Enlighten Sauna InfraNature Original Series User Manual

Infrared sauna
Hide thumbs Also See for InfraNature Original Series:
Table of Contents

Advertisement

Quick Links

User Manual
Sierra - 5
Thank you for choosing our InfraNature Original Series!
The Infrared sauna
Congratulations on the purchase of your brand new infrared sauna. Please
carefully review and read through this material. Keep this manual and your
proof of purchase for future reference and service calls.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the InfraNature Original Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Enlighten Sauna InfraNature Original Series

Summary of Contents for Enlighten Sauna InfraNature Original Series

  • Page 1 User Manual Sierra - 5 Thank you for choosing our InfraNature Original Series! The Infrared sauna Congratulations on the purchase of your brand new infrared sauna. Please carefully review and read through this material. Keep this manual and your proof of purchase for future reference and service calls.
  • Page 2 Please let us know if there is anything you need. We are here to help. Happy Detox! Enlighten Sauna Team...
  • Page 3 What You Need to Prepare Before Installing the Sauna 1. Choose the right Outdoor space and clear it out for the sauna. 2. When determining a location for your sauna, please keep in mind the following: ● The main power cord on the sauna must be easily accessible. ○...

  • Page 4: Power Plugs

    that the sauna is properly grounded. Serious injury may result if the proper electrical requirements are not me WARNING! Keep the sauna away from any potential hazards, including any water source or liquids. Select a dry, suitable location for sauna installation. Do not expose the heater elements to any water source or liquids as it may cause electrical shock.
  • Page 5 Installation requirements for your sauna are as follows: 1. Your Enlighten sauna is a self-contained and freestanding unit. It should not be built into any structure without prior authorization. 2. Any modifications made to the sauna can waive the warranty, please get authorization before proceeding.

  • Page 6: Cleaning And Maintenance

    2. Apply sealant on the sides (as shown on the images) as well as on the bottom and top of walls. Cleaning and Maintenance 1. Before using your sauna for the first time, clean the inside of the sauna with a clean damp cloth. 2.
  • Page 7 3. Use a clean damp towel. DO NOT use a towel that is too wet and can drip water inside the sauna and DO NOT use cleaning agents inside the sauna. 4. DO NOT leave towels, water glasses or bottles inside the sauna after use. Wipe the exterior surface of the sauna with a towel and clean the glass at least once a month.
  • Page 8 2. Keep all liquids away from the Infrared heating panels. Flammable objects and corrosive chemical substances should be kept far away from the sauna. Your Infrared sauna will come packaged in five boxes if you choose a SLOPE roof (seven boxes for PEAK roof saunas).
  • Page 9 1) Floor 4) Right Side Wall 7) Front Wall 2) Back Wall 5) Under Bench Support 8) Ceiling 9) Outdoor Roof 3) Left Side Wall 6) Bench Connecting the Panels: Each sauna offers two types of panel-locking systems to connect the different sides of the sauna. Please use the instructions below as a reference guide on how to connect the sauna panels.

  • Page 10: Latch System

    Lift the panel with the male locks a few inches. Push it against the opposite panel; make sure to apply pressure around the top and bottom corners. Slide the panel down to lock it in place. Make sure all the locks are connected (top and bottom). Inspect the panels and make sure they are leveled (the top of the panel is flat and matching).

  • Page 11: Where To Start

    Where to Start: Lay the boxes flat on the ground and open them carefully. The accessories and smaller parts are located in the box that includes the top and bottom panels (Figure G-4). Figure G-4: Open the Boxes...
  • Page 12 ASSEMBLY INSTRUCTIONS – General Guide for: FLOOR PANEL Placement: Place the floor panel flat on the desired location. Make sure to leave a space around the sidewalls for one person to stand and install the side panels (Figure C-1). You can slide the sauna once it’s complete next to a wall.
  • Page 13 REAR PANEL Placement: Place the rear panel on the back end of the floor panel. At this point, someone should hold the rear panel until the next connection is made. SIDE PANELS Placement: Connect the side panels to the back panel as in the image below (Figure C-2, Page 8). Refer to “Connecting the Panels”...
  • Page 14 BENCH Placement Some saunas will include square bench support. Place it in front of the windows (Figure C-3). Figure C-3: Bench Support...
  • Page 15 Step 1. Place the bench stand panels by lining up its side with the vertical guides on the rear panel. After placing the bench stand panel, connect the heaters’ plugs. Step 2. Slide the benchtop panel over the horizontal guide on the side panels. Make sure the smooth and finished side is facing up and forward (Figure C-4, Page 21) Step 3.
  • Page 16 FRONT PANEL Placement: (Note: Install the door handle before installing the front panel.) Connect the front panel to both side panels as in the image below (Figure C-5). Refer to “Connecting the Panels” section (page 6) on how to lock the panels toget Tips: Make sure to align the corners of the two side panels and the edges of the front panel.
  • Page 17 TOP PANEL Placement: Step 1. Raise the top panel over the sauna body. Insert the wires for the control panel, temperature sensor, and heaters through the openings in the ceiling. Step 2. Connect the control panel wire (white ribbon) and the heat sensor (2-pin wire) on top of the sauna.
  • Page 18 If you bought an Indoor Version, the Top Panel is your Indoor Roof. Skip OUTDOOR ROOF ASSEMBLY INSTRUCTIONS. If you bought an Outdoor Version, please proceed with the OUTDOOR ROOF ASSEMBLY INSTRUCTIONS. OUTDOOR SAUNAS ASSEMBLY INSTRUCTIONS: Installation steps start at the section “Assembly Instructions –...
  • Page 19 Roofing Shingles Support Install the roofing shingles support beams around the top. Each beam is labeled alphabetically to a matching corner or side (Figure D-2, Page 25). For example, the beam marked with “A” should be screwed into the “A” corner. Repeat for all the corners and sides (based on the model, you might have eight or six supporting beams).
  • Page 20 Roof Sealing Screw the corner roof shingles around all corners. Each corner will have two shingles curved upward to easily identify the position of the screws (Figure D-4). Figure D-4: Corner Roof Shingles After screwing in the corners, flatten the curved shingles and place the pyramid roof shingles on top (Figure D-5).
  • Page 21 Slope Roof CAUTION! BEFORE PLACING THE SLOPE ROOF, MAKE SURE THAT EVERYTHING IS WORKING AND CONNECTED PROPERLY ON THE CEILING. If you had something damaged or had any issues, please call our technical department and wait till you get everything resolved and working properly before placing the roof. The roof is heavy and it will be hard to remove it in order to install parts.
  • Page 22 ACCESSORIES Oxygen Ionizer (Recommended) Locate the ionizer plug which is extended out of the sauna ceiling (1-pin plug). Connect the oxygen ionizer and screw it into the back panel. Cup Holder (Optional) The cup holder is a small wooden table that can be screwed in one of the front corners (either right or left, based on the user preferences).
  • Page 23 Color Therapy Lights (Recommended) Some models will include color therapy lights (or chromo lights aka chromotherapy). Color therapy lights function as light therapy for physical and mental health. Scientists have determined that each color emits a frequency. Our body consists of Seven Layers of the Auric Field and the Seven Chakras (energy centers of the body).
  • Page 24 Function when disturbed/unhealthy: Grief, Attachment, Easily Hurt. Emotional dependence on others. Heartlessness. Physical Health: Heart problems, lung problems, blood pressure problems. 5th Chakra – Throat Chakra (LIGHT BLUE) Location: The throat Function/Qualities: Language; Ability to communicate effectively; Authenticity; Inspiring, teaching. Function when disturbed/unhealthy: Lethargy, weakness in expressive abilities;...
  • Page 25 Function Function Power Button (On/Off) Temperature Control (reduce) Heat Light Fahrenheit Light Timer Control (reduce) Celsius Light Timer Control (increase) Lights Button/Pause Temperature Control (increase)
  • Page 26 Function Function Power Button (On/Off) Temperature Control (increase) Power Light Temperature Control (reduce) Timer Control (reduce) Lights Button/Pause Timer Control (increase)
  • Page 27 Function Function Power Button (On/Off) Fahrenheit Light Timer/Sound Control (reduce) Bluetooth connected light Timer/Sound Control (increase) Lights Button/Pause Temperature Control (increase) USB connect interface Temperature Control (reduce) Settings control Celsius Light...
  • Page 28 Function Function Power Button (On/Off) Turn on Bluetooth button USB connect interface Set time buttons Turn on the radio button Set temperature buttons Turn on the AUX function button Set 45 ⁰C on 60 minutes Turn on USB function button Lights Button/Pause...
  • Page 29 Function Function Power Button (On/Off) Turn on the AUX function button Set 45 ⁰C on 60 minutes Set time buttons Turn on USB function button Set temperature buttons Turn on Bluetooth button Lights Button/Pause Turn on radio button...
  • Page 30 1. Turn on the light wave. Click the "On/Off"(1) button to turn the light wave on or off. In the power-on state, The first click is to turn on the light wave, and the second click is to turn off the light wave. After setting the temperature (30-65), the system temperature has a memory function, and the last set temperature is the value.
  • Page 31 3. Press the “USB”(3) button to open the USB function, the temperature zone displays USB, the temperature +/- adjusts the previous one, the next one, the clock area displays “XX”, the time +/- adjusts the volume, and the button has no button response for 8 seconds. , the display switches to temperature and time.

  • Page 32: Usage Guide

    Usage Guide Allow your sauna to warm up for 15-20 minutes or until it reaches 110 F° (43 ° C). You may close the vent on the ceiling to speed up the preheating process. Drink plenty of water to avoid dehydration before and after the sauna session.
  • Page 33 Sauna and Contraindications Sauna and Medications Individuals who are using prescription drugs should seek the advice of their personal physician or pharmacist for possible changes in the drug’s effect when the body is exposed to far-infrared waves or elevated body temperature. Diuretics, barbiturates, and beta-blockers may impair the body's natural heat loss mechanisms.
  • Page 34 Sauna and Hemophiliacs / Individuals Prone To Bleeding The use of Infrared saunas should be avoided by anyone who is predisposed to bleeding. Sauna and Fever An individual that has a fever should not use any type of sauna. Sauna and Insensitivity to Heat An individual that has an insensitivity to heat should not use any type of sauna.

  • Page 35: Troubleshooting

    Troubleshooting The sauna doesn’t power on: Make sure the power cord is securely connected to the power socket and the control box (on top ● of the sauna). Make sure the breaker did not turn off. ● Make sure the control panel white ribbon wire is securely connected. ●...

  • Page 36: Warranty Information

    Warranty Information Enlighten Saunas warrants its products to be free of defects in material and workmanship. This warranty extends only to: a retail purchaser of a sauna or parts directly from the supplier; the authorized wholesale purchaser of a sauna or parts directly from the supplier; or a retail purchaser of a sauna or parts from an authorized wholesaler.

  • Page 37: Extended Warranty

    Extended Warranty 5 years optional You can extend for an additional 5% of the MSRP price of the sauna. This amount must be paid within 90 days of the date of delivery ● Factory-Installed Heater Components - 5 years ● Factory-Installed Sauna Controls and Wiring - 5 years ●...

  • Page 38: Commercial Use

    Indoor-Residential Use: The sauna or parts must be placed in an indoor environment unless the sauna or parts are specifically bought for outdoor/indoor use. If an indoor sauna or parts are placed in an outdoor environment, the warranty shall be null and void and of no further force and effect. A warranty shall not apply to any product or a component used for any industrial, rental, professional or neglect, accident, abuse, improper installation and/or reckless operation by the purchaser, including but not limited to: exposure to a fire or excessive heat, and other hazardous...
  • Page 39 Standard Warranty The standard 3-year warranty covers the following: Factory-Installed Heater Components - 3 years • Factory-Installed Sauna Controls and Wiring- 3 years • Factory-Installed Audio Components - 3 years • Enlighten Saunas® Brand Cabin (Wood / Construction) - 3 Years •...
  • Page 40 held liable for injury to any persons or damages to any properties. Specifications are subject to change without notice. Enlighten Saunas® uses the highest quality wood in our product lines. All structures using wood are susceptible to minor dents, scratches, and scuffing. This is normal and will not affect the integrity or operation of your sauna.
  • Page 41 Weight Loss Infrared Sauna is an effective way to support any weight loss program. According to the Journal of the American Medical Association, a sauna session can burn between 300-700 calories. Also, Dr. Oz. explained in the Oprah show that an infrared sauna session can burn up to 700 calories. A 20-minute sauna session is equal to a 20-minute long jog run.

This manual is also suitable for:

Sierra 5Sierra 5 peakSierra 5 indoorSierra 5 slope
