Presenza QR0302 Installation Manual And User's Manual

Under cabinet range hood

Advertisement

Quick Links

UNDER CABINET
RANGE HOOD
INSTALLATION GUIDE
AND USER MANUAL
Model No. QR0302

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QR0302 and is the answer not in the manual?

Questions and answers

Summary of Contents for Presenza QR0302

  • Page 1 UNDER CABINET RANGE HOOD INSTALLATION GUIDE AND USER MANUAL Model No. QR0302...
  • Page 2: Table Of Contents

    Table of Contents Table of Contents ......2 Maintenance ......Safety Information .
  • Page 3 Safety Information (continued) Cooking Safety Information WARNING: To reduce the risk of fire, use only metal 1 . Never leave the range hood unattended when in use . duct work . Never use plastic duct work . 2 . Never cook over open flames under the range hood. WARNING: To reduce the risk of fire or electric shock, 3 .
  • Page 4: Warranty

    Warranty ONE YEAR LIMITED WARRANTY A thorough inspection must be made before installation and any damage must be promptly reported . We will not be liable for failures or damage that could have been discovered or avoided by proper inspection and testing prior to installation . Conglom Kitchen &...
  • Page 5: Pre-Installation

    Pre-Installation TOOLS REQUIRED Measuring tape Level Utility knife Adjustable Pencil Duct tape wrench Flathead Needle nose Phillips screwdriver screwdriver pliers Hammer Electric drill Safety goggles Safety gloves HARDWARE INCLUDED NOTE: Parts not shown to actual size. Part Description Quantity Long tapping screw - (M5 mm x 12 mm) Short tapping screw - (M4 mm x 8 mm) CONGLOMKB .COM Please contact customer.service@conglomkb.com or 1-877-333-0098 for further assistance.
  • Page 6: Package Contents

    Pre-Installation (continued) PACKAGE CONTENTS Part Description Quantity Range hood (including filters) Damper (located inside the hood)
  • Page 7: Planning Installation

    Pre-Installation (continued) PLANNING INSTALLATION WARNING: Always wear safety goggles and gloves Number of people required: 2 or more during installation . Carefully check the range hood for damage and for missing parts prior to installation . If there is any damage or if you are missing parts, do not proceed with the installation .
  • Page 8 Pre-Installation (continued) FOLLOW THESE GUIDELINES WHEN INSTALLING DUCT WORK: - Your venting system must vent to the outdoors either horizontally through the back wall (13) or vertically through the roof (14) (refer to Fig . 5/Fig . 6/Fig . 7) . - Use round metal duct work with a uniform diameter of 6 in .
  • Page 9 Pre-Installation (continued) WIRING CONNECTION REQUIREMENTS DANGER: Risk of electrical shock . This range hood Installation work and electrical wiring must be done by a qualified must be properly grounded . person(s) in accordance with all applicable codes and standards, including fire-rated construction. OBSERVE ALL GOVERNING CODES AND ORDINANCES WARNINGS DANGER: Turn off the power circuit breaker or the power switch on the junction box before installing this...
  • Page 10: Installation

    Installation REMOVING THE ELECTRICAL KNOCK-OUT HOLE REMOVING THE VENTING HOLE - Choose the venting hole to remove for your installation WARNING: Always wear safety goggles and gloves type . Use the top hole (3) for a top venting installation and during installation .
  • Page 11 Installation (continued) INSTALLING THE RANGE HOOD DANGER: Turn off the power circuit breaker or the power switch on the junction box before installing this unit . Touching circuitry inside the range hood while it is energized will result in death or serious injury . DANGER: If installing this unit over a gas range, turn off the gas at the source before installing or servicing this unit .
  • Page 12: Operation

    Operation NOTE: The fan and lights operate independently of each other. TURNING ON/OFF THE UNIT TURNING ON/OFF THE LIGHTS - To turn on the fan, press the appropriate speed control - Press the light switch (5) to turn on and off the lights . switch [Low Speed (2), Medium Speed (3), High Speed (4)] to select the desired level of power .
  • Page 13: Maintenance

    Maintenance REPLACING FILTERS DANGER: Turn off the power circuit breaker or the power switch on the junction box before performing When filters need replacing, exchange with similar filters with maintenance . Touching circuitry inside the range hood while stainless steel clips. Also replace filters that are damaged with it is energized will result in death or serious injury .
  • Page 14: Care And Cleaning

    Care and Cleaning RANGE HOOD WARNING: Failure to maintain basic standards of care and cleaning of the range hood will increase the risk of fire. The range hood should be cleaned (regularly internally and externally) to preserve its appearance and performance . Do Not: - Always clean in the direction of the grain (original - Do not use corrosive or abrasive detergents, steel...
  • Page 15: Troubleshooting

    Troubleshooting DANGER: Turn off the power circuit breaker or the power switch on the junction box before performing maintenance . Touching circuitry inside the range hood while it is energized will result in death or serious injury . Problem Solution The range hood will not operate .
  • Page 16: Specifications

    Venting Options 29.8 in. (757 mm) W High 2 x Max . 25W or 120~60Hz 320 ± Top venting QR0302 35W/ JDR 16, GU10 18 in. (458 mm) D Medium twist and lock base 1 .5A Back venting 9 in. (228 mm) H...
  • Page 17: External Diagram Of Range Hood

    Specifications (continued) EXTERNAL DIAGRAM OF RANGE HOOD 757 mm (29.8 in) 706 mm (27.79 in) 250 mm (9.81 in) 28 mm (1.25 in) 22 mm (0.87 in) 39 mm dia. hole (1.5 in) 18 mm (0.68 in) 80 mm (3.12 in) 93.5 mm (3.68 in) 50 mm (2 in)
  • Page 18: Service Parts

    Service Parts If you are missing parts or if you require replacement parts, please contact our customer service team at customer.service@conglomkb.com or 1-877-333-0098 (8:30 am – 5 pm, EST, Monday–Friday). Identify the required part(s) and have the part number(s) ready . Part Description Code Quantity...
  • Page 19 Imported by: St-Laurent, Québec, H4S 2C3 1-877-333-0098 customer.service@conglomkb.com www.conglomkb.com Made in China Retain this manual for future use.
