8.2 Opening the uint
Cover1 Cover 2
Cover 1/2/3 give access to the compartment of water pipes and water side heat exchanger.
Cover 4 give access to the electrical parts.
Cover 5/6 give access to the hydraulic compartment.
Cover 1 Cover 2
Fig. 8-7 Doors of MUENR-90-H12T / MUENR-90-H12T(K) & MUENR-140-H12T /MUENR-140-H12T(K)
Cover 1/2/3 give access to the compartment of water pipes and water side heat exchanger.
Cover 4 give access to the electrical parts.
Cover 5/6 give access to the hydraulic compartment.
Cover 3
Fig. 8-6 Doors of MUENR-75-H12T / MUENR-75-H12T(K)
Cover 3
Cover 6 Cover 5
13
Cover 6 Cover 5
Cover 4
Cover 4
