Page 1 FF210001 Owner’s Manual BL00005132-200...
Page 2: For The Latest Information
For the Latest Information The latest versions of the manuals are available from: http://fujifilm-dsc.com/en/manual/ The site can be accessed not only from your computer but also from smartphones and tablets. It also contains information on the software license.
Page 3 Chapter Index Menu List Before You Begin First Steps Basic Photography and Playback Movie Recording and Playback Taking Photographs The Shooting Menus Playback and the Playback Menu The Setup Menus Shortcuts Peripherals and Optional Accessories Connections Technical Notes...
Page 4: Menu List
Menu List Camera menu options are listed below. Shooting Menus Adjust settings when shooting photos or movies. See page 109 for details. Photo Menus Items marked with both x and F icons are available in both the still photography and movie shooting menus. Changes to these items in either menu also apply to the item in the remaining menu.
Page 5 Menu List G AF/MF SETTING A SHOOTING SETTING FOCUS AREA SELF-TIMER AF MODE SAVE SELF-TIMER SETTING STORE AF MODE BY ORIENTATION 131 SELF-TIMER LAMP RAPID AF INTERVAL TIMER SHOOTING 1⁄3 1⁄3 1⁄2 1⁄2 LOW LIGHT PRIORITY AF-S INTERVAL TIMER SHOOTING EXPOSURE SMOOTHING AF POINT DISPLAY yz AE BKT SETTING...
Page 6 Movie Menus Items marked with both x and F icons are available in both the still photography and movie shooting menus. Changes to these items in either menu also apply to the item in the remaining menu. B MOVIE SETTING H IMAGE QUALITY SETTING MOVIE MODE F FILM SIMULATION...
Page 7 Menu List G AF/MF SETTING P AUDIO SETTING F FOCUS AREA INTERNAL MIC LEVEL ADJUSTMENT 172 EXTERNAL MIC LEVEL ADJUSTMENT 172 F AF MODE MIC JACK SETTING xF AF ILLUMINATOR MIC LEVEL LIMITER F FACE/EYE DETECTION SETTING 167 1⁄2 1⁄2 WIND FILTER F MF ASSIST LOW CUT FILTER...
Page 8: The Playback Menu
Before You Begin The Playback Menu Adjust playback settings. See page 183 for details. C PLAY BACK MENU C PLAY BACK MENU SWITCH SLOT RED EYE REMOVAL RAW CONVERSION VOICE MEMO SETTING ERASE RATING SIMULTANEOUS DELETE COPY 2⁄3 2⁄3 (RAW SLOT1/JPG SLOT2) 1⁄3 1⁄3 IMAGE TRANSFER ORDER...
Page 9: Setup Menus
Menu List Setup Menus Adjust basic camera settings. See page 203 for details. D USER SETTING D SCREEN SETTING FORMAT EVF BRIGHTNESS DATE/TIME EVF COLOR TIME DIFFERENCE EVF COLOR ADJUSTMENT LCD BRIGHTNESS 1⁄3 1⁄3 1⁄2 1⁄2 LCD COLOR x MY MENU SETTING LCD COLOR ADJUSTMENT F MY MENU SETTING IMAGE DISP.
Page 10 D BUTTON/DIAL SETTING D SAVE DATA SETTING FOCUS LEVER SETTING FRAME NO. x EDIT/SAVE QUICK MENU SAVE ORG IMAGE F EDIT/SAVE QUICK MENU EDIT FILE NAME x CARD SLOT SETTING FUNCTION (Fn) SETTING 1⁄3 1⁄3 1⁄2 1⁄2 F CARD SLOT SETTING COMMAND DIAL SETTING COMMAND DIAL DIRECTION SELECT SLOT(xSEQUENTIAL)
Page 11: Table Of Contents
Table of Contents Introduction ....................ii For the Latest Information ................... ii Menu List ......................iv Shooting Menus ......................iv The Playback Menu ....................viii Setup Menus .......................ix Supplied Accessories ................xxiii About This Manual .................. xxiv Symbols and Conventions ................xxiv Terminology ......................xxiv Before You Begin Before You Begin Parts of the Camera ..................2 The Serial Number Plate ..................5...
Page 12 Using the Menus ..................25 The Menus ........................25 Selecting a Menu Tab ................... 26 Touch Screen Mode ................... 27 Shooting Touch Controls ................... 27 Playback Touch Controls ..................31 First Steps First Steps Attaching the Strap ................... 34 Attaching a Lens ..................35 Inserting the Battery .................
Page 13 Table of Contents Taking Photographs Taking Photographs P, S, A, and M Modes .................. 64 Mode P: Program AE ..................... 64 Mode S: Shutter-Priority AE ................66 Mode A: Aperture-Priority AE ................68 Mode M: Manual Exposure ................70 Custom Modes ......................74 Autofocus ......................
Page 14 COLOR CHROME FX BLUE ................116 SMOOTH SKIN EFFECT ..................116 DYNAMIC RANGE ....................117 D RANGE PRIORITY....................118 WHITE BALANCE ....................119 TONE CURVE ......................123 COLOR......................... 123 SHARPNESS ......................123 HIGH ISO NR ......................124 CLARITY ........................124 LONG EXPOSURE NR ..................
Page 15 Table of Contents xF AF RANGE LIMITER ................139 xF TOUCH SCREEN MODE ............... 140 SHOOTING SETTING (Still Photography) ..........142 SELF-TIMER ....................... 142 SAVE SELF-TIMER SETTING ................143 SELF-TIMER LAMP ....................143 INTERVAL TIMER SHOOTING ................144 INTERVAL TIMER SHOOTING EXPOSURE SMOOTHING ....145 AE BKT SETTING ....................
Page 16 ZEBRA LEVEL ......................159 MOVIE OPTIMIZED CONTROL oL ............160 TALLY LIGHT ......................160 F EDIT/SAVE CUSTOM SETTING ............... 161 AUTO UPDATE CUSTOM SETTING ............. 161 xF WIRELESS COMMUNICATION ............161 IMAGE QUALITY SETTING (Movie Recording) ........162 F FILM SIMULATION ..................162 F MONOCHROMATIC COLOR ..............
Page 17 Table of Contents TIME CODE SETTING (Movie Recording) ..........174 TIME CODE DISPLAY ................... 174 START TIME SETTING ..................174 COUNT UP SETTING ................... 174 DROP FRAME ......................175 HDMI TIME CODE OUTPUT ................175 Playback and the Playback Menu Playback and the Playback Menu The Playback Display ................178 The DISP/BACK Button ..................
Page 18 The Setup Menus The Setup Menus USER SETTING ....................204 FORMAT ........................204 DATE/TIME ........................ 205 TIME DIFFERENCE ....................205 Qa ......................206 x MY MENU SETTING ..................206 F MY MENU SETTING ..................206 SENSOR CLEANING ..................... 207 BATTERY AGE ......................207 RESET ...........................
Page 19 Table of Contents DISP. CUSTOM SETTING..................217 LARGE INDICATORS MODE(EVF) ..............218 LARGE INDICATORS MODE(LCD) ..............218 LARGE INDICATORS DISP. SETTING ............219 INFORMATION CONTRAST ADJ..............219 SUB MONITOR SETTING ................... 220 SUB MONITOR BACKGROUND COLOR ........... 222 x Q MENU BACKGROUND ................223 F Q MENU BACKGROUND ................
Page 20 EDIT FILE NAME ..................... 236 x CARD SLOT SETTING .................. 236 F CARD SLOT SETTING ................... 237 SELECT SLOT(xSEQUENTIAL) ..............237 SELECT SLOT(FSEQUENTIAL) ..............237 SELECT FOLDER ....................238 COPYRIGHT INFO ....................238 CONNECTION SETTING ................239 Bluetooth SETTINGS................... 239 NETWORK SETTING .................... 240 instax PRINTER CONNECTION SETTING ..........
Page 21 FUJIFILM X Acquire/FUJIFILM Pixel Shift Combiner ..... 286 Copying Pictures from a Memory Card to a Computer ....287 Using Your Camera as a Webcam (FUJIFILM X Webcam) ... 287 Converting RAW Images: FUJIFILM X RAW STUDIO ....... 288 Backing up and Restoring Camera Settings (FUJIFILM X Acquire) ..................
Page 22 Capture One Express Fujifi lm ............... 298 Capture One Pro Fujifi lm ................. 298 Adobe® Photoshop® Lightroom® Classic CC + FUJIFILM Tether Shooting Plug-in PRO for GFX ......299 FUJIFILM X Acquire ..................... 299 FUJIFILM X Webcam ..................299 FUJIFILM X RAW STUDIO ................. 300 FUJIFILM Pixel Shift Combiner ..............
Page 23: Supplied Accessories
Supplied Accessories The following are included with the camera: • NP-W235 rechargeable battery • AC-5VJ AC power adapter • Plug adapter • USB cable (approx. 0.6 m/2 ft.) • Body cap (comes attached to camera) • Shoulder strap • Cable protector • Hot shoe cover (comes attached to hot shoe) •...
Page 24: About This Manual
About This Manual This manual contains instructions for your FUJIFILM GFX50S II digital camera. Be sure you have read and understood its contents before proceeding. Symbols and Conventions The following symbols are used in this manual: Information that should be read to prevent damage to the product.
Page 25: Before You Begin
Before You Begin...
Page 26: Parts Of The Camera
Parts of the Camera Fn2 button .............255 Lens signal contacts Fn3 button .............255 Lens release button ........35 Secondary LCD monitor........22 Fn4 button .............255 Microphone ..........57, 172 Front command dial .......8, 225 Hot shoe ............266 ON/OFF switch ..........44 Diopter adjustment control ......11 Shutter button ..........52 Dial lock release ........50, 56 Fn1 button .............255...
Page 27 Parts of the Camera DRIVE button ............7 Battery-chamber cover .........36 b (delete) button ...........54 DISP (display)/BACK button ....18, 179 a (playback) button ........53 Electronic viewﬁ nder (EVF) ............. 12, 16, 17, 27 Speaker ............ 60, 210 Eye cup (lockable) ...........11 MENU/OK button ..........25 VIEW MODE button .........16 AEL (exposure lock) button ....
Page 28 The Cable Protector Attach the protector as shown to prevent accidental disconnection. Insert the tab on the connector into the matching slot on the camera. Position the protector on the camera. Tighten the lock screw. Connect the cable and pass it through the protector as shown.
Page 29: The Serial Number Plate
Parts of the Camera The Serial Number Plate Do not remove the serial number plate, which provides the CMIIT ID, serial num- ber, and other important information. Serial number plate The Memory Card Slot Cover (Detachable) The memory card slot cover can be re- moved by lowering the interior latch.
Page 30: The Mode Dial
The Mode Dial To select a shooting mode, rotate the dial until the icon for the desired mode aligns with the index. Mode Mode Description Description P (PROGRAM AE) Aperture and shutter speed can be ad- justed using program shift. S (SHUTTER PRIORITY AE) Select for full control over camera set- A (APERTURE PRIORITY AE)
Page 31: The Still/Movie Mode Switch
Parts of the Camera The STILL/MOVIE Mode Switch Slide the STILL/MOVIE mode switch to STILL to take photographs or to MOVIE to record movies. The DRIVE Button Press the DRIVE button to adjust shooting settings. The options displayed vary with the position of the STILL/MOVIE mode switch. •...
Page 32: The Command Dials
The Command Dials Rotate or press the command dials to: Front command dial Rear command dial • Highlight menu items • Choose the desired combina- tion of shutter speed and aper- ture (program shift) • 1, 4 Choose a shutter speed •...
Page 33: The Indicator Lamp
Parts of the Camera The Indicator Lamp Camera status is shown by the indicator lamp. Indicator lamp Indicator lamp Camera status Camera status Glows green Focus locked. Blinks green Focus or slow shutter speed warning. Pictures can be taken. • Camera on: Recording pictures, or picture displayed for con- ﬁ...
Page 34: The Lcd Monitor
The LCD Monitor The LCD monitor can be tilted for eas- ier viewing, but be careful not to touch the wires or trap fi ngers or other objects behind the monitor. Touching the wires could cause camera malfunction. The LCD monitor also functions as a touch screen that can be used for: •...
Page 35: The Eye Cup
Parts of the Camera The Eye Cup To remove the eye cup, hold the buttons on either side and slide eye cup up. Focusing the Viewfi nder If the indicators displayed in the viewfi nder are blurred, put your eye to the viewfi nder and rotate the diopter adjustment control until the display is in sharp focus.
Page 36: Camera Displays
Camera Displays This section lists the indicators that may be displayed during shooting. For illustrative purposes, displays are shown with all indicators lit. The Electronic Viewfi nder EFGHI S T U...
Page 37 Camera Displays Crop factor .............155 Virtual horizon ..........21 IS mode ............149 Focus frame ..........85, 96 Flash (TTL) mode .........268 Histogram ............21 Flash compensation ........268 Power supply ............43 Self-timer indicator ........142 Battery level ............45 Continuous mode ........103 Sensitivity ............92 Shutter type ...........147 Exposure compensation .......95 AF+MF indicator ........135...
Page 38: The Lcd Monitor
The LCD Monitor...
Page 39 Camera Displays Crop factor .............155 Power supply ............43 Focus check ..........91, 136 Battery level ............45 Depth-of-ﬁ eld preview ......69, 90 Distance indicator ........90 Location data download status ..244, 280 Sensitivity ............92 35mm format mode ........150 Exposure compensation .......95 Bluetooth ON/OFF ........239 Aperture ..........65, 68, 70 Image transfer status ......239, 280 Time code ............174...
Page 40: Choosing A Display Mode
Choosing a Display Mode Press the VIEW MODE button to cycle through the following display modes. Option Option Description Description Putting your eye to the viewﬁ nder turns the viewﬁ nder E EYE SENSOR EYE SENSOR on and the LCD monitor oﬀ ; taking your eye away turns the viewﬁ...
Page 41: Adjusting Display Brightness
Camera Displays Adjusting Display Brightness The brightness and saturation of the viewfi nder and LCD monitor can be adjusted using the items in the D SCREEN SET-UP menu. Choose EVF BRIGHTNESS or EVF COLOR to adjust viewfi nder brightness or saturation, LCD BRIGHTNESS or LCD COLOR to do the same for the LCD monitor.
Page 42: The Disp/Back Button
The DISP/BACK Button The DISP/BACK button controls the display of indicators in the viewfi nder and LCD monitor. Indicators for the EVF and LCD must be selected separately. To choose the EVF dis- play, place your eye to the viewfi nder while using the DISP/BACK button.
Page 43: The Dual Display
Camera Displays LCD Monitor Standard indicators No indicators Dual display Info display (manual focus mode only) The Dual Display The dual display consists of a large full-frame window and a smaller close-up of the focus area.
Page 44: Customizing The Standard Display
Customizing the Standard Display To choose the items shown in the standard indicator display: Display standard indicators. Use the DISP/BACK button to display standard indicators. Select DISP. CUSTOM SETTING. Select D SCREEN SET-UP > DISP. CUSTOM SETTING in the setup menu. Choose items.
Page 45 Camera Displays Virtual Horizon Selecting ELECTRONIC LEVEL displays a virtu- al horizon. The camera is level when the two lines overlap. Note that the virtual horizon may not be displayed if the camera lens is pointed up or down. For a 3D display (shown), press the function button to which ELECTRONIC LEVEL is assigned (P 225, 255).
Page 46: The Secondary Lcd Monitor
The Secondary LCD Monitor Among the settings that can be viewed in the secondary LCD monitor are shutter speed, aperture, and ISO sensitivity. Secondary LCD monitor Default Default A SHUTTER SPEED G FILM SIMULATION B APERTURE H BATTERY LEVEL C ISO I FRAMES REM.
Page 47 Camera Displays Cycling Through Indicators in the Secondary LCD Monitor The indicators displayed in the second- ary LCD monitor change each time the secondary LCD monitor mode button is pressed. INFORMATION DIALS HISTOGRAM...
Page 48 Camera Displays The secondary monitor backlight button To turn on the secondary LCD monitor back- light when you fi nd the secondary LCD monitor too dark to read, press the secondary monitor backlight button. Press the button again to turn the backlight off .
Page 49: Using The Menus
Using the Menus To display the menus, press MENU/OK. The Menus Diff erent menus are displayed during still photography, movie recording, and playback. IMAGE QUALITY SETTING IMAGE SIZE IMAGE QUALITY RAW RECORDING FILM SIMULATION MONOCHROMATIC COLOR GRAIN EFFECT COLOR CHROME EFFECT COLOR CHROME FX BLUE STILL/MOVIE mode switch EXIT...
Page 50: Selecting A Menu Tab
Using the Menus Selecting a Menu Tab To navigate the menus: Press MENU/OK to display the menus. IMAGE QUALITY SETTING IMAGE SIZE IMAGE QUALITY RAW RECORDING FILM SIMULATION MONOCHROMATIC COLOR GRAIN EFFECT COLOR CHROME EFFECT COLOR CHROME FX BLUE EXIT Press the focus stick (focus lever) IMAGE QUALITY SETTING IMAGE SIZE...
Page 51: Touch Screen Mode
Touch Screen Mode The LCD monitor also functions as a touch screen. Shooting Touch Controls TOUCH SCREEN SETTINGS To enable touch controls, select ON for TOUCH SCREEN SETTING D BUTTON/DIAL SETTING > TOUCH DOUBLE TAP SETTING TOUCH FUNCTION SCREEN SETTING > x TOUCH SCREEN TOUCH SCREEN SETTING EVF TOUCH SCREEN AREA SETTINGS SETTING.
Page 52 LCD Monitor The operation performed can be selected by tapping the touch screen mode indica- tor in the display. Touch controls can be used for the following operations: Mode Mode Description Description • In focus mode S (AF-S), the camera focuses when you tap your subject in the display.
Page 53 Touch Screen Mode MOVIE OPTIMIZED CONTROL oL Selecting ON for B MOVIE SETTING > MOVIE OPTIMIZED CONTROL oL or tapping the movie-optimized mode but- ton in the shooting display optimizes the command dials and touch controls for movie recording. This can be used to pre- vent camera sounds being recorded with Movie-optimized movie footage.
Page 54 Touch Function Functions can be assigned to the follow- ing fl ick gestures in much the same way as function buttons (P 255): • Flick up: T-Fn1 • Flick left: T-Fn2 • Flick right: T-Fn3 • Flick down: T-Fn4 • In some cases, touch-function fl ick ges- INTERNAL MIC LEVEL ADJUSTMENT tures display a menu;...
Page 55: Playback Touch Controls
Touch Screen Mode Playback Touch Controls When ON is selected for D BUTTON/DIAL SETTING > TOUCH SCREEN SETTING > a TOUCH SCREEN SETTING, touch controls can be used for the following playback operations: • Swipe: Swipe a fi nger across the display to view other images.
Page 56 MEMO...
Page 57: First Steps
First Steps...
Page 58: Attaching The Strap
Attaching the Strap Attach the strap. Attach the strap to the two strap clips as shown below. To avoid dropping the camera, be sure the strap is correctly secured.
Page 59: Attaching A Lens
Lenses and Other Optional Accessories The camera can be used with lenses and accessories for the FUJIFILM G-mount. Observe the following precautions when attaching or removing (ex- changing) lenses.
Page 60: Inserting The Battery
Inserting the Battery Insert the battery in the camera as described below. Open the battery-chamber cover. Slide the battery-chamber cover latch as shown and open the bat- tery-chamber cover. • Do not open the battery-chamber cover when the camera is on. Fail- ure to observe this precaution could damage image fi les or memory cards.
Page 61 Inserting the Battery Close the battery-chamber cover. Close and latch the cover. If the cover does not close, check that the battery is in the correct orienta- tion. Do not attempt to force the cov- er shut. Removing the Battery Before removing the battery, turn the camera off and open the battery-cham- ber cover.
Page 62: Inserting Memory Cards
Inserting Memory Cards Pictures are stored on memory cards (sold separately). The camera can be used with two cards, one in each of its two slots. Open the memory card slot cover. Unlatch and open the cover. Do not turn the camera off or remove the memory card while the memory card is being formatted or data are being recorded to or de- leted from the card.
Page 63: Using Two Cards
Inserting Memory Cards Removing Memory Cards Before removing memory cards, turn the camera off and open the memory card slot cover. Press and release the card to eject it part way (to prevent the card falling from the slot, press the center of the card and release it slowly, without removing your fi nger from the card).
Page 64: Compatible Memory Cards
• A list of supported memory cards is available on the Fujifi lm website. For details, visit: https://fujifilm-x.com/support/compatibility/cameras/. • Do not turn the camera off or remove the memory card while the memo- ry card is being formatted or data are being recorded to or deleted from the card.
Page 65: Charging The Battery
Charging the Battery For reasons of safety, the battery is not charged at ship- ment. The camera will not function if the battery is not charged; be sure to charge the battery before use. Before charging the battery, turn the camera off . •...
Page 66 Charge Status The indicator lamp shows battery charge status as follows: Indicator lamp Indicator lamp Battery status Battery status Battery charging Oﬀ Charging complete Blinks Charging error • The supplied AC power adapter is compatible with power supplies of 100 to 240 V (a plug adapter may be needed for overseas use). •...
Page 67 Charging the Battery • If the camera is turned on during charging, charging will end and the USB connection will instead be used to power the camera. The battery level will begin to gradually decline (P 243). • The camera will display a “power supply” icon when powered via USB. Charging via Computer The camera can be charged via USB.
Page 68: Turning The Camera On And Off
Turning the Camera On and Off Use the ON/OFF switch to turn the camera on and off . Slide the switch to ON to turn the camera on, or to OFF to turn the camera off . Fingerprints and other marks on the lens or viewfi nder can aff ect pic- tures or the view through the viewfi nder.
Page 69: Checking The Battery Level
Checking the Battery Level After turning the camera on, check the battery level in the display. Battery level is shown as follows: Indicator Indicator Description Description Battery partially discharged. Battery about 80% full. Battery about 60% full. Battery about 40% full. Battery about 20% full.
Page 70: Basic Setup
If you intend to pair the camera with a smartphone or tablet, install and launch the latest version of the FUJIFILM Camera Remote App on the smart device before proceeding. For more information, visit: http://app.fujifilm-dsc.com/en/camera_remote/...
Page 71 Basic Setup Check the time. When pairing is complete, you will be PAIRING REGISTRATION prompted to set the camera clock to PAIRING COMPLETE the time reported by the smartphone 12/ 31/2021 12:10 AM or tablet. Check that the time is cor- SET DATE/TIME FROM SMARTPHONE? rect.
Page 72: Choosing A Diff Erent Language
Basic Setup Choosing a Diff erent Language To change the language: Display language options. Select D USER SETTING > Qa. Choose a language. Highlight the desired option and press MENU/OK. Changing the Time and Date To set the camera clock: Display DATE/TIME options. Select D USER SETTING >...
Page 73: Basic Photography And Playback
Basic Photography and Playback...
Page 74: Taking Photographs (Mode P)
Taking Photographs (Mode P) This section describes how to take pictures using program AE (mode P). See pages 64–73 for information on S, A, and M modes. Slide the STILL/MOVIE mode switch to STILL. Rotate the focus mode selector to S. Rotate the mode dial to P.
Page 75 Taking Photographs (Mode P) Ready the camera. • Hold the camera steady with both hands and brace your elbows against your sides. Shaking or un- steady hands can blur your shots. • To prevent pictures that are out of focus or too dark (underexposed), keep your fi ngers and other objects away from the lens and AF-assist illuminator.
Page 76 Taking Photographs (Mode P) Focus. Press the shutter button halfway to set focus and exposure. Focus indicator Focus frame • If the camera is able to focus, the focus frame and focus indicator will glow green. • If the camera is unable to focus, the focus frame will turn red, s will be displayed, and the focus indicator will blink white.
Page 77: Viewing Pictures
Viewing Pictures Pictures can be viewed in the viewfi nder or LCD monitor. To view pictures full frame, press a. 100-0001 Additional pictures can be viewed by pressing the focus stick (fo- cus lever) left or right or rotating the front command dial. Press the focus stick or rotate the dial right to view pictures in the order recorded, left to view pictures in reverse order.
Page 78: Deleting Pictures
Deleting Pictures Use the b button to delete pictures. Deleted pictures cannot be recovered. Protect important pictures or copy them to a computer or other storage device before proceeding. With a picture displayed full frame, press the b button and select FRAME.
Page 79: Movie Recording And Playback
Movie Recording and Playback...
Page 80: Recording Movies
Recording Movies This section describes how to fi lm movies in auto mode. Slide the STILL/MOVIE mode switch to MOVIE. Rotate the mode dial to P. AUTO will appear in the display. Rotate the mode dial only after pressing the dial lock release to release the dial.
Page 81 Recording Movies Press the shutter button all the way down. Recording will start. • A recording indicator (V) is dis- played while recording is in prog- ress. • The time remaining is shown by a Recording time countdown display, while another Time remaining display counts up to show the re- cording time.
Page 82 • The indicator lamp lights while recording is in progress (the B MOVIE SETTING > TALLY LIGHT option can be used to choose the lamp— indicator or AF-assist—that lights during movie recording and whether the lamp blinks or remains steady). During recording, you can change exposure compensation by up to ±2 EV and adjust zoom using the zoom ring on the lens (if available).
Page 83: Adjusting Movie Settings
Recording Movies Adjusting Movie Settings • Pressing MENU/OK when MOVIE is selected with the STILL/MOVIE mode switch displays the movie menu. • The frame rate can be selected using B MOVIE SETTING > MOVIE MODE. • To choose the card used to store movies, use D SAVE DATA SET-UP >...
Page 84: Viewing Movies
Viewing Movies View movies on the camera. In full-frame playback, movies are identi- fi ed by a W icon. Press the focus stick (fo- cus lever) down to start movie playback. PLAY PLAY +1.0 12800 The following operations can be per- formed while a movie is displayed: Focus stick Focus stick...
Page 85 Viewing Movies Playback Speed 29m59s 29m59s Press the focus stick (focus lever) left or right to adjust playback speed during playback. Speed is shown by the number of arrows (M or N). Arrows...
Page 86 MEMO...
Page 87: Taking Photographs
Taking Photographs...
Page 88: P, S, A, And M Modes
P, S, A, and M Modes P, S, A, and M modes give you varying degrees of control over shutter speed and aperture. Mode P: Program AE Let the camera choose shutter speed and aperture for optimal exposure. Other values that produce the same exposure can be selected with program shift.
Page 89 P, S, A, and M Modes Program Shift If desired, you can rotate the rear command dial to select other combinations of shutter speed and aperture without altering exposure (pro- gram shift). Aperture Shutter speed Program shift is not available in any of the following circumstances: •...
Page 90: Mode S: Shutter-Priority Ae
Mode S: Shutter-Priority AE Choose a shutter speed and let the camera adjust aperture for optimal exposure. Slide the STILL/MOVIE mode switch to STILL. Rotate the mode dial to S. S will appear in the display. Rotate the rear command dial to choose the shutter speed.
Page 91 P, S, A, and M Modes • If the correct exposure cannot be achieved at the selected shutter speed, aperture will be displayed in red. • If the subject is outside the metering range of the camera, the aper- ture display will show “– – –”. •...
Page 92: Mode A: Aperture-Priority Ae
Mode A: Aperture-Priority AE Choose an aperture and let the camera adjust shutter speed for optimal exposure. Slide the STILL/MOVIE mode switch to STILL. Rotate the mode dial to A. A will appear in the display. Rotate the lens aperture ring to choose an aperture. •...
Page 93 P, S, A, and M Modes • If the correct exposure cannot be achieved at the selected aperture, shutter speed will be displayed in red. • If the subject is outside the metering range of the camera, the shutter speed display will show “– – –”. •...
Page 94: Mode M: Manual Exposure
Mode M: Manual Exposure In manual mode, the user controls both shutter speed and aperture. Shots can be deliberately overexposed (brighter) or underexposed (darker), opening the door for a variety of individual creative ex- pression. The amount the picture would be under- or over-exposed at current settings is shown by the exposure indicator;...
Page 95 P, S, A, and M Modes Rotate the rear command dial to choose a shutter speed and the lens aperture ring to choose the aperture. • The manual exposure display includes an exposure indicator that shows the amount the picture would be under- or over-ex- posed at current settings.
Page 96 BULB Select a shutter speed of BULB for long time-exposures in which you open and close the shutter manually. Use of a tripod is rec- ommended to prevent the camera moving during the exposure. Set shutter speed to BULB. Press the shutter button all the way down. •...
Page 97 P, S, A, and M Modes Using a Remote Release A remote release can be used for long time-ex- posures. When using an optional RR-100 remote release or an electronic release from third-party suppliers, connect it to the camera’s remote re- lease connector.
Page 98: Custom Modes
Custom Modes Rotate the mode dial to any of modes C1 (CUSTOM 1) through C6 (CUSTOM 6) to take pictures using previously-saved shooting menu settings. Settings can be saved or edited using H IMAGE QUALITY SETTING > EDIT/SAVE CUSTOM SETTING. Saving Current Settings Save current settings in a custom settings bank.
Page 99 P, S, A, and M Modes Editing Custom Settings Edit existing custom settings banks. Select H IMAGE QUALITY SETTING > EDIT/SAVE CUSTOM SETTING in the shooting menu and press MENU/OK. Highlight the desired custom set- EDIT/SAVE CUSTOM SETTING CUSTOM 1 tings bank and press MENU/OK.
Page 100 Press MENU/OK to save the changes and return to the shooting menu list. Adjust additional items as desired. If DISABLE is selected for H IMAGE QUALITY SETTING > AUTO UPDATE CUSTOM SETTING, red dots will appear next to the edit- ed items but the changes will not be saved automatically. •...
Page 101 P, S, A, and M Modes Copying Custom Settings Copy custom settings from one bank to another, overwriting the settings in the destination bank. If the source bank has been re- named, the name will also be copied to the destination bank. Select H IMAGE QUALITY SETTING ...
Page 102 Resetting Custom Settings Reset selected custom settings banks. Select H IMAGE QUALITY SETTING > EDIT/SAVE CUSTOM SETTING in the shooting menu and press MENU/OK. Highlight the desired custom set- EDIT/SAVE CUSTOM SETTING CUSTOM 1 tings bank and press MENU/OK. CUSTOM 2 CUSTOM 3 CUSTOM 4 CUSTOM 5...
Page 103 P, S, A, and M Modes Renaming Custom Settings Banks Rename selected custom settings banks. Select H IMAGE QUALITY SETTING > EDIT/SAVE CUSTOM SETTING in the shooting menu and press MENU/OK. Highlight the desired custom set- EDIT/SAVE CUSTOM SETTING CUSTOM 1 tings bank and press MENU/OK.
Page 104: Autofocus
Autofocus Take pictures using autofocus. Rotate the focus mode selector to S or C (P 81). Choose an AF mode (P 83). Choose the position and size of the focus frame (P 85). Take pictures.
Page 105: Focus Mode
Autofocus Focus Mode Use the focus mode selector to choose how the camera focuses. Choose from the following options: Mode Mode Description Description Single AF: Focus locks while the shutter button is pressed halfway. (AF-S) Choose for stationary subjects. Continuous AF: Focus is continually adjusted to reﬂ ect changes in the distance to the subject while the shutter button is pressed halfway.
Page 106 The Focus Indicator Focus status is shown by the focus indicator. Focus indicator Focus indicator Focus status Focus status Camera focusing. Subject in focus; focus locked (focus z (lights green) mode S). Subject in focus (focus mode C). (z) (lights green) Focus is automatically adjusted for Focus indicator changes in distance to subject.
Page 107: Autofocus Options (Af Mode)
Autofocus Autofocus Options (AF Mode) Focus can be adapted to a variety of subjects by changing the combination of settings selected for focus and AF modes. Press MENU/OK and go to the shooting menu. Select G AF/MF SETTING > AF MODE. Choose an AF mode.
Page 108 Focus Mode C (AF-C) Focus Mode C (AF-C) Option Option Description Description Sample image Sample image Focus tracks subject at selected fo- cus point. Use for subjects moving SINGLE POINT toward or away from camera. Camera tracks focus in selected fo- cus zone.
Page 109: Focus-Point Selection
Autofocus Focus-Point Selection Choose a focus point for autofocus. Viewing the Focus-Point Display Press MENU/OK and go to the shooting menu. Select G AF/MF SETTING > FOCUS AREA to view the fo- cus-point display. Use the focus stick (focus lever) and rear command dial to choose a focus area.
Page 110 The Focus-Point Display The focus-point display varies with the option selected for AF mode. Focus frames are shown by small squares (), focus zones by the large squares. AF mode AF mode r SINGLE POINT y ZONE z WIDE/TRACKING SINGLE POINT ZONE WIDE/TRACKING Number of points avail-...
Page 111 Autofocus Checking Focus To zoom in on the current focus area for precise focus, press the center of the rear command dial. Use the focus stick (focus lever) to choose another focus area. Press the center of the rear command dial again to cancel zoom. Normal display Focus zoom •...
Page 112: Manual Focus
Manual Focus Adjust focus manually. Rotate the focus mode selector to M. j will appear in the display. Focus manually using the lens focus ring. Rotate the ring left to reduce the focus distance, right to increase. Take pictures. • Use D BUTTON/DIAL SETTING >...
Page 113 Manual Focus Quick Focus • To use autofocus to focus on the subject in the selected focus area, press the button to which focus lock or AF-ON has been assigned (the size of the focus area can be chosen with the rear command dial). •...
Page 114: Checking Focus
Checking Focus A variety of options are available for checking focus in manual focus mode. The Manual Focus Indicator The white line indicates the distance to the subject in the fo- cus area (in meters or feet according to the option selected for D SCREEN SET-UP >...
Page 115 Manual Focus Focus Zoom If ON is selected for G AF/MF SETTING > FOCUS CHECK, the camera will automatically zoom in on the selected focus area when the focus ring is rotated. Press the center of the rear com- mand dial to exit zoom. •...
Page 116: Sensitivity
Sensitivity Adjust the camera’s sensitivity to light. Set sensitivity using A SHOOTING SETTING > ISO. Option Option Description Description Sensitivity is automatically adjusted in response to shooting AUTO1 conditions according to combination of standard and max- AUTO2 imum sensitivity and minimum shutter speed chosen for A SHOOTING SETTING ...
Page 117: Auto
Sensitivity AUTO Choose the base sensitivity, maximum sensitivity, and minimum shutter speed for AUTO1, AUTO2, and AUTO3. Default Default Item Item Options Options AUTO1 AUTO1 AUTO2 AUTO2 AUTO3 AUTO3 DEFAULT SENSITIVITY 100–12800 MAX. SENSITIVITY 200–12800 1600 3200 MIN. SHUTTER SPEED ⁄–¼...
Page 118: Metering
Metering Choose how the camera meters exposure. A SHOOTING SETTING > PHOTOMETRY off ers a choice of the following metering options: The selected option will only take eff ect when G AF/MF SETTING > FACE/EYE DETECTION SETTING is OFF. Mode Mode Description Description The camera instantly determines exposure based on an analy-...
Page 119: Exposure Compensation
Exposure Compensation Adjust exposure. Hold the d button and rotate the rear command dial until the desired value is displayed in the viewfi nder or LCD mon- itor. The amount of compensation available varies with the shooting mode. The d Button If ON/OFF SWITCH is selected for D BUTTON/DIAL SETTING ...
Page 120: Focus/Exposure Lock
Focus/Exposure Lock Focus and exposure lock when the shutter button is pressed halfway. Position the subject in the focus frame and press the shutter button halfway to lock focus and exposure. Focus and exposure will remain locked while the shutter button is pressed halfway (AF/AE lock).
Page 121: Other Controls
Focus/Exposure Lock Other Controls Focus and exposure can also be locked using function buttons. At default set- tings, you can use the AEL button to lock exposure without locking focus. If the AFON button is assigned AF LOCK ONLY (P 255), it can similarly be used to lock AEL button focus without locking exposure.
Page 122: Bracketing
Bracketing Automatically vary settings over a series of pictures. Press the DRIVE button to display drive mode options. Press the focus stick (focus lever) up or down to highlight one of the following: Option Option Option Option W ISO BKT s Bracketing V WHITE BALANCE BKT Press the focus stick left or right to highlight the desired...
Page 123: W Iso Bkt
Bracketing W ISO BKT Select a bracketing amount (±1⁄3, ±2⁄3, or ±1) in the drive mode display. Each time the shutter is released, the camera will take a picture at the current sensitivity and process it to create two additional copies, one with sensitivity raised and the other with sensitivity lowered by the selected amount.
Page 124: Bracketing
s Bracketing O AE BKT Use A SHOOTING SETTING > AE BKT SETTING to choose the bracketing amount, bracketing order, and number of shots. The camera will take the specifi ed number of shots in sequence: one using the metered value for exposure and the others over- or un- der-exposed by multiples of the selected bracketing amount.
Page 125 Bracketing Z FOCUS BKT Each time the shutter button is pressed, the camera takes a se- ries of photos, varying focus with each shot. The A SHOOTING SETTING > FOCUS BKT SETTING item off ers a choice of MANUAL and AUTO bracketing. •...
Page 126 Bracketing AUTO AUTO In AUTO mode, the camera calculates FRAMES and STEP auto- matically. Select A SHOOTING SETTING in the shooting menu, high- light FOCUS BKT SETTING, and press MENU/OK. Select AUTO and choose an INTERVAL. The view through the lens will be displayed. Focus on the nearest end of the sub- FOCUS BKT SETTING SET POINT A...
Page 127: Continuous Shooting (Burst Mode)
Continuous Shooting (Burst Mode) Capture motion in a series of pictures. Press the DRIVE button to display drive mode options. If I CONTINUOUS is selected, the camera will take pictures continuously while the shutter-release button is pressed. Shooting ends when the shutter button is released or the memory card is full.
Page 128 Continuous Shooting (Burst Mode) Exposure To vary exposure with each shot, select OFF for D BUTTON/DIAL SETTING > SHUTTER AE. Depending on such factors as aperture, sensitivity, and exposure com- pensation, exposure may not be adjusted automatically.
Page 129: Multiple Exposures
Multiple Exposures Create a photograph that combines multiple exposures. Press the DRIVE button to display the drive mode options and select MULTIPLE EXPOSURE. Choose a blend mode. Option Option Description Description The camera adds the exposures together. You may need to ADDITIVE lower exposure compensation depending on the number of shots.
Page 130 Multiple Exposures Press MENU/OK. The fi rst shot will be shown superimposed on the view through the lens and you will be prompted to take the second shot. NEXT RETRY EXIT • To return to the previous step and retake the fi rst shot, press the focus stick (focus lever) left.
Page 131: Pixel-Shift Multi-Shot
To minimize vibration, use the self-timer or a remote re- lease. Combine the shots on a computer. • The shots can be combined using FUJIFILM Pixel Shift Combiner. • To save high-resolution RAW pictures in other formats, use Capture One Express Fujifi lm, Capture One Pro Fujifi lm, or Capture One Pro, available from Capture One A/S.
Page 132 Capture One Pro: https://www.captureone.com/explore-features • Pixel-shift multi-shot photography can be performed via tethered shooting. For this purpose, use FUJIFILM Pixel Shift Combiner. • The fl ash will synchronize with the shutter at shutter speeds of 1⁄3 s or slower. •...
Page 133: The Shooting Menus
The Shooting Menus...
Page 134: Image Quality Setting (Still Photography)
IMAGE QUALITY SETTING (Still Photography) Adjust image quality settings for still photography. To display image quality settings, press IMAGE QUALITY SETTING IMAGE SIZE MENU/OK in the photo shooting display and IMAGE QUALITY RAW RECORDING select the H (IMAGE QUALITY SETTING) FILM SIMULATION MONOCHROMATIC COLOR tab.
Page 135: Image Quality
IMAGE QUALITY SETTING (Still Photography) IMAGE QUALITY Choose a fi le format and compression ratio. Option Option Description Description SUPER FINE Very low compression ratios are used for maximum image quality. FINE Low compression ratios are used for higher-quality images. Higher compression ratios are used to increase the number of NORMAL images that can be stored.
Page 136: Raw Recording
ﬁ le size with no loss of image data. The im- ages can be viewed in Capture One Express Fujiﬁ lm, RAW FILE CONVERTER EX powered by SILKYPIX, FUJIFILM X RAW LOSSLESS COMPRESSED STUDIO, or other software that supports “lossless” RAW compression.
Page 137: Film Simulation
IMAGE QUALITY SETTING (Still Photography) FILM SIMULATION Simulate the eff ects of diff erent kinds of fi lm, including black- and-white (with or without color fi lters). Choose a palette ac- cording to your subject and creative intent. Option Option Description Description PROVIA/STANDARD Ideal for a wide range of subjects.
Page 138 MONOCHROME+G FILTER: Produces pleasing skin tones in portrait. Shoots in sepia tone. SEPIA • Film simulation options can be combined with tone and sharpness settings. • Film simulation settings can also be accessed via shortcuts (P 246). • For more information, visit: https://fujifilm-x.com/global/tag/the-world-of-film-simulation/?post_type=xstories...
Page 139: Monochromatic Color
IMAGE QUALITY SETTING (Still Photography) MONOCHROMATIC COLOR Add a reddish or bluish tinge (warm or MONOCHROMATIC COLOR cool color cast) to the a ACROS and b MONOCHROME monochrome fi lm simulations. Color can be adjusted on the WARM–COOL and G (Green)–M (Magenta) axes.
Page 140: Color Chrome Fx Blue
COLOR CHROME FX BLUE Increase the range of tones available for rendering blues. Option Option Description Description STRONG Choose for a strong eﬀ ect. WEAK Choose for a weak eﬀ ect. Turn the eﬀ ect oﬀ . SMOOTH SKIN EFFECT Smooth complexions.
Page 141: Dynamic Range
IMAGE QUALITY SETTING (Still Photography) DYNAMIC RANGE Adjust dynamic range. Wide dynamic ranges reduce loss of de- tail in highlights for more natural results with high-contrast or backlit scenes. Option Option Description Description V 100% Choose for increased contrast. AUTO W 200% Reduce loss of detail in highlights.
Page 142: D Range Priority
D RANGE PRIORITY Reduce loss of detail in highlights and shadows for natural-look- ing results when photographing high-contrast scenes. Option Option Description Description Contrast is adjusted automatically in response to lighting con- AUTO ditions. Adjust dynamic range by a large amount for very high-contrast STRONG scenes.
Page 143: White Balance
IMAGE QUALITY SETTING (Still Photography) WHITE BALANCE For natural colors, choose a white balance option that matches the light source. Option Option Description Description WA WHITE White balance is adjusted automatically. Choose for whiter PRIORITY whites in scenes lit by incandescent bulbs. AUTO White balance is adjusted automatically.
Page 144 Fine-Tuning White Balance Pressing MENU/OK after selecting a white WB SHIFT balance option displays a fi ne-tuning dialog; use the focus stick (focus lever) to fi ne-tune white balance. • To exit without fi ne-tuning white balance, press DISP/BACK after se- lecting a white balance option.
Page 145 IMAGE QUALITY SETTING (Still Photography) Custom White Balance Choose k, l, or m to adjust white CUSTOM 1 balance for unusual lighting conditions using a white object as a reference (col- ored objects can also be used to lend photos a color cast). A white balance tar- SHUTTER : NEW WB get will be displayed;...
Page 146 k: Color Temperature Adjust white balance to match the color temperature of the light source. Color temperature can be adjusted to make pictures “warmer” or “cold- er” or deliberately produce colors that diff er radically from those in real life. Select k in the white balance menu.
Page 147: Tone Curve
IMAGE QUALITY SETTING (Still Photography) Color Temperature Color temperature is an objective measure of the color of a light source, ex- pressed in Kelvin (K). Light sources with a color temperature close to that of direct sunlight appear white; light sources with a lower color temperature have a yellow or red cast, while those with a higher color temperature are tinged with blue.
Page 148: High Iso Nr
HIGH ISO NR Reduce noise in pictures taken at high sensitivities. Choose high- er values to reduce noise and smooth outlines, lower values to leave outlines visible. Options Options −4 −3 −2 −1 CLARITY Increase defi nition while altering tones in highlights and shad- ows as little as possible.
Page 149: Lens Modulation Optimizer
IMAGE QUALITY SETTING (Still Photography) LENS MODULATION OPTIMIZER Select ON to improve defi nition by adjusting for diff raction and the slight loss of focus at the periphery of the lens. Options Options COLOR SPACE Choose the gamut of colors available for color reproduction. Option Option Description...
Page 150: Pixel Mapping
PIXEL MAPPING Use this option if you notice bright spots in your pictures. Press MENU/OK in the shooting display and select the H IMAGE QUALITY SETTING tab. Highlight PIXEL MAPPING and press MENU/OK to perform pix- el mapping. • Results are not guaranteed. •...
Page 151: Xf Mount Adaptor Setting
IMAGE QUALITY SETTING (Still Photography) xF MOUNT ADAPTOR SETTING Adjust settings for lenses attached via a mount adapter. Any changes made using this item also apply in movie mode (P 165). Shutter Select When using lenses with an internal shutter, choose whether to use the shutter on the camera (BODY) or the lens (LENS).
Page 152 Color Shading Correction Color Shading Correction Color (shading) variations between the center and edges of the frame can be ad- justed separately for each corner. To use color shading correction, follow the steps below. NEXT Rotate the rear command dial to choose a corner. The select- ed corner is indicated by a triangle.
Page 153 IMAGE QUALITY SETTING (Still Photography) Peripheral Illumination Correction Peripheral Illumination Correction Choose from values between –5 and +5. Choosing positive values increases peripheral illumination, while choosing negative values reduces peripheral il- lumination. Positive values are recom- mended for vintage lenses, negative val- CANCEL ues to create the eff ect of images taken with an antique lens or a pinhole camera.
Page 154: Af/Mf Setting (Still Photography)
AF/MF SETTING (Still Photography) Adjust focus settings for still photography. To display AF/MF settings, press MENU/OK AF/MF SETTING FOCUS AREA in the photo shooting display and select AF MODE STORE AF MODE BY ORIENTATION the G (AF/MF SETTING) tab. RAPID AF LOW LIGHT PRIORITY AF-S AF POINT DISPLAY NUMBER OF FOCUS POINTS...
Page 155: Store Af Mode By Orientation
AF/MF SETTING (Still Photography) STORE AF MODE BY ORIENTATION Choose whether the AF mode used when the camera is in por- trait orientation is stored separately from that used when the camera is in landscape orientation. Option Option Description Description The same settings are used in both orientations.
Page 156: Number Of Focus Points
NUMBER OF FOCUS POINTS Choose the number of focus points available for focus-point se- lection in manual focus mode or when SINGLE POINT is selected for AF MODE. Option Option Description Description 117 POINTS Choose from 117 focus points arranged in a 9- by 13-point grid. (9 ×...
Page 157: Face/Eye Detection Setting
AF/MF SETTING (Still Photography) FACE/EYE DETECTION SETTING If the camera detects human faces, it will assign them priority over the background and adjust settings appropriately for por- traits when setting focus and exposure. You can also choose whether the camera focuses on the left or right eye when face detection is on.
Page 158 • The face selected by the camera is indicated by a green border. Any other faces detected by the camera are indicated by gray borders. To have the camera focus on a diff erent subject, tap inside the gray border. The g icon will change from white to green. •...
Page 159: Af+Mf
AF/MF SETTING (Still Photography) AF+MF If ON is selected in focus mode S and focus has been locked (whether by pressing the shutter button halfway or by other means), focus lock can be ended and focus adjusted manually by rotating the focus ring. Options Options •...
Page 160: Mf Assist
MF ASSIST Choose how focus is displayed in manual focus mode. Option Option Description Description STANDARD Focus is displayed normally. FOCUS PEAK The camera heightens high-contrast outlines. Choose a color and HIGHLIGHT peaking level. You can also choose MF assist options by holding the center of the rear command dial.
Page 161: Interlock Spot Ae & Focus Area
AF/MF SETTING (Still Photography) INTERLOCK SPOT AE & FOCUS AREA Choose ON to meter the current focus frame when SPOT or MULTI metering is selected. Options Options xF INSTANT AF SETTING Choose whether the camera focuses using single AF (AF-S) or continuous AF (AF-C) when a button to which focus lock or AF-ON is assigned is pressed in manual focus mode.
Page 162: Xf Depth-Of-Field Scale
xF DEPTH-OF-FIELD SCALE Choose FILM FORMAT BASIS to help you make practical assess- ments of depth of fi eld for pictures that will be viewed as prints and the like, PIXEL BASIS to help you assess depth of fi eld for pictures that will be viewed at high resolutions on computers or other electronic displays.
Page 163: Xf Af Range Limiter
AF/MF SETTING (Still Photography) xF AF RANGE LIMITER Limit the range of available focus distances for increased focus speed. Option Option Description Description Focus limiter disabled. Limit focus to a range of distances deﬁ ned by a minimum and maximum. •...
Page 164: Xf Touch Screen Mode
xF TOUCH SCREEN MODE Choose the shooting operations performed using touch controls. Mode Mode Description Description • In focus mode S (AF-S), the camera focuses when you tap your subject in the display. Focus locks at the current distance until you tap the AF OFF icon.
Page 165 AF/MF SETTING (Still Photography) Touch Controls for Focus Zoom Diff erent touch controls are used during focus zoom (focus check enabled). Central Area Central Area Tapping the center of the display performs the operations below. Mode Mode Operation performed Operation performed AF-S: AF AF AF MF: Instant AF...
Page 166: Shooting Setting (Still Photography)
SHOOTING SETTING (Still Photography) Adjust shooting options for still photography. To display shooting settings, press MENU/OK SHOOTING SETTING SELF-TIMER in the photo shooting display and select SAVE SELF-TIMER SETTING SELF-TIMER LAMP the A (SHOOTING SETTING) tab. INTERVAL TIMER SHOOTING INTERVAL TIMER SHOOTING EXPOSURE SMOOTHING AE BKT SETTING The options available vary with the shoot- FILM SIMULATION BKT...
Page 167: Save Self-Timer Setting
SHOOTING SETTING (Still Photography) SAVE SELF-TIMER SETTING If ON is selected, the chosen self-timer setting will remain in ef- fect after a picture is taken or the camera is turned off . Options Options SELF-TIMER LAMP If ON is selected, the self-timer lamp will light during self-timer photography.
Page 168: Interval Timer Shooting
INTERVAL TIMER SHOOTING Confi gure the camera to take photos automatically at a preset interval. Highlight INTERVAL TIMER SHOOTING INTERVAL/NUMBER OF TIMES INTERVAL NUMBER OF TIMES in the A (SHOOTING SETTING) tab and press MENU/OK. CANCEL Use the focus stick (focus lever) to START WAITING TIME choose the interval and number of shots.
Page 169: Interval Timer Shooting Exposure Smoothing
SHOOTING SETTING (Still Photography) INTERVAL TIMER SHOOTING EXPOSURE SMOOTHING Select ON to automatically adjust exposure during interval-timer photography to prevent it changing dramatically between shots. Options Options • Large changes in subject brightness may make exposure appear er- ratic. We recommend that you choose shorter values for INTERVAL TIMER SHOOTING >...
Page 170: Ae Bkt Setting
AE BKT SETTING Adjust exposure bracketing settings. Option Option Description Description Choose the number of shots in the bracketing sequence and the amount exposure is varied with each shot. • FRAMES: Choose the number of shots in the bracketing FRAMES/STEP SETTING sequence.
Page 171: Shutter Type
SHOOTING SETTING (Still Photography) SHUTTER TYPE Choose the shutter type. Choose the electronic shutter to mute the shutter sound. Option Option Description Description t MECHANICAL SHUTTER Take pictures with the mechanical shutter. s ELECTRONIC SHUTTER Take pictures with the electronic shutter. t E-FRONT CURTAIN The camera chooses the mechanical or electronic SHUTTER...
Page 172: Flicker Reduction
FLICKER REDUCTION Reduce fl icker in pictures and the display when shooting under fl uorescent lighting and other similar light sources. Option Option Description Description Flicker reduction is applied to all frames continuous ALL FRAMES shooting frame rate reduces. Flicker measurement is taken prior to the ﬁ rst frame only FIRST FRAME and the same reduction amount is applied to all subse- quent frames that ﬂ...
Page 173: Is Mode
SHOOTING SETTING (Still Photography) IS MODE Turn image stabilization on or off . Option Option Description Description CONTINUOUS Image stabilization on. Image stabilization enabled only when the shutter button SHOOTING ONLY is pressed halfway (focus mode C) or the shutter is released. Image stabilization oﬀ...
Page 174: 35Mm Format Mode
35mm FORMAT MODE Enabling A SHOOTING SETTING > 35mm FORMAT MODE in the shooting menu sets the picture angle to 35 mm; the change is refl ected in the display. Option Option Description Description The picture angle is set to 35 mm; the change is reﬂ ected in the display.
Page 175: Xf Wireless Communication
SHOOTING SETTING (Still Photography) xF WIRELESS COMMUNICATION Connect to smartphones running the latest version of the FUJIFILM Camera Remote app. The smartphone can then be used to: • Control the camera and take pictures remotely • Receive pictures uploaded from the camera •...
Page 176: Flash Setting (Still Photography)
FLASH SETTING (Still Photography) Adjust fl ash-related settings for still photography. To display fl ash settings, press MENU/OK FLASH SETTING FLASH FUNCTION SETTING in the photo shooting display and select RED EYE REMOVAL TTL-LOCK MODE the F (FLASH SETTING) tab. LED LIGHT SETTING COMMANDER SETTING CH SETTING EXIT...
Page 177: Ttl-Lock Mode
FLASH SETTING (Still Photography) TTL-LOCK MODE Instead of adjusting fl ash level with each shot, TTL fl ash control can be locked for consistent results across a series of photo- graphs. Option Option Description Description Flash output is locked at the value metered for the most LOCK WITH LAST FLASH recent photo.
Page 178: Commander Setting
FLASH SETTING (Still Photography) COMMANDER SETTING Choose groups when using the camera fl ash unit as a command- er for Fujifi lm optical wireless remote fl ash control. This option is available when the camera is used with clip-on fl ash units that support Fujifi lm optical wireless fl ash control.
Page 179: Movie Setting (Movie Recording)
MOVIE SETTING (Movie Recording) Adjust movie-recording options. To display options for movie recording, MOVIE SETTING MOVIE MODE press MENU/OK in the movie shooting dis- FIX MOVIE CROP MAGNIFICATION FULL HD MOVIE OUTPUT play and select the B (MOVIE SETTING) HDMI OUTPUT INFO DISPLAY HDMI REC CONTROL tab.
Page 180: Full Hd Movie Output
FULL HD MOVIE OUTPUT Choose the destination for Full HD movies shot while the camera is connected to an HDMI device. Option Option Description Description Full HD movies are output to the HDMI device and recorded to b FHD Y FHD the camera memory card.
Page 181: Hdmi Output Info Display
MOVIE SETTING (Movie Recording) HDMI OUTPUT INFO DISPLAY If ON is selected, HDMI devices to which the camera is connected will mirror the information in the camera display. Options Options HDMI REC CONTROL Choose whether the camera sends movie start and stop signals to the HDMI device when the shutter button is pressed to start and stop movie recording.
Page 182: F Is Mode
F IS MODE Turn image stabilization on or off . Option Option Description Description Enable in-body (IBIS) and optical (OIS) image stabilization. IBIS/OIS IBIS is used with lenses that do not support OIS. Enable in-body (IBIS), optical (OIS), and digital (DIS) image IBIS/OIS + DIS stabilization.
Page 183: F Iso
MOVIE SETTING (Movie Recording) F ISO Adjust the camera’s sensitivity to light. Option Option Description Description 200–6400 Adjust sensitivity manually. Selected value is shown in display. Sensitivity is automatically adjusted in response to shooting AUTO conditions. ZEBRA SETTING Highlights that may be overexposed are shown by zebra stripes in the movie mode display.
Page 184: Movie Optimized Control Ol
MOVIE OPTIMIZED CONTROL oL Select ON to allow movie settings to be adjusted using only the command dials and touch-screen controls. You may fi nd this helpful in preventing the sounds of camera controls being re- corded with movies (P 29). Options Options TALLY LIGHT...
Page 185: F Edit/Save Custom Setting
MOVIE SETTING (Movie Recording) F EDIT/SAVE CUSTOM SETTING Options are the same as those for still photography, but settings must be adjusted separately (P 74). AUTO UPDATE CUSTOM SETTING This item is also found in the photo menus (P 126). xF WIRELESS COMMUNICATION This item is also found in the photo menus (P 151).
Page 186: Image Quality Setting (Movie Recording)
IMAGE QUALITY SETTING (Movie Recording) Adjust image quality settings for movies. To display image quality settings, press IMAGE QUALITY SETTING FILM SIMULATION MENU/OK in the movie shooting display and MONOCHROMATIC COLOR WHITE BALANCE select the H (IMAGE QUALITY SETTING) TONE CURVE COLOR tab.
Page 187: F White Balance
IMAGE QUALITY SETTING (Movie Recording) F WHITE BALANCE Options are the same as those for still photography, but settings must be adjusted separately (P 119). F TONE CURVE Options are the same as those for still photography, but settings must be adjusted separately (P 123). F COLOR Options are the same as those for still photography, but settings must be adjusted separately (P 123).
Page 188: F Sharpness
F SHARPNESS Options are the same as those for still photography, but settings must be adjusted separately (P 123). F HIGH ISO NR Options are the same as those for still photography, but settings must be adjusted separately (P 124).
Page 189: F Peripheral Light Correction
IMAGE QUALITY SETTING (Movie Recording) F PERIPHERAL LIGHT CORRECTION Select ON to enable peripheral illumination correction during movie recording. Options Options • If ON is selected when a lens that does not transmit data to the camera is attached, peripheral illumination will be adjusted according to the option selected for H IMAGE QUALITY SETTING ...
Page 190: Af/Mf Setting (Movie Recording)
AF/MF SETTING (Movie Recording) Adjust focus settings for movies. To display AF/MF settings, press MENU/OK AF/MF SETTING FOCUS AREA in the movie shooting display and select AF MODE AF ILLUMINATOR the G (AF/MF SETTING) tab. FACE/EYE DETECTION SETTING MF ASSIST FOCUS CHECK INSTANT AF SETTING DEPTH-OF-FIELD SCALE EXIT...
Page 191: F Face/Eye Detection Setting
AF/MF SETTING (Movie Recording) F FACE/EYE DETECTION SETTING Enable or disable Intelligent Face Detection when recording movies. Option Option Description Description FACE DETECTION ON See “FACE/EYE DETECTION SETTING” (P 133). Intelligent Face Detection and eye priority oﬀ . When Intelligent Face Detection is enabled, the camera will focus using continuous AF even when single AF (S) is chosen with the focus mode selector.
Page 192: F Focus Check
F FOCUS CHECK Options are the same as those for still photography, but settings must be adjusted separately (P 136). xF INSTANT AF SETTING This item is also found in the photo menus (P 137). Changes to one apply to the other. xF DEPTH-OF-FIELD SCALE This item is also found in the photo menus (P 138).
Page 193: Xf Touch Screen Mode
AF/MF SETTING (Movie Recording) xF TOUCH SCREEN MODE Choose the shooting operations performed using touch controls. Mode Mode Description Description Tapping the display focuses the camera on the selected point. Use the shutter button to start and stop recording. • In focus mode S (AF-S), you can refocus at any time by tapping your subject in the display.
Page 194 • To disable touch controls and hide the touch screen mode indica- tor, select OFF for D BUTTON/DIAL SETTING > TOUCH SCREEN SETTING > x TOUCH SCREEN SETTING. • This item is also found in the photo menus (P 140). Changes to one apply to the other.
Page 195: Focus Check Lock
AF/MF SETTING (Movie Recording) FOCUS CHECK LOCK Choose whether focus zoom remains in eff ect once movie re- cording begins. Options Options...
Page 196: Audio Setting (Movie Recording)
AUDIO SETTING (Movie Recording) Adjust settings for audio recorded during fi lming. To display audio settings, press MENU/OK AUDIO SETTING INTERNAL MIC LEVEL ADJUSTMENT in the movie shooting display and select EXTERNAL MIC LEVEL ADJUSTMENT MIC JACK SETTING the P (AUDIO SETTING) tab. MIC LEVEL LIMITER WIND FILTER LOW CUT FILTER...
Page 197: Mic Jack Setting
AUDIO SETTING (Movie Recording) MIC JACK SETTING Specify the type of hardware connected to the microphone jack. Option Option Description Description Choose this option for direct connection to an external micro- phone. Choose this option for external audio devices connected via LINE line output.
Page 198: Time Code Setting (Movie Recording)
TIME CODE SETTING (Movie Recording) Adjust time code (hour, minute, second, and frame num- ber) display settings for movie recording. To display time code settings, press TIME CODE SETTING TIME CODE DISPLAY MENU/OK in the movie shooting display START TIME SETTING COUNT UP SETTING and select the Q (TIME CODE SETTING) DROP FRAME...
Page 199: Drop Frame
TIME CODE SETTING (Movie Recording) DROP FRAME At frame rates of 29.97P, a discrepancy will gradually develop be- tween the time code (measured in seconds) and the actual re- cording time (measured in fractions of a second). Choose wheth- er the camera drops frames as necessary to match the recording time to the time code.
Page 200 MEMO...
Page 201: Playback And The Playback Menu
Playback and the Playback Menu...
Page 202: The Playback Display
The Playback Display This section lists the indicators that may be displayed during playback. For illustrative purposes, displays are shown with all indicators lit. E F G Date and time ........46, 48, 205 Dynamic range ..........117 Frame-number display White balance ..........119 Face detection indicator ......133 Sensitivity ............148 Bluetooth ON/OFF ........239...
Page 203: The Disp/Back Button
The Playback Display The DISP/BACK Button The DISP/BACK button controls the display of indicators during playback. Standard Information off NEXT Info display...
Page 204 The Playback Display Viewing Photo Information The photo information display changes each time the focus stick (focus lever) is pressed up. Basic data Info display 1 NEXT 1/1000 12800 +1.0 1/1000 12800 +1.0 BACK NEXT Info display 3 Info display 2 Zooming in on the Focus Point Press the center of the rear command dial to zoom in on the focus point.
Page 205: Viewing Pictures
Viewing Pictures Read this section for information on playback zoom and multi-frame playback. Use the rear command dial to go from full-frame playback to playback zoom or multi-frame playback. Full-frame playback 100-0001 Multi-frame Playback playback zoom DISP/BACK MENU/OK Nine-frame view Medium zoom Hundred- frame view Maximum zoom...
Page 206: Playback Zoom
Viewing Pictures Playback Zoom Rotate the rear command dial right to zoom in on the current picture, left to zoom out. To exit zoom, press DISP/BACK, MENU/OK, or the center of the rear command dial. • The maximum zoom ratio varies with the option selected for H IMAGE QUALITY SETTING >...
Page 207: The Playback Menu
The Playback Menu Adjust playback settings. The playback menu is displayed when PLAY BACK MENU SWITCH SLOT you press MENU/OK in playback mode. RAW CONVERSION ERASE SIMULTANEOUS DELETE (RAW SLOT1/JPG SLOT2) CROP RESIZE PROTECT IMAGE ROTATE EXIT SWITCH SLOT Choose the card from which images will be played back. If two memory cards are inserted, you can press and hold the a but- ton to choose a card for playback.
Page 208: Raw Conversion
RAW CONVERSION Even if you don’t have a computer, you can use the camera to modify RAW pictures and save them in other formats. Saving RAW Pictures in Another Format Display a RAW picture. Highlight RAW CONVERSION in the playback menu. Press MENU/OK.
Page 209 The Playback Menu The settings that can be adjusted when converting pictures from RAW to another format are: Setting Setting Description Description Create a copy using the settings in eﬀ ect at the time REFLECT SHOOTING COND. the photo was taken. FILE TYPE Choose a ﬁ...
Page 210: Erase
ERASE Delete individual pictures, multiple selected pictures, or all pic- tures. Deleted pictures cannot be recovered. Protect important pictures or copy them to a computer or other storage device before proceeding. Option Option Description Description FRAME Delete pictures one at a time. SELECTED FRAMES Delete multiple selected pictures.
Page 211 The Playback Menu SELECTED FRAMES Select SELECTED FRAMES for ERASE in the playback menu. Highlight pictures and press MENU/OK to select. • Selected pictures are indicated by check marks (R). • To deselect a highlighted picture, press MENU/OK again. When the operation is complete, press DISP/BACK to display a confi rmation dialog.
Page 212: Simultaneous Delete(Raw Slot1/Jpg Slot2)
SIMULTANEOUS DELETE(RAW SLOT1/JPG SLOT2) Taking photos with RAW / JPEG selected for D SAVE DATA SET-UP > x CARD SLOT SETTING creates two copies. Choose whether deleting the RAW image will also delete the JPEG copy. Option Option Description Description Deleting the RAW image from the card in Slot 1 also deletes the JPEG copy from the card in Slot 2.
Page 213: Resize
The Playback Menu RESIZE Create a small copy of the current picture. Display the desired picture. Select RESIZE in the playback menu. Highlight a size and press MENU/OK to display a confi rmation dialog. Press MENU/OK again to save the resized copy to a separate fi le.
Page 214: Protect
PROTECT Protect pictures from accidental deletion. Highlight one of the following options and press MENU/OK. Option Option Description Description Protect selected pictures. Press the focus stick (focus lever) left or FRAME right to view pictures and press MENU/OK to select or deselect. Press DISP/BACK when the operation is complete.
Page 215: Image Rotate
The Playback Menu IMAGE ROTATE Rotate pictures. Select ON for D SCREEN SET-UP > AUTOROTATE PB. Display the desired picture. Select IMAGE ROTATE in the playback menu. Press the focus stick (focus lever) down to rotate the picture 90° clockwise, up to rotate it 90° counterclockwise. Press MENU/OK.
Page 216: Red Eye Removal
RED EYE REMOVAL Remove red-eye from portraits. The camera will analyze the im- age; if red-eye is detected, the image will be processed to create a copy with reduced red-eye. Display the desired picture. Select RED EYE REMOVAL in the playback menu. Press MENU/OK.
Page 217: Voice Memo Setting
The Playback Menu VOICE MEMO SETTING Add a voice memo to the current photograph. Select ON for VOICE MEMO SETTING in the playback menu. Display a photo to which you wish to add a voice memo. Press and hold the center of the front command dial to re- cord the memo.
Page 218: Rating
RATING Rate pictures using stars. Select RATING in the playback menu. Rotate the front command dial to choose a picture and the rear command dial to choose a rating of from 0 to 5 stars (“I”). • The focus stick (focus lever) can be used in place of the front com- mand dial to choose a picture.
Page 219: Copy
The Playback Menu COPY Copy pictures between the cards in the fi rst and second slots. Select COPY in the playback menu. Highlight one of the following options. Option Option Description Description Copy pictures from the card in the ﬁ rst slot to the card in SLOT1 y SLOT2 the second slot.
Page 220: Image Transfer Order
IMAGE TRANSFER ORDER Select photos for upload to a paired smartphone or tablet. Select IMAGE TRANSFER ORDER > SELECT FRAMES in the playback menu. Highlight photos and press MENU/OK to select or deselect. Re- peat until all the desired photos have been selected. Press DISP/BACK to exit to playback.
Page 221: Xf Wireless Communication
The Playback Menu xF WIRELESS COMMUNICATION Connect to smartphones running the latest version of the FUJIFILM Camera Remote app. The smartphone can then be used to: • Control the camera and take pictures remotely • Receive pictures uploaded from the camera •...
Page 222: Photobook Assist
PHOTOBOOK ASSIST Create books from your favorite photos. Creating a Photobook Select NEW BOOK for C PLAY BACK MENU > PHOTOBOOK ASSIST. Scroll through the images and press the focus stick (focus le- ver) up to select or deselect. Press MENU/OK to exit when the book is complete.
Page 223 The Playback Menu Viewing Photobooks Highlight a book in the photobook assist menu and press MENU/OK to display the book, then press the focus stick (focus lever) left or right to scroll through the pictures. Editing and Deleting Photobooks Display the photobook and press MENU/OK. The following options will be displayed;...
Page 224: Print Order (Dpof)
PRINT ORDER (DPOF) Create a digital “print order” for DPOF-compatible printers. Select C PLAY BACK MENU > PRINT ORDER (DPOF). Select WITH DATE s to print the date of recording on pic- tures, WITHOUT DATE to print pictures without dates, or RESET ALL to remove all pictures from the print order before proceeding.
Page 225: Instax Printer Print
Select C PLAY BACK MENU > instax PRINTER PRINT PRINTER PRINT. The camera will con- instax-12345678 nect to the printer. CONNECTING FUJIFILM-CAMERA-1234 CANCEL Use the focus stick (focus lever) to PRINTER PRINT 100-0020 display the picture you want to print, then press MENU/OK. The picture will be sent to the printer and printing will start.
Page 226: Disp Aspect
The Playback Menu DISP ASPECT Choose how High Defi nition (HD) devices display pictures with an aspect ratio of 4∶3 (this option is available only when an HDMI cable is connected). 16:9 Option Option 16∶9 4∶3 Display ∶ Select 16 9 to display the image so that it fi lls the screen with its top ∶...
Page 227: The Setup Menus
The Setup Menus...
Page 228: User Setting
USER SETTING Adjust basic camera settings. To access basic camera settings, press USER SETTING FORMAT MENU/OK, select the D (SET UP) tab, and DATE/TIME TIME DIFFERENCE choose USER SETTING. x MY MENU SETTING FMY MENU SETTING SENSOR CLEANING BATTERY AGE EXIT FORMAT To format a memory card:...
Page 229: Date/Time
USER SETTING DATE/TIME To set the camera clock: Select D USER SETTING > DATE/TIME in the D (SET UP) tab. Press the focus stick (focus lever) left or right to highlight the year, month, day, hour, or minute and press up or down to change.
Page 230: My Menu Setting
Choose a language. x MY MENU SETTING Edit the items listed in the E (MY MENU) tab, a personalized cus- tom menu of frequently-used photo menu options (P 247). F MY MENU SETTING Edit the items listed in the E (MY MENU) tab, a personalized cus- tom menu of frequently-used movie menu options (P 247).
Page 231: Sensor Cleaning
USER SETTING SENSOR CLEANING Remove dust from the camera image sensor. Option Option Description Description Clean the sensor immediately. Sensor cleaning will be performed when the camera is WHEN SWITCHED ON turned on. Sensor cleaning will be performed when the camera turns WHEN SWITCHED OFF oﬀ...
Page 232: Reset
USER SETTING RESET Reset shooting or setup menu options to default values. Highlight the desired option and press MENU/OK. Option Option Description Description Reset all photo menu settings other than custom white STILL MENU RESET balance and custom settings banks created using EDIT/ SAVE CUSTOM SETTING to default values.
Page 233: Sound Setting
SOUND SETTING Make changes to camera sounds. To access sound settings, press MENU/OK, SOUND SETTING AF BEEP VOL. select the D (SET UP) tab, and choose SELF-TIMER BEEP VOL. OPERATION VOL. SOUND SET-UP. SHUTTER VOLUME SHUTTER SOUND PLAYBACK VOLUME EXIT AF BEEP VOL.
Page 234: Operation Vol
SOUND SETTING OPERATION VOL. Adjust the volume of the sounds produced when camera con- trols are operated. Choose eOFF to disable control sounds. Options Options b (high) c (medium) d (low) eOFF (mute) SHUTTER VOLUME Adjust the volume of the sounds produced by the electronic shutter.
Page 235: Screen Setting
SCREEN SETTING Make changes to display settings. To access display settings, press MENU/OK, SCREEN SETTING EVF BRIGHTNESS select the D (SET UP) tab, and choose EVF COLOR EVF COLOR ADJUSTMENT SCREEN SET-UP. LCD BRIGHTNESS LCD COLOR LCD COLOR ADJUSTMENT IMAGE DISP. AUTOROTATE DISPLAYS EXIT EVF BRIGHTNESS...
Page 236: Lcd Brightness
LCD BRIGHTNESS Adjust monitor brightness. Options Options −5 −4 −3 −2 −1 LCD COLOR Adjust monitor saturation. Options Options −5 −4 −3 −2 −1 LCD COLOR ADJUSTMENT Adjust the color of the display in the LCD monitor. Adjust colors using the focus stick (focus lever). Press MENU/OK.
Page 237: Image Disp
SCREEN SETTING IMAGE DISP. Choose how long images are displayed after shooting. Option Option Description Description Pictures are displayed until the MENU/OK button is pressed or the shutter button is pressed halfway. To zoom in on the active focus CONTINUOUS point, press the center of the rear command dial;...
Page 238: Preview Exp./Wb In Manual Mode
PREVIEW EXP./WB IN MANUAL MODE Choose whether to enable exposure and/or white balance preview in manual exposure mode. Option Option Description Description PREVIEW EXP./WB Enable exposure and white balance preview. Preview white balance only. Choose this option in situations in which exposure and white balance are likely to change during PREVIEW WB shooting, as may be the case when you use a ﬂ...
Page 239: Framing Guideline
SCREEN SETTING FRAMING GUIDELINE Choose a framing grid for shooting mode. Option Option F GRID 9 G GRID 24 H HD FRAMING For “rule of thirds” compo- A six-by-four grid. Frame HD pictures in the sition. crop shown by the lines at the top and bottom of the display.
Page 240: Autorotate Pb
AUTOROTATE PB Choose ON to automatically rotate “tall” (portrait-orientation) pictures during playback. Options Options PLAYBACK MAGNIFICATION Choose the zoom ratio selected when the center of the rear com- mand dial is pressed during playback. Option Option Description Description 2x (FROM CENTER) View the center area of the picture at the selected zoom 4x (FROM CENTER) ratio.
Page 241: Dual Display Setting
SCREEN SETTING DUAL DISPLAY SETTING Choose the content of the two windows in the dual display. Option Option Description Description The right (small) window shows a close-up of the focus area, R:FOCUS L:FRAME while the left (large) window shows the entire frame. The right (small) window shows the entire frame, while the left R:FRAME L:FOCUS (large) window shows a close-up of the focus area.
Page 242: Large Indicators Mode(Evf)
LARGE INDICATORS MODE(EVF) Select ON to display large indicators in the electronic viewfi nd- er. The indicators displayed can be selected using D SCREEN SET-UP > LARGE INDICATORS DISP. SETTING. Some icons are not displayed when ON is selected for LARGE INDICATORS MODE(EVF) (P 13).
Page 243: Large Indicators Disp. Setting
SCREEN SETTING LARGE INDICATORS DISP. SETTING Choose the indicators displayed when LARGE INDICATORS DISP. SETTING Expo. DISP. ON is selected for D SCREEN SET-UP > Scale LARGE INDICATORS MODE(EVF) or LARGE INDICATORS MODE(LCD). Option Option Description Description Choose the items listed at the bottom of the display. A Expo.
Page 244: Sub Monitor Setting
SUB MONITOR SETTING Choose the indicators displayed in the secondary LCD monitor. Separate displays are available for still photography and movie recording. Choose from the following: Option Option Description Description Display camera settings. You can choose the settings INFORMATION displayed. DIALS Display dials showing ISO sensitivity and shutter speed.
Page 245 SCREEN SETTING Highlight the indicator you wish to change and press MENU/OK. SUB MONITOR SETTING INFORMATION(STILL) d Scale SHUTTER SPEED APERTURE SHOOTING MODE IMAGE SIZE/QUALITY WHITE BALANCE FILM SIMULATION Highlight the indicator you wish to DISPLAY 1 SETTING SHUTTER SPEED display and press MENU/OK.
Page 246: Sub Monitor Background Color
Repeat Steps 4 and 5 to change additional indicators. Scale indicator can only be enabled or disabled. d Scale SUB MONITOR BACKGROUND COLOR Adjusting the background color of the secondary LCD monitor according to lighting conditions makes the display easier to read. Option Option Description...
Page 247: Q Menu Background
SCREEN SETTING x Q MENU BACKGROUND Choose the background color used for the quick menu when it is displayed during still photography. Options Options TRANSPARENT BLACK F Q MENU BACKGROUND Choose the background color used for the quick menu when it is displayed during movie recording.
Page 248: Button/Dial Setting
BUTTON/DIAL SETTING Access options for camera controls. To access control options, press MENU/OK, BUTTON/DIAL SETTING FOCUS LEVER SETTING select the D (SET UP) tab, and choose xEDIT/SAVE QUICK MENU FEDIT/SAVE QUICK MENU BUTTON/DIAL SETTING. FUNCTION (Fn) SETTING COMMAND DIAL SETTING COMMAND DIAL DIRECTION SHUTTER AF SHUTTER AE...
Page 249: Function (Fn) Setting
BUTTON/DIAL SETTING FUNCTION (Fn) SETTING Choose the roles played by the function buttons (P 255). COMMAND DIAL SETTING Choose the roles played by the command dials. Option Option Description Description FRONT COMMAND Assign shutter speed (S.S. (PROGRAM SHIFT)) or aper- DIAL 1 ture (APERTURE) to FRONT COMMAND DIAL 1.
Page 250: Command Dial Direction
COMMAND DIAL DIRECTION Choose the direction in which the command dials are rotated to choose values. Settings for the front and rear command dials can be adjusted separately. Option Option Description Description Rotate the dial right for higher values or to move to the next - –––––...
Page 251: Shutter Ae
BUTTON/DIAL SETTING SHUTTER AE If ON is selected, exposure will lock while the shutter button is pressed halfway. The setting for focus mode C (AF-C) can be ad- justed separately from that for modes S (AF-S) and M (manual fo- cus).
Page 252: Shoot Without Lens
SHOOT WITHOUT LENS Choose ON to enable the shutter release when no lens is at- tached. Options Options SHOOT WITHOUT CARD Choose whether the shutter can be released without a memory card inserted in the camera. Option Option Description Description When no memory card is inserted, the shutter can be released to test camera function and the shooting and setup menus can be displayed.
Page 253: Focus Ring
BUTTON/DIAL SETTING FOCUS RING Choose the direction in which the focus ring is rotated to in- crease the focus distance. Options Options X CW (clockwise) Y CCW (counterclockwise) FOCUS RING OPERATION Choose how the camera adjusts focus in response to the move- ment of the focus ring.
Page 254: Ae/Af-Lock Mode
AE/AF-LOCK MODE This option determines the behavior of the button to which exposure and/or focus lock is assigned. Option Option Description Description AE&AF ON WHEN Exposure and/or focus will lock while the button is pressed. PRESSING AE&AF ON/OFF Exposure and/or focus will lock when the button is pressed and re- SWITCH main locked until it is pressed again.
Page 255: Touch Screen Setting
BUTTON/DIAL SETTING TOUCH SCREEN SETTING Enable or disable touch-screen controls. x TOUCH SCREEN SETTING Option Option Description Description The LCD monitor functions as a touch screen during shooting. Touch controls disabled. x DOUBLE TAP SETTING Option Option Description Description Tap the LCD monitor twice to zoom in on your subject during shooting.
Page 256: Lock
BUTTON/DIAL SETTING EVF TOUCH SCREEN AREA SETTINGS Select the area of the LCD monitor used for touch controls while the viewfi nder is active. The area used for touch controls can be selected from: Option Option Description Description All. Right half. Top right quarter.
Page 257: Power Management
POWER MANAGEMENT Adjust power management settings. To access power management settings, POWER MANAGEMENT AUTO POWER OFF press MENU/OK, select the D (SET UP) tab, SHOOTING STAND BY MODE AUTO POWER SAVE and choose POWER MANAGEMENT. AUTO POWER OFF TEMP. EXIT AUTO POWER OFF Choose the length of time before the camera turns off automati- cally when no operations are performed.
Page 258: Shooting Stand By Mode
POWER MANAGEMENT SHOOTING STAND BY MODE Choose the delay before the camera enters shooting standby mode. Option Option Description Description 5 MIN The camera will suspend all functions and enter power- 2 MIN ing-saving (standby) mode if no operations are performed 1 MIN for the selected period.
Page 259: Save Data Setting
SAVE DATA SETTING Make changes to fi le management settings. To access fi le management settings, SAVE DATA SETTING FRAME NO. press MENU/OK, select the D (SET UP) tab, SAVE ORG IMAGE EDIT FILE NAME and choose SAVE DATA SET-UP. xCARD SLOT SETTING FCARD SLOT SETTING SELECT SLOT(...
Page 260: Save Org Image
SAVE ORG IMAGE Choose ON to save unprocessed copies of pictures taken using RED EYE REMOVAL. Options Options EDIT FILE NAME Change the fi le name prefi x. sRGB images use a four-letter prefi x (default “DSCF”), Adobe RGB images a three-letter prefi x (“DSF”) preceded by an underscore.
Page 261: F Card Slot Setting
SAVE DATA SETTING F CARD SLOT SETTING Choose the role played by the card in the second slot. Option Option Description Description The card in the second slot is used only when the card in the SEQUENTIAL ﬁ rst slot is full. BACKUP Each picture is recorded twice, once to each card.
Page 262: Select Folder
SAVE DATA SETTING SELECT FOLDER Create folders and choose the folder used to store subsequent pictures. Option Option Description Description To choose the folder in which subsequent pictures will be SELECT FOLDER stored, press the focus stick (focus lever) up or down to highlight an existing folder and press MENU/OK.
Page 263: Connection Setting
Adjust Bluetooth settings. Option Option Description Description PAIRING Pair the camera with a smartphone running the FUJIFILM Camera Remote app. REGISTRATION Choose a connection from a list of devices with which the SELECT PAIRING camera has been paired using PAIRING REGISTRATION.
Page 264: Network Setting
• Install the latest version of the FUJIFILM Camera Remote app on your smartphone or tablet before pairing the device with your camera or uploading images. • When ON is selected for both Bluetooth ON/OFF and AUTO IMAGE TRANSFER or images are currently selected for upload using the IMAGE TRANSFER ORDER option in the C (playback) menu, upload to paired...
Page 265: Instax Printer Connection Setting
CONNECTION SETTING instax PRINTER CONNECTION SETTING Adjust settings for connection to optional Fujifi lm instax SHARE printers. The Printer Name (SSID) and Password The printer name (SSID) can be found on the bottom of the printer; the default password is “1111”.
Page 266: Connection Mode
USB TETHER be® Photoshop® Lightroom® + Tether Plugin, FUJIFILM X SHOOTING AUTO Acquire, or FUJIFILM Pixel Shift Combiner. FUJIFILM X Ac- quire can also be used to save and load camera settings. • The camera can be used as a webcam when connected to a computer running FUJIFILM X Webcam.
Page 267: Usb Power Supply Setting
USB RAW conversion/backup restore mode. The camera functions normally when not connected. • USB RAW CONV. (requires FUJIFILM X RAW STUDIO): Use the cam- USB RAW CONV./ era’s image processing engine to rapidly convert RAW ﬁ les BACKUP RESTORE to other formats while maintaining image quality.
Page 268: General Settings
CONNECTION SETTING GENERAL SETTINGS Adjust settings for connection to wireless networks. Option Option Description Description Choose a name (NAME) to identify the camera on the wireless NAME network (the camera is assigned a unique name by default). Choose whether to resize images for upload to smartphones. Resizing applies only to the copy uploaded to the smartphone;...
Page 269: Shortcuts
Shortcuts...
Page 270: Shortcut Options
Shortcut Options Customize camera controls to suit your style or situation. Frequently-used options can be added to the Q menu or a cus- tom “my” menu or assigned to a function button or touch-func- tion gesture for direct access: Shortcut Option Shortcut Option Description Description...
Page 271: My Menu
MY MENU Access a personalized menu of frequently-used options. To display “my menu”, press MENU/OK in the MY MENU SELF-TIMER shooting display and select the E (MY INTERVAL TIMER SHOOTING FILM SIMULATION MENU) tab. GRAIN EFFECT SHUTTER TYPE IS MODE FACE/EYE DETECTION SETTING EXIT The E tab is only available if options have been assigned to...
Page 272 MY MENU Choose a position for the item and SELECT ITEM LOCATION 1 IMAGE SIZE press MENU/OK. The item will be added 2 IMAGE QUALITY to “my menu”. MOVE SAVE Press MENU/OK to return to the edit display. Repeat Steps 3 and 4 until all the desired items have been added.
Page 273: The Quick Menu
The Quick Menu Use the quick menu for quick access to selected options. To view the quick menu, press the Q button. The Quick Menu Display The quick menu off ers diff erent options in photo and movie modes. At default settings, it contains the following items: Still photography SHOOTING MODE LONG PRESS...
Page 274 Movie recording SHOOTING MODE LONG PRESS EDIT/SAVE CUSTOM Default Default A A SHOOTING MODE E E APERTURE (MOVIE OPTIMIZED CONTROL oL) B B SHUTTER SPEED F F F ISO C C MOVIE MODE G G FILM SIMULATION D F WHITE BALANCE H H WHITE BALANCE COLOR TEMP.
Page 275: Viewing And Changing Settings
The Quick Menu Viewing and Changing Settings Press Q to display the quick menu during shooting. Use the focus stick (focus lever) to highlight items and rotate the rear command dial to change. LONG PRESS EDIT/SAVE CUSTOM To jump to the EDIT/SAVE CUSTOM SETTING menu, press and hold the Q button when the quick menu is displayed.
Page 276: Editing The Quick Menu
Editing the Quick Menu To choose the items displayed in the quick menu: Press and hold the Q button during shooting. The camera displays the photo quick menu during still photogra- phy and the movie quick menu when in movie mode. The current quick menu will be displayed;...
Page 277 The Quick Menu Available Items (Still Photography) Choose from: • • IMAGE SIZE CLARITY • • IMAGE QUALITY HIGH ISO NR • • FILM SIMULATION AF MODE • • GRAIN EFFECT FACE/EYE DETECTION SETTING • • COLOR CHROME EFFECT MF ASSIST •...
Page 278 The Quick Menu Available Items (Movies) • • FILM SIMULATION MOVIE MODE • • WHITE BALANCE MOVIE AF MODE • • WHITE BALANCE COLOR TEMP. FIX MOVIE CROP MAGNIFICATION • F IS MODE (WHEN k SELECTED) • • F IS MODE BOOST HIGHLIGHT TONE •...
Page 279: Function Controls
Function Controls Assign a role to each function button or touch-function gesture for quick access to the selected feature. The Function Buttons Assign a role to the function buttons for quick access to the se- lected feature. Function Button Defaults The default assignments are: Back-of-Camera Function Buttons Back-of-Camera Function Buttons...
Page 280 Front-of-Camera Function Buttons Front-of-Camera Function Buttons Function buttons Function buttons Default Default A A Fn3 button SUB MONITOR MODE B B Fn2 button FACE DETECTION ON/OFF C C Fn1 button EXPO. COMP. D D Fn4 button RAPID AF...
Page 281 Function Controls Assigning Roles to the Function Buttons The roles played by the function buttons can be selected using the D BUTTON/DIAL SETTING > FUNCTION (Fn) SETTING op- tion in the setup menu. • • EXPO. COMP. WIRELESS COMMUNICATION • •...
Page 282 AF-ON Controls to which AF-ON is assigned can be used for autofocus. MODELING FLASH If MODELING FLASH is selected when a compatible shoe-mount- ed fl ash unit is attached, you can press the control to test-fi re the fl ash and check for shadows and the like (modeling fl ash). TTL-LOCK If TTL-LOCK is selected, you can press the control to lock fl ash output according to the option selected for F FLASH SETTING >...
Page 283: Touch-Function Gestures
Function Controls Touch-Function Gestures Assign roles to touch-function gestures (T-Fn1, T-Fn2, T-Fn3, or T-Fn4) for quick access to selected features. Touch-function gestures are disabled by default. To enable touch-func- tion gestures, select ON for D BUTTON/DIAL SETTING > TOUCH SCREEN SETTING > c TOUCH FUNCTION. Touch-Function Gesture Defaults The default assignments for the diff erent gestures are: Touch-Function Gestures...
Page 284 Function Controls Assigning Roles to Touch-Function Gestures The roles played by touch-function gestures can be selected us- ing the D BUTTON/DIAL SETTING > FUNCTION (Fn) SETTING option in the setup menu. • • IMAGE SIZE IS MODE • • IMAGE QUALITY 35mm FORMAT MODE •...
Page 285: Peripherals And Optional Accessories
Peripherals and Optional Accessories...
Page 286: Lenses
Lenses The camera can be used with lenses for the FUJIFILM G-mount. Lens Parts Lens hood Aperture ring Mounting marks Lens signal contacts Focus ring Front lens cap Aperture ring lock release Rear lens cap Mounting marks (focal length) A GF63mmF2.8 R WR lens is used here for illustrative purposes.
Page 287: Lens Care
Lenses Lens Care • Use a blower to remove dust, then gently wipe with a soft, dry cloth. Any remaining stains can be removed by wiping gently with a piece of Fujifi lm lens-cleaning paper to which a small amount of lens-cleaning fl uid has been applied. •...
Page 288: Aperture Rings
Lenses Aperture Rings In modes A (aperture-priority AE) and M (manual), you can choose the aperture (f-number) by rotating the lens aperture ring. Aperture ring Aperture ring lock release Setting Setting Description Description With the aperture ring in the C or A position, you can choose C ( C ( the aperture (f-number) by rotating the camera command dial.
Page 289: External Flash Units
External Flash Units Use optional external fl ash units for fl ash photography. Some units support high-speed sync (FP) and can be used at shutter speeds faster than the fl ash sync speed, while others can function as commanders controlling remote units via optical wireless fl ash control.
Page 290: Flash Settings
Flash Settings Connect the unit to the camera. In shooting mode, select FLASH FLASH SETTING FLASH FUNCTION SETTING FUNCTION SETTING in the F (FLASH RED EYE REMOVAL TTL-LOCK MODE SETTING) menu tab. The options LED LIGHT SETTING COMMANDER SETTING available vary with the fl ash unit. CH SETTING EXIT Menu...
Page 291: Sync Terminal
External Flash Units SYNC TERMINAL The following options are available when no compatible fl ash unit is connected or if a unit is connected via the sync terminal or uses only the X-contact on the hot shoe. MODE SYNC TERMINAL ADJUST Setting Setting...
Page 292: Shoe Mount Flash
SHOE MOUNT FLASH The following options are available when an optional shoe-mounted fl ash unit is attached and turned on. MODE SHOE MOUNT FLASH ADJUST Setting Setting Description Description The ﬂ ash control mode selected with the ﬂ ash unit. This can in some cases be adjusted from the camera;...
Page 293 External Flash Units Setting Setting Description Description The options available vary with ﬂ ash control mode. • TTL: Adjust ﬂ ash compensation (the full value may not be applied if the limits of the ﬂ ash control system are exceed- ed).
Page 294 Setting Setting Description Description Control ﬂ ash timing. • H (1ST CURTAIN): The ﬂ ash ﬁ res immediately after the shut- ter opens (generally the best choice). • I (2ND CURTAIN): The ﬂ ash ﬁ res immediately before the shutter closes. Sync •...
Page 295: Commander(Optical)
External Flash Units COMMANDER(OPTICAL) The options will be displayed if the unit is currently functioning as a commander for Fujifi lm optical wireless remote fl ash control. MODE COMMANDER(OPTICAL) ADJUST Fujifi lm optical wireless remote fl ash control off ers a choice of four channels (Channels 1 through 4) for the exchange of optical signals between the commander and remote fl ash units.
Page 296 Setting Setting Description Description Choose ﬂ ash control modes for groups A, B, and C. TTL% is available for groups A and B only. Flash control mode • TTL: The units in the group ﬁ re in TTL mode. Flash com- (group A) pensation can be adjusted separately for each group.
Page 297 External Flash Units Setting Setting Description Description Choose a ﬂ ash mode for TTL ﬂ ash control. The options available vary with the shooting mode (P, S, A, or M) se- lected. • E (FLASH AUTO): The ﬂ ash ﬁ res only as required; ﬂ ash level is adjusted according to subject brightness.
Page 298 External Flash Units Setting Setting Description Description Choose the group for units functioning as a command- er for Fujiﬁ lm optical wireless remote ﬂ ash control in TTL, TTL%, or M mode. This option is available only with clip- on ﬂ ash units that support Fujiﬁ lm optical wireless remote ﬂ...
Page 299: Handgrips
Handgrips Using a handgrip makes the camera easier to hold. Attaching the Handgrip The MHG-GFX S handgrip attaches to the tripod socket.
Page 300 MEMO...
Page 301: Connections
Connections...
Page 302: Hdmi Output
HDMI Output Camera shooting and playback displays can be output to HDMI devices. Connecting to HDMI Devices Connect the camera to TVs or other HDMI devices using a third-party HDMI cable. Turn the camera off . Connect the cable as shown below. Insert into HDMI connector Insert into HDMI Micro...
Page 303: Shooting
HDMI Output Shooting Display Full HD live view or movie footage on a TV or save it to an external recorder. Playback To start playback, press the camera a button. The camera mon- itor turns off and pictures and movies are output to the HDMI device.
Page 304: Wireless Connections (Bluetooth®, Wireless Lan/Wi-Fi)
Connect to the camera via Bluetooth or wireless LAN. To establish a wireless connection to the camera, you will need to in- stall the latest version of the FUJIFILM Camera Remote app on your smartphone or tablet. FUJIFILM Camera Remote...
Page 305 Wireless Connections (Bluetooth®, Wireless LAN/Wi-Fi) SmartPhones and Tablets: Bluetooth® Pairing Use D CONNECTION SETTING > Bluetooth SETTINGS > PAIRING REGISTRATION to pair the camera with smartphones or tablets. Pairing off ers a simple method for downloading photos from the camera. • Photos are downloaded via a wireless connection. •...
Page 306: Tethered Shooting: Capture One Pro Fujifi Lm/Adobe® Photoshop® Lightroom® Classic Cc + Fujifilm Tether Shooting Plug-In Pro For Gfx/Fujifilm X Acquire
Tethered shooting can be performed using software such as Capture One Pro Fujifi lm, Adobe® Photoshop® Lightroom® Classic CC, and FUJIFILM X Acquire. If you use Adobe® Photoshop® Lightroom® Classic CC, download FUJIFILM Tether Shooting Plug-in PRO for GFX from the Adobe Exchange web- site.
Page 307: Connecting Via Usb
Combiner” (P 286) • “Copying Pictures from a Memory Card to a Computer” (P 287) • “Using Your Camera as a Webcam (FUJIFILM X Webcam)” (P 287) • “Converting RAW Images: FUJIFILM X RAW STUDIO” (P 288) • “Backing up and Restoring Camera Settings (FUJIFILM X Acquire)”...
Page 308 Tethered shooting: During tethered shooting, you can copy pictures using tethered shooting software such as the Capture One Pro Fujifi lm/Adobe® Photoshop® Lightroom® Classic CC + FUJIFILM Tether Shooting Plug-in PRO for GFX/ FUJIFILM X Acquire. • Image transfer: Use applications provided with your operat- ing system.
Page 309 Connecting via USB • Turn the camera off before disconnecting the USB cable. • When connecting USB cables, be sure the connectors are fully in- serted in the correct orientation. Connect the camera directly to the computer; do not use a USB hub or keyboard. •...
Page 310: Tethered Shooting: Capture One Pro Fujifi Lm/Adobe® Photoshop® Lightroom® Classic Cc + Fujifilm Tether Shooting Plug-In Pro For Gfx/ Fujifilm X Acquire/Fujifilm Pixel Shift Combiner
• For more information on Capture One Pro Fujifi lm, Adobe® Photoshop® Lightroom® Classic CC + FUJIFILM Tether Shooting Plug-in PRO for GFX, FUJIFILM X Acquire, and FUJIFILM Pixel Shift Combiner, see “Software for Use with Your Camera” (P 298).
Page 311: Copying Pictures From A Memory Card To A Computer
USB RAW CONV./BACKUP RESTORE camera menus. USB POWER SUPPLY SETTING GENERAL SETTINGS • Launch FUJIFILM X Webcam. INFORMATION RESET WIRELESS SETTING ESET WIRELESS SETTING For more information on FUJIFILM X Webcam, see “Software for Use with Your Camera” (P 298).
Page 312: Converting Raw Images: Fujifilm X Raw Studio
RESET WIRELESS SETTING ESET WIRELESS SETTING to convert RAW images to JPEG or TIFF images. For more information on FUJIFILM X RAW STUDIO, see “Software for Use with Your Camera” (P 298). Backing up and Restoring Camera Settings (FUJIFILM X Acquire) •...
Page 313: Connecting To Smartphones
Connecting via USB Connecting to Smartphones To copy pictures to a smartphone, select OFF for D CONNECTION SETTING > USB POWER SUPPLY SETTING and connect the cam- era to the phone using a USB cable. For Customers Using Android Devices How you will connect the camera depends on the type of USB connector with which your smartphone is equipped.
Page 314 Set the camera’s D CONNECTION SETTING > USB POWER SUPPLY SETTING to OFF. Connect the camera and smartphone using a USB cable. If the smartphone asks for permission for an application other than the “Camera Importer” to access the camera, tap “Cancel” and move on to the next step.
Page 315 Connecting via USB For Customers Using iOS Use a camera adapter. Given that the camera is equipped with a USB Type-C connector, you will need to supply a cable with a USB Type-A connector for connection to the camera adapter. Apple Lightning to Third-party USB cable USB Camera Adapter...
Page 316: Instax Share Printers
instax SHARE Printers Print pictures from your digital camera to instax SHARE printers. Establishing a Connection Select D CONNECTION SETTING > instax PRINTER CONNECTION SETTING and enter the instax SHARE printer name (SSID) and pass- word. The Printer Name (SSID) and Password The printer name (SSID) can be found on the bottom of the printer;...
Page 317: Printing Pictures
Select C PLAY BACK MENU > instax PRINTER PRINT PRINTER PRINT. The camera will con- instax-12345678 nect to the printer. CONNECTING FUJIFILM-CAMERA-1234 CANCEL Use the focus stick (focus lever) to PRINTER PRINT 100-0020 display the picture you want to print, then press MENU/OK.
Page 318 MEMO...
Page 319: Technical Notes
Technical Notes...
Page 320: Accessories From Fujifi Lm
30 W or above reduces charging times to as little as 150 minutes. FUJINON lenses FUJINON lenses GF-series lenses: Interchangeable lenses for use exclusively with the FUJIFILM G-mount. Eye cups Eye cups EC-XH W/EC-XT L/EC-XT M/EC-XT S/EC-GFX: Attach viewﬁ nder eyecups to prevent light leaking into the viewﬁ...
Page 321 Accessories from Fujifi lm Shoe-mounted fl ash units Shoe-mounted fl ash units EF-BP1: A battery pack for EF-X500 ﬂ ash units. Takes up to 8 AA batteries. EF-60: In addition to manual and TTL ﬂ ash control, this clip-on ﬂ ash unit has a Guide Number of 60/197 (ISO 100, m/ft.) and supports FP (high-speed sync), allowing it to be used at shutter speeds that exceed the ﬂ...
Page 322: Software For Use With Your Camera
Software for Use with Your Camera The camera can be used with the following software. For the latest information on software available from Fujifi lm, visit https://fujifilm-x.com/support/compatibility/cameras/. FUJIFILM Camera Remote Establish a wireless connection between your camera and a smartphone or tablet (P 280). http://app.fujifilm-dsc.com/en/camera_remote/...
Page 323: Adobe® Photoshop® Lightroom® Classic Cc + Fujifilm Tether Shooting Plug-In Pro For Gfx
Adobe® Photoshop® Lightroom® Classic CC + FUJIFILM Tether Shooting Plug-in PRO for GFX Installing this dedicated plug-in allows tethered shooting us- ing Adobe® Photoshop® Lightroom® Classic CC. FUJIFILM Tether Shooting Plug-in PRO for GFX is available free of charge from the Adobe Exchange website.
Page 324: Fujifilm X Raw Studio
Software for Use with Your Camera FUJIFILM X RAW STUDIO When the camera is connected to a computer via USB, FUJIFILM X RAW STUDIO can use the camera’s unique image processing engine to rapidly convert RAW fi les to create high-quality images in other formats.
Page 325: For Your Safety
For Your Safety IMPORTANT SAFETY INSTRUCTIONS • Read Instructions Read Instructions: All the safety and operating instructions Power-Cord Protection: Power-supply cords should be routed should be read before the appliance is operated. so that they are not likely to be walked on or pinched by •...
Page 326 Power Lines: An outside antenna system should not be locat- Damage Requiring Service: Unplug this video product from ed in the vicinity of overhead power lines or other electric the wall outlet and refer servicing to qualiﬁ ed service person- light or power circuits, or where it can fall into such power nel under the following conditions: •...
Page 327 For Your Safety WARNING WARNING WARNING WARNING If the battery leaks and fl uid gets in contact with your If the battery leaks and fl uid gets in contact with your Do not use the camera in the bathroom or shower. Do not use the camera in the bathroom or shower.
Page 328 CAUTION CAUTION Do not use this came Do not use this camera in locations aff e ra in locations aff ected by oil cted by oil fumes, s fumes, steam, humidity or du team, humidity or dust. st. This can cause a ﬁ re or electric shock.
Page 329 For Your Safety The Battery and Power Supply Note: Check the type of battery used in your camera and read Cautions: Handling the Battery Cautions: Handling the Battery ■ ■ • the appropriate sections. Do not transport or store with metal objects such as neck- laces or hairpins.
Page 330 Digital Split Image is a trademark or registered trademark of such as the sun in a cloudless sky. Failure to observe this FUJIFILM Corporation. Digital Micro Prism is a trademark or precaution could damage the camera image sensor. registered trademark of FUJIFILM Corporation. The typefaces •...
Page 331 For Your Safety NOTICES To prevent fire or shock hazard, do not expose the unit to rain or moisture. Please read the “Safety Notes” and make sure you understand them before using the camera. Perchlorate Material—special handling may apply. See: http://www.dtsc.ca.gov/hazardouswaste/perchlorate For Customers in the U.
Page 332 For Customers in Canada For Customers in Canada Disposal of Electrical and Electronic Equipment in Private Households Disposal of Electrical and Electronic Equipment in Private Households CAN ICES-3 (B)/NMB-3(B) In the European Union, Norway, Iceland and CAUTION: This Class B digital apparatus complies with Cana- Liechtenstein: This symbol on the product, or in dian ICES-003.
Page 333 Hereby, FUJIFILM Corporation declares that the radio er attention to security than applies in the case of wired equipment type FF210001 is in compliance with Directive networks. 2014/53/EU. Do not connect to unknown networks or networks to...
Page 334 For Your Safety Be sure to read these notes before using the lens Safety Notes WARNING WARNING • Make sure that you use the lens correctly. Read these safety Do not i Do not immerse in or expose mmerse in or expose to water. to water.
Page 335: Product Care
Product Care To ensure continued enjoyment of the product, observe the following precautions. Camera body: Use a soft, dry cloth to clean the camera body after each use. Do not use alcohol, thinner, or other volatile chemicals, which could discolor or deform the leather on the camera body. Any liquid on the camera should be removed immediately with a soft, dry cloth.
Page 336: Cleaning The Image Sensor
Cleaning the Image Sensor Dust that cannot be removed using D USER SETTING > SENSOR CLEANING can be removed manually as de- scribed below. Note that there will be a charge to repair or replace the image sensor if it is damaged during cleaning. Use a blower (not a brush) to remove dust from the sensor.
Page 337: Firmware Updates
Firmware Updates Updates to product fi rmware may result in changes not described in the manual. For more information, visit: https://fujifilm-x.com/support/download/firmware/cameras/ Checking the Firmware Version The camera will only display the fi rmware version if a memory card is inserted.
Page 338: Troubleshooting
Troubleshooting Consult the table below should you encounter problems using your camera. If you don’t fi nd the solution here, con- tact your local Fujifi lm distributor. Power and Battery Problem Problem Solution Solution • The battery is exhausted: Charge the battery or insert a ful- ly-charged spare battery (P 41).
Page 339 Troubleshooting Problem Problem Solution Solution • Make sure that the AC power adapter is correctly plugged in (P 41). • Ensure that the plug adapter is correctly connected to the AC power adapter (P 41). Charging does not start. • The battery has not been recharged for an extended period: If the battery has not been charged for an extended period, charging will be disabled to ensure safety.
Page 340 Shooting Problem Problem Solution Solution • The memory card is full: Insert a new memory card or delete pictures (P 38, 186). • The memory card is not formatted: Format the memory card in the camera (P 204). • There is dirt on the memory card contacts: Clean the contacts with a soft, dry cloth.
Page 341 Troubleshooting Problem Problem Solution Solution • The fl ash is disabled: Adjust settings (P 152). • The electronic shutter is enabled: Choose a SHUTTER TYPE that does not use the electronic shutter (P 147). • The fl ash does not fi re. The battery is exhausted: Charge the battery or insert a ful- ly-charged spare battery (P 41).
Page 342 Playback Problem Problem Solution Solution The pictures were taken with a diﬀ erent make or model of Pictures are grainy. camera. Playback zoom is The pictures were created using RESIZE or with a diﬀ erent unavailable. make or model of camera. •...
Page 343 The computer does not Be sure the camera and computer are correctly connected recognize the camera. (P 283). FUJIFILM X RAW STUDIO Check the option selected for CONNECTION MODE or FUJIFILM X Acquire on the camera. Select USB RAW CONV./BACKUP fails to correctly detect RESTORE before connecting the USB cable (P 288).
Page 344 Wireless Transfer For additional information on troubleshooting wireless connec- tions, visit: https://digitalcamera-support-en.fujifilm.com/ Problem Problem Solution Solution Cannot connect to smartphone. • The smartphone is too far away: Move the devices closer The camera is slow (P 280). to connect or upload •...
Page 345 Troubleshooting Miscellaneous Problem Problem Solution Solution • Temporary camera malfunction: Remove and reinsert the battery (P 36). • The battery is exhausted: Charge the battery or insert a fully-charged spare battery (P 41). The camera is unresponsive. • The camera is connected to a wireless LAN: End the con- nection.
Page 346: Warning Messages And Displays
Warning Messages and Displays The following warnings appear in the display. Warning Warning Description Description Low battery. Charge the battery or insert a fully-charged i (red) spare battery. Battery exhausted. Charge the battery or insert a ful- j (blinks red) ly-charged spare battery.
Page 347 Warning Messages and Displays Warning Warning Description Description • The memory card is not formatted for use in the camera: For- mat the card. • The memory card contacts require cleaning or the memory card is damaged: Clean the contacts with a soft, dry cloth. If the CARD ERROR message is repeated, format the card.
Page 348 Warning Warning Description Description • The fi le is corrupt or was not created with the camera: The ﬁ le cannot be viewed. • The memory card contacts require cleaning: Clean the con- READ ERROR tacts with a soft, dry cloth. If the message is repeated, format the card.
Page 349 Warning Messages and Displays Warning Warning Description Description p (yellow) The camera is approaching the maximum temperature al- CAMERA IS APPROACHING lowed when STANDARD is selected for AUTO POWER STANDARD OFF TEMP. and will shortly turn oﬀ automatically. Turn the TEMPERATURE LIMIT camera oﬀ...
Page 350: Memory Card Capacity
Memory Card Capacity The following table shows the recording time or number of pictures available at diff erent image sizes. All fi gures are approximate; fi le size varies with the scene recorded, pro- ducing wide variations in the number of fi les that can be stored.
Page 351: Specifi Cations
Specifi cations System Model FUJIFILM GFX50S II Product Number FF210001 Eff ective pixels Approx. 51.4 million Image sensor 43.8 mm × 32.9 mm Bayer array with primary color ﬁ lter Storage media Fujiﬁ lm-recommended SD/SDHC/SDXC memory cards Memory card slots Two SD memory card slots (UHS-II compliant) •...
Page 352 System Metering 256-segment through-the-lens (TTL) metering; MULTI, SPOT, AVERAGE, CENTER WEIGHTED Exposure control Programmed AE (with program shift); shutter-priority AE; aperture-priority AE; manual exposure • Exposure compensation Still pictures: −5 EV – +5 EV in increments of ⁄ EV • Movies: −2 EV – +2 EV in increments of ⁄ EV •...
Page 353 Specifi cations System • Flash mode MODE: TTL MODE (FLASH AUTO, STANDARD, SLOW SYNC.), MANUAL, MULTI, OFF • SYNC. MODE: 1ST CURTAIN, 2ND CURTAIN, AUTO FP (high- speed sync) • RED EYE REMOVAL: e FLASH+REMOVAL, L FLASH, d REMOVAL, OFF Hot shoe Accessory shoe with TTL contacts;...
Page 354 Power supply/other Power supply NP-W235 rechargeable battery (supplied with camera) • Battery life Battery type: NP-W235 • Lens: GF63mmF2.8 R WR • External fl ash units: Disabled • Shooting mode: Mode P • AUTO POWER SAVE: ON Number of shots Number of shots Approx.
Page 355 Specifi cations Wireless transmitter Wireless LAN Standards IEEE 802.11b/g/n (standard wireless protocol) Operating frequency 2,412 MHz–2,462 MHz (11 channels) (center frequency) Access protocols Infrastructure Bluetooth® Standards Bluetooth version 4.2 (Bluetooth Low Energy) Operating frequency 2,402 MHz–2,480 MHz (center frequency)
Page 356 Specifi cations NP-W235 rechargeable battery Nominal voltage 7.2 V Nominal capacity 2350 mAh Rating capacity 2200 mAh Operating 0 °C to +40 °C/+32 °F to +104 °F temperature Dimensions 38.92 mm × 22.8 mm × 52.26 mm/ 1.5 in. × 0.9 in. × 2.1 in. (W ×...
Page 357 MEMO...
Page 358 MEMO...
Page 359 MEMO...
Page 360 7-3, AKASAKA 9-CHOME, MINATO-KU, TOKYO 107-0052, JAPAN https://fujifilm-x.com...

This manual is also suitable for:

Gfx 50sii

FujiFilm FF210001 Owner's Manual

Quick Links

Need help?

Questions and answers

Related Manuals for FujiFilm FF210001

Summary of Contents for FujiFilm FF210001
