reverse order of removal.
Page 494
5-2. Steps to take in an emergency CAUTION ■ Using the jack Improper use of the jack may lead to death or serious injury due to the vehicle suddenly falling off the jack. ● Do not use the jack for any purpose other than replacing tires or install- ing and removing tire chains.
Page 495
• If there are any cracks or deformations in the bolt screws, nut threads or bolt holes of the wheel, have the vehicle inspected by your Toyota dealer. • When installing the wheel nuts, be sure to install them with the...
Page 496
When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer or other qualified service shop as soon as possible. Make sure to replace the tire pressure warning valve and transmitter when replacing the tire.
One of the following may be the cause of the problem. ● One or both of the battery terminals may be disconnected. ● The battery may be discharged. (P. 500) Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown.
(a system to prevent accidental operation of the shift lever). Have the vehicle inspected by your Toyota dealer immediately. The following steps may be used as an emergency measure to ensure that the shift lever can be shifted.
5-2. Steps to take in an emergency If you lose your keys New genuine Toyota keys can be made by your Toyota dealer using one of the master keys and the key number stamped on your key number plate. (P. 30) ■...
You can call your Toyota dealer or qualified repair shop. If you have a set of jumper (or booster) cables and a second vehi- cle with a 12-volt battery, you can jump start your Toyota following the steps below. Connecting the jumper cables...
Page 501
Once the vehicle’s engine has started, remove the jumper cables in the exact reverse order in which they were con- nected. Once the engine starts, have the vehicle checked at your Toyota dealer as soon as possible. ■ Starting the engine when the battery is discharged (vehicles with an automatic transmission) The engine cannot be started by push-starting.
Page 502
5-2. Steps to take in an emergency CAUTION ■ To avoid battery fires or explosions Observe the following precautions to prevent accidentally igniting the flam- mable gas that may be emitted from the battery. ● Make sure the jumper cable is connected to the correct terminal and that it is not unintentionally in contact with any part other than the intended termi- nal.
Page 503
5-2. Steps to take in an emergency NOTICE ■ To prevent damaging the vehicle (vehicles with a manual transmission) Do not pull- or push-start the vehicle, because the three-way catalytic con- verter may overheat and become a fire hazard. ■ When handling jumper cables Be careful that the jumper cables do not become tangled in the cooling fan or any of the belts when connecting or disconnecting them.
(radia- tor) for any leaks. Radiator Cooling fan If a large amount of coolant leaks, immediately contact your Toyota dealer. The coolant level is satisfactory if it is between the F (Full) and L (Low) lines on the reservoir.
Page 505
If the fan is not operating: Stop the engine immediately and contact your Toyota dealer. If the fan is operating: Have the vehicle inspected at the nearest Toyota dealer. CAUTION ■ To prevent an accident or injury when inspecting under the hood of your vehicle ●...
Page 506
5-2. Steps to take in an emergency NOTICE ■ When adding engine coolant Wait until the engine has cooled down before adding engine coolant. When adding coolant, do so slowly. Adding cool coolant to a hot engine too quickly can cause damage to the engine. ■...
5-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt, or snow. Stop the engine. Set the parking brake and put the shift lever in P (automatic transmission) or N (manual transmis- sion).
Page 508
5-2. Steps to take in an emergency CAUTION ■ When attempting to free a stuck vehicle If you choose to rock the vehicle back and forth to free it, make sure the sur- rounding area is clear, to avoid striking other vehicles, objects or persons. The vehicle may also lunge forward or lunge back suddenly as it becomes free.
5-2. Steps to take in an emergency If your vehicle has to be stopped in an emergency Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way, stop the vehicle using the following pro- cedure: Steadily step on the brake pedal with both feet and firmly depress it.
Page 510
5-2. Steps to take in an emergency CAUTION ■ If the engine has to be turned off while driving ● Power assist for the brakes and steering wheel will be lost, making the brake pedal harder to depress and the steering wheel heavier to turn. Decelerate as much as possible before turning off the engine.
6-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions and weights Overall length 183.9 in. (4670 mm) Overall width 75.0 in. (1905 mm) 2WD models 71.3 in. (1810 mm) Overall height 4WD models 72.0 in. (1830 mm) Wheelbase 105.9 in. (2690 mm) Front tread 63.2 in.
Page 513
Vehicle identification number The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle. This number is stamped on the top left of the instrument panel.
Page 514
6-1. Specifications ■ Engine number The engine number is stamped on the engine block as shown. Engine Model 1GR-FE Type 6-cylinder V type, 4-cycle, gasoline 3.70 3.74 in. (94.0 95.0 mm) Bore and stroke Displacement 241.4 cu.in. (3956 cm Drive belt tension Automatic adjustment Valve clearance...
Page 515
■ Engine oil selection “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following grade and viscosity. Oil grade: ILSAC GF-5 multigrade engine oil...
Page 516
10.4 qt. (9.8 L, 8.6 Imp.qt.) Capacity Vehicles with a manual transmission 9.9 qt. (9.4 L, 8.3 Imp.qt.) Use either of the following. • “Toyota Super Long Life Coolant” • Similar high-quality ethylene glycol-based Coolant type non-silicate, non-amine, non-nitrite, and non-borate coolant with long-life hybrid organic acid technology Do not use plain water alone.
Page 517
6-1. Specifications Ignition system Spark plug Make DENSO SK16HR11 0.043 in. (1.1 mm) NOTICE ■ Iridium-tipped spark plugs Use only iridium-tipped spark plugs. Do not adjust gap when tuning engine. Electrical system Battery 12.6 12.8 V Fully charged Open voltage at 12.2 ...
Page 518
Rear 75W-85 GL-5 or equivalent : Your Toyota vehicle is filled with “Toyota Genuine Differential Gear Oil” at the factory. Use Toyota approved “Toyota Genuine Differential Gear Oil” or an equivalent of matching quality to satisfy the above specification. Please contact your Toyota dealer for further details.
Page 519
Recommended oil viscosity SAE 75W : Your Toyota vehicle is filled with “Toyota Genuine Transfer Gear oil LF” at the factory. Use Toyota approved “Toyota Genuine Transfer Gear oil LF” or an equivalent of matching quality to satisfy the above specification. Please...
Page 520
6-1. Specifications Brakes Pedal clearance 2.1 in. (54 mm) Min. 0.04 0.24 in. (1 6 mm) Pedal free play Brake pad wear limit 0.04 in. (1.0 mm) Parking brake lining wear limit 0.04 in. (1.0 mm) Parking brake lever travel 5 —...
Page 521
6-1. Specifications Steering Free play Less than 1.2 in. (30 mm) ® Automatic transmission fluid DEXRON II or Power steering fluid type Tires and wheels Tire size P265/70R17 113S Front tires: 32 psi (220 kPa, 2.2 kgf/cm or bar) Tire inflation pressure Rear tires: (Recommended cold tire 32 psi (220 kPa, 2.2 kgf/cm...
Page 522
6-1. Specifications Light bulbs Light Bulbs Bulb No. Type Headlights and daytime running — 60/55 lights Front turn signal/parking and front — 21/5 side marker lights Outside rear view mirror illumination — Exterior lights Rear turn signal lights — Stop/tail and rear side marker lights 7443 21/5 Back-up lights...
ASTM D4814 in the U.S.A. and CGSB3.5-M93 in Canada. ■ Fuel tank opening for unleaded gasoline To help prevent incorrect fueling, your Toyota has a fuel tank opening that only accommodates the special nozzle on unleaded fuel pumps. ■...
Page 524
10% ethanol). (85% ethanol) ● If you use gasohol in your Toyota, be sure that it has an octane rating no lower than 91. ● Toyota does not recommend the use of gasoline containing methanol.
Page 525
(Methylcyclopentadienyl Manganese Tricarbonyl). Toyota does not recommend the use of gasoline that contains MMT. If fuel containing MMT is used, your emission control system may be adversely affected. The malfunction indicator lamp on the instrument cluster may come on. If this happens, contact your Toyota dealer for service.
6-1. Specifications Tire information Typical tire symbols Tire size (P. 528) DOT and Tire Identification Number (TIN) (P. 527) Location of treadwear indicators (P. 425) Tire ply composition and materials Plies are layers of rubber-coated parallel cords. Cords are the strands which form the plies in a tire.
Page 527
6-1. Specifications Radial tires or bias-ply tires A radial tire has RADIAL on the sidewall. A tire not marked RADIAL is a bias-ply tire. Summer tire or all season tire (P. 429) An all season tire has M+S on the sidewall. A tire not marked M+S is a summer tire.
Page 528
6-1. Specifications Tire size ■ Typical tire size information The illustration indicates typical tire size. Tire use (P = Passenger car, T = Temporary use) Section width (millimeters) Aspect ratio (tire height to section width) Tire construction code (R = Radial, D = Diagonal) Wheel diameter (inches) Load index (2 digits or 3 digits) Speed symbol...
Page 529
U.S.A. Department of Transportation. It provides the purchasers and/or prospective purchasers of Toyota vehicles with information on uniform tire quality grading. Your Toyota dealer will help answer any questions you may have as you read this information. ■ DOT quality grades All passenger vehicle tires must conform to Federal Safety Requirements in addition to these grades.
Page 530
6-1. Specifications ■ Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded 150 would wear one and a half (1 - 1/2) times as well on the government course as a tire graded 100.
Page 531
6-1. Specifications Warning: The temperature grades for this tire are established for a tire that is properly inflated and not overloaded. Excessive speed, underinflation, or excessive loading, either separately or in combination, can cause heat buildup and possible tire failure. Glossary of tire terminology Tire related term Meaning...
Page 532
6-1. Specifications Tire related term Meaning 150 lb. (68 kg) times the number of occupants Normal occupant specified in the second column of Table 1 that weight follows Distribution of occupants in a vehicle as Occupant distribution specified in the third column of Table 1 below The combined weight of installed regular production options weighing over 5 lb.
Page 533
6-1. Specifications Tire related term Meaning The surface area of the rim not covered by the Weather side inflated tire The part of the tire that is made of steel wires, Bead wrapped or reinforced by ply cords and that is shaped to fit the rim A breakdown of the bond between components Bead separation...
Page 534
6-1. Specifications Tire related term Meaning The parting of the innerliner from cord material Innerliner separation in the carcass (a)The sidewall that contains a whitewall, bears white lettering, or bears manufacturer, brand, and/or model name molding that is higher or deeper than the same molding on Intended outboard the other sidewall of the tire, or sidewall...
Page 535
6-1. Specifications Tire related term Meaning A layer of rubber-coated parallel cords A parting of rubber compound between Ply separation adjacent plies A mechanical device made of rubber, chemicals, fabric and steel or other materials, Pneumatic tire that, when mounted on an automotive wheel, provides the traction and contains the gas or fluid that sustains the load A pneumatic tire in which the ply cords that...
Page 536
6-1. Specifications Tire related term Meaning That portion of a tire that comes into contact Tread with the road A tread section running circumferentially Tread rib around a tire Tread separation Pulling away of the tread from the tire carcass The projections within the principal grooves Treadwear indicators designed to give a visual indication of the...
Programming these preferences requires specialized equipment and may be performed by an autho- rized Toyota dealership. Some function settings are changed simultaneously with other functions being customized. Contact your Toyota dealer for further details. Customized Item Function...
Page 538
6-2. Customization Customized Item Function Default setting setting Automatic Time elapsed before 0 seconds light off sys- headlights automati- 60 seconds 30 seconds cally turn off after doors 90 seconds (P. 148) are closed 7.5 seconds Time elapsed before 15 seconds lights turn off 30 seconds Operation after the...
6-2. Customization Items to initialize The following items must be initialized for normal system operation in cases such as after the battery is reconnected, or maintenance is performed on the vehicle. Item When to initialize Reference After the maintenance is per- Maintenance data P.
For owners Reporting safety defects for U.S. owners ....542 Seat belt instructions for Canadian owners (in French) ..... 543 SRS airbag instructions for Canadian owners (in French) ..... 545...
If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Toyota Motor Sales, U.S.A., Inc. (Toll-free: 1-800-331-4331). If NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles, it may order a recall and remedy campaign.
Seat belt instructions for Canadian owners (in French) The following is a French explanation of seat belt instructions extracted from the seat belt section in this manual. See the seat belt section for more detailed seat belt instructions in English. Utilisation correcte des ceintures de sécurité...
Page 544
Entretien et soins ■ Ceintures de sécurité Avec un tissu ou une éponge, nettoyez à l’aide d’un savon doux et de l’eau tiède. Vérifiez aussi les ceintures régulièrement pour vous assurer qu’elles présentent d’usure excessive, d’effilochage ou de coupures. ATTENTION ■...
SRS airbag instructions for Canadian owners (in French) The following is a French explanation of SRS airbag instructions extracted from the SRS airbag section in this manual. See the SRS airbag section for more detailed SRS airbag instruc- tions in English. Coussins gonflables avant Coussin gonflable du conducteur/du passager avant Peut protéger la tête et la poitrine du conducteur et du passager...
Page 546
Composants du système de coussins gonflables Coussin gonflable du pas- Prétensionneurs et limit- sager avant eurs d’effort de ceintures de sécurité Coussins gonflables rideaux Capteurs de coussin gon- Coussins gonflables flable en rideau et latéraux latéraux Coussin gonflable du con- Système de classification ducteur d’occupant du siège pas-...
Page 547
Module de capteur de cous- Capteurs de coussin gon- sin gonflable flable avant Votre véhicule est équipé de ADVANCED AIRBAGS (SACS DE SÉCURITÉ GONFLABLES ÉVOLUÉS), dont la conception est basée sur les normes de sécurité des véhicules automobiles américains (FMVSS208). L’ensemble de capteurs des sacs de sécurité gon- flables (ECU) contrôle le déploiement des sacs de sécurité...
Page 548
ATTENTION ■ Précautions relatives aux coussins gonflables SRS Observez les précautions suivantes en ce qui concerne les coussins gon- flables. Les négliger pourrait occasionner des blessures graves, voire mortelles. ● Le conducteur et tous les passagers du véhicule doivent porter leur cein- ture de sécurité...
Page 549
Un bébé ou un enfant trop petit pour utiliser une ceinture de sécurité doit être correctement retenu à l’aide d’un dispositif de retenue pour enfants. Toyota recommande vivement de placer et d’attacher cor- rectement tous les bébés et enfants sur les sièges arrière du véhicule à...
Page 550
ATTENTION ■ Précautions relatives aux coussins gonflables SRS ● N’installez jamais un dispositif de retenue pour enfants de type dos à la route sur le siège du passager avant, même si la lampe témoin AIR BAG OFF est allumée. En cas d’accident, la force et la vitesse de déploiement du coussin gonflable du passager avant sont telles qu’elles pourraient infliger à...
Page 551
ATTENTION ■ Précautions relatives aux coussins gonflables SRS ● Ne laissez personne s’agenouiller face à la portière sur le siège du passager ou sortir la tête ou les mains à l’extérieur du véhicule. ● Ne fixez et ne déposez rien sur des endroits tels que le tableau de bord ou le tampon de volant.
Page 552
SRS Ne mettez pas le véhicule au rebut et n’effectuez aucune des modifications suivantes sans d’abord consulter votre concessionnaire Toyota. Les coussins gonflables SRS pourraient fonctionner de manière incorrecte ou se déployer (gonfler) accidentellement, ce qui serait susceptible d’occa- sionner des blessures graves, voire mortelles.
Page 553
Désactivation des coussins gonflables rideau si le véhicule fait des tonneaux ON/OFF (maintenez enfoncé pendant quelques secondes) La lampe témoin RSCA OFF s’allume. (uniquement si le con- tacteur du moteur est en position ON.) La fonction de désactivation des coussins gonflables rideau et des dispositifs de tension des cein- tures de sécurité...
Abbreviation list Abbreviation/Acronym list ABBREVIATIONS MEANING Two Wheel Drive Four Wheel Drive Anti-Lock Brake System Accessory AI-SHIFT Artificial Intelligence shifting Automatic Locking Retractor A-TRAC Active Traction Control AUTO LSD Automatic Limited Slip Differential Child Restraint System English/U.S. Customary System and metric Electronic Control Unit Event Data Recorder Emergency Locking Retractor...
Page 557
Abbreviation list ABBREVIATIONS MEANING Tire Identification Number TPMS Tire Pressure Warning System TRAC Traction Control Treadwear indicators Trailer Weight Rating Vehicle Identification Number Vehicle Stability Control...
Alphabetical index Alphabetical index A/C..........236 Audio system ABS ...........196 Antenna....252, 293, 394 Access doors ......38 Audio input ......289 Accessory meter ......146 AUX port/USB port....289 Active traction control CD player ......255 system ........182 MP3/WMA disc ..... 263 Air conditioning filter....440 Optimal use......
Page 559
Alphabetical index Bottle holders ....353, 359 Child safety Brake assist ......196 Airbag precautions ....91 Brakes Battery precautions ..422, 502 Brake system warning Child restraint system....102 buzzer ....184, 186, 199 How your child should wear Brake system warning the seat belt ......62 light ........
Page 560
Alphabetical index Doors Emergency flashers Access doors......38 Switch ........466 Door glasses ......74 Engine Door lock ......32, 35 Compartment ......411 Open door warning light ..477 Engine switch......129 Side doors .......35 Exhaust gas ......125 Side mirrors......71 Hood ........410 Driver’s seat belt reminder How to start the engine ..
Page 561
Alphabetical index Floor mat........373 Garage door opener....379 Fluid Gas station information...572 Brake ........417 Gauges........140 Washer ......... 423 Glass hatch.........45 Four-wheel drive system Glove box......353, 354 Four-wheel drive control lever ........176 Hands-free phone system Front-wheel drive control (for cellular phone) ....313 lever ........
Page 562
Alphabetical index Jack Limited slip differential ... 185 Positioning the jack ....487 Load capacity....210, 512 Vehicle-equipped jack ...484 Lock steering column....66 Jack handle ......487 Luggage compartment features ........376 Luggage storage box ....375 Keyless entry......32 Keys Engine switch ......129 Maintenance If you lose your keys .....499 Do-it-yourself maintenance ...
Page 564
Alphabetical index Seat belts Shift lever Adjustment ......60 Automatic transmission..132 ALR .........62 Four-wheel drive ....176 Automatic Locking Retractor ...62 Front-wheel drive ....179 Child restraint system If the shift lever cannot be installation......106 shifted from P ..... 498 Cleaning and maintaining..398 Manual transmission .....
Page 565
Alphabetical index Storage feature......353 Tachometer.......140 Storage precautions ....206 Tail lights Stuck Replacing light bulbs .....456 If the vehicle becomes Switch........148 stuck........507 Wattage.........522 Sun visors Talk switch........318 Front ........361 Telephone switch.....318 Side ........361 Theft deterrent system Switch Engine immobilizer system ..79 Active traction control...
Page 566
Alphabetical index Tools .........484 Electronic engine control Total load capacity....210 system ........ 475 Towing Four-wheel drive system..475 Dinghy towing......232 Front passenger occupant Emergency towing....467 classification system... 475 Trailer towing......214 Front passenger’s seat belt... 477 TRAC .........196 Low brake fluid...... 474 Traction control system ..196 Low engine oil pressure ..
Page 567
Alphabetical index Wheels........437 Window glasses ....45, 74 Window lock switch ....74 Windows Power windows ...... 74 Rear window defogger ..243 Washer ......151, 153 Windshield wipers... 151, 153 Winter driving tips....211 Wireless remote control key Replacing the battery ...
What to do if... What to do if... If you have a flat tire P. 484 A tire punctures P. 497 If the engine will not start The engine does not start P. 79 Engine immobilizer system P. 500 If the vehicle battery is discharged If the shift lever cannot be shifted The shift lever cannot be P.
Page 569
What to do if... ■ Instrument cluster ■ Center panel...
Page 570
What to do if... ■Warning lights Brake system warning Unengaged “Park” light warning light P. 476 Cruise control indicator light P. 474 P. 476 Charging system warning Open door warning light light P. 475 P. 477 Low engine oil pressure Driver’s seat belt warning light reminder light...
Need help?
Do you have a question about the FJ Cruiser 2014 and is the answer not in the manual?
Questions and answers
