Polygroup Evergreen Classics TG70CH119P00 Manual

NEED HELP?
DO NOT RETURN TO STORE. PLEASE VISIT US AT:
www.polygroupstore.com OR +1 (888) 919-0070
TREE ASSEMBLY INSTRUCTIONS
Congratulations on purchasing your new tree from
This tree comes with Quick Set® technology - allowing you to set up your tree and light it up in minutes!
Carefully follow the instructions below on how to quickly and easily set up your new tree:
1. Choose a level surface near a wall outlet.
2. Assemble the tree stand (See Fig. A).
Fig. A - Tree Stand Assembly
Fig. B - Tree and Light Assembly
Section 1
3. Identify all tree sections (See Fig. B) by the sticker on them, and start assembling from bottom to top.
4. Open the protective cap of pole, and insert the pole into the stand. Allow all branches fall down into place. Check to make sure
that all wires are free from branch hinges.
5. Shape the tree section one branch at a time. Start with the tips closest to the pole and move outwards. Fan all the tips out in
alternating directions, and slightly upsweep them for a natural look (See Fig. C).
Fig. C
Top view
MODEL #: TG70CH119P00, TG76P4A52P07, TG90CH119P00
Polygroup®!
Click
Tree Top
Section 2
Side view
Pull apart the legs of the stand so that they
are snapped into an x-shape, place the tree
stand on a level surface.
To close the stand, press the metal button
and fold the legs together.
Do Not Tamper
Internal Parts
Open the
cap cover
Align both arrows in
a straight line before
sliding down to insert
Insert Green
Plug Adapter
Label Extension
Cord into Adapter
Into Wall
Outlet
1
*Electrical Rating For The Tree
(For Indoor Use Only)
Input: AC 120V, 60Hz, 0.83A
Output: DC 24V 2A
Controller: 24V 2A
