User Manual
Sapphire - 4 Corner
Diamond - 4 Corner
Thank you for choosing our InfraNature Duet Series!
The Hybrid Sauna
Congratulations on the purchase of your brand new infrared/traditional sauna. Please
carefully review and read through this material. Keep this manual and your
proof of purchase for future reference and service calls.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Sapphire and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Enlighten Sauna Sapphire

Summary of Contents for Enlighten Sauna Sapphire

  • Page 1 User Manual Sapphire - 4 Corner Diamond - 4 Corner Thank you for choosing our InfraNature Duet Series! The Hybrid Sauna Congratulations on the purchase of your brand new infrared/traditional sauna. Please carefully review and read through this material. Keep this manual and your...
  • Page 2 It is truly part of our personal journey, healing and inner belief that infrared saunas are safe and incredibly effective sources for personal detoxification and more. Please let us know if there is anything you need. We are here to help. Happy Detox! Enlighten Sauna Team...
  • Page 3 What You Need to Prepare Before Installing the Sauna 1. Choose the right Outdoor space and clear it out for the sauna. 2. When determining a location for your sauna, please keep in mind the following: ● The main power cord on the sauna must be easily accessible. ○...

  • Page 4: Power Plugs

    make sure that the sauna is properly grounded. Serious injury may result if the proper electrical requirements are not me WARNING! Keep the sauna away from any potential hazards, including any water source or liquids (for Infrared heaters, pouring water over Harvia heater is allowed). Select a dry, suitable location for sauna installation.
  • Page 5 Installation requirements for your sauna are as follows: 1. Your Enlighten sauna is a self-contained and freestanding unit. It should not be built into any structure without prior authorization. 2. Any modifications made to the sauna can waive the warranty, please get authorization before...
  • Page 6 3. Please maintain a minimum of 4-inch clearance on all sides of the unit to allow air to circulate while giving access for the power cord. Sealant Application VERY IMPORTANT: Please follow these steps during installation as they are very important to ensure the sauna is properly installed.

  • Page 7: Cleaning And Maintenance

    Cleaning and Maintenance 1. Before using your sauna for the first time, clean the inside of the sauna with a clean damp cloth. 2. Make sure to always keep the sauna dry and clean. 3. Use a clean damp towel. DO NOT use a towel that is too wet and can drip water inside the sauna and DO NOT use cleaning agents inside the sauna.
  • Page 8 details on how to maintain the wood in an outdoor environment. You can use any outdoor exterior clear wood sealer. Sauna Installation Instructions Please read the following directions carefully The sauna installation requires a minimum of 2 people, 5 person model sizes require at least 3 people to install.
  • Page 9 5. Right Side Wall 6. Front Wall 7. Back Wall 8. Bench and Bench Support 9. Harvia Electric Heater, BC-45E 10. Outdoor Roof ( SLOPE OR PEAK) Location of Sauna & Installation Order When determining a location for your sauna, please keep in mind the following: 1.
  • Page 10 Inner-Locking System: The inner-locking system is designed to be completely invisible when the sauna is installed. The locks are built on the side of each panel and they connect by sliding one over the other (Figure G-2). To connect two panels, follow these few steps: Lift the panel with the male locks a few inches.
  • Page 11 Where to Start: Lay the boxes flat on the ground and open them carefully. The accessories and smaller parts are located in the box that includes the top and bottom panels (Figure G-4). Figure G-4: Open the box to uncover accessories...
  • Page 12 Sauna Assembly: Connecting the Panels Steps. Step 1. Begin with the FLOOR PANEL Placement Place the floor panel flat on the desired location. Make sure to leave a space around the sidewalls for one person to stand and install the side panels (Figure B-1). You can slide the sauna once it’s complete next to a wall.
  • Page 13 Step 2. FIRST BACK PANEL Placement: Place the first back panel on the floor panel as an image on page 15 (Figure B-2). At this point, someone should hold the back panel until the next connection is made. Tips: ● The first panel will have female locks on both sides. Step 3.
  • Page 14 Step 4. FRONT SIDES Placement: Install the two front side panels (Figure B-4). Figure B-4: Installing the front panels...
  • Page 15 Sauna Assembly: Install HARVIA Heater BEFORE Installing the Bench and Other Panels. Step 5. Heater Installation. These instructions for installation and use are intended for the owner or the person in charge of the sauna, as well as for the electrician in charge of the electrical installation of the heater. After completing the installation, the person in charge of the installation should give these instructions to the owner of the sauna or to the person in charge of its operation.
  • Page 16 For the installation of Harvia heater, please refer to these steps: Step 1. When you step into the unit, you place the heater on the left side wall towards the front wall. Step 2. There are three wires coming out of the floor on the left-hand side. Step 3.
  • Page 17 Instructions For Harvia Heater Use Piling of the Sauna Stones The piling of the sauna stones has a great effect on the functioning of the heater (figure 1). Important information on sauna stones: The stones are provided with the sauna, but if you choose to buy additional stones, please see below: ●...
  • Page 18 Maintenance of the Stones Due to large variation in temperature, the sauna stones disintegrate in use. Rearrange the stones at least once a year or even more often if the sauna is in frequent use. At the same time, remove any pieces of stones from the bottom of the heater and replace any disintegrated stones with new ones.
  • Page 19 Cabin Assembly Continued: Step 6. ASSEMBLY OF BENCHES: Some saunas will include square bench support. Place it in front of the windows (Figure B-5, Page 16). Figure B-5: Bench Support Place the bench stand panels by lining up its side with the vertical guides on the back panels. Connect the heater’...
  • Page 20 Figure B-6: Bench Installation Step 7. DOOR PANEL Placement Note: Install the door handle first. Connect the door panel to the front side panels. For the inner-lock system, make sure to match the edges of the front panels to the corners of the door panel (Figure B-7 below). Tips: The front panel is heavy because of the glass door.
  • Page 21 Figure B-7: Front Panel Step 8. TOP PANEL Placement: Step 1. Raise the top panel over the sauna body. Insert the wires for the control panel, temperature sensors, and heaters through the openings in the ceiling. Step 2. Connect the control panel wire (white ribbon) and the heat sensor (2-pin wire) on top of the sauna. Step 3.
  • Page 22 Figure B-8: Top Panels and Connections NOTE: Accessories installation instructions continue below the outdoor models.
  • Page 23 If you bought an Indoor Version, the Top Panel is your Indoor Roof. Skip OUTDOOR ROOF ASSEMBLY INSTRUCTIONS. If you bought an Outdoor Version, please proceed with the OUTDOOR ROOF ASSEMBLY INSTRUCTIONS. OUTDOOR ROOF ASSEMBLY INSTRUCTIONS Step 9. Roof Placement. PEAK ROOF Main Support Place the roof bottom section on top of the sauna and screw the center support beam (Figure D-1).
  • Page 24 Roofing Shingles Support Install the roofing shingles support beams around the top. Each beam is labeled alphabetically to a matching corner or side (Figure D-2). For example, the beam marked with “A” should be screwed into the “A” corner. Repeat for all the corners and sides (based on the model, you might have eight or six supporting beams).
  • Page 25 Roof Sealing Screw the corner roof shingles around all corners. Each corner will have two shingles curved upward to easily identify the position of the screw (Figure D-4). Figure D-4: Corner Roof Shingles After screwing in the corners, flatten the curved shingles and place the pyramid roof shingles on top (Figure D-5).
  • Page 26 SLOPE ROOF CAUTION! BEFORE PLACING THE SLOPE ROOF, MAKE SURE THAT EVERYTHING IS WORKING AND CONNECTED PROPERLY ON THE CEILING. If you had something damaged or had any issues, please call our technical department and wait till you get everything resolved and working properly before placing the roof. The roof is heavy and it will be hard to remove it in order to install parts.
  • Page 27 Full Spectrum Heater Installation for Diamond Models Step 1. Locate the wooden bracket and full spectrum heater. Step 2. Align the holes from the wooden bracket to the holes on the back of the full spectrum heater. Step 3. Screw on the bolt.
  • Page 28 Step 4. Place 2 full spectrum heaters on the front wall besides the door. Digital Controller for BC45E Heater models BC45E, BC60E, BC80E and BC90E are controlled from a separate control unit. See the instructions for use of the BC45E control unit model.
  • Page 29 Function Function Power Button Temperature Control (reduce) (On/Off) Power on/off Fahrenheit Light indicator Timer Control Celsius Light (reduce time) Timer Control Lights Button On/Off (increase) Temperature Control Bluetooth connected light (increase) Setting the Temperaturer The purpose of the thermostat is to keep the temperature in the sauna room on a desired level. By experimenting, you can find the setting that suits you best.
  • Page 30 Throwing Water on Heated Stones The air in the sauna room becomes dry when warmed up. Therefore, it is necessary to throw water on the heated stones to reach a suitable level of humidity in the sauna. The effect of heat and steam on people varies –...
  • Page 31 Digital Controller for Infrared Heating System Function Function Power Button (On/Off) Turn on the AUX function button Set 45 ⁰C on 60 minutes Set time buttons Turn on USB function button Set temperature buttons Turn on Bluetooth button Lights Button/Pause Turn on radio button...
  • Page 32 1.Turn on the light wave. Click the "On/Off"(1) button to turn the light wave on or off. In the power-on state, The first click is to turn on the light wave, and the second click is to turn off the light wave. After setting the temperature (30-65), the system temperature has a memory function, and the last set temperature is the value.
  • Page 33 3. Press the “USB”(3) button to open the USB function, the temperature zone displays USB, the temperature +/- adjusts the previous one, the next one, the clock area displays “XX”, the time +/- adjusts the volume, and the button has no button response for 8 seconds. , the display switches to temperature and time.
  • Page 34 ACCESSORIES Oxygen Ionizer (Recommended) Locate the ionizer plug which is extended out of the sauna ceiling (1-pin plug). Connect the oxygen ionizer and screw it into the back panel. Cup Holder (Optional) The cup holder is a small wooden table that can be screwed in one of the front corners (either right or left, based on the user preference).
  • Page 35 Color Therapy Lights (Recommended) Some models will include color therapy lights (or chromo lights aka chromotherapy). Color therapy lights function as light therapy for physical and mental health. Scientists have determined that each color emits a frequency. Our body consists of Seven Layers of the Auric Field and the Seven Chakras (energy centers of the body).
  • Page 36 Location: The throat Function/Qualities: Language; Ability to communicate effectively; Authenticity; Inspiring, teaching. Function when disturbed/unhealthy: Lethargy, weakness in expressive abilities; Shyness, voice problems, insecurity, fear of others’ judgments/opinions. Physical Health: Throat, neck, thyroid problems. 6th Chakra – Third Eye (INDIGO BLUE) Location: Between the eyebrows.
  • Page 37 OTHER ACCESSORIES: Bucket with ladle Analog Thermostat Rocks Sand Timer/Hourglass Clock Wall for Sauna...

  • Page 38: Usage Guide

    Usage Guide Allow your sauna to warm up for 15-20 minutes or until it reaches 110 F° (43 ° C). You may close the vent on the ceiling to speed up the preheating process. Drink plenty of water to avoid dehydration before and after the sauna session.
  • Page 39 ● Sea air and a humid climate may corrode the metal surfaces of the heater. ● Do not hang clothes to dry in the sauna, as this may cause a risk of fire. Excessive moisture content may also cause damage to the electrical equipment.
  • Page 40 Instructions for Bathing • Begin by washing yourself. • Stay in the sauna for as long as you feel com- fortable. • Forget all your troubles and relax. • According to established sauna conventions, you must not disturb other bathers by speaking in a loud voice.
  • Page 41 Sauna and Contraindications Sauna and Medications Individuals who are using prescription drugs should seek the advice of their personal physician or pharmacist for possible changes in the drug’s effect when the body is exposed to far-infrared waves or elevated body temperature. Diuretics, barbiturates, and beta-blockers may impair the body's natural heat loss mechanisms.
  • Page 42 Parkinson's, Multiple Sclerosis, Central Nervous System Tumors and Diabetes with Neuropathy are conditions that are associated with impaired sweating. Sauna and Hemophiliacs / Individuals Prone To Bleeding The use of Infrared saunas should be avoided by anyone who is predisposed to bleeding. Sauna and Fever An individual that has a fever should not use any type of sauna.

  • Page 43: Troubleshooting

    Troubleshooting The sauna doesn’t power on: ● Make sure the power cord is securely connected to the power socket and the control box (located under the bench ). ● Make sure the breaker did not turn off. ● Make sure the control panel white ribbon wire is securely connected. ●...
  • Page 44 The heater does not heat. ● Check that the fuses to the heater are in good condition. ● Check that the connection cable is connected. ● Turn the timer switch to the “on” section. ● Turn the thermostat to a higher setting. ●...
  • Page 45 FM/USB/AUX/MP3/BLUETOOTH PLAYER WITH SPEAKERS is not working: If the radio has a bad reception, extend the antenna outside the sauna roof. ● If the USB cannot read an MP3 player, use an Aux-In plug and play the music from the MP3 player. ●...

  • Page 46: Warranty Information

    Warranty Information Enlighten Saunas warrants its products to be free of defects in material and workmanship. This warranty extends only to: a retail purchaser of a sauna or parts directly from the supplier; the authorized wholesale purchaser of a sauna or parts directly from the supplier; or a retail purchaser of a sauna or parts from an authorized wholesaler.
  • Page 47 Extended Warranty 5 years optional You can extend for an additional 5% of the MSRP price of the sauna. This amount must be paid within 90 days of the date of delivery ● Factory-Installed Heater Components - 5 years ● Factory-Installed Sauna Controls and Wiring - 5 years ●...
  • Page 48 Indoor-Residential Use: The sauna or parts must be placed in an indoor environment unless the sauna or parts are specifically bought for outdoor/indoor use. If an indoor sauna or parts are placed in an outdoor environment, the warranty shall be null and void and of no further force and effect. A warranty shall not apply to any product or a component used for any industrial, rental, professional or neglect, accident, abuse, improper installation and/or reckless operation by the purchaser, including but not limited to: exposure to a fire or excessive heat, and other hazardous elements/activities.

  • Page 49: Commercial Use

    Commercial Use: Standard Warranty The standard 3-year warranty covers the following: Factory-Installed Heater Components - 3 years • Factory-Installed Sauna Controls and Wiring- 3 years • Factory-Installed Audio Components - 3 years • Enlighten Saunas® Brand Cabin (Wood / Construction) - 3 Years •...
  • Page 50 Enlighten Saunas® shall not be liable for the loss of use of the sauna or other incidental or consequential damages. Under no circumstances shall the supplier or any of its representatives be held liable for injury to any persons or damages to any properties. Specifications are subject to change without notice.
