Fig. 8-8 Doors of MUENR-180-H12T / MUENR-180-H12T(K)
Door 1/2/3/9/10 give access to the compartment of water pipes and water side heat exchanger.
Door 4/5 give access to the hydraulic compartment.
Door 6/7/8 give access to the electrical parts.
