Summary of Contents for Presenza QR0292
- Page 1 UNDER CABINET RANGE HOOD INSTALLATION GUIDE AND USER MANUAL Model No. QR0292...
-
Page 2: Table Of Contents
Table of Contents Table of Contents ......2 Maintenance ......Safety Information . - Page 3 Safety Information (continued) Cooking Safety Information WARNING: To reduce the risk of fire, use only metal duct 1 . Never leave the range hood unattended when in use . work . Never use plastic duct work . 2 . Never cook over open flames under the range hood. 3 .
-
Page 4: Warranty
Warranty ONE YEAR LIMITED WARRANTY A thorough inspection must be made before installation and any damage must be promptly reported . We will not be liable for failures or damage that could have been discovered or avoided by proper inspection and testing prior to installation . Conglom Kitchen &... -
Page 5: Pre-Installation
Pre-Installation TOOLS REQUIRED Measuring tape Level Utility knife Adjustable Pencil Tape wrench Flathead Needle nose Phillips screwdriver screwdriver pliers Hammer Electric drill Safety goggles Safety gloves HARDWARE INCLUDED NOTE: Parts not shown to actual size. Part Description Quantity Long tapping screw - (M5 mm x 12 mm) Short tapping screw - (M4 mm x 8 mm) CONGLOMKB .COM Please contact customer.service@conglomkb.com or 1-877-333-0098 for further assistance. -
Page 6: Package Contents
Pre-Installation (continued) PACKAGE CONTENTS Part Description Quantity Range hood Charcoal filter (located inside the hood) Damper (located inside the hood) -
Page 7: Planning Installation
Pre-Installation (continued) PLANNING INSTALLATION Number of people required: 2 or more WARNING: Always wear safety goggles and gloves during Carefully check the range hood for damage and for missing parts installation . prior to installation . If there is any damage or if you are missing parts, do not proceed with the installation . - Page 8 Pre-Installation (continued) Follow these guidelines when installing duct work: - Your venting system must vent to the outdoors either horizontally through the back wall (13) or vertically through the roof (14) (refer to Fig . 5/Fig . 6/Fig . 7) . - Use round metal duct work with a uniform diameter of 6 in .
- Page 9 Pre-Installation (continued) WIRING CONNECTION REQUIREMENTS DANGER: Risk of electrical shock . This range hood Installation work and electrical wiring must be done by a qualified must be properly grounded . person(s) in accordance with all applicable codes and standards, including fire-rated construction. DANGER: Turn off the power circuit breaker or the OBSERVE ALL GOVERNING CODES AND ORDINANCES WARNINGS...
-
Page 10: Installation
Installation REMOVING THE ELECTRICAL KNOCK-OUT HOLE REMOVING THE VENTING HOLE - Choose the venting hole to remove for your WARNING: Always wear safety goggles and gloves during installation type . Use the top hole (3) for a top venting installation . installation and the back hole (4) for a back venting installation . - Page 11 Installation INSTALLING THE CHARCOAL FILTER (SKIP THIS STEP IF YOU ARE USING EXTERIOR VENTING) NOTE: The charcoal filter should only be installed if you are not using a venting system. - Turn over the range hood (A) and place its top on a protective surface . - Unhook the charcoal filter support (9) from the support hook (10) and pull the charcoal filter support up.
- Page 12 Installation (continued) INSTALLING THE RANGE HOOD DANGER: Turn off the power circuit breaker or the power switch on the junction box before installing this unit . Touching circuitry inside the range hood while it is energized will result in death or serious injury . DANGER: If installing this unit over a gas range, turn off the gas at the source before installing or servicing this unit .
-
Page 13: Operation
Operation NOTE: The fan and lights operate independently of each other. TURNING ON/OFF THE UNIT TURNING ON/OFF THE LIGHTS - To turn on the fan, press the appropriate speed control - Press the light switch (5) to turn on and off the lights . switch [Low Speed (2), Medium Speed (3), High Speed (4)] to select the desired level of power . -
Page 14: Maintenance
Maintenance FILTERS DANGER: Turn off the power circuit breaker or the power switch on the junction box before performing maintenance . When filters need replacing, exchange with similar filters with Touching circuitry inside the range hood while it is stainless steel clips. Also replace filters that are damaged with energized will result in death or serious injury . -
Page 15: Care And Cleaning
Care and Cleaning RANGE HOOD WARNING: Failure to maintain basic standards of care and cleaning of the range hood will increase the risk of fire. The range hood should be cleaned (regularly internally and externally) to preserve its appearance and performance . Do Not: - Always clean in the direction of the grain (original - Do not use corrosive or abrasive detergents, steel... -
Page 16: Troubleshooting
Troubleshooting DANGER: Turn off the power circuit breaker or the power switch on the junction box before performing maintenance . Touching circuitry inside the range hood while it is energized will result in death or serious injury . Problem Solution The range hood will not operate . -
Page 17: Specifications
2 x Max . 25W or Top venting 275 ± 120~60Hz 35W/JDR 16, GU10 Back venting 18 in . (458 mm) D Medium QR0292 Push Button 1 .6A twist and lock base Recirculating/ 5 in . (127 mm) H light bulb Inside venting... -
Page 18: External Diagram Of Range Hood
Specifications (continued) EXTERNAL DIAGRAM OF RANGE HOOD 27.75 in. (705 mm) 9.81 in. (250 mm) 0.88 in. 1.1 in. (28 mm) (22 mm) D 1.5 in. (38 mm) 3.13 in. (80 mm) 7.62 in. (193.5 mm) 0.69 in. (18 mm) 11 in. -
Page 19: Service Parts
Service Parts If you are missing parts or if you require replacement parts, please contact our customer service team at customer.service@conglomkb.com or 1-877-333-0098 (8:30 am – 5 pm, EST, Monday–Friday). Identify the required part(s) and have the part number(s) ready . Part Description Code Quantity... - Page 20 Imported by: St-Laurent, Québec, H4S 2C3 1-877-333-0098 customer.service@conglomkb.com www.conglomkb.com Made in China Retain this manual for future use.
