Page 1 FF220001 Owner’s Manual BL00005204-200...
Page 2: For The Latest Information
For the Latest Information The latest versions of the manuals are available from: https://fujifilm-dsc.com/en/manual/ The website can be accessed not only from your computer but also from smartphones and tablets. It also contains information on the software license.
Page 3 Chapter Index Menu List Before You Begin First Steps Basic Photography and Playback Movie Recording and Playback Taking Photographs The Shooting Menus Playback and the Playback Menu Network/USB Features and Settings The Setup Menus Shortcuts Peripherals and Optional Accessories Technical Notes...
Page 4: Menu List
Menu List Camera menu options are listed below. Shooting Menus Adjust settings when shooting photos or movies. See page 117 for details. Photo Menus Items marked with both x and F icons are available in both the still photography and movie shooting menus. Changes to these items in either menu also apply to the item in the remaining menu.
Page 5 Menu List G AF/MF SETTING A SHOOTING SETTING FOCUS AREA DRIVE SETTING AF MODE SPORTS FINDER MODE PRE-SHOT sJ AF-C CUSTOM SETTINGS STORE AF MODE BY ORIENTATION 148 SELF-TIMER 1⁄3 1⁄3 1⁄3 1⁄3 AF POINT DISPLAY yz SAVE SELF-TIMER SETTING xF WRAP FOCUS POINT SELF-TIMER LAMP PHOTOMETRY...
Page 6 Movie Menus Items marked with both x and F icons are available in both the still photography and movie shooting menus. Changes to these items in either menu also apply to the item in the remaining menu. B MOVIE SETTING H IMAGE QUALITY SETTING MOVIE SETTING LIST F FILM SIMULATION...
Page 7 Menu List G AF/MF SETTING P AUDIO SETTING F FOCUS AREA INTERNAL MIC LEVEL ADJUSTMENT 213 EXTERNAL MIC LEVEL ADJUSTMENT 213 F AF MODE MIC JACK SETTING F AF-C CUSTOM SETTING MIC LEVEL LIMITER xF WRAP FOCUS POINT WIND FILTER xF AF ILLUMINATOR 1⁄2 1⁄2...
Page 8: The Playback Menu
The Playback Menu Adjust playback settings. See page 225 for details. C PLAY BACK MENU C PLAY BACK MENU SWITCH SLOT IMAGE ROTATE RAW CONVERSION VOICE MEMO SETTING HEIF TO JPEG/TIFF CONVERSION RATING ERASE COPY 1⁄3 1⁄3 2⁄3 2⁄3 SIMULTANEOUS DELETE TRANSFER IMAGE TO SMARTPHONE 239 CROP xF WIRELESS COMMUNICATION 241...
Page 9: Setup Menus
Menu List Setup Menus Adjust basic camera settings. See page 271 for details. D USER SETTING D SCREEN SETTING FORMAT VIEW MODE SETTING b AREA SETTING EVF BRIGHTNESS EVF COLOR DATE/TIME TIME DIFFERENCE EVF COLOR ADJUSTMENT 1⁄ 4 1⁄ 4 1⁄2 1⁄2 LCD BRIGHTNESS...
Page 10 Menu List D BUTTON/DIAL SETTING D POWER MANAGEMENT FOCUS LEVER SETTING AUTO POWER OFF x EDIT/SAVE QUICK MENU PERFORMANCE F EDIT/SAVE QUICK MENU EVF/LCD BOOST SETTING AUTO POWER OFF TEMP. FUNCTION (Fn) SETTING 1⁄3 1⁄3 POWER ZOOM LENS FUNCTION D SAVE DATA SETTING (Fn) SETTING FRAME NO.
Page 11: The Network/Usb Settings Menu
Menu List The Network/USB Settings Menu Adjust settings for network and USB connections. See page 264 for details. I NETWORK/USB SETTING Bluetooth/SMARTPHONE SETTING AIRPLANE MODE NETWORK SETTING instax PRINTER CONNECTION SETTING CONNECTION MODE USB POWER SUPPLY/ COMM SETTING INFORMATION RESET WIRELESS SETTING...
Page 12: Table Of Contents
Table of Contents Introduction ......................ii For the Latest Information ..................ii Menu List .......................iv Shooting Menus ......................iv The Playback Menu ......................viii Setup Menus ........................ix The Network/USB Settings Menu ................. xi Supplied Accessories ..................xxv About This Manual ..................xxvi Symbols and Conventions ...................xxvi Terminology ........................xxvi Before You Begin Before You Begin...
Page 13 Table of Contents Customizing the Standard Display ..............21 Virtual Horizon ........................ 23 Using the Menus ....................24 The Menus ......................... 24 Selecting a Menu Tab ....................25 Touch Screen Mode ..................26 Shooting Touch Controls ..................26 Playback Touch Controls ................... 31 First Steps First Steps Attaching the Strap ..................
Page 14 Taking Photographs Taking Photographs P, S, A, and M Modes ..................72 Mode P: Program AE ....................72 Mode S: Shutter-Priority AE..................74 Mode A: Aperture-Priority AE ................78 Mode M: Manual Exposure ..................80 Autofocus ......................82 Focus Mode ........................83 Autofocus Options (AF Mode) ................
Page 15 Table of Contents The Shooting Menus The Shooting Menus IMAGE QUALITY SETTING (Still Photography) ........118 IMAGE SIZE ........................118 IMAGE QUALITY ......................119 RAW RECORDING ....................... 120 SELECT JPEG/HEIF ...................... 121 FILM SIMULATION ...................... 122 MONOCHROMATIC COLOR .................. 124 GRAIN EFFECT ......................124 COLOR CHROME EFFECT ..................
Page 16 PRE-AF ..........................149 xF AF ILLUMINATOR ..................150 g FACE/EYE DETECTION SETTING ..............151 SUBJECT DETECTION SETTING ................153 AF+MF ..........................155 MF ASSIST ........................156 FOCUS CHECK ......................156 INTERLOCK SPOT AE & FOCUS AREA .............. 157 xF INSTANT AF SETTING ................. 157 xF DEPTH-OF-FIELD SCALE ................
Page 17 Table of Contents TTL-LOCK MODE ......................181 LED LIGHT SETTING ....................181 COMMANDER SETTING ..................182 CH SETTING ........................182 MOVIE SETTING (Still Photography) ............183 MOVIE MODE ........................ 183 HIGH SPEED REC ......................183 MEDIA REC SETTING ....................183 F IS MODE ........................184 F IS MODE BOOST ....................
Page 18 IMAGE QUALITY SETTING (Movie Recording) ........201 F FILM SIMULATION ....................201 F MONOCHROMATIC COLOR ................201 F WHITE BALANCE ....................202 F DYNAMIC RANGE ....................202 F TONE CURVE ......................202 F COLOR ........................202 F SHARPNESS ......................203 F HIGH ISO NR ......................203 INTERFRAME NR ......................
Page 19 Table of Contents TIME CODE SETTING (Movie Recording) ..........216 TIME CODE DISPLAY ....................216 START TIME SETTING ....................216 COUNT UP SETTING....................217 DROP FRAME ........................ 217 HDMI TIME CODE OUTPUT ................... 218 Playback and the Playback Menu Playback and the Playback Menu The Playback Display ..................220 The DISP/BACK Button ....................
Page 20 Connecting to Smartphones (Bluetooth) ..........249 Installing Smartphone Apps ................249 Connecting to a Smartphone ................249 Using the Smartphone App ................251 Connecting to Smartphones (USB) ............252 Copying Pictures to a Smartphone ..............252 Connecting the Camera and Computer ............. 255 Using the Camera as a Webcam ...............257 instax SHARE Printers ...................258 Establishing a Connection..................
Page 21 Table of Contents SENSOR CLEANING ....................276 BATTERY AGE ........................ 276 RESET ..........................277 REGULATORY ......................... 277 SOUND SETTING .....................278 AF BEEP VOL........................278 SELF-TIMER BEEP VOL....................278 OPERATION VOL......................279 F REC START/STOP VOLUME ................279 tt ELECTRONIC SHUTTER VOLUME ............
Page 22 LARGE INDICATORS MODE(EVF) ............... 291 LARGE INDICATORS MODE(LCD) ..............291 LARGE INDICATORS DISP. SETTING ..............292 INFORMATION CONTRAST ADJ................292 LOCATION INFO ......................293 x Q MENU BACKGROUND ................. 293 F Q MENU BACKGROUND ................. 293 BUTTON/DIAL SETTING ................294 FOCUS LEVER SETTING ...................
Page 23 Table of Contents SAVE DATA SETTING ..................308 FRAME NO........................308 EDIT FILE NAME ......................309 x CARD SLOT SETTING ..................309 SELECT SLOT(xSEQUENTIAL) ................309 SELECT FOLDER ......................310 COPYRIGHT INFO ......................310 GEOTAGGING ........................ 310 Shortcuts Shortcuts Shortcut Options ....................312 MY MENU ......................313 MY MENU SETTING ....................
Page 24 RAW FILE CONVERTER EX powered by SILKYPIX ........359 Capture One Express for Fujifi lm ..............360 Capture One for Fujifi lm ..................360 FUJIFILM Tether Shooting Plug-in (Exclusively for Lightroom) ..360 FUJIFILM X Acquire ....................361 FUJIFILM X RAW STUDIO ..................361 FUJIFILM Pixel Shift Combiner ................
Page 25: Supplied Accessories
Supplied Accessories The following are included with the camera: • NP-W235 rechargeable battery For reasons of safety, the battery is not charged at shipment. The camera will not function if the battery is not charged; be sure to charge the battery before use (P 42). •...
Page 26: About This Manual
About This Manual This manual contains instructions for your FUJIFILM X-T5 dig- ital camera. Be sure you have read and understood its con- tents before proceeding. Symbols and Conventions The following symbols are used in this manual: Information that should be read to prevent damage to the product.
Page 27: Before You Begin
Before You Begin...
Page 28: Parts Of The Camera
Parts of the Camera Fn1 button .............321 Lens release button ........35 Exposure compensation dial ....6, 99 Fn2 button .............321 Shutter button ..........55 AF-assist illuminator........150 Shutter speed dial Self-timer lamp ..........168 ..........5, 72, 74, 78, 80 Tally light ............199 Dial lock release ..........5 STILL/MOVIE mode dial .....
Page 29 Parts of the Camera b (delete) button ...........59 Selector buttons ..........4 a (playback) button ........56 MENU/OK button ..........24 Battery-chamber cover latch ......36 Electronic viewﬁ nder (EVF) ............. 12, 16, 18, 26 Battery-chamber cover .........36 DISP (display)/BACK button ....19, 221 Eye cup (lockable) ...........11 x(Bluetooth) button ........249 VIEW MODE button .........16...
Page 30: The Serial Number Plate
The Serial Number Plate Do not remove the serial number plate, which provides the CMIIT ID, serial num- ber, and other important information. Serial number plate The Focus Stick (Focus Lever) Tilt or press the focus stick to select the fo- cus area.
Page 31: The Shutter Speed And Sensitivity Dials
Parts of the Camera The Shutter Speed and Sensitivity Dials Press the dial lock release to release the dial before rotating it to the desired set- ting. Press the release again to lock the dial in place. Shutter speed Sensitivity STILL/MOVIE mode dial Rotate the STILL/MOVIE mode dial to STILL to take photos and to MOVIE to record...
Page 32: The Exposure Compensation Dial
The Exposure Compensation Dial Rotate the dial to choose an exposure compensation amount. The Drive Dial Rotate the dial to choose from the follow- ing the drive modes. Mode Mode Mode Mode u Panorama CL CL Low-speed burst ADV. ADV. Advanced ﬁlter S S Single frame h HDR BKT Bracketing...
Page 33: The Command Dials
Parts of the Camera The Command Dials Rotate or press the command dials to: Front command dial Rear command dial • Highlight menu items • Choose the desired combina- • Select menu tabs or page tion of shutter speed and aper- through menus ture (program shift) •...
Page 34 4 Available only if FOCUS CHECK is assigned to a function button. 5 Exposure compensation dial rotated to C or ON selected for MOVIE OPTIMIZED CONTROL oL. 6 Can be used to switch back and forth between aperture, sensitivity, and exposure com- pensation when exposure compensation dial is rotated to C or ON is selected for MOVIE OPTIMIZED CONTROL oL.
Page 35: The Indicator Lamp
Parts of the Camera The Indicator Lamp Camera status is shown by the indicator lamp. Indicator lamp Indicator lamp Camera status Camera status Glows green Focus locked. Focus or slow shutter speed warning. Pictures can be Blinks green taken. • Camera on: Recording pictures, or picture displayed for conﬁ...
Page 36: The Lcd Monitor
The LCD Monitor The LCD monitor can be tilted for eas- ier viewing, but be careful not to touch the wires or trap fi ngers or other objects behind the monitor. Touching the wires could cause camera malfunction. The LCD monitor also functions as a touch screen that can be used for: •...
Page 37: The Eye Cup
Parts of the Camera The Eye Cup To remove the eye cup, hold the buttons on either side and slide eye cup up. Focusing the Viewfi nder If the indicators displayed in the viewfi nder are blurred, put your eye to the viewfi nder and rotate the diopter adjustment control until the display is in sharp focus.
Page 38: Camera Displays
Camera Displays This section lists the indicators that may be displayed during shooting. For illustrative purposes, displays are shown with all indicators lit. The Electronic Viewfi nder F L M N O P Q GHIJK U V W...
Page 39 Camera Displays Crop factor .............193 Temperature warning ......39, 393 IS mode ............174 Control lock ..........305 Flash (TTL) mode .........346 Boost mode ...........307 Flash compensation ........346 Power supply ............44 Movie compression ........191 Histogram ............22 Digital teleconverter ........175 Battery level ............47 Self-timer indicator ......168, 190 Sensitivity ............96 Continuous mode ........105...
Page 40: The Lcd Monitor
The LCD Monitor C DE...
Page 41 Camera Displays Crop factor .............193 Touch zoom ............30 Location data download status ....310 Temperature warning ......39, 393 Focus check ..........94, 156 Control lock ..........305 Depth-of-ﬁ eld preview ......79, 93 Battery level ............47 Image transfer status ......249, 264 Power supply ............44 Movie compression ........191 Sensitivity ............96 Digital teleconverter ........175...
Page 42: Choosing A Display Mode
Choosing a Display Mode Press the VIEW MODE button to cycle through the following display modes. You can choose separate display modes for shooting and playback. Use D SCREEN SET-UP > VIEW MODE SETTING in the setup menu to choose a display mode for the EVF and LCD monitor. SHOOTING Option Option...
Page 43 Camera Displays PLAYBACK Option Option Description Description Putting your eye to the viewﬁ nder turns the viewﬁ nder E EYE SENSOR EYE SENSOR on and the LCD monitor oﬀ ; taking your eye away turns the viewﬁ nder oﬀ and LCD monitor on. LCD ONLY LCD ONLY LCD monitor on, viewﬁ...
Page 44: Adjusting Display Brightness
Adjusting Display Brightness The brightness and saturation of the viewfi nder and LCD monitor can be adjusted using the items in the D SCREEN SET-UP menu. Choose EVF BRIGHTNESS or EVF COLOR to adjust viewfi nder brightness or saturation, LCD BRIGHTNESS or LCD COLOR to do the same for the LCD monitor.
Page 45: The Disp/Back Button
Camera Displays The DISP/BACK Button The DISP/BACK button controls the display of indicators in the viewfi nder and LCD monitor. Indicators for the EVF and LCD must be selected separately. To choose the EVF dis- play, place your eye to the viewfi nder while using the DISP/BACK button.
Page 46: The Dual Display
LCD Monitor Standard indicators No indicators 12800 12800 Dual display Info display (manual focus mode only) The Dual Display The dual display consists of a large full-frame window and a smaller close-up of the focus area.
Page 47: Customizing The Standard Display
Camera Displays Customizing the Standard Display To choose the items shown in the standard indicator display: Display standard indicators. Use the DISP/BACK button to display standard indicators. Select DISP. CUSTOM SETTING. Select D SCREEN SET-UP > DISP. CUSTOM SETTING in the setup menu.
Page 48 Framing Outline Enable FRAMING OUTLINE to make the borders of the frame easier to see against dark backgrounds. Histograms Histograms show the distribution of tones in the image. Brightness is shown by the horizontal axis, the number of pixels by the vertical axis. Number of pixels Shadows Highlights...
Page 49: Virtual Horizon
Camera Displays Virtual Horizon Check whether the camera is level. The display type can be cho- sen using D SCREEN SET-UP > ELECTRONIC LEVEL SETTING. Use the virtual horizon to level the camera when mounting it on a tripod or the like. Pitch Roll •...
Page 50: Using The Menus
Using the Menus To display the menus, press MENU/OK. The Menus Diff erent menus are displayed during still photography, movie recording, and playback. IMAGE QUALITY SETTING IMAGE SIZE IMAGE QUALITY RAW RECORDING SELECT JPEG/HEIF FILM SIMULATION MONOCHROMATIC COLOR GRAIN EFFECT COLOR CHROME EFFECT EXIT STILL/MOVIE mode dial...
Page 51: Selecting A Menu Tab
Using the Menus Selecting a Menu Tab To navigate the menus: Press MENU/OK to display the menus. IMAGE QUALITY SETTING IMAGE SIZE IMAGE QUALITY RAW RECORDING SELECT JPEG/HEIF FILM SIMULATION MONOCHROMATIC COLOR GRAIN EFFECT COLOR CHROME EFFECT EXIT Press the selector left to highlight the IMAGE QUALITY SETTING IMAGE SIZE tab for the current menu.
Page 52: Touch Screen Mode
Touch Screen Mode The LCD monitor also functions as a touch screen. Shooting Touch Controls To enable touch controls, select ON for TOUCH SCREEN SETTINGS D BUTTON/DIAL SETTING > TOUCH TOUCH SCREEN SETTING DOUBLE TAP SETTING SCREEN SETTING > x TOUCH SCREEN TOUCH FUNCTION TOUCH ZOOM TOUCH SCREEN SETTING...
Page 53 Touch Screen Mode LCD Monitor The operation performed can be selected by tapping the touch screen mode indica- tor in the display. Touch controls can be used for the following operations: Mode Mode Description Description Tap your subject in the display to focus and release the shutter. TOUCH TOUCH In burst mode, pictures will be taken while you keep your ﬁ...
Page 54 N • To disable touch controls and hide the touch screen mode indica- tor, select OFF for D BUTTON/DIAL SETTING > TOUCH SCREEN SETTING > x TOUCH SCREEN SETTING. • Touch control settings can be adjusted using G AF/MF SETTING > TOUCH SCREEN MODE. For information on the touch controls available during movie recording, see “Movie Recording (F TOUCH SCREEN MODE;...
Page 55 Touch Screen Mode Touch Function Functions can be assigned to the follow- ing fl ick gestures in much the same way as function buttons (P 321): • Flick up: T-Fn1 • Flick left: T-Fn2 • Flick right: T-Fn3 • Flick down: T-Fn4 N •...
Page 56 Touch Zoom If the lens supports touch zoom, you can zoom in and out by touching the display. Tap the touch zoom button in the display to enable touch zoom. Touch zoom is controlled using the but- tons in the display. Button Button Description...
Page 57: Playback Touch Controls
Touch Screen Mode Playback Touch Controls When ON is selected for D BUTTON/DIAL SETTING > TOUCH SCREEN SETTING > a TOUCH SCREEN SETTING, touch controls can be used for the following playback operations: • Swipe: Swipe a fi nger across the display to view other images.
Page 58 MEMO...
Page 59: First Steps
First Steps...
Page 60: Attaching The Strap
Attaching the Strap Attach the strap. Attach the strap to the two strap clips as shown below. To avoid dropping the camera, be sure the strap is correctly secured.
Page 61: Attaching A Lens
Lenses and Other Optional Accessories The camera can be used with lenses and accessories for the FUJIFILM X-mount. Observe the following precautions when attaching or removing (ex- changing) lenses.
Page 62: Inserting The Battery
Inserting the Battery Insert the battery in the camera as described below. Open the battery-chamber cover. Slide the battery-chamber cover latch as shown and open the bat- tery-chamber cover. O • Do not open the battery-chamber cover when the camera is on. Fail- ure to observe this precaution could damage image fi les or memory cards.
Page 63 Inserting the Battery Close the battery-chamber cover. Close and latch the cover. If the cover does not close, check that the battery is in the correct orienta- tion. Do not attempt to force the cov- er shut. Removing the Battery Before removing the battery, turn the camera off and open the battery-cham- ber cover.
Page 64: Inserting Memory Cards
Inserting Memory Cards Pictures are stored on memory cards (sold separately). The camera can be used with two cards, one in each of its two slots. Open the memory card slot cover. Unlatch and open the cover. Do not turn the camera off or remove the memory card while the memory card is being formatted or data are being recorded to or de- leted from the card.
Page 65 Inserting Memory Cards Removing Memory Cards Turn the camera off and open the memory card slot cover. Eject the card by pressing it in with a fi nger and then slowly releasing it; the card can then be removed by hand. O •...
Page 66: Using Two Cards
Using Two Cards The camera can be used with two cards, one in each of its two slots. At default settings, photos are saved to the card in the sec- ond slot only when the card in the fi rst slot is full. This can be changed using D SAVE DATA SET-UP >...
Page 67: Compatible Memory Cards
• A list of supported memory cards is available on the Fujifi lm website. For details, visit: https://fujifilm-x.com/support/compatibility/cameras/. O • Do not turn the camera off or remove the memory card while the memo- ry card is being formatted or data are being recorded to or deleted from the card.
Page 68: Charging The Battery
Charging the Battery For reasons of safety, the battery is not charged at ship- ment. The camera will not function if the battery is not charged; be sure to charge the battery before use. Before charging the battery, turn the camera off . O •...
Page 69 Charging the Battery Charge Status The indicator lamp shows battery charge status as follows: Indicator lamp Indicator lamp Battery status Battery status Battery charging Oﬀ Charging complete Blinks Charging error...
Page 70 O • The supplied AC power adapter is compatible with power supplies of 100 to 240 V (a plug adapter may be needed for overseas use). • Do not use the AC power adapter or USB cable with other devices, as this could cause malfunction.
Page 71 Charging the Battery Charging via Computer The camera can be charged via USB. USB charging is available with com- puters with a manufacturer-approved operating system and USB interface. Leave the computer on during charging. O • The battery will not charge while the camera is on. •...
Page 72: Turning The Camera On And Off
Turning the Camera On and Off Use the ON/OFF switch to turn the camera on and off . Slide the switch to ON to turn the camera on, or to OFF to turn the camera off . Fingerprints and other marks on the lens or viewfi nder can aff ect pic- tures or the view through the viewfi nder.
Page 73: Checking The Battery Level
Checking the Battery Level After turning the camera on, check the battery level in the display. Battery level is shown as follows: Indicator Indicator Description Description Battery partially discharged. Battery about 80% full. Battery about 60% full. Battery about 40% full. Battery about 20% full.
Page 74: Basic Setup
Basic Setup When you turn the camera on for the fi rst time, you can choose a language and set the camera clock. Follow the steps below when turning the camera on for the fi rst time. Turn the camera on. A language-selection dialog will be displayed.
Page 75 Basic Setup Set the clock. DATE/TIME GMT +1:00 BERLIN/PARIS 2022 31 12 View information on the smartphone app. • The camera will display a QR code APPLICATION you can scan with your smartphone IMAGES CAN BE EASILY TRANSFERRED TO THE SMARTPHONE. to open a website where you can download the smartphone app.
Page 76: Choosing A Diff Erent Language
Basic Setup Choosing a Diff erent Language To change the language: Display language options. Select D USER SETTING > Qa. Choose a language. Highlight the desired option and press MENU/OK. Changing the Time and Date To set the camera clock: Display DATE/TIME options. Select D USER SETTING >...
Page 77: Basic Photography And Playback
Basic Photography and Playback...
Page 78: Taking Photographs (Mode P)
Taking Photographs (Mode P) This section describes how to take pictures using program AE (mode P). See pages 72–81 for information on S, A, and M modes. Rotate the STILL/MOVIE mode dial to STILL. Slide the lens aperture mode switch to A.
Page 79 Taking Photographs (Mode P) Rotate the drive dial to S. Rotate the sensitivity dial to A. Rotate the focus mode selector to S.
Page 80 Ready the camera. • Hold the camera steady with both hands and brace your elbows against your sides. Shaking or un- steady hands can blur your shots. • To prevent pictures that are out of focus or too dark (underexposed), keep your fi ngers and other objects away from the lens and AF-assist illuminator.
Page 81 Taking Photographs (Mode P) Focus. Press the shutter button halfway to set focus and exposure. Focus indicator Focus frame • If the camera is able to focus, the focus frame and focus indicator will glow green. • If the camera is unable to focus, the focus frame will turn red, s will be displayed, and the focus indicator will blink white.
Page 82: Viewing Pictures
Viewing Pictures Pictures can be viewed in the viewfi nder or LCD monitor. To view pictures full frame, press a. 100-0001 Additional pictures can be viewed by pressing the selector left or right or rotating the front command dial. Press the selector or rotate the dial right to view pictures in the order recorded, left to view pictures in reverse order.
Page 83: Hdmi Output
Viewing Pictures HDMI Output Camera shooting and playback displays can be output to HDMI devices. Connecting to HDMI Devices Connect the camera to TVs or other HDMI devices using a third-party HDMI cable. Turn the camera off . Connect the cable as shown below. Insert into HDMI connector Insert into HDMI Micro...
Page 84 Viewing Pictures Shooting Display live view or movie footage on a TV or save it to an exter- nal recorder that supports HDMI input. Playback To start playback, press the camera a button. The camera mon- itor turns off and pictures and movies are output to the HDMI device.
Page 85: Deleting Pictures
Deleting Pictures Use the b button to delete pictures. Deleted pictures cannot be recovered. Protect important pictures or copy them to a computer or other storage device before proceeding. With a picture displayed full frame, press the b button and select FRAME.
Page 86 MEMO...
Page 87: Movie Recording And Playback
Movie Recording and Playback...
Page 88: Recording Movies
Recording Movies Record movies with sound. Recording Movies Movies can be recorded by pressing the shutter button when the STILL/MOVIE mode dial is rotated to MOVIE or by pressing a function button to which MOVIE RECORDING RELEASE is assigned. The STILL/MOVIE Mode Dial (MOVIE) For access to a full range of camera settings when fi lming movies, rotate the STILL/MOVIE mode dial to MOVIE and record movies by pressing the shutter button.
Page 89 Recording Movies Rotate the shutter speed dial to A. AUTO will appear in the display. Rotate the sensitivity dial to A. Rotate the focus mode selector to C. To use the shutter speed and sensitivity dials, press the dial lock release and rotate the dial to the desired setting.
Page 90 Press the shutter button all the way down. Recording will start. • A recording indicator (V) is dis- played while recording is in prog- ress. • The borders of the display turn Recording time red during movie recording, green Time remaining during high-speed recording.
Page 91 Recording Movies Using a Function Button (MOVIE RECORDING RELEASE) Use the function button to which MOVIE RECORDING RELEASE is assigned to quickly and easily record movies while in still pho- tography mode. The camera automatically selects focus mode C (AF-C); exposure is adjusted automatically.
Page 92 O • Sound is recorded via the built-in microphone or an optional external microphone. Do not cover the microphone during recording. • Note that the microphone may pick up lens noise and other sounds made by the camera during recording. •...
Page 93 Recording Movies Temperature Warnings The camera automatically turns off to protect itself when its temperature or the temperature of the battery rises. If a temperature warning is displayed, image noise may increase. Turn the camera off and wait for it to cool before turning it on again.
Page 94: Adjusting Movie Settings
Recording Movies Adjusting Movie Settings Movie settings can be adjusted from the movie menus or using the B MOVIE SETTING item in the photo menus (P 24). • Use the B MOVIE SETTING item in the photo menus to quickly adjust settings when recording movies via a button to which MOVIE RECORDING RELEASE has been assigned (P 183).
Page 95: Viewing Movies
Viewing Movies View movies on the camera. In full-frame playback, movies are identi- fi ed by a W icon. Press the selector down to start movie playback. PLAY AUDIO SET. The following operations can be per- formed while a movie is displayed: Playback in Playback in Playback...
Page 96 Viewing Movies Playback Speed Press the selector left or right to adjust play- 29m59s back speed during playback. Speed is shown by the number of arrows (M or N). Arrows...
Page 97: Taking Photographs
Taking Photographs...
Page 98: P, S, A, And M Modes
P, S, A, and M Modes P, S, A, and M modes give you varying degrees of control over shutter speed and aperture. Mode P: Program AE Let the camera choose shutter speed and aperture for optimal exposure. Other values that produce the same exposure can be selected with program shift.
Page 99 P, S, A, and M Modes O • If the subject is outside the metering range of the camera, the shutter speed and aperture displays will show “– – –”. • To use the shutter speed dial, press the dial lock release and rotate the dial to the desired setting.
Page 100: Mode S: Shutter-Priority Ae
Mode S: Shutter-Priority AE Choose a shutter speed and let the camera adjust aperture for optimal exposure. Rotate the STILL/MOVIE mode dial to STILL. Slide the lens aperture mode switch to A. Rotate the shutter speed dial to se- lect a shutter speed. S will appear in the display.
Page 101 P, S, A, and M Modes O • If the correct exposure cannot be achieved at the selected shutter speed, aperture will be displayed in red. • If the subject is outside the metering range of the camera, the aper- ture display will show “–...
Page 102 Rotate the rear command dial to choose a shutter speed. Press the shutter button all the way down to take a picture at the selected shutter speed. At speeds of 1 s or slower, a count-down timer will be displayed while the exposure is in progress.
Page 103 P, S, A, and M Modes Press the shutter button all the way down. • The shutter will remain open for up to 60 minutes while the shutter button is pressed. • The display shows the time elapsed since the exposure started.
Page 104: Mode A: Aperture-Priority Ae
Mode A: Aperture-Priority AE Choose an aperture and let the camera adjust shutter speed for optimal exposure. Rotate the STILL/MOVIE mode dial to STILL. Rotate the shutter speed dial to A. Slide the lens aperture mode switch to Z. A will appear in the display. Rotate the lens aperture ring to choose an aperture.
Page 105 P, S, A, and M Modes O • If the correct exposure cannot be achieved at the selected aperture, shutter speed will be displayed in red. • If the subject is outside the metering range of the camera, the shutter speed display will show “–...
Page 106: Mode M: Manual Exposure
Mode M: Manual Exposure In manual mode, the user controls both shutter speed and aperture. Shots can be deliberately overexposed (brighter) or underexposed (darker), opening the door for a variety of individual creative ex- pression. The amount the picture would be under- or over-exposed at current settings is shown by the exposure indicator;...
Page 107 P, S, A, and M Modes Rotate the shutter speed dial to choose a shutter speed and the lens aperture ring to choose an aperture. The manual exposure display includes an exposure indicator that shows the amount the picture would be under- or over-exposed at current settings.
Page 108: Autofocus
Autofocus Take pictures using autofocus. Rotate the focus mode selector to S or C (P 83). Choose an AF mode (P 85). Choose the position and size of the focus frame (P 87). Take pictures.
Page 109: Focus Mode
Autofocus Focus Mode Use the focus mode selector to choose how the camera focuses. Choose from the following options: Mode Mode Description Description Single AF: Focus locks while the shutter button is pressed halfway. (AF-S) Choose for stationary subjects. Continuous AF: Focus is continually adjusted to reﬂ ect changes in the distance to the subject while the shutter button is pressed (AF-C) halfway.
Page 110 The Focus Indicator Focus status is shown by the focus indicator. Focus indicator Focus indicator Focus status Focus status Camera focusing. Subject in focus; focus locked (focus z (lights green) mode S). Subject in focus (focus mode C). Focus indicator (z) (lights green) Focus is automatically adjusted for changes in distance to subject.
Page 111: Autofocus Options (Af Mode)
Autofocus Autofocus Options (AF Mode) Focus can be adapted to a variety of subjects by changing the combination of settings selected for focus and AF modes. Press MENU/OK and go to the shooting menu. Select G AF/MF SETTING > AF MODE. Choose an AF mode.
Page 112 Focus Mode C (AF-C) Focus Mode C (AF-C) Option Option Description Description Sample image Sample image Focus tracks subject at selected fo- cus point. Use for subjects moving SINGLE POINT toward or away from camera. Camera tracks focus in selected fo- cus zone.
Page 113: Focus-Point Selection
Autofocus Focus-Point Selection Choose a focus point for autofocus. Viewing the Focus-Point Display Press MENU/OK and go to the shooting menu. Select G AF/MF SETTING > FOCUS AREA to view the fo- cus-point display. Use the focus stick (focus lever) and rear command dial to choose a focus area.
Page 114 N • Manual focus-point selection is not available when z WIDE/TRACKING is selected in focus mode S. • If j ALL is selected for AF mode, you can rotate the rear command dial in the focus-point selection display to cycle through AF modes in the following order: r SINGLE POINT (6 frame sizes), y ZONE (3 frame sizes), and either z WIDE (focus mode S) or z TRACKING (focus mode C).
Page 115 Autofocus Autofocus Although the camera boasts a high-precision autofocus system, it may be unable to focus on the subjects listed below. • Very shiny subjects such as mirrors or car bodies. • Subjects photographed through a window or other refl ective object. •...
Page 116 Autofocus Checking Focus To zoom in on the current focus area for precise focus, press the center of the rear command dial. Use the focus stick (focus lever) to choose another focus area. Press the center of the rear command dial again to cancel zoom. Normal display Focus zoom N •...
Page 117: Manual Focus
Manual Focus Adjust focus manually. Rotate the focus mode selector to M. j will appear in the display. Focus manually using the lens focus ring. Rotate the ring left to reduce the focus distance, right to increase. Take pictures. N • Use D BUTTON/DIAL SETTING >...
Page 118 Quick Focus • To use autofocus to focus on the subject in the selected focus area, press the button to which focus lock or AF-ON has been assigned (the size of the focus area can be chosen with the rear command dial). •...
Page 119: Checking Focus
Manual Focus Checking Focus A variety of options are available for checking focus in manual focus mode. The Manual Focus Indicator The white line indicates the distance to the subject in the fo- cus area (in meters or feet according to the option selected for D SCREEN SET-UP >...
Page 120 Focus Zoom If ON is selected for G AF/MF SETTING > FOCUS CHECK, the camera will automatically zoom in on the selected focus area when the focus ring is rotated. Press the center of the rear com- mand dial to exit zoom. N •...
Page 121 Manual Focus • FOCUS PEAK HIGHLIGHT: Highlights high-con- trast outlines. Rotate the focus ring until the subject is highlighted. • FOCUS METER: A meter is displayed below the focus point indicating whether fo- cus is in front of or behind the subject. The needle swings left when focus is in front of the subject and right when it is behind the subject.
Page 122: Sensitivity
Sensitivity Adjust the camera’s sensitivity to light. Press the sensitivity dial lock release, ro- tate the dial to the desired setting, and press the release again to lock the dial in place. Option Option Description Description Sensitivity is automatically adjusted in response to shooting conditions according to option chosen for A SHOOTING A (auto) SETTING > ISO AUTO SETTING.
Page 123: Auto
Sensitivity AUTO Use A SHOOTING SETTING > ISO AUTO SETTING to choose the base sensitivity, maximum sensitivity, and minimum shut- ter speed for the A position on the sensitivity dial. Settings for AUTO1, AUTO2, and AUTO3 can be stored separately; the de- faults are shown below.
Page 124: Metering
Metering Choose how the camera meters exposure. A SHOOTING SETTING > PHOTOMETRY off ers a choice of the following metering options: The selected option will only take eff ect if OFF is selected for g FACE/ EYE DETECTION SETTING and SUBJECT DETECTION SETTING in the G AF/MF SETTING menu.
Page 125: Exposure Compensation
Exposure Compensation Adjust exposure. Rotate the exposure compensation dial. O • The amount of compensation available varies with the shooting mode. • Exposure compensation can be previewed in the shooting display, although the display may not accurately refl ect its eff ects if: the exposure compensation amount exceeds ±3 EV, W 200% or X 400% is selected for DYNAMIC RANGE, or STRONG or WEAK is selected for D RANGE PRIORITY.
Page 126: C (Custom)
Exposure Compensation Exposure Compensation C (Custom) When the exposure compensation dial is rotated to C, exposure compensation can be adjusted by rotating the front com- mand dial. N • The front command dial can be used to set exposure compensation to values between −5 and +5 EV.
Page 127: Focus/Exposure Lock
Focus/Exposure Lock Focus and exposure lock when the shutter button is pressed halfway. Position the subject in the focus frame and press the shutter button halfway to lock focus and exposure. Focus and exposure will remain locked while the shutter button is pressed halfway (AF/AE lock).
Page 128: Other Controls
Focus/Exposure Lock Other Controls Focus and exposure can also be locked using the AEL and AFON buttons. At de- fault settings, you can use the AEL button to lock exposure without locking focus. If the AFON button is assigned AF LOCK ONLY, it can similarly be used to lock fo- AEL button cus without locking exposure.
Page 129: Bracketing
Bracketing Automatically vary settings over a series of pictures. Rotate the drive dial to BKT. Navigate to DRIVE SETTING > BKT SETTING in the A SHOOTING SETTING menu (P 162). This feature can also be accessed via shortcuts (P 312). Take photographs.
Page 130: Film Simulation Bkt
Bracketing X FILM SIMULATION BKT Each time the shutter is released, the camera takes one shot and processes it to create copies with diff erent fi lm simulation set- tings. V WHITE BALANCE BKT Select a bracketing amount (±1, ±2, or ±3). Each time the shutter is released, the camera takes one shot and processes it to create three copies: one at the current white balanced setting, one with fi ne-tuning increased by the selected amount, and another with...
Page 131: Continuous Shooting (Burst Mode)
Continuous Shooting (Burst Mode) Capture motion in a series of pictures. Rotate the drive dial to select CH (high- speed burst) or CL (low-speed burst). Navigate to DRIVE SETTING in the A SHOOTING SETTING menu and choose a frame advance rate. This feature can also be accessed via shortcuts (P 312).
Page 132 Continuous Shooting (Burst Mode) O • If fi le numbering reaches 9999 before shooting is complete, the re- maining pictures will be recorded to a new folder. • Shooting ends when the memory card is full; the camera will record all photos shot to that point.
Page 133: Hdr
Each time the shutter button is pressed, the camera takes three shots, varying exposure each time, and combines them into a single picture. The resulting photograph pre- serves details in highlights and shadows. Rotate the drive dial to HDR. Navigate to DRIVE SETTING > HDR MODE in the A SHOOTING SETTING menu and choose the amount the brightnesses of the exposures vary (P 166).
Page 134 O • Keep the camera steady. • The desired results may not be achieved in the subject moves or the composition or lighting changes during shooting. • The picture will be cropped a very small amount and the resolution will drop slightly. •...
Page 135: Advanced Filters
Advanced Filters Take photos with fi lter eff ects. Rotate the drive dial to ADV.. Navigate to DRIVE SETTING > ADV. FILTER SETTING in the A SHOOTING SETTING menu and choose a fi lter eff ect. This feature can also be accessed via shortcuts (P 312). Take photographs.
Page 136: Advanced Filter Options
Advanced Filters Advanced Filter Options Choose from the following fi lters: Filter Filter Description Description G TOY CAMERA Choose for a retro toy camera eﬀ ect. The tops and bottoms of pictures are blurred for a H MINIATURE diorama eﬀ ect. I POP COLOR Create high-contrast images with saturated colors.
Page 137: Panoramas
Panoramas Follow an on-screen guide to create a panorama. Rotate the drive dial to u. To select the size of the angle through which you will pan the camera while shooting, press the selector left. Highlight a size and press MENU/OK. Press the selector right to view a choice of pan directions.
Page 138 For Best Results • Move the camera slowly in a small circle at a steady speed • Keep the camera parallel or at right angles to the horizon and be sure to pan only in the direction shown by the guides •...
Page 139 Panoramas Viewing Panoramas With the panorama displayed full frame, press the selector down to start panorama playback. Vertical panoramas will scroll vertically, horizontal pan- oramas horizontally. PLAY STOP PAUSE • In full-frame playback, you can use the rear command dial to zoom pan- oramas in or out.
Page 140: Multiple Exposures
Multiple Exposures Create a photograph that combines multiple exposures. Select ON for A SHOOTING SETTING > MULTI EXPOSURE and choose a blend mode (P 176). Take the fi rst shot. Press MENU/OK. The fi rst shot will be shown superimposed on the view through the lens and you will be prompted to take the second shot.
Page 141 Multiple Exposures Press MENU/OK. The combined exposures will be dis- played as a guide to composing the next shot. RETRY EXIT N • If you would like to retake the second shot, press the selector left. • To end shooting and create a multiple exposure from the shots taken to this point, press DISP/BACK.
Page 142 MEMO...
Page 143: The Shooting Menus
The Shooting Menus...
Page 144: Image Quality Setting (Still Photography)
IMAGE QUALITY SETTING (Still Photography) Adjust image quality settings for still photography. To display image quality settings, press IMAGE QUALITY SETTING IMAGE SIZE MENU/OK in the photo shooting display and IMAGE QUALITY RAW RECORDING select the H (IMAGE QUALITY SETTING) SELECT JPEG/HEIF FILM SIMULATION tab.
Page 145: Image Quality
IMAGE QUALITY SETTING (Still Photography) IMAGE QUALITY Choose a fi le format and compression ratio. Option Option Description Description FINE Low compression ratios are used for higher-quality images. Higher compression ratios are used to increase the number of NORMAL images that can be stored. FINE + RAW Record both RAW and ﬁ...
Page 146: Raw Recording
, RAW FILE LOSSLESS COMPRESSED CONVERTER EX powered by SILKYPIX , FUJIFILM X RAW STUDIO, or other software that supports “lossless” RAW compression. Quality is the same as UNCOMPRESSED, but the resulting ﬁ les are anywhere from about 30 to 90 percent of their uncompressed size.
Page 147: Select Jpeg/Heif
IMAGE QUALITY SETTING (Still Photography) SELECT JPEG/HEIF Choose whether pictures are recorded in JPEG or HEIF. Option Option Description Description Pictures are recorded in the widely-supported JPEG for- JPEG mat. Pictures are recorded in HEIF, a format with excellent com- HEIF pression but limited options for viewing and sharing.
Page 148: Film Simulation
FILM SIMULATION Simulate the eff ects of diff erent kinds of fi lm, including black- and-white (with or without color fi lters). Choose a palette ac- cording to your subject and creative intent. Option Option Description Description PROVIA/STANDARD Ideal for a wide range of subjects. Vibrant reproduction, ideal for landscape and nature.
Page 149 MONOCHROME+G FILTER: Produces pleasing skin tones in portrait. Shoots in sepia tone. SEPIA N • Film simulation options can be combined with tone and sharpness settings. • Film simulation settings can also be accessed via shortcuts (P 312). • For more information, visit: https://fujifilm-x.com/global/tag/the-world-of-film-simulation/?post_type=xstories...
Page 150: Monochromatic Color
MONOCHROMATIC COLOR Add a reddish or bluish tinge (warm or MONOCHROMATIC COLOR cool color cast) to the a ACROS and b MONOCHROME monochrome fi lm simulations. Color can be adjusted on the WARM–COOL and G (Green)–M (Magenta) axes. GRAIN EFFECT Add a fi lm grain eff ect.
Page 151: Color Chrome Effect
IMAGE QUALITY SETTING (Still Photography) COLOR CHROME EFFECT Increase the range of tones available for rendering colors that tend to be highly saturated, such as reds, yellows, and greens. Option Option Description Description STRONG Choose for a strong eﬀ ect. WEAK Choose for a weak eﬀ...
Page 152: White Balance
WHITE BALANCE For natural colors, choose a white balance option that matches the light source. Option Option Description Description WA WHITE White balance is adjusted automatically. Choose for whiter PRIORITY whites in scenes lit by incandescent bulbs. AUTO White balance is adjusted automatically. AA AMBIENCE White balance is adjusted automatically.
Page 153 IMAGE QUALITY SETTING (Still Photography) Fine-Tuning White Balance Pressing MENU/OK after selecting a white WB SHIFT balance option displays the dialog shown at right; use the selector to fi ne-tune white balance. N • To exit without fi ne-tuning white balance, press DISP/BACK after se- lecting a white balance option.
Page 154 Custom White Balance Choose k, l, or m to adjust white CUSTOM 1 balance for unusual lighting conditions using a white object as a reference (col- ored objects can also be used to lend photos a color cast). A white balance tar- SHUTTER : NEW WB get will be displayed;...
Page 155 IMAGE QUALITY SETTING (Still Photography) Select k in the white balance menu. WHITE BALANCE The option currently selected for col- or temperature will be displayed. COLOR TEMPERATURE R:0 B:0 SHIFT Edit the color temperature using the COLOR TEMPERATURE selector and press MENU/OK. A fi ne-tuning dialog will be dis- played.
Page 156: Dynamic Range
DYNAMIC RANGE Adjust dynamic range. Wide dynamic ranges reduce loss of de- tail in highlights for more natural results with high-contrast or backlit scenes. Option Option Description Description V 100% Choose for increased contrast. AUTO W 200% Reduce loss of detail in highlights. X 400% Mottling may appear in pictures taken at higher values.
Page 157: Tone Curve
IMAGE QUALITY SETTING (Still Photography) TONE CURVE With reference to a tone curve, adjust the TONE CURVE HIGHLIGHTS SHADOWS appearance of highlights or shadows, making them harsher or softer. Choose higher values to make shadows and highlights harsher, lower values to make them softer.
Page 158: High Iso Nr
HIGH ISO NR Reduce noise in pictures taken at high sensitivities. Choose high- er values to reduce noise and smooth outlines, lower values to leave outlines visible. Options Options −4 −3 −2 −1 CLARITY Increase defi nition while altering tones in highlights and shad- ows as little as possible.
Page 159: Lens Modulation Optimizer
IMAGE QUALITY SETTING (Still Photography) LENS MODULATION OPTIMIZER Select ON to improve defi nition by adjusting for diff raction and the slight loss of focus at the periphery of the lens. Options Options COLOR SPACE Choose the gamut of colors available for color reproduction. Option Option Description...
Page 160: Select Custom Setting
x SELECT CUSTOM SETTING Recall settings saved to custom settings banks 1 through 7 (CUSTOM 1 through CUSTOM 7) using x EDIT/SAVE CUSTOM SETTING. Banks Banks NOTHING SELECTED CUSTOM 1 CUSTOM 2 CUSTOM 3 CUSTOM 4 CUSTOM 5 CUSTOM 6 CUSTOM 7 If you would prefer not to recall saved settings, select NOTHING SELECTED.
Page 161 IMAGE QUALITY SETTING (Still Photography) Editing Custom Settings Edit existing custom settings banks. Select H IMAGE QUALITY SETTING > x EDIT/SAVE CUSTOM SETTING in the shooting menu and press MENU/OK. To save settings for movie recording, navigate to B MOVIE SETTING in the movie menus and select F EDIT/SAVE CUSTOM SETTING.
Page 162 If DISABLE is selected for H IMAGE QUALITY SETTING > AUTO UPDATE CUSTOM SETTING in the photo menu or for B MOVIE SETTING > FAUTO UPDATE CUSTOM SETTING in the mov- ie menu, red dots will appear next to the edited items but the changes will not be saved automatically.
Page 163 IMAGE QUALITY SETTING (Still Photography) Copying Custom Settings Copy custom settings from one bank to another, overwriting the settings in the destination bank. If the source bank has been re- named, the name will also be copied to the destination bank. Select H IMAGE QUALITY SETTING >...
Page 164 Deleting Custom Settings Delete settings from selected custom settings banks. Select H IMAGE QUALITY SETTING > x EDIT/SAVE CUSTOM SETTING in the shooting menu and press MENU/OK. To save settings for movie recording, navigate to B MOVIE SETTING in the movie menus and select F EDIT/SAVE CUSTOM SETTING.
Page 165: Auto Update Custom Setting
IMAGE QUALITY SETTING (Still Photography) Renaming Custom Settings Banks Rename selected custom settings banks. Select H IMAGE QUALITY SETTING > x EDIT/SAVE CUSTOM SETTING in the shooting menu and press MENU/OK. To save settings for movie recording, navigate to B MOVIE SETTING in the movie menus and select F EDIT/SAVE CUSTOM SETTING.
Page 166: Xf Mount Adaptor Setting
xF MOUNT ADAPTOR SETTING Adjust settings for lenses attached via a mount adapter. The camera can store settings for multiple lenses (LENS 1 through LENS 6). N • DISTORTION CORRECTION, COLOR SHADING CORRECTION, and PERIPHERAL ILLUMINATION CORRECTION are available with lens- es connected via an M mount adapter.
Page 167 IMAGE QUALITY SETTING (Still Photography) COLOR SHADING CORRECTION Color (shading) variations between the center and edges of the frame can be ad- justed separately for each corner. To use color shading correction, follow the steps below. NEXT Rotate the rear command dial to choose a corner. The select- ed corner is indicated by a triangle.
Page 168 IMAGE QUALITY SETTING (Still Photography) PERIPHERAL ILLUMINATION CORRECTION Choose from values between –5 and +5. Choosing positive values increases peripheral illumination, while choosing negative values reduces peripheral il- lumination. Positive values are recom- CANCEL mended for vintage lenses, negative val- ues to create the eff ect of images taken with an antique lens or a pinhole camera.
Page 169: Af/Mf Setting (Still Photography)
AF/MF SETTING (Still Photography) Adjust focus settings for still photography. To display AF/MF settings, press MENU/OK AF/MF SETTING FOCUS AREA in the photo shooting display and select AF MODE AF-C CUSTOM SETTINGS the G (AF/MF SETTING) tab. STORE AF MODE BY ORIENTATION AF POINT DISPLAY xF WRAP FOCUS POINT NUMBER OF FOCUS POINTS...
Page 170: Af-C Custom Settings
AF-C CUSTOM SETTINGS Select focus-tracking options for focus AF-C CUSTOM SETTINGS SET 1 MULTI PURPOSE mode C. Choose from Sets 1–5 according to your subject or select Set 6 for custom focus-tracking options. TRACKING SENSITIVITY SPEED TRACKING SENSITIVITY ZONE AREA SWITCHING AUTO Option Option...
Page 171 AF/MF SETTING (Still Photography) Focus Tracking Options The individual parameters that are part of a focus tracking set are described below. TRACKING SENSITIVITY TRACKING SENSITIVITY This parameter determines how long the TRACKING SENSITIVITY camera waits to switch focus when an QUICK LOCKED ON object enters the focus area behind or in...
Page 172 ZONE AREA SWITCHING ZONE AREA SWITCHING This parameter determines the focus ZONE AREA SWITCHING area given priority in zone AF. CENTER AUTO FRONT SETS THE SWITCHING SENSITIVITY OF FOCUS FRAME IN ZONE AREA ADJUST SWITCH Option Option Description Description FRONT Zone AF assigns priority to the subjects closest to the camera.
Page 173 AF/MF SETTING (Still Photography) Custom Focus Tracking Options Follow the steps below to adjust settings for Set 6. Select AF-C CUSTOM SETTINGS > AF-C CUSTOM SETTINGS SET 6 CUSTOM SET 6 CUSTOM. TRACKING SENSITIVITY SPEED TRACKING SENSITIVITY AUTO ZONE AREA SWITCHING ADJUST SET DETAIL RESET...
Page 174: Store Af Mode By Orientation
STORE AF MODE BY ORIENTATION Choose whether the AF mode used when the camera is in por- trait orientation is stored separately from that used when the camera is in landscape orientation. Option Option Description Description The same settings are used in both orientations. FOCUS AREA ONLY The focus area for each orientation can be selected separately.
Page 175: Number Of Focus Points
AF/MF SETTING (Still Photography) NUMBER OF FOCUS POINTS Choose the number of focus points available for focus-point se- lection in manual focus mode or when SINGLE POINT is selected for AF MODE. Option Option Description Description Choose from 117 focus points arranged in a 9- by 13-point 117 POINTS (9 ×...
Page 176: Xf Af Illuminator
xF AF ILLUMINATOR If ON is selected, the AF-assist illuminator will light to assist autofocus. Options Options O • The camera may be unable to focus using the AF-assist illuminator in some cases. • If the camera is unable to focus, try increasing the distance to the subject.
Page 177: Face/Eye Detection Setting
AF/MF SETTING (Still Photography) g FACE/EYE DETECTION SETTING If the camera detects human faces, it will assign them priority over the background and adjust settings appropriately for por- traits when setting focus and exposure. You can also choose whether the camera focuses on the left or right eye when face detection is on.
Page 178 N • A single face detected in or near the focus area will be marked with a white frame. • If multiple faces are detected in the focus area, the camera will select one automatically. • You can choose a diff erent subject by tapping the display to repo- sition the focus area.
Page 179: Subject Detection Setting
AF/MF SETTING (Still Photography) SUBJECT DETECTION SETTING Choose whether the camera prioritizes subjects of a selected type, such as animals or vehicles, when setting focus. Option Option Description Description Select one of the subject types listed below to enable subject detection.
Page 180 N • A single subject of the chosen type detected in or near the focus area will be marked with a white frame. • If multiple subjects are detected in the focus area, the camera will select one automatically. • You can choose a diff erent subject by tapping the display to repo- sition the focus area.
Page 181: Af+Mf
AF/MF SETTING (Still Photography) AF+MF If ON is selected and focus has been locked (whether by pressing the shutter button halfway or by other means), focus lock can be ended and focus adjusted manually by rotating the focus ring. Options Options O •...
Page 182: Mf Assist
MF ASSIST Choose how focus is displayed in manual focus mode (P 94). Option Option Description Description Displays a black-and-white (MONOCHROME) or color (COLOR) DIGITAL SPLIT split image in the center of the frame. Frame the subject in the IMAGE split-image area and rotate the focus ring until the four parts of the split image are correctly aligned.
Page 183: Interlock Spot Ae & Focus Area
AF/MF SETTING (Still Photography) INTERLOCK SPOT AE & FOCUS AREA Choose ON to meter the current focus frame when SPOT or MULTI metering is selected. Options Options xF INSTANT AF SETTING Choose whether the camera focuses using single AF (AF-S) or continuous AF (AF-C) when a button to which focus lock or AF-ON is assigned is pressed in manual focus mode.
Page 184: Release/Focus Priority
RELEASE/FOCUS PRIORITY Choose how the camera focuses in focus mode AF-S or AF-C. Option Option Description Description Shutter response is prioritized over focus. Pictures can be taken RELEASE when the camera is not in focus. Focus is prioritized over shutter response. Pictures can be only FOCUS taken when the camera is in focus.
Page 185: Xf Af Range Limiter
AF/MF SETTING (Still Photography) xF AF RANGE LIMITER Limit the range of available focus distances for increased focus speed. Option Option Description Description Focus limiter disabled. Limit focus to a range of distances deﬁ ned by a minimum and maximum. •...
Page 186: Touch Screen Mode
TOUCH SCREEN MODE Choose the shooting operations performed using touch controls. Mode Mode Description Description Tap your subject in the display to focus and release the shutter. TOUCH In burst mode, pictures will be taken while you keep your ﬁ nger SHOOTING on the display.
Page 187 AF/MF SETTING (Still Photography) Touch Controls for Focus Zoom Diff erent touch controls are used during focus zoom (focus check enabled). Central Area Central Area Tapping the center of the display performs the operations below. Mode Mode Still Photography Still Photography TOUCH SHOOTING TOUCH SHOOTING AF-S/MF: Take a picture...
Page 188: Shooting Setting (Still Photography)
SHOOTING SETTING (Still Photography) Adjust shooting options for still photography. To display shooting settings, press MENU/OK SHOOTING SETTING DRIVE SETTING in the photo shooting display and select SPORTS FINDER MODE PRE-SHOT the A (SHOOTING SETTING) tab. SELF-TIMER SAVE SELF-TIMER SETTING SELF-TIMER LAMP The options available vary with the shoot- PHOTOMETRY ing mode selected.
Page 189 SHOOTING SETTING (Still Photography) AE BKT AE BKT The following options are available when O AE BKT is chosen for BKT SELECT. Option Option Description Description Choose the number of shots in the bracketing sequence and the amount exposure is varied with each shot. •...
Page 190 FOCUS BKT SETTING FOCUS BKT SETTING Choose from AUTO and MANUAL focus bracketing modes. • MANUAL: In MANUAL mode, you choose the following. Option Option Description Description FRAMES Choose the number of shots. STEP Choose the amount focus changes with each shot. INTERVAL Choose the interval between shots.
Page 191 SHOOTING SETTING (Still Photography) • AUTO: In AUTO mode, the camera calculates FRAMES and STEP automatically. Navigate to A SHOOTING SETTING > DRIVE SETTING > BKT SETTING in the photo menus, highlight FOCUS BKT, and press MENU/OK. Select AUTO and choose an INTERVAL. The view through the lens will be displayed.
Page 192 CH HIGH SPEED BURST Select the frame rate used when the drive dial is rotated to CH (continuous high speed). The display frame rate when the electronic shutter is used is 40 fps, or 60 fps in 1.29× crop mode. Options Options 20fps(1.29X CROP) R 13fps(1.29X CROP) R 10fps(1.29X CROP) R...
Page 193: Sports Finder Mode
SHOOTING SETTING (Still Photography) SPORTS FINDER MODE Take pictures using the crop in the center of the display. Choose this option for pic- tures of athletes, birds, and other moving subjects. Option Option Description Description Pictures are taken using a 1.29× crop, reducing the picture angle by an amount equivalent to increasing lens focal length by 1.29×;...
Page 194: Pre-Shot Sj
PRE-SHOT sJ To reduce the lag between your pressing the shutter button all the way down and the resulting picture being recorded to the memory card, the camera starts shooting with the electronic shutter when the shutter button is pressed halfway and saves a series shots starting just before the shutter button is pressed the rest of the way down.
Page 195: Save Self-Timer Setting
SHOOTING SETTING (Still Photography) SAVE SELF-TIMER SETTING If ON is selected, the chosen self-timer setting will remain in ef- fect after a picture is taken or the camera is turned off . Options Options SELF-TIMER LAMP If ON is selected, the self-timer lamp will light during self-timer photography.
Page 196: Shutter Type
SHUTTER TYPE Choose the shutter type. Choose the electronic shutter to mute the shutter sound. Option Option Description Description t MECHANICAL SHUTTER Take pictures with the mechanical shutter. s ELECTRONIC SHUTTER Take pictures with the electronic shutter. t E-FRONT CURTAIN Take pictures with the electronic front curtain shutter.
Page 197: Interval Timer Shooting
SHOOTING SETTING (Still Photography) INTERVAL TIMER SHOOTING Confi gure the camera to take photos automatically at a preset interval. Highlight INTERVAL TIMER SHOOTING INTERVAL TIMER SHOOTING in the A (SHOOTING SETTING) tab and press MENU/OK. WITH IN-CAMERA TIMER WITH EXTERNAL TIMER Highlight WITH IN-CAMERA TIMER INTERVAL/NUMBER OF TIMES INTERVAL...
Page 198: Interval Timer Shooting Exposure Smoothing
N • Use of a tripod is recommended. • We recommend using an AC-5VJ AC power adapter. • To view the pictures taken so far, press the a button during inter- val-timer photography. To return to the shooting display, press the a button again or wait until the start of the next interval.
Page 199: Interval Priority Mode
INTERVAL PRIORITY MODE If ON is selected, the camera will adjust shutter speed during in- terval-timer photography to ensure that exposures are not lon- ger than the interval between photographs. Options Options This option takes eff ect only when shutter speed is set to A (auto). FLICKER REDUCTION Reduce fl icker in pictures and the display when shooting under fl uorescent lighting and other similar light sources.
Page 200: Flickerless S.s. Setting
FLICKERLESS S.S. SETTING Select ON to allow shutter speed to be fi ne-tuned to reduce fl ick- er caused by LED lighting and the like. Options Options This option takes eff ect only in modes S and M. IS MODE Turn image stabilization on or off .
Page 201: Iso Auto Setting
SHOOTING SETTING (Still Photography) ISO AUTO SETTING Choose the base sensitivity, maximum sensitivity, and minimum shutter speed for use when ISO sensitivity is set to A (auto). Set- tings for AUTO1, AUTO2, and AUTO3 can be stored separately (P 97). DIGITAL TELE-CONV. Zoom in on your subject during shooting using ultra-high-reso- lution digital zoom.
Page 202: Multi Exposure
MULTI EXPOSURE Choose how the camera combines shots to create a multiple ex- posure. Option Option Description Description Adjust multiple exposure settings and record multiple expo- sures. • ADDITIVE: The camera adds the exposures together. You may need to lower exposure compensation depending on the number of shots.
Page 203: Pixel Shift Multi Shot
To minimize vibration, use the self-timer or a remote re- lease. Combine the shots on a computer. • The shots can be combined using FUJIFILM Pixel Shift Combiner. • To save high-resolution RAW pictures in other formats, use Capture One Express for Fujifi lm, Capture One for Fujifi lm, or Capture One Pro, available from Capture One A/S.
Page 204 Capture One Pro: https://www.captureone.com/explore-features • Pixel-shift multi-shot photography can be performed via tethered shooting. For this purpose, use FUJIFILM Pixel Shift Combiner. • The fl ash will synchronize with the shutter at shutter speeds of ½ 5 s or slower. •...
Page 205: Xf Wireless Communication
• Control the camera and take pictures remotely • Receive pictures uploaded from the camera • Browse the pictures on the camera and download selected pic- tures • Upload location data to the camera For more information, visit: https://app.fujifilm-dsc.com/...
Page 206: Flash Setting (Still Photography)
FLASH SETTING (Still Photography) Adjust fl ash-related settings for still photography. To display fl ash settings, press MENU/OK FLASH SETTING in the photo shooting display and select FLASH FUNCTION SETTING RED EYE REMOVAL the F (FLASH SETTING) tab. TTL-LOCK MODE LED LIGHT SETTING COMMANDER SETTING CH SETTING EXIT...
Page 207: Ttl-Lock Mode
FLASH SETTING (Still Photography) TTL-LOCK MODE Instead of adjusting fl ash level with each shot, TTL fl ash control can be locked for consistent results across a series of photo- graphs. Option Option Description Description Flash output is locked at the value metered for the most LOCK WITH LAST FLASH recent photo.
Page 208: Commander Setting
FLASH SETTING (Still Photography) COMMANDER SETTING Choose groups when using the camera fl ash unit as a command- er for Fujifi lm optical wireless remote fl ash control. This option is available when the camera is used with clip-on fl ash units that support Fujifi lm optical wireless fl ash control.
Page 209: Movie Setting (Still Photography)
MOVIE SETTING (Still Photography) Adjust options for movies shot during still photography using function buttons that have been assigned MOVIE RECORDING RELEASE. To display movie settings, press MENU/OK MOVIE SETTING MOVIE MODE in the photo shooting display and select HIGH SPEED REC MEDIA REC SETTING the B (MOVIE SETTING) tab.
Page 210: F Is Mode
F IS MODE This item is also found in the movie menus (P 196). Changes here also apply to the item in the movie menus. F IS MODE BOOST This item is also found in the movie menus (P 196). Changes here also apply to the item in the movie menus.
Page 211 MOVIE SETTING (Still Photography) MIC JACK SETTING Specify the type of hardware connected to the microphone jack. Option Option Description Description Choose this option for direct connection to an external micro- phone. Choose this option for external audio devices connected via LINE line output.
Page 212: F Rec Frame Indicator
MOVIE SETTING (Still Photography) XLR MIC ADAPTER SETTING Adjust microphone input channel settings and the like for use with XLR microphone adapters. Option Option Description Description Record four-channel (quadraphonic) sound with the help of the camera’s built-in microphone, or two-channel (stereo) sound using only a microphone connected via the XLR microphone adapter.
Page 213: Movie Setting (Movie Recording)
MOVIE SETTING (Movie Recording) Adjust movie-recording options. To display options for movie recording, MOVIE SETTING MOVIE SETTING LIST press MENU/OK in the movie shooting dis- MOVIE MODE HIGH SPEED REC play and select the B (MOVIE SETTING) FSELF-TIMER MEDIA REC SETTING tab.
Page 214: Movie Mode
MOVIE MODE Before shooting movies, choose the MOVIE MODE frame rate and the frame size and aspect ratio. HIGH QUALITY 4K MOVIE WITH 6.2K OVERSAMPLING CANNOT USE S.S. SLOWER THAN FRAMERATE CANCEL In the shooting menu, select B MOVIE SETTING, then high- light MOVIE MODE and press MENU/OK.
Page 215: High Speed Rec
MOVIE SETTING (Movie Recording) HIGH SPEED REC Record high-frame-rate movies. High-frame-rate movies can be played back in slow motion, giving you time to view fast-moving subjects or details too fl eeting for the naked eye. Select ON to choose the recording and playback rates separately. Choose ON HDMI ONLY to record footage only to external recorders connected via HDMI.
Page 216: F Self-Timer
F SELF-TIMER Choose the delay between the shutter button being pressed all the way down and the start of recording. • The display shows the number of sec- onds remaining before recording be- gins. • To stop the timer before recording be- gins, press DISP/BACK.
Page 217 MOVIE SETTING (Movie Recording) File Type and Compression File Type and Compression Choose the movie fi le type and compression. Option Option Description Description A highly-portable compressed format. Footage is recorded H.264 ALL-I 420 at a depth of 8 bits using All-I interframe compression and 4 : 2 : 0 chroma sub-sampling.
Page 218: Hdmi Output Setting
Bit Rate Bit Rate Choose the movie bit rate. Options Options 50Mbps 100Mbps 200Mbps 360Mbps The options available for bit rate vary with the settings chosen for high- speed movie recording and compression. The actual bit rate may be slower than the selected value depending on the subject. HDMI OUTPUT SETTING Adjust settings for use when the shooting display is output to an HDMI device.
Page 219: Fix Movie Crop Magnification
MOVIE SETTING (Movie Recording) RAW OUTPUT SETTING Choose whether to output RAW footage to external recorders connected via HDMI. Option Option Description Description RAW OUTPUT RAW OUTPUT Output RAW footage to ATOMOS video recorders. SETTING ATOMOS SETTING ATOMOS RAW OUTPUT Output RAW footage to Blackmagic Design video recorders.
Page 220: F-Log/Hlg Recording
F-Log/HLG RECORDING Choose the destination for F‐Log and HLG (Hybrid Log-Gamma) movies shot while the camera is connected to an HDMI device. Option Option Description Description The footage is processed using ﬁ lm simulation and both c P Y P saved to the memory card and output to the HDMI device.
Page 221: Data Level Setting
MOVIE SETTING (Movie Recording) DATA LEVEL SETTING Choose a signal range for movie recording. Option Option Description Description The signal range for 8-bit movies is limited to 16–235 and that VIDEO RANGE for 10-bit movies to 64–940. The signal ranges for 8-bit and 10-bit movies are respectively FULL RANGE 0–255 and 0–1023.
Page 222: F Is Mode
F IS MODE Turn image stabilization on or off . Option Option Description Description Enable in-body (IBIS) and optical (OIS) image stabilization. IBIS/OIS IBIS is used with lenses that do not support OIS. Enable in-body (IBIS), optical (OIS), and digital (DIS) image IBIS/OIS + DIS stabilization.
Page 223: Zebra Setting
MOVIE SETTING (Movie Recording) ZEBRA SETTING Highlights that may be overexposed are shown by zebra stripes in the movie mode display. Option Option Description Description ZEBRA RIGHT Right-slanting stripes. ZEBRA LEFT Left-slanting stripes. Stripes oﬀ . ZEBRA LEVEL Choose the brightness threshold for the zebra stripe display. Options Options...
Page 224: Movie Optimized Control Ol
MOVIE OPTIMIZED CONTROL oL Select ON to allow movie settings to be adjusted using only the command dials and touch-screen controls. You may fi nd this helpful in preventing the sounds of camera controls being re- corded with movies (P 28). Options Options F REC FRAME INDICATOR...
Page 225: Tally Light
MOVIE SETTING (Movie Recording) TALLY LIGHT Choose the lamp (indicator or AF-assist) that lights during movie recording and whether the lamp blinks or remains steady. Indicator lamp AF-assist illuminator Option Option Description Description FRONT OFF The indicator lamp lights during movie recording. REAR z FRONT OFF The indicator lamp blinks during movie recording.
Page 226: F Select Custom Setting
MOVIE SETTING (Movie Recording) F SELECT CUSTOM SETTING Options are the same as those for still photography, but settings must be adjusted separately (P 134). F EDIT/SAVE CUSTOM SETTING Options are the same as those for still photography, but settings must be adjusted separately (P 134).
Page 227: Image Quality Setting (Movie Recording)
IMAGE QUALITY SETTING (Movie Recording) Adjust image quality settings for movies. To display image quality settings, press IMAGE QUALITY SETTING FFILM SIMULATION MENU/OK in the movie shooting display and FMONOCHROMATIC COLOR FWHITE BALANCE select the H (IMAGE QUALITY SETTING) FDYNAMIC RANGE FTONE CURVE tab.
Page 228: F White Balance
F WHITE BALANCE Options are the same as those for still photography, but settings must be adjusted separately (P 126). F DYNAMIC RANGE Choose a dynamic range for movie recording. Option Option Description Description V100% W200% See “DYNAMIC RANGE” (P 130). X400% N •...
Page 229: F Sharpness
IMAGE QUALITY SETTING (Movie Recording) F SHARPNESS Options are the same as those for still photography, but settings must be adjusted separately (P 131). F HIGH ISO NR Options are the same as those for still photography, but settings must be adjusted separately (P 132). INTERFRAME NR Select AUTO to automatically adjust interframe noise reduction according to shooting conditions.
Page 230: F Peripheral Light Correction
IMAGE QUALITY SETTING (Movie Recording) F PERIPHERAL LIGHT CORRECTION Select ON to enable peripheral illumination correction during movie recording. Options Options N • If ON is selected when a lens that does not transmit data to the camera is attached, peripheral illumination will be adjusted according to the option selected for H IMAGE QUALITY SETTING ...
Page 231: Af/Mf Setting (Movie Recording)
AF/MF SETTING (Movie Recording) Adjust focus settings for movies. To display AF/MF settings, press MENU/OK AF/MF SETTING FFOCUS AREA in the movie shooting display and select F AF MODE FAF-C CUSTOM SETTING the G (AF/MF SETTING) tab. xFWRAP FOCUS POINT xFAF ILLUMINATOR Fg FACE/EYE DETECTION SETTING FSUBJECT DETECTION SETTING FAF+MF...
Page 232: F Af-C Custom Setting
F AF-C CUSTOM SETTING Select focus-tracking options when recording movies in focus mode C. TRACKING SENSITIVITY Choose how long the camera waits to switch focus when an ob- ject enters the focus area behind or in front of the current sub- ject.
Page 233: Xf Af Illuminator
AF/MF SETTING (Movie Recording) xF AF ILLUMINATOR This item is also found in the photo menus (P 150). Changes to one apply to the other. Fg FACE/EYE DETECTION SETTING Enable or disable Intelligent Face Detection when recording movies. Option Option Description Description FACE DETECTION ON...
Page 234: F Mf Assist
F MF ASSIST Choose how focus is displayed in manual focus mode (P 94). Option Option Description Description The camera heightens high-contrast outlines. Choose a FOCUS PEAK HIGHLIGHT color and peaking level. A needle indicates whether focus is in front of or behind FOCUS METER the subject.
Page 235: Xf Depth-Of-Field Scale
AF/MF SETTING (Movie Recording) xF DEPTH-OF-FIELD SCALE This item is also found in the photo menus (P 157). Changes to one apply to the other. xF AF RANGE LIMITER This item is also found in the photo menus (P 159). Changes to one apply to the other.
Page 236: F Touch Screen Mode
F TOUCH SCREEN MODE Choose the shooting operations performed using touch controls. Mode Mode Description Description Tapping the display focuses the camera on the selected point. Use the shutter button to start and stop recording. • In focus mode S (AF-S), you can refocus at any time by tapping your subject in the display.
Page 237 AF/MF SETTING (Movie Recording) Touch Controls for Focus Zoom Diff erent touch controls are used during focus zoom (focus check enabled). Central Area Central Area Tapping the center of the display performs the operations below. Mode Mode Movie Recording Movie Recording AF-S: AF AF AF MF: Instant AF...
Page 238: Focus Check Lock
AF/MF SETTING (Movie Recording) FOCUS CHECK LOCK Choose whether focus zoom remains in eff ect once movie re- cording begins. Options Options...
Page 239: Audio Setting (Movie Recording)
AUDIO SETTING (Movie Recording) Adjust settings for audio recorded during fi lming. To display audio settings, press MENU/OK AUDIO SETTING INTERNAL MIC LEVEL ADJUSTMENT in the movie shooting display and select EXTERNAL MIC LEVEL ADJUSTMENT MIC JACK SETTING the P (AUDIO SETTING) tab. MIC LEVEL LIMITER WIND FILTER LOW CUT FILTER...
Page 240: Mic Jack Setting
MIC JACK SETTING Specify the type of hardware connected to the microphone jack. Option Option Description Description Choose this option for direct connection to an external micro- phone. Choose this option for external audio devices connected via LINE line output. MIC LEVEL LIMITER Reduces distortion caused by input that exceeds the limits of the microphone’s audio circuits.
Page 241: Xlr Mic Adapter Setting
AUDIO SETTING (Movie Recording) XLR MIC ADAPTER SETTING Adjust microphone input channel settings and the like for use with XLR microphone adapters. Option Option Description Description Record four-channel (quadraphonic) sound with the help of the camera’s built-in microphone, or two-channel (stereo) sound using only a microphone connected via the XLR microphone adapter.
Page 242: Time Code Setting (Movie Recording)
TIME CODE SETTING (Movie Recording) Adjust time code (hour, minute, second, and frame num- ber) display settings for movie recording. To display time code settings, press TIME CODE SETTING MENU/OK in the movie shooting display TIME CODE DISPLAY START TIME SETTING and select the Q (TIME CODE SETTING) COUNT UP SETTING DROP FRAME...
Page 243: Count Up Setting
TIME CODE SETTING (Movie Recording) COUNT UP SETTING Choose whether time is clocked continuously or only during movie recording. Option Option Description Description REC RUN Time is clocked only during movie recording. FREE RUN Time is clocked continuously. DROP FRAME At frame rates of 59.94P, and 29.97P, a discrepancy will gradu- ally develop between the time code (measured in seconds) and the actual recording time (measured in fractions of a second).
Page 244: Hdmi Time Code Output
TIME CODE SETTING (Movie Recording) HDMI TIME CODE OUTPUT Choose whether time codes are output to HDMI devices. Options Options...
Page 245: Playback And The Playback Menu
Playback and the Playback Menu...
Page 246: The Playback Display
The Playback Display This section lists the indicators that may be displayed during playback. For illustrative purposes, displays are shown with all indicators lit. E FG H I 1/999 12/31/2022 Date and time ........48, 50, 273 White balance ..........126 Frame-number display Sensitivity ............96 Location data..........310 Exposure compensation .......99...
Page 247: The Disp/Back Button
The Playback Display The DISP/BACK Button The DISP/BACK button controls the display of indicators during playback. Standard Information off 12/31/2022 1/999 2022.12.31 1/999 12/31/2022 1/999 NEXT Info display...
Page 248 The Playback Display Viewing Photo Information The photo information display changes each time the selector is pressed up. Basic data Info display 1 12/31/2022 1/999 12/31/2022 1/999 2022.12.31 1/999 NEXT LENS 23.0mm F5.6 FOCAL LENGTH 23.0mm COLOR SPACE sRGB 1/999 LENS MODULATION OPT.
Page 249: Viewing Pictures
Viewing Pictures Read this section for information on playback zoom and multi-frame playback. Use the rear command dial to go from full-frame playback to playback zoom or multi-frame playback. Full-frame playback Multi-frame Playback playback zoom DISP/BACK MENU/OK Nine-frame view Medium zoom Hundred- frame view Maximum zoom...
Page 250: Playback Zoom
Viewing Pictures Playback Zoom Rotate the rear command dial right to zoom in on the current picture, left to zoom out. To exit zoom, press DISP/BACK, MENU/OK, or the center of the rear command dial. The maximum zoom ratio varies with the option selected for H IMAGE QUALITY SETTING >...
Page 251: The Playback Menu
The Playback Menu Adjust playback settings. The playback menu is displayed when PLAY BACK MENU SWITCH SLOT you press MENU/OK in playback mode. RAW CONVERSION HEIF TO JPEG/TIFF CONVERSION ERASE SIMULTANEOUS DELETE CROP RESIZE PROTECT EXIT SWITCH SLOT Choose the card from which images will be played back. If two memory cards are inserted, you can press and hold the a but- ton to choose a card for playback.
Page 252: Raw Conversion
RAW CONVERSION Even if you don’t have a computer, you can use the camera to modify RAW pictures and save them in other formats. Saving RAW Pictures in Another Format Display a RAW picture. Highlight RAW CONVERSION in the playback menu. Press MENU/OK.
Page 253 The Playback Menu The settings that can be adjusted when converting pictures from RAW to another format are: Setting Setting Description Description Create a copy using the settings in eﬀ ect at the time the REFLECT SHOOTING COND. photo was taken. FILE TYPE Choose a ﬁ...
Page 254 Setting Setting Description Description HIGH ISO NR Process the copy to reduce mottling. CLARITY Increase deﬁ nition. Improve deﬁ nition by adjusting for diﬀ raction and the LENS MODULATION OPTIMIZER slight loss of focus at the periphery of the lens. COLOR SPACE Choose the color space used for color reproduction.
Page 255: Heif To Jpeg/Tiff Conversion
The Playback Menu HEIF TO JPEG/TIFF CONVERSION Convert HEIF pictures to JPEG or TIFF. SELECT IMAGES Select HEIF pictures for conversion. FILE FORMAT Choose a format for the converted pictures. Options Options JPEG TIFF 8bit TIFF 16bit SELECT SLOT TO RECORD Choose the memory card to which the converted pictures will be saved.
Page 256: Erase
ERASE Delete individual pictures, multiple selected pictures, or all pic- tures. Deleted pictures cannot be recovered. Protect important pictures or copy them to a computer or other storage device before proceeding. Option Option Description Description FRAME Delete pictures one at a time. SELECTED FRAMES Delete multiple selected pictures.
Page 257 The Playback Menu SELECTED FRAMES Select SELECTED FRAMES for ERASE in the playback menu. Highlight pictures and press MENU/OK to select. • Selected pictures are indicated by check marks (R). • To deselect a highlighted picture, press MENU/OK again. When the operation is complete, press DISP/BACK to display a confi rmation dialog.
Page 258: Simultaneous Delete
SIMULTANEOUS DELETE Taking photos with SEPARATE selected for D SAVE DATA SET-UP > x CARD SLOT SETTING creates two copies. Choose whether deleting the RAW image will also delete the JPEG or HEIF copy. Option Option Description Description Deleting the RAW image from the card in Slot 1 also deletes the JPEG or HEIF copy from the card in Slot 2.
Page 259: Resize
The Playback Menu RESIZE Create a small copy of the current picture. Display the desired picture. Select RESIZE in the playback menu. Highlight a size and press MENU/OK to display a confi rmation dialog. Press MENU/OK again to save the resized copy to a separate fi le.
Page 260: Protect
PROTECT Protect pictures from accidental deletion. Highlight one of the following options and press MENU/OK. Option Option Description Description Protect selected pictures. Press the selector left or right to view FRAME pictures and press MENU/OK to select or deselect. Press DISP/BACK when the operation is complete.
Page 261: Image Rotate
The Playback Menu IMAGE ROTATE Rotate pictures. Select ON for D SCREEN SET-UP > AUTOROTATE PB. Display the desired picture. Select IMAGE ROTATE in the playback menu. Press the selector down to rotate the picture 90° clockwise, up to rotate it 90° counterclockwise. Press MENU/OK.
Page 262: Voice Memo Setting
VOICE MEMO SETTING Add a voice memo to the current photograph. Select ON for VOICE MEMO SETTING in the playback menu. Display a photo to which you wish to add a voice memo. Press and hold the center of the front command dial to re- cord the memo.
Page 263: Rating
The Playback Menu RATING Rate pictures using stars. Select RATING in the playback menu. Rotate the front command dial to choose a picture and the rear command dial to choose a rating of from 0 to 5 stars (“I”). N • The selector can be used in place of the front command dial to choose a picture.
Page 264: Copy
COPY Copy pictures between the cards in the fi rst and second slots. Select COPY in the playback menu. Highlight one of the following options. Option Option Description Description Copy pictures from the card in the ﬁ rst slot to the card in SLOT1 y SLOT2 the second slot.
Page 265: Transfer Image To Smartphone
The Playback Menu TRANSFER IMAGE TO SMARTPHONE Select photos for upload to a paired smartphone or tablet via Bluetooth (P 249). Select TRANSFER IMAGE TO SMARTPHONE > SELECT FRAMES. Select RESET to remove “upload to smartphone” marking from all pictures before proceeding. Mark pictures for upload.
Page 266 Filtering Pictures/Choosing a Slot To switch to the memory card in the other slot or display only pictures that meet selected criteria, press DISP/BACK in the picture-selection dialog. • To display only pictures that meet selected cri- SELECT FRAMES teria, choose FILTERING. START TRANSFER •...
Page 267: Xf Wireless Communication
• Upload location data to the camera N • For downloads and other information, visit: https://app.fujifilm-dsc.com/ • If r WIRELESS COMMUNICATION is selected for D BUTTON/ DIAL SETTING > a Fn1 BUTTON SETTING, you can connect to the smartphone using the Fn1 button.
Page 268: Photobook Assist
PHOTOBOOK ASSIST Create books from your favorite photos. Creating a Photobook Select NEW BOOK for C PLAY BACK MENU > PHOTOBOOK ASSIST. Scroll through the images and press the selector up to select or deselect. Press MENU/OK to exit when the book is complete. N •...
Page 269 The Playback Menu Viewing Photobooks Highlight a book in the photobook assist menu and press MENU/OK to display the book, then press the selector left or right to scroll through the pictures. Editing and Deleting Photobooks Display the photobook and press MENU/OK. The following options will be displayed;...
Page 270: Print Order (Dpof)
PRINT ORDER (DPOF) Create a digital “print order” for DPOF-compatible printers. Select C PLAY BACK MENU > PRINT ORDER (DPOF). Select WITH DATE s to print the date of recording on pic- tures, WITHOUT DATE to print pictures without dates, or RESET ALL to remove all pictures from the print order before proceeding.
Page 271: Instax Printer Print
Select C PLAY BACK MENU > instax PRINTER PRINT PRINTER PRINT. The camera will con- instax-12345678 nect to the printer. CONNECTING FUJIFILM-CAMERA-1234 CANCEL Use the selector to display the pic- PRINTER PRINT 100-0020 ture you want to print, then press MENU/OK. The picture will be sent to the printer and printing will start.
Page 272: Disp Aspect
DISP ASPECT Choose the aspect ratio used for the display of still pictures on High Defi nition (HD) devices (this option is available only when an HDMI cable is connected). Options Options 16 : 9 3 : 2 Choose 16 : 9 to display photos with an aspect ratio of 3 : 2 full screen. The pictures will be displayed full screen with tops and bottoms cropped out.
Page 273: Network/Usb Features And Settings
Network/USB Features and Settings...
Page 274: Overview
Overview This chapter outlines features that can among other things be used to upload pictures to, or control the camera and take pictures remotely from, a smartphone or computer. Supported Features This camera supports the following features: Feature Feature Description Description Connect to smartphones via Bluetooth®...
Page 275: Connecting To Smartphones (Bluetooth)
Visit the following website and install the desired apps on your phone. https://app.fujifilm-dsc.com/ The apps available vary with the smartphone operating system. Connecting to a Smartphone Pair the camera with the smartphone and connect via Bluetooth®.
Page 276 Bluetooth ON/OFF Launch the app on the smartphone and pair the smartphone with the camera. More information is available at the following website: https://app.fujifilm-dsc.com/ When pairing is complete, the cam- era and smartphone will automati- cally connect via Bluetooth. A smart-...
Page 277: Using The Smartphone App
You can download selected pictures to a smartphone using the smartphone app. More information is available from the following website: https://app.fujifilm-dsc.com/ Uploading Pictures as They Are Taken Pictures taken with ON selected for Bluetooth/SMARTPHONE SETTING > AUTO IMAGE TRANSFER ORDER in the network/USB setting menu will automatically be uploaded to the paired de- vice.
Page 278: Connecting To Smartphones (Usb)
Connecting to Smartphones (USB) Connect to smartphones and computers via USB to upload pictures from the camera. Copying Pictures to a Smartphone Before connecting to the smartphone to upload pictures via USB, select either AUTO or POWER SUPPLY OFF/COMM ON for USB POWER SUPPLY/COMM SETTING in the network/USB setting menu.
Page 279 Connecting to Smartphones (USB) Micro-B Micro-B Use a USB on-the-go (OTG) cable. Third-party USB cable USB OTG cable Type-C connector (male) Micro-B connector (male) Type-A connector Type-A connector (male) (female) O • The smartphone must support USB OTG. • The desired results cannot be achieved with a USB Type-C–to– Mirco-B cable.
Page 280 From the recommended apps, select “Camera Importer”. The app will automatically start and allow you to import pho- tos and movies to your smartphone. If the message “There is no MTP device connected” appears on the app, please try again from step 3. For Customers Using iOS Use a camera adapter.
Page 281: Connecting The Camera And Computer
Connecting to Smartphones (USB) Connecting the Camera and Computer Select either AUTO or POWER SUPPLY OFF/COMM ON for USB POWER SUPPLY/COMM SETTING in the network/USB setting menu. Select USB CARD READER for CONNECTION MODE. Turn the camera off . Turn the computer on. Connect a USB cable.
Page 282 Connecting to Smartphones (USB) O • Turn the camera off before disconnecting the USB cable. • When connecting USB cables, be sure the connectors are fully in- serted in the correct orientation. Connect the camera directly to the computer; do not use a USB hub or keyboard. •...
Page 283: Using The Camera As A Webcam
Using the Camera as a Webcam The camera can be connected to a computer for use as a webcam. Select either AUTO or POWER SUPPLY OFF/COMM ON for USB POWER SUPPLY/COMM SETTING in the network/USB setting menu. Select USB WEBCAM for CONNECTION MODE. Connect the camera to the computer via USB and then turn the camera on (P 255).
Page 284: Instax Share Printers
instax SHARE Printers Print pictures from your digital camera to instax SHARE printers. Establishing a Connection Select instax PRINTER CONNECTION SETTING in the network/USB setting menu and enter the instax SHARE printer name (SSID) and password. The Printer Name (SSID) and Password The printer name (SSID) can be found on the bottom of the printer;...
Page 285: Printing Pictures
Select C PLAY BACK MENU > instax PRINTER PRINT PRINTER PRINT. The camera will con- instax-12345678 nect to the printer. CONNECTING FUJIFILM-CAMERA-1234 CANCEL Use the selector to display the pic- PRINTER PRINT 100-0020 ture you want to print, then press MENU/OK.
Page 286: Tethered Photography
Tethered Photography Computers connected via USB or wireless LAN can be used to control the camera and take photographs remotely or to download pictures from the camera for storage. Tethered Photography via USB Connect the camera to a computer via USB for tethered photog- raphy.
Page 287: Tethered Photography Via Wireless Lan
Tethered Photography Take pictures via tethered photography. Use software such as “Adobe Lightroom Classic + FUJIFILM Tether Shooting Plug-in”, “FUJIFILM X Acquire”, or “Capture One”. N • To take pictures when using X Acquire, use the shutter button on the camera.
Page 288: Raw Processing
Connect the camera to the computer via USB and then turn the camera on (P 255). Launch X RAW STUDIO. RAW processing can be performed using X RAW STUDIO. Visit the website below for information on the software used. https://fujifilm-x.com/products/software/...
Page 289: Saving And Loading Settings
Connect the camera to the computer via USB and then turn the camera on (P 255). Launch FUJIFILM X Acquire. Camera settings can be saved or loaded using FUJIFILM X Acquire. Visit the website below for information on the software used.
Page 290: Network/Usb Setting Menus
Network/USB Setting Menus Adjust camera network and USB settings. To access network/USB settings from NETWORK/USB SETTING Bluetooth/SMARTPHONE SETTING the shooting or playback display, press AIRPLANE MODE NETWORK SETTING MENU/OK and select the I (network/USB PRINTER CONNECTION SETTING CONNECTION MODE setting) tab. USB POWER SUPPLY/COMM SETTING INFORMATION RESET WIRELESS SETTING...
Page 291 Network/USB Setting Menus Bluetooth DEVICE LIST List the devices with which the camera is paired (other than the smartphone) or end pairing with selected devices. Bluetooth ON/OFF If ON is selected, the camera will automatically connect with paired smartphones or tablets running the smartphone app. Options Options AUTO IMAGE TRANSFER ORDER...
Page 292 IMAGE TRANSFER WHILE POWER OFF If ON is selected, the camera will continue to upload pictures to paired smartphones or tablets even while off . Options Options RESIZE IMAGE FOR SMARTPHONE Select ON (recommended) to enable compression, reducing fi le size for upload.
Page 293: Airplane Mode
Network/USB Setting Menus AIRPLANE MODE Select ON to disable the camera’s wireless LAN and Bluetooth features. Options Options NETWORK SETTING Adjust settings for connection to wireless networks. Option Option Description Description • SIMPLE SETUP: Connect to an access point using simple settings.
Page 294: Connection Mode
Capture One, Adobe® SHOOTING AUTO Photoshop® Lightroom® + Tether Plugin, FUJIFILM X Acquire, or FUJIFILM Pixel Shift Combiner. FUJIFILM X Acquire can also be used to save and load camera settings. • Remote photography and movie recording are available when the camera is connected to a compatible device such as a gimbal or drone.
Page 295 USB RAW conversion/backup restore mode. The camera functions normally when not connected. • USB RAW CONV. (requires FUJIFILM X RAW STUDIO): Use the cam- USB RAW CONV./ era’s image processing engine to rapidly convert RAW ﬁ les BACKUP RESTORE to other formats while maintaining image quality.
Page 296: Usb Power Supply/Comm Setting
Network/USB Setting Menus USB POWER SUPPLY/COMM SETTING Choose whether USB connections to computers, smartphones, or other devices are used for power delivery or data transfer. Option Option Description Description The camera switches between power delivery and data trans- AUTO fer automatically. POWER SUPPLY ON/ The camera draws power from the connected device, reducing COMM OFF...
Page 297: The Setup Menus
The Setup Menus...
Page 298: User Setting
USER SETTING Adjust basic camera settings. To access basic camera settings, press USER SETTING FORMAT MENU/OK, select the D (SET UP) tab, and bAREA SETTING DATE/TIME TIME DIFFERENCE choose USER SETTING. x MY MENU SETTING F MY MENU SETTING SENSOR CLEANING EXIT FORMAT To format a memory card:...
Page 299: Area Setting
USER SETTING b AREA SETTING Adjust settings for your current time zone. AREA SETTING Choose your time zone from a map. DAYLIGHT SAVINGS Turn daylight saving time on or off . Option Option Description Description Daylight saving time on. Daylight saving time oﬀ . DATE/TIME To set the camera clock: Select D USER SETTING >...
Page 300: Time Difference
TIME DIFFERENCE Switch the camera clock instantly from your home time zone to the local time at your destination when traveling. To specify the diff erence between your local and home time zone: Use b AREA SETTING to choose your home time zone before select- ing a local time zone using g LOCAL.
Page 301: My Menu Setting
USER SETTING Choose a language. x MY MENU SETTING Edit the items listed in the E (MY MENU) tab, a personalized cus- tom menu of frequently-used photo menu options (P 313). F MY MENU SETTING Edit the items listed in the E (MY MENU) tab, a personalized cus- tom menu of frequently-used movie menu options (P 313).
Page 302: Sensor Cleaning
SENSOR CLEANING Remove dust from the camera image sensor. Option Option Description Description Clean the sensor immediately. Sensor cleaning will be performed when the camera is WHEN SWITCHED ON turned on. Sensor cleaning will be performed when the camera turns WHEN SWITCHED OFF oﬀ...
Page 303: Reset
USER SETTING RESET Reset shooting or setup menu options to default values. Highlight the desired option and press MENU/OK. Option Option Description Description Reset all photo menu settings other than custom white STILL MENU RESET balance and custom settings banks created using x EDIT/SAVE CUSTOM SETTING to default values.
Page 304: Sound Setting
SOUND SETTING Make changes to camera sounds. To access sound settings, press MENU/OK, SOUND SETTING AF BEEP VOL. select the D (SET UP) tab, and choose SELF-TIMER BEEP VOL. OPERATION VOL. SOUND SET-UP. FREC START/STOP VOLUME ttELECTRONIC SHUTTER VOLUME ttELECTRONIC SHUTTER SOUND sELECTRONIC SHUTTER VOLUME sELECTRONIC SHUTTER SOUND EXIT...
Page 305: Operation Vol
SOUND SETTING OPERATION VOL. Adjust the volume of the sounds produced when camera con- trols are operated. Choose eOFF to disable control sounds. Options Options b (high) c (medium) d (low) eOFF (mute) F REC START/STOP VOLUME Choose the volume at the start and end of movie recording. Options Options b (high)
Page 306: Tt Electronic Shutter Sound
tt ELECTRONIC SHUTTER SOUND Choose the sound made by the mechanical or electronic front-curtain shutter. Options Options i SOUND 1 j SOUND 2 k SOUND 3 s ELECTRONIC SHUTTER VOLUME Adjust the volume of the sounds produced by the electronic shutter.
Page 307: Playback Volume
SOUND SETTING PLAYBACK VOLUME Adjust the volume for movie playback. Options Options 4ch AUDIO PLAYBACK Adjust audio settings for use when viewing 4ch movies. Option Option Description Description The camera plays audio recorded via external micro- phones connected via the XLR microphone adapter. The camera plays audio recorded via the camera’s built-in CAMERA microphone or external microphones connected via the...
Page 308: Screen Setting
SCREEN SETTING Make changes to display settings. To access display settings, press MENU/OK, SCREEN SETTING VIEW MODE SETTING select the D (SET UP) tab, and choose EVF BRIGHTNESS EVF COLOR SCREEN SET-UP. EVF COLOR ADJUSTMENT LCD BRIGHTNESS LCD COLOR LCD COLOR ADJUSTMENT IMAGE DISP.
Page 309: Evf Color Adjustment
SCREEN SETTING EVF COLOR ADJUSTMENT Adjust the color of the display in the electronic viewfi nder. Adjust colors using the selector. EVF COLOR ADJUSTMENT CANCEL Press MENU/OK.
Page 310: Lcd Brightness
LCD BRIGHTNESS Adjust monitor brightness. Options Options −5 −4 −3 −2 −1 LCD COLOR Adjust monitor saturation. Options Options −5 −4 −3 −2 −1 LCD COLOR ADJUSTMENT Adjust the color of the display in the LCD monitor. Adjust colors using the selector. Press MENU/OK.
Page 311: Image Disp
SCREEN SETTING IMAGE DISP. Choose how long images are displayed after shooting. Option Option Description Description Pictures are displayed until the MENU/OK button is pressed or the shutter button is pressed halfway. To zoom in on the active focus CONTINUOUS point, press the center of the rear command dial;...
Page 312: Preview Exp./Wb In Manual Mode
PREVIEW EXP./WB IN MANUAL MODE Choose whether to enable exposure and/or white balance preview in manual exposure mode. Option Option Description Description PREVIEW EXP./WB Enable exposure and white balance preview. Preview white balance only. Choose this option in situations in PREVIEW WB which exposure is likely to change during shooting, as may be the case when you use a ﬂ...
Page 313: F-Log View Assist
SCREEN SETTING F-Log VIEW ASSIST Select ON to display a tone-corrected preview (equivalent to BT.709) when recording or viewing F-log movies. Options Options ELECTRONIC LEVEL SETTING Adjust settings for use when taking pictures using the virtual horizon display (P 23).
Page 314: Framing Guideline
FRAMING GUIDELINE Choose a framing grid for shooting mode. Option Option F GRID 9 G GRID 24 H HD FRAMING For “rule of thirds” compo- A six-by-four grid. Frame HD pictures in the sition. crop shown by the lines at the top and bottom of the display.
Page 315: Autorotate Pb
SCREEN SETTING AUTOROTATE PB Choose ON to automatically rotate “tall” (portrait-orientation) pictures during playback. Options Options FOCUS SCALE UNITS Choose the units used for the focus distance indicator. Options Options METERS FEET APERTURE UNIT FOR CINEMA LENS Choose whether the camera displays aperture as a T-number (used for movie camera lenses) or an f/-number (used for still camera lenses) when an optional FUJINON MKX-series lens is attached.
Page 316: Dual Display Setting
DUAL DISPLAY SETTING Choose the content of the two windows in the dual display. Option Option Description Description The right (small) window shows a close-up of the focus area, R:FOCUS L:FRAME while the left (large) window shows the entire frame. The right (small) window shows the entire frame, while the left R:FRAME L:FOCUS (large) window shows a close-up of the focus area.
Page 317: Large Indicators Mode(Evf)
SCREEN SETTING LARGE INDICATORS MODE(EVF) Select ON to display large indicators in the electronic viewfi nd- er. The indicators displayed can be selected using D SCREEN SET-UP > LARGE INDICATORS DISP. SETTING. Some icons are not displayed when ON is selected for LARGE INDICATORS MODE(EVF) (P 13).
Page 318: Large Indicators Disp. Setting
LARGE INDICATORS DISP. SETTING Choose the indicators displayed when LARGE INDICATORS DISP. SETTING Expo. DISP. ON is selected for D SCREEN SET-UP > Scale LARGE INDICATORS MODE(EVF) or LARGE INDICATORS MODE(LCD). Option Option Description Description Choose the items listed at the bottom of the display. A Expo.
Page 319: Location Info
SCREEN SETTING LOCATION INFO Select ON to display location info downloaded from a smart- phone. Options Options x Q MENU BACKGROUND Choose the background color used for the quick menu when it is displayed during still photography. Options Options TRANSPARENT BLACK F Q MENU BACKGROUND Choose the background color used for the quick menu when it is...
Page 320: Button/Dial Setting
BUTTON/DIAL SETTING Access options for camera controls. To access control options, press MENU/OK, BUTTON/DIAL SETTING FOCUS LEVER SETTING select the D (SET UP) tab, and choose EDIT/SAVE QUICK MENU EDIT/SAVE QUICK MENU BUTTON/DIAL SETTING. FUNCTION (Fn) SETTING POWER ZOOM LENS FUNCTION (Fn) SETTING SELECTOR BUTTON SETTING COMMAND DIAL SETTING o S.S OPERATION...
Page 321: Edit/Save Quick Menu
BUTTON/DIAL SETTING x EDIT/SAVE QUICK MENU Choose the items displayed in the quick menu during still pho- tography (P 315). F EDIT/SAVE QUICK MENU Choose the items displayed in the quick menu when fi lming movies (P 315). FUNCTION (Fn) SETTING Choose the roles played by the function buttons (P 321).
Page 322: Command Dial Setting
COMMAND DIAL SETTING Choose the roles played by the command dials. Option Option Description Description FRONT COMMAND Assign shutter speed (S.S. (PROGRAM SHIFT)) or aper- DIAL 1 ture (APERTURE) to FRONT COMMAND DIAL 1. Assign shutter speed (S.S. (PROGRAM SHIFT)), ap- FRONT COMMAND erture (APERTURE) , exposure compensation (EXP.
Page 323: S.s Operation
BUTTON/DIAL SETTING o S.S OPERATION Select OFF to disable shutter-speed fi ne-tuning using the com- mand dials. Options Options COMMAND DIAL DIRECTION Choose the direction in which the command dials are rotated to choose values. Settings for the front and rear command dials can be adjusted separately.
Page 324: Shutter Af
SHUTTER AF Choose whether the camera focuses when the shutter button is pressed halfway. Option Option Description Description • ON: Focus locks when the shutter button is pressed halfway. • AF-S OFF: No focus operation is performed when the shutter but- ton is pressed halfway.
Page 325: Shoot Without Lens
BUTTON/DIAL SETTING SHOOT WITHOUT LENS Choose ON to enable the shutter release when no lens is at- tached. Options Options SHOOT WITHOUT CARD Choose whether the shutter can be released without a memory card inserted in the camera. Option Option Description Description When no memory card is inserted, the shutter can be released to...
Page 326: Lens Zoom/Focus Setting
LENS ZOOM/FOCUS SETTING Adjust settings for compatible lenses with focus rings or power zoom. FOCUS RING ROTATE Choose the direction in which the focus ring is rotated to in- crease the focus distance. Options Options X CW (clockwise) Y CCW (counterclockwise) FOCUS RING OPERATION Choose how the camera adjusts focus in response to the move- ment of the focus ring.
Page 327 BUTTON/DIAL SETTING CONSTANT SPEED ZOOM/FOCUS (Fn) OPERATION Choose whether the function buttons on compatible power zoom lenses need only be pressed once to start and stop power focus or power zoom. Option Option Description Description START/STOP The operation starts when the button is pressed and stops when SWITCH it is pressed a second time.
Page 328: Ae/Af-Lock Mode
AE/AF-LOCK MODE This option determines the behavior of the button to which exposure and/or focus lock is assigned. Option Option Description Description AE&AF ON WHEN Exposure and/or focus will lock while the button is pressed. PRESSING AE&AF ON/OFF Exposure and/or focus will lock when the button is pressed and re- SWITCH main locked until it is pressed again.
Page 329: Aperture Ring Setting (A)
BUTTON/DIAL SETTING APERTURE RING SETTING (A) Choose whether the front command dial can be used to adjust aperture when aperture is set to A (auto). Option Option Description Description AUTO The camera adjusts aperture automatically. COMMAND Aperture can be adjusted using the front command dial. APERTURE SETTING Choose the method used to adjust aperture when using lenses with no aperture rings.
Page 330: Touch Screen Setting
TOUCH SCREEN SETTING Enable or disable touch-screen controls. x TOUCH SCREEN SETTING Option Option Description Description The LCD monitor functions as a touch screen during shooting. Touch controls disabled. x DOUBLE TAP SETTING Option Option Description Description Tap the LCD monitor twice to zoom in on your subject during shooting.
Page 331: Lock
BUTTON/DIAL SETTING EVF TOUCH SCREEN AREA SETTINGS Select the area of the LCD monitor used for touch controls while the viewfi nder is active. The area used for touch controls can be selected from: Option Option Description Description All. Right half. Top right quarter.
Page 332: Power Management
POWER MANAGEMENT Adjust power management settings. To access power management settings, POWER MANAGEMENT press MENU/OK, select the D (SET UP) tab, AUTO POWER OFF and choose POWER MANAGEMENT. PERFORMANCE EVF/LCD BOOST SETTING AUTO POWER OFF TEMP. EXIT AUTO POWER OFF Choose the length of time before the camera turns off automati- cally when no operations are performed.
Page 333: Evf/Lcd Boost Setting
POWER MANAGEMENT EVF/LCD BOOST SETTING Adjust the behavior of the EVF and LCD monitor when BOOST is selected for PERFORMANCE. Option Option Description Description EVF/LCD LOW LIGHT Display brightness is adjusted to make subjects in shad- PRIORITY ows easier to see. Motion blur may cause ghosting. EVF/LCD RESOLUTION Display resolution is increased to make details easier to PRIORITY...
Page 334: Save Data Setting
SAVE DATA SETTING Make changes to fi le management settings. To access fi le management settings, SAVE DATA SETTING FRAME NO. press MENU/OK, select the D (SET UP) tab, EDIT FILE NAME xCARD SLOT SETTING and choose SAVE DATA SET-UP. SELECT SLOT(x SEQUENTIAL) SELECT FOLDER COPYRIGHT INFO...
Page 335: Edit File Name
SAVE DATA SETTING EDIT FILE NAME Change the fi le name prefi x. sRGB images use a four-letter prefi x (default “DSCF”), Adobe RGB images a three-letter prefi x (“DSF”) preceded by an underscore. Option Option Default prefi x Default prefi x Sample fi le name Sample fi le name sRGB...
Page 336: Select Folder
SAVE DATA SETTING SELECT FOLDER Create folders and choose the folder used to store subsequent pictures. Option Option Description Description To choose the folder in which subsequent pictures will be SELECT FOLDER stored, press the selector up or down to highlight an exist- ing folder and press MENU/OK.
Page 337: Shortcuts
Shortcuts...
Page 338: Shortcut Options
Shortcut Options Customize camera controls to suit your style or situation. Frequently-used options can be added to the Q menu or a cus- tom “my” menu or assigned to a function button or touch-func- tion gesture for direct access: Shortcut Option Shortcut Option Description Description...
Page 339: My Menu
MY MENU Access a personalized menu of frequently-used options. To display “my menu”, press MENU/OK in the MY MENU SELF-TIMER shooting display and select the E (MY INTERVAL TIMER SHOOTING FILM SIMULATION MENU) tab. GRAIN EFFECT PHOTOMETRY SHUTTER TYPE IS MODE gFACE/EYE DETECTION SETTING EXIT The E tab is only available if options have been assigned to...
Page 340 MY MENU SELECT ITEM LOCATION Choose a position for the item and 1 IMAGE SIZE press MENU/OK. The item will be added 2 IMAGE QUALITY to “my menu”. MOVE SAVE Press MENU/OK to return to the edit display. Repeat Steps 3 and 4 until all the desired items have been added.
Page 341: The Quick Menu
The Quick Menu Use the quick menu for quick access to selected options. To view the quick menu, press the Q button. The Quick Menu Display The quick menu off ers diff erent options in photo and movie modes. At default settings, it contains the following items: Still photography SELECT CUSTOM SETTING APERTURE PRIORITY AE...
Page 342 Movie recording SELECT CUSTOM SETTING APERTURE PRIORITY AE LONG PRESS EDIT/SAVE CUSTOM Default Default A A F SELECT CUSTOM SETTING E E APERTURE (MOVIE OPTIMIZED CONTROL oL) B B S.S. (MOVIE OPTIMIZED F F ISO (MOVIE OPTIMIZED CONTROL oL) CONTROL oL) C C MOVIE MODE RESOLUTION/ G G MOVIE MODE FRAME RATE ASPECT RATIO...
Page 343: Viewing And Changing Settings
The Quick Menu Viewing and Changing Settings Press Q to display the quick menu during shooting. Use the selector to highlight items SELECT CUSTOM SETTING APERTURE PRIORITY AE and rotate the rear command dial to change. LONG PRESS EDIT/SAVE CUSTOM To jump to the x EDIT/SAVE CUSTOM SETTING or F EDIT/ SAVE CUSTOM SETTING menu, press and hold the Q button when the quick menu is displayed.
Page 344: Editing The Quick Menu
Editing the Quick Menu To choose the items displayed in the quick menu: Press and hold the Q button during shooting. The camera displays the photo quick menu during still photogra- phy and the movie quick menu when in movie mode. The current quick menu will be displayed;...
Page 345 The Quick Menu Available Items (Still Photography) Choose from: • • IMAGE SIZE SUBJECT DETECTION SETTING • • IMAGE QUALITY MF ASSIST • • FILM SIMULATION TOUCH SCREEN MODE • • GRAIN EFFECT SELF-TIMER • • COLOR CHROME EFFECT PHOTOMETRY •...
Page 346 The Quick Menu Available Items (Movies) • • FILM SIMULATION BIT RATE • • DYNAMIC RANGE HIGH SPEED REC • • F WHITE BALANCE F SELF-TIMER • • F WHITE BALANCE COLOR TEMP. MOVIE AF MODE • (WHEN k SELECTED) FIX MOVIE CROP MAGNIFICATION •...
Page 347: Function Controls
Function Controls Assign a role to each function button or touch-function gesture for quick access to the selected feature. The Function Buttons Assign a role to the function buttons for quick access to the se- lected feature. Function Button Defaults The default assignments are: Back-of-Camera Function Buttons Back-of-Camera Function Buttons...
Page 348 Front-of-Camera Function Buttons Front-of-Camera Function Buttons Function buttons Function buttons Default Default A VIEW MODE button VIEW MODE button VIEW MODE SETTING B Fn1 button Fn1 button FACE DETECTION ON/OFF C Fn2 button Fn2 button DRIVE SETTING The Selector The Selector Function buttons Function buttons Default...
Page 349 Function Controls Assigning Roles to the Function Buttons Pressing and holding the DISP/BACK button displays a dialog where you can choose the roles assigned to the function buttons. Press and hold the DISP/BACK button until a control selection menu is dis- played.
Page 350 Roles That Can Be Assigned to the Function Buttons Roles That Can Be Assigned to the Function Buttons Choose from: • • IMAGE SIZE DIGITAL TELE-CONV. • • IMAGE QUALITY MULTI EXPOSURE • • WIRELESS COMMUNICATION • • FILM SIMULATION FLASH FUNCTION SETTING •...
Page 351 Function Controls • • AF-ON AUTO IMAGE TRANSFER ORDER • • AWB LOCK ONLY Bluetooth ON/OFF • • APERTURE SETTING QUICK MENU • • LOCK SETTING PLAYBACK • • PERFORMANCE NONE N • The selector cannot be assigned more than one role at a time. •...
Page 352: Touch-Function Gestures
Touch-Function Gestures Assign roles to touch-function gestures (T-Fn1, T-Fn2, T-Fn3, or T-Fn4) for quick access to selected features. Touch-function gestures are disabled by default. To enable touch-func- tion gestures, select ON for D BUTTON/DIAL SETTING > TOUCH SCREEN SETTING > c TOUCH FUNCTION. Touch-Function Gesture Defaults The default assignments for the diff erent gestures are: Touch-Function Gestures...
Page 353 Function Controls Assigning Roles to Touch Function Gestures Pressing and holding the DISP/BACK button displays a dialog where you can choose the roles assigned to touch function gestures. Press and hold the DISP/BACK button until a control selection menu is dis- played.
Page 354 Roles That Can Be Assigned to Touch Function Gestures Roles That Can Be Assigned to Touch Function Gestures Choose from: • • IMAGE SIZE DIGITAL TELE-CONV. • • IMAGE QUALITY MULTI EXPOSURE • • WIRELESS COMMUNICATION • • FILM SIMULATION FLASH FUNCTION SETTING •...
Page 355: Lens Function Buttons
Function Controls Lens Function Buttons Choose the roles played by the function buttons on the lens (where applicable). Lens Function Button Defaults The default assignments are: A XF18-120mmF4 LM PZ WR lens is used here for illustrative purposes. Lens function button Lens function button Default Default...
Page 356 Assigning Roles to the Lens Function Buttons The roles played by the lens function buttons can be selected using the D BUTTON/DIAL SETTING > POWER ZOOM LENS FUNCTION (Fn) SETTING option in the setup menu. • • IMAGE SIZE IS MODE •...
Page 357 Function Controls • • AE/AF LOCK AUTO IMAGE TRANSFER ORDER • • AF-ON Bluetooth ON/OFF • • AWB LOCK ONLY QUICK MENU • • APERTURE SETTING PLAYBACK • • LOCK SETTING NONE • PERFORMANCE N • To disable the function button, choose NONE. •...
Page 358 MEMO...
Page 359: Peripherals And Optional Accessories
Peripherals and Optional Accessories...
Page 360: Lenses
Lenses The camera can be used with lenses for the FUJIFILM X-mount. Lens Parts Lens hood O.I.S. switch Mounting marks Aperture mode switch Focus ring Lens signal contacts Zoom ring Front lens cap Aperture ring Rear lens cap A XF18-55mmF2.8-4 R LM OIS lens is used here for illustrative purposes.
Page 361: Lens Care
Lenses Lens Care • Use a blower to remove dust, then gently wipe with a soft, dry cloth. Any remaining stains can be removed by wiping gently with a piece of Fujifi lm lens-cleaning paper to which a small amount of lens-cleaning fl uid has been applied. •...
Page 362: Attaching Lens Hoods
Attaching Lens Hoods When attached, lens hoods reduce glare and protect the front lens element.
Page 363: Lenses With Aperture Rings
Lenses Lenses with Aperture Rings At settings other than A, you can adjust aperture by rotating the lens aperture A 16 11 8 5.6 4 2.8 ring (exposure modes A and M). A 16 11 8 5.6 4 Aperture ring N •...
Page 364: Lenses With No Aperture Rings
Lenses with No Aperture Rings The method used to adjust aperture can be selected using D BUTTON/DIAL SETTING > APERTURE SETTING. When an option other than AUTO is selected, aperture can be adjusted using the front command dial. Aperture control defaults to the front command dial, but can be reas- signed to the rear command dial using D BUTTON/DIAL SETTING >...
Page 365: Manual Focus Lenses
Lenses Manual Focus Lenses Slide the focus ring to the front for auto- focus. For manual focus, slide the focus ring to the back and rotate it while checking the results in the camera display. The focus distance and depth-of-fi eld indicators can be used to assist manual focus.
Page 366: Power Zoom Lenses
Lenses Power Zoom Lenses Zoom can be adjusted on power zoom lenses using the zoom/ focus control ring, zoom button, or zoom ring. Adjusting zoom while the lens is wet makes it easier for water to fi nd its way inside the lens. Wipe any water from the lens before adjusting zoom.
Page 367: External Flash Units
External Flash Units Use optional external fl ash units for fl ash photography. Some units support high-speed sync (FP) and can be used at shutter speeds faster than the fl ash sync speed, while others can function as commanders controlling remote units via optical wireless fl ash control.
Page 368: Flash Settings
Flash Settings Connect the unit to the camera. In shooting mode, select FLASH FLASH SETTING FUNCTION SETTING in the F (FLASH FLASH FUNCTION SETTING RED EYE REMOVAL SETTING) menu tab. The options TTL-LOCK MODE LED LIGHT SETTING available vary with the fl ash unit. COMMANDER SETTING CH SETTING EXIT...
Page 369: Ef-X8
External Flash Units EF-X8 The following settings are available when an optional EF-X8 shoe-mounted fl ash unit is attached. MODE EF-X8 ADJUST Setting Setting Description Description Choose from the following options: • TTL: TTL mode. Adjust ﬂ ash compensation ( ) and choose a ﬂ...
Page 370 Setting Setting Description Description Choose a ﬂ ash mode for TTL ﬂ ash control. The options avail- able vary with the shooting mode (P, S, A, or M) selected. • E (FLASH AUTO): The ﬂ ash ﬁ res only as required; ﬂ ash lev- el is adjusted according to subject brightness.
Page 371: Sync Terminal
External Flash Units SYNC TERMINAL The following options are available when no compatible fl ash unit is connected or if a unit is connected via the sync terminal or uses only the X-contact on the hot shoe. MODE SYNC TERMINAL ADJUST Setting Setting...
Page 372: Shoe Mount Flash
SHOE MOUNT FLASH The following options are available when an optional shoe-mounted fl ash unit is attached and turned on. MODE SHOE MOUNT FLASH ADJUST Setting Setting Description Description The ﬂ ash control mode selected with the ﬂ ash unit. This can in some cases be adjusted from the camera;...
Page 373 External Flash Units Setting Setting Description Description The options available vary with ﬂ ash control mode. • TTL: Adjust ﬂ ash compensation (the full value may not be applied if the limits of the ﬂ ash control system are exceed- ed).
Page 374 Setting Setting Description Description Control ﬂ ash timing. • H (1ST CURTAIN): The ﬂ ash ﬁ res immediately after the shut- ter opens (generally the best choice). • I (2ND CURTAIN): The ﬂ ash ﬁ res immediately before the shutter closes. Sync •...
Page 375: Commander(Optical)
External Flash Units COMMANDER(OPTICAL) The options will be displayed if the unit is currently functioning as a commander for Fujifi lm optical wireless remote fl ash control. MODE COMMANDER(OPTICAL) ADJUST Fujifi lm optical wireless remote fl ash control off ers a choice of four channels (Channels 1 through 4) for the exchange of optical signals between the commander and remote fl ash units.
Page 376 Setting Setting Description Description Choose ﬂ ash control modes for groups A, B, and C. TTL% is available for groups A and B only. Flash control mode • TTL: The units in the group ﬁ re in TTL mode. Flash com- (group A) pensation can be adjusted separately for each group.
Page 377 External Flash Units Setting Setting Description Description Choose a ﬂ ash mode for TTL ﬂ ash control. The options available vary with the shooting mode (P, S, A, or M) se- lected. • E (FLASH AUTO): The ﬂ ash ﬁ res only as required; ﬂ ash level is adjusted according to subject brightness.
Page 378 External Flash Units Setting Setting Description Description Choose the group for units functioning as a command- er for Fujiﬁ lm optical wireless remote ﬂ ash control in TTL, TTL%, or M mode. This option is available only with clip- on ﬂ ash units that support Fujiﬁ lm optical wireless remote ﬂ...
Page 379: Handgrips
Handgrips Using a handgrip makes the camera easier to hold. The MHG-XT5 handgrip attaches to the tripod socket.
Page 380 MEMO...
Page 381: Technical Notes
Technical Notes...
Page 382: Accessories From Fujifi Lm
Stereo microphones Stereo microphones MIC-ST1: An external microphone for movie recording. FUJINON lenses FUJINON lenses XF-/XC-series lenses: Interchangeable lenses for use exclusively with the FUJIFILM X-mount. FUJINON MKX-series lenses: Cinema lenses for the FUJIFILM X-mount. Macro extension tubes Macro extension tubes MCEX-11/16: Attach between the camera and the lens to shoot at high reproduc- tion ratios.
Page 383 Accessories from Fujifi lm Mount adapters Mount adapters FUJIFILM M MOUNT ADAPTER: Allows the camera to be used with a wide selection of M-mount lenses. Body caps Body caps BCP-001: Cover the camera lens mount when no lens is attached.
Page 384 Accessories from Fujifi lm Tripod grips Tripod grips TG-BT1: Record movies, take photographs, or adjust zoom on compatible power zoom lenses while holding this Bluetooth tripod grip. Grip belts Grip belts GB-001: Improves grip. Combine with a hand grip for more secure handling. instax SHARE printers instax SHARE printers SP-1/SP-2/SP-3: Connect via wireless LAN to print pictures on instax ﬁ...
Page 385: Software For Use With Your Camera
Software for Use with Your Camera The camera can be used with the following software. For the latest information on software available from Fujifi lm, visit https://fujifilm-x.com/support/compatibility/cameras/. Smartphone Apps Establish a wireless connection between your camera and a smartphone or tablet.
Page 386: Capture One Express For Fujifi Lm
Visit the website above for information on when support will be avail- able. FUJIFILM Tether Shooting Plug-in (Exclusively for Lightroom) A plug-in for Adobe Lightroom Classic. • FUJIFILM Tether Shooting Plug-in PRO/FUJIFILM Tether Shooting Plug-in https://fujifilm-x.com/products/software/adobe-photoshop-lightroom- tether-plugin/...
Page 387: Fujifilm X Acquire
USB. https://fujifilm-x.com/products/software/x-acquire/ FUJIFILM X RAW STUDIO When the camera is connected to a computer via USB, FUJIFILM X RAW STUDIO can use the camera’s unique image processing engine to rapidly convert RAW fi les to create high-quality images in other formats.
Page 388: For Your Safety
For Your Safety IMPORTANT SAFETY INSTRUCTIONS • Read Instructions Read Instructions: All the safety and operating instructions Power-Cord Protection: Power-supply cords should be routed should be read before the appliance is operated. so that they are not likely to be walked on or pinched by •...
Page 389 For Your Safety Power Lines: An outside antenna system should not be locat- Damage Requiring Service: Unplug this video product from ed in the vicinity of overhead power lines or other electric the wall outlet and refer servicing to qualiﬁ ed service person- light or power circuits, or where it can fall into such power nel under the following conditions: •...
Page 390 WARNING WARNING WARNING WARNING If the battery leaks and fl uid gets in contact with your If the battery leaks and fl uid gets in contact with your Do not use the camera in the bathroom or shower. Do not use the camera in the bathroom or shower. This eyes, skin or clothing, fl ush the aff ected area with clean eyes, skin or clothing, fl ush the aff ected area with clean can cause a ﬁ...
Page 391 For Your Safety CAUTION CAUTION Do not use this camera in locations aff ected by oil Do not use this camera in locations aff ected by oil fumes, steam, humidity or dust. fumes, steam, humidity or dust. This can cause a ﬁ re or electric shock.
Page 392 The Battery and Power Supply Note: Check the type of battery used in your camera and read Cautions: Handling the Battery Cautions: Handling the Battery ■ ■ • the appropriate sections. Do not transport or store with metal objects such as neck- laces or hairpins.
Page 393 Digital Split Image is a trademark or registered trademark of such as the sun in a cloudless sky. Failure to observe this FUJIFILM Corporation. Digital Micro Prism is a trademark or precaution could damage the camera image sensor. registered trademark of FUJIFILM Corporation. The typefaces •...
Page 394 NOTICES To prevent fire or shock hazard, do not expose the unit to rain or moisture. Please read the “Safety Notes” and make sure you understand them before using the camera. Perchlorate Material—special handling may apply. See: http://www.dtsc.ca.gov/hazardouswaste/perchlorate For Customers in the U. S. A. For Customers in the U.
Page 395 ﬁ ndings Liechtenstein: If you wish to discard this product, including have not been conﬁ rmed by additional research. X-T5 has the batteries or accumulators, please contact your local au- been tested and found to comply with IC radiation exposure thorities and ask for the correct way of disposal.
Page 396 RoHS Directive 2011/65/EU • RE Directive 2014/53/EU Hereby, FUJIFILM Corporation declares that the radio equipment type FF220001 is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: https://dl.fujifilm-x.com/global/products/cameras/x-t5/pdf/x-t5_doc-ysk.pdf The full text of the UK declaration of conformity is available at the following internet address: https://dl.fujifilm-x.com/en-gb/products/cameras/x-t5/pdf/x-t5_doc-ysk_uk.pdf...
Page 397 The maximum SAR value is 0.093 W/kg (head/body) averaged over 10 gram of tissue. U.K. Importer: FUJIFILM UK Limited Fujiﬁ lm House, Whitbread Way, Bedford, Bedfordshire, MK42 0ZE, United Kingdom EU Importer: FUJIFILM Electronic Imaging Europe GmbH Fujistrasse 1 47533 Kleve, Germany...
Page 398 For Your Safety Be sure to read these notes before using the lens Safety Notes WARNING WARNING • Make sure that you use the lens correctly. Read these safety Do not immerse in or expose to water. Do not immerse in or expose to water. Failure to ob- notes and the camera Basic Manual carefully before use.
Page 399: Product Care
Product Care To ensure continued enjoyment of the product, observe the following precautions. Camera body: Use a soft, dry cloth to clean the camera body after each use. Do not use alcohol, thinner, or other volatile chemicals, which could discolor or deform the leather on the camera body. Any liquid on the camera should be removed immediately with a soft, dry cloth.
Page 400: Cleaning The Image Sensor
Cleaning the Image Sensor Dust that cannot be removed using D USER SETTING > SENSOR CLEANING can be removed manually as de- scribed below. Note that there will be a charge to repair or replace the image sensor if it is damaged during cleaning. Use a blower (not a brush) to remove dust from the sensor.
Page 401: Firmware Updates
Firmware Updates Updates to product fi rmware may result in changes not described in the manual. For more information, visit: https://fujifilm-x.com/support/download/firmware/cameras/ Checking the Firmware Version The camera will only display the fi rmware version if a memory card is inserted.
Page 402: Troubleshooting
Troubleshooting Consult the table below should you encounter problems using your camera. If you don’t fi nd the solution here, con- tact your local Fujifi lm distributor. Power and Battery Problem Problem Solution Solution • The battery was not charged before fi rst use: The battery is not charged at shipment.
Page 403 Troubleshooting Problem Problem Solution Solution • The battery is cold: Warm the battery by placing it in a pock- et or other warm place and reinsert it in the camera im- mediately before taking a picture. • There is dirt on the battery terminals: Clean the terminals The battery runs down with a soft, dry cloth.
Page 404 Problem Problem Solution Solution • Make sure that the AC power adapter is correctly plugged in (P 42). • Ensure that the plug adapter is correctly connected to the AC power adapter (P 42). Charging does not start. • The battery has not been recharged for an extended period: If the battery has not been charged for an extended period, charging will be disabled to ensure safety.
Page 405 Troubleshooting Problem Problem Solution Solution • There is dirt on the battery terminals: Clean the terminals with a soft, dry cloth (P 36). The indicator lamp • The battery has been charged many times: Select BATTERY blinks, but the battery AGE to view the battery age;...
Page 406 Shooting Problem Problem Solution Solution • The memory card is full: Insert a new memory card or delete pictures (P 38, 230). • The memory card is not formatted: Format the memory card in the camera (P 272). • There is dirt on the memory card contacts: Clean the contacts with a soft, dry cloth.
Page 407 Troubleshooting Problem Problem Solution Solution No panorama is recorded when the The indicator lamp was orange when you attempted to record a shutter button is panorama: Wait until the indicator lamps turns oﬀ (P 9). pressed. • The subject’s face is obscured by sunglasses, a hat, long hair, or other objects: Remove the obstructions (P 151).
Page 408 Problem Problem Solution Solution • The fl ash is disabled: Adjust settings (P 180). • The electronic shutter is enabled: Choose a SHUTTER TYPE that does not use the electronic shutter (P 170). • The fl ash does not fi re. The battery is exhausted: Charge the battery or insert a ful- ly-charged spare battery (P 42).
Page 409 Troubleshooting Problem Problem Solution Solution • The lens is dirty: Clean the lens. • The lens is blocked: Keep objects away from the lens Pictures are blurred. (P 54). • s is displayed during shooting and the focus frame is dis- played in red: Check focus before shooting (P 55).
Page 410 Playback Problem Problem Solution Solution The pictures were taken with a diﬀ erent make or model of Pictures are grainy. camera. Playback zoom is The pictures were created using RESIZE or with a diﬀ erent unavailable. make or model of camera. •...
Page 411 The computer does not Be sure the camera and computer are correctly connected recognize the camera. (P 255). FUJIFILM X RAW STUDIO Check the option selected for CONNECTION MODE or FUJIFILM X Acquire on the camera. Select USB RAW CONV./BACKUP fails to correctly detect RESTORE before connecting the USB cable (P 263).
Page 412 Problem Problem Solution Solution POWER SUPPLY ON/COMM OFF is selected for USB POWER SUPPLY/COMM SETTING. Select POWER Cannot connect to SUPPLY OFF/COMM ON when the camera is connected iPhones or iPads. via a Lightning connection to a device that do not supply power (P 270).
Page 413 Troubleshooting Wireless Transfer For additional information on troubleshooting wireless connec- tions, visit: https://digitalcamera-support-en.fujifilm.com/ Problem Problem Solution Solution Cannot connect to smartphone. • The smartphone is too far away: Move the devices closer The camera is slow (P 249). to connect or upload •...
Page 414 Troubleshooting Miscellaneous Problem Problem Solution Solution • Temporary camera malfunction: Remove and reinsert the battery (P 36). • The battery is exhausted: Charge the battery or insert a ful- The camera is unre- ly-charged spare battery (P 42). • sponsive. The camera is connected to a wireless LAN: End the connec- tion.
Page 415: Warning Messages And Displays
Warning Messages and Displays The following warnings appear in the display. Warning Warning Description Description Low battery. Charge the battery or insert a fully-charged i (red) spare battery. Battery exhausted. Charge the battery or insert a ful- j (blinks red) ly-charged spare battery.
Page 416 Warning Warning Description Description Turn the camera oﬀ , remove the lens, and check for for- eign matter between the lens and the camera body, then LENS ERROR replace the lens and turn the camera on. If the problem persists, contact a Fujiﬁ lm dealer. •...
Page 417 Warning Messages and Displays Warning Warning Description Description • Memory card error or connection error: Reinsert the card or turn the camera oﬀ and then on again. If the message persists, contact a Fujiﬁ lm dealer. • Not enough memory remaining to record additional pictures: Delete pictures or insert a memory card with more free space.
Page 418 Warning Warning Description Description • The fi le is corrupt or was not created with the camera: The ﬁ le cannot be viewed. • The memory card contacts require cleaning: Clean the con- READ ERROR tacts with a soft, dry cloth. If the message is repeated, format the card.
Page 419 Warning Messages and Displays Warning Warning Description Description The selected operation is not supported: Check whether the F CANNOT EXECUTE picture was recorded with a diﬀ erent model of camera. m CANNOT EXECUTE p (yellow) The camera is approaching the maximum temperature al- lowed when STANDARD is selected for AUTO POWER CAMERA IS APPROACHING OFF TEMP.
Page 420: Memory Card Capacity
Memory Card Capacity The following table shows the recording time or number of pictures available at diff erent image sizes. All fi gures are approximate; fi le size varies with the scene recorded, pro- ducing wide variations in the number of fi les that can be stored.
Page 421: Specifi Cations
Specifi cations System Model FUJIFILM X-T5 Product Number FF220001 Eff ective pixels Approx. 40.2 million Image sensor 23.5 mm × 15.7 mm (APS-C), X-Trans CMOS 5 HR sensor with primary color ﬁ lter Storage media Fujiﬁ lm-recommended SD/SDHC/SDXC memory cards Memory card slots Two SD memory card slots (UHS-II compliant) •...
Page 422 : vertical (2160 × 9600)/horizontal (9600 × 1440) P panorama : vertical (2160 × 6400)/horizontal (6400 × 1440) Lens mount FUJIFILM X mount • Sensitivity Still pictures: Standard output sensitivity equivalent to ISO 125 – 12800 in increments of ⁄ EV; AUTO 1–3; extended output sensitivity equivalent to ISO 64, 80, 100, 25600, or 51200 •...
Page 423 Specifi cations System • Shutter speed MECHANICAL SHUTTER, E-FRONT CURTAIN SHUTTER, E-FRONT + MECHANICAL ⁃ Modes P and A: 30 s to ⁄ s ⁃ Modes S and M: 15 min. to ⁄ s ⁃ Bulb: Max. 60 min. • ELECTRONIC SHUTTER ⁃ Modes P and A: 30 s to ⁄ s ⁃...
Page 424 System White balance Auto (WHITE PRIORITY, AUTO, AMBIENCE PRIORITY), Custom 1, Custom 2, Custom 3, color temperature selection, direct sun- light, shade, daylight ﬂ uorescent, warm white ﬂ uorescent, cool white ﬂ uorescent, incandescent, underwater • Self-timer Still pictures: Oﬀ , 2 sec., 10 sec. •...
Page 425 Specifi cations System • ∶ ∶ Movie size: W 16 9, W 17 High-speed movies • Frame advance rate: 240P, 200P, 120P, 100P Input/output terminals Microphone connector ⌀3.5 mm mini-stereo jack Headphone jack socket The USB connector can be converted to a headphone jack using the supplied headphone adapter Remote release connector ⌀2.5 mm 3-pole mini jack Digital input/output USB connector (Type-C) USB3.2 Gen2x1...
Page 426 Power supply/other Power supply NP-W235 rechargeable battery (supplied with camera) • Battery life Battery type: NP-W235 • Lens: XF35mmF1.4 R • External fl ash units: Disabled • Shooting mode: Mode P Number of shots Number of shots PERFORMANCE PERFORMANCE 1 1 BOOST Approx.
Page 427 Specifi cations Power supply/other Camera size 129.5 mm × 91 mm × 63.8 mm (37.9 mm excluding projections, (W × H × D) measured at thinnest part)/5.1 in. × 3.58 in. × 2.51 in. (1.49 in.) Camera weight Approx. 476 g/16.8 oz., excluding battery, accessories, and memory card Shooting weight Approx.
Page 428 Specifi cations NP-W235 rechargeable battery Nominal voltage 7.2 V Nominal capacity 2350 mAh Rating capacity 2200 mAh Operating 0 °C to +40 °C/+32 °F to +104 °F temperature Dimensions 38.92 mm × 22.8 mm × 52.26 mm/ 1.5 in. × 0.9 in. × 2.1 in. (W ×...
Page 429 MEMO...
Page 430 MEMO...
Page 431 MEMO...
Page 432 7-3, AKASAKA 9-CHOME, MINATO-KU, TOKYO 107-0052, JAPAN https://fujifilm-x.com...

This manual is also suitable for:

Ff220001

FujiFilm X-T5 Owner's Manual

Quick Links

Related Manuals for FujiFilm X-T5

Summary of Contents for FujiFilm X-T5
