READ CAREFULLY AND KEEP FOR FUTURE REFERENCE.
Before use check that the voltage stated on the rating plate on the rear of your microwave oven corresponds to your mains voltage.
The mains socket must be well earthed. Do not plug the oven into a mains adaptor into which other units are connected.
If the door or door seals are damaged, the oven must not be operated until it has been repaired by a competent person.
It is hazardous for anyone other than a competent person to carry out any service or repair operation that involves the removal of a cover which gives protection against exposure to microwave energy.
This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children unless they are aged from 8 years and above and supervised.
Keep the appliance and its cord out of reach of children less than 8 years.
Do not use the microwave oven with a damaged cord or plug or after the appliance has malfunctioned or is damaged. Seek expert assistance.
Do not touch hot surfaces. Use handles or knobs only. Allow the appliance to cool before cleaning.
Do not operate the microwave oven empty. This could cause damage to the oven.
Do not immerse the body of the microwave oven or the electrical cord or plug in water or liquids.
Do not place the microwave oven on or near a hot gas or electric burner. Use the appliance on a stable heat-resistant surface.
Never leave the microwave oven unattended when it is operational.
Make sure that the power cable does not touch any hot surface or overhang a table edge.
Do not use the microwave oven outdoors.
Unplug the oven before cleaning.
Do not obstruct the ventilation slots or place objects on top of the oven. Do not use attachments or accessories not recommended by the manufacturer.
Heat-insulation (oven) gloves should be used when removing a hot container from the oven.
When not in use, do not store utensils, food or other objects in the oven.
There are no user serviceable parts in your microwave oven. Unauthorised dismantling or servicing will void the product warranty.
When cooking with your oven:
Only use utensils that are suitable for use in microwave ovens.
When heating food in plastic or paper containers, keep an eye on the oven due to the possibility of ignition.
If you use plastic film when re-heating or cooking food use only film designed for microwave ovens and ensure that the film does not touch the food. If necessary, prick the film all over to allow steam to escape. Grill & microwave/grill cooking: Do not use paper or plastic containers, or plastic film.
Utensils for combination-cooking should be heatproof and microwave safe. Use your microwave oven only to heat food.
Do not heat oil for frying, or try to fry food in the microwave oven. The oil could catch fire.
Liquids and other foods must not be heated in sealed containers since they are liable to explode. If covered containers are used, the covers should be loose. Move such containers to and from the oven with care as food may splash and the lid may fall.
Eggs in their shells and whole hard-boiled eggs, fruits in thick skins and nuts in their shells should not be heated in the microwave as they may explode even after microwave heating has ended.
Items such as potatoes, sausages and chestnuts must be peeled or pierced thoroughly before cooking.
The contents of feeding bottles and baby food jars shall be stirred or shaken and the temperature checked before consumption, in order to avoid burns.
Microwave heating of beverages can result in delayed eruptive boiling, therefore care must be taken when handling the container.
Food can burn if overcooked. If you are unsure about how long to cook a food for, start with short cooking time, and check the food regularly.
The oven should be cleaned regularly and any food deposits removed.
Failure to maintain the oven in a clean condition could lead to deterioration of the surface that could adversely affect the life of the appliance and possibly result in hazardous situation.
If smoke is observed, switch off or unplug the appliance and keep the door closed in order to stifle any flames.
When Using the Grill:
Use oven gloves when inserting and removing utensils when the grill is on.
When you remove utensils from the oven, place them on a heatproof surface, or on an insulating mat.
Keep small children away from the grill and hot dishes.
Children should only use the oven under adult supervision due to the temperatures generated.
Do not use the microwave oven for any purpose not expressly specified in this manual.
RAW MEAT AND RAW MEAT PRODUCTS
Meat and meat products should not be fully cooked from raw in a microwave oven. Raw meat may be partially cooked in a microwave oven but the final cooking process must be carried out by conventional cooking processes, (i.e boiling, roasting, frying, grilling etc) using a conventional cooker.
When defrosting raw meat and meat products in a microwave oven ensure the item is fully defrosted and then immediately cook the meat using conventional cooking processes.
Always clean the oven cavity thoroughly after partially cooking or defrosting raw meat.
Do not use the microwave oven for any purpose not expressly specified in this manual.
ELECTRICAL INFORMATION
Before using this appliance ensure that the voltage of your electricity supply is the same as that indicated on the rating plate of the appliance.
THIS APPLIANCE MUST BE EARTHED.
The disconnect device for this appliance is the mains plug. The mains plug must not be obstructed in any way and must remain readily removable from the mains supply.
The microwave oven shall not be placed in a cabinet unless it has been tested in a Cabinet. The minimum installation height is 85cm.
Some accessible surfaces may be hot during operation of this appliance.
Microwave cooking is very quick and efficient. Microwave cooking can also help preserve the minerals and vitamins in many foods.
The microwave power output of your oven is 800 watts.
Because the temperature in a microwave oven is relatively cool (unlike a normal oven) you have to remember that the food can be extremely hot. Always take precautions when handling containers.
Radio Interference:
Operation of the microwave oven can cause interference to your radio, TV or similar equipment. When there is interference, it may be reduced or eliminated by taking the following measures:
Your oven can carry out a number of cooking processes.
In this last process, food is partially cooked by microwaves and then finished by grilling. This accelerates the cooking process whilst maintaining the finish and texture of traditionally cooked foods. There is also a programme that enables you to defrost frozen food and then combination cook it thus completing the entire cooking process in one operation.
Your oven has 8 preset programmes. These programmes allow you to automate the cooking of a range of standard foods for greater convenience.
So you can just select the programme, dial in the amount of food you want to cook and the oven will do the rest!
Some basic guidelines are given in the table below.
Cookware | Microwave | Grill | Combination |
Heat-resistant glass | ![]() | ![]() | ![]() |
Non heat –resistant glass | ![]() | ![]() | ![]() |
Heat-resistant ceramics | ![]() | ![]() | ![]() |
Microwave-safe plastics | ![]() | ![]() | ![]() |
Kitchen paper | ![]() | ![]() | ![]() |
Metal trays/metal racks | ![]() | ![]() | ![]() |
Aluminium foil | ![]() | ![]() | ![]() |
Metal foil containers | ![]() | ![]() | ![]() |
(*Combination refers to microwave + grill cooking)
Use heat resistant porcelain, glass or plastic containers made for microwave ovens, otherwise there is a risk of shrinking, deforming or burning. Metal containers, or containers having metal decoration or trim are not suitable for use with your microwave oven.
When you are combination cooking, the container must be fully heatproof as well as suitable for microwave cooking. Avoid containers which narrow at the top as these may cause the contents to erupt when removed from the oven. Tesco stores stock a wide range of microwave containers and wraps designed for microwave ovens. Plastic films should not touch food as they may gas, melt or break down when hot and contaminate food.
Wax paper, oven cooking bags, parchment paper and white microwave paper towels are safe for microwave use. Wooden objects may catch fire - so avoid their use.
Do not use aluminium foil for microwave cooking unless the recipe requires it. Keep foil at least 25mm away from the oven walls. Metal skewers, ties, etc. should be removed from food before cooking.
Please make sure you read all the instructions and the safety notes carefully and that you familiarise yourself with the features and operation of your oven before use.
Remove the polystyrene top packing pieces and lift out the oven.
Unpack the oven completely removing all the protective tape.
Open the oven door. In the oven compartment you should find the turntable and rotating support ring, and the grill rack. Unpack all these items.
Check the oven carefully, especially the door, door seals and the locking mechanism. If any items are missing or damaged, contact your nearest Tesco store for assistance.
If possible retain the packaging. If you dispose of the packaging, do so having regard to recycling provisions in your area.
Place your microwave oven on a flat, level stable work surface away from sources of cold, heat and damp. The minimum installation height is 85cm.
For good ventilation, the rear and the left side should have a clearance of at least 7.5 cm from the wall, the right side should be open and the free distance above the top should be at least 30cm.
Always operate your microwave oven with the turntable assembly properly installed.
Press the Door Release to open the door. Drop the Turntable Rotor gently through the hole in the centre of the oven and locate it on the spindle beneath. There is a flat machined on the spindle to hold the rotor securely during operation.
Place the support ring in the recess.
Place the turntable on the support ring with the smooth side uppermost. Locate the turntable on the rotor and check that it is central to and properly supported by the ring. Refer to the drawing below.
Close the door.
Unwrap the power cord fully. Plug the oven directly into the wall socket.
Plug the oven in Switch on at the mains point.
The screen will display
The clock is a 24 hour clock. To enter a time of 8:30 pm
The time is set. To reset the clock follow the above procedure.
Each click increases/decreases the time interval as follows:
0 -1 min: 5 seconds: 1- 5 min: 10 seconds: 5 -10 min: 30 seconds
10 - 30 min: 1 minute: 30 - 95 min: 5 minute intervals
Example: Cook food at full power for 10 min.
Open the door to interrupt cooking. To continue cooking, close the oven door and press the Start/+30SEC./Confirm button.
Press Stop/Clear:
The cooking process is interrupted.
To continue cooking press the Start/+30SEC./Confirm button.
Pressing Stop/Clear twice will stop the oven and any cooking programme will be erased.
The oven will beep 5 times
The clock time will re-appear.
The default setting of the oven is full (100%) power. Many recipes call for lower power settings. There are 5 power settings available on your oven.
100% - 80% - 50% - 30% - 10%
To alter the microwave power level
Repeatedly pressing Micro/Grill/Combi will also vary the Power level..
Example: Cook food at 50% power for 10 min.
By pressing the Start/+30SEC./Confirm.button repeatedly you can program the oven for Express cooking. at FULL power(100%).
All cooking programs can be set up with the oven door open or closed with the exception of the Quick Start program which requires the door to be closed.
If you are setting up a program when the door is open, pressing the Stop/Clear button once will erase the program.
There are two auto-defrosting programmes
DEFROST PROGRAMME 1 (DEF 1) - defrost by weight. You can auto defrost 100g to 2kg of food (in 100g increments)
DEFROST PROGRAMME 2 (DEF 2) - defrost by time.
Example 1: Auto Defrost 1 kg of food
The programme automatically calculates the time required.
Example 2. Auto-Defrost food for 20 minutes
During Defrosting:
It is good practice to periodically check food during the defrosting process, turning it if necessary.
After Defrosting:
Your oven can calculate the cooking time of various foods. Just select the program from the table below and enter the weight.
The results of auto-cooking depend on many factors, the actual type of food, the temperature it goes into the oven at, etc. If after the program has ended the food is underdone, use the Basic Cooking Procedure for a short time to complete the process.
NUMBER OF CLICKS | |||||
MENU | SUGGESTED FOOD | POWER | 1 | 2 | 3 |
A-1 | Reheat food | 100% | 200 g | 400 g | 600 g |
A-2 | Most vegetables | 100% | 200 g | 300 g | 400 g |
A-3 | Fish | 80% | 250 g | 350 g | 450 g |
A-4 | Broccoli | 100% | 250 g | 350 g | 450 g |
A-5 | Pasta* | 80% | 50 g Plus 450ml water | 100 g Plus 800ml water | |
A-6 | Baked potato | 100% | 200 g | 400 g | 600 g |
A-7 | Pizza | 100% | 200 g | 400 g | |
A-8 | Soup | 80% | 200 g | 400 g |
* NOTE: Add enough boiling water to the food before cooking.
Example: Auto Cook 450g of Fish:
Press Start/+30SEC./Confirm to start cooking
The Child safety lock prevents operation by small children. All oven functions are disabled including the clock when the child lock is on.
The grill is useful for cooking thin slices of meat, steaks, kebabs, sausages and pieces of chicken. It is also suitable for hot sandwiches and au gratin dishes. Grilling takes place at full power.
The maximum time available for grilling is 95 minutes.
Example: To grill food for 10 minutes:
Half way through cooking the oven will beep twice. This to remind you that you need to turn the food over.
Open the door, turn the food with heatproof tongs and close the door and press the Start/+30SEC./Confirm button to continue.
When the cooking cycle is over: The oven will 'beep' five times, and reset to the clock time.
Points to remember when grilling:
When you use the grill, the cooking utensils and the interior of the oven get very hot, much hotter than when you are using the oven as a regular microwave.
Always stir food with long handled implements, tongs, etc.
Always use oven gloves when removing or placing utensils in an oven where the grill has recently been on. When you set utensils down on a surface make sure it is heatproof or use an insulating mat.
After use allow an extra long period for the oven to cool down before cleaning or re-use.
Combination Microwave and grill cooking offers you the speed of a microwave oven with the finish and taste of a conventional grill. To help you realise the potential of this form of cooking, we advise you to buy a recipe book dedicated to this cooking art.
There are two Combi-grill programs. They both work in exactly the same way but have different settings. Both microwave the food first and then grill it to give a browned, tasty finish.
COMBINATION 1: Microwaves the food for55% of the total time and grills it for 45%. Use this program for puddings omelettes, baked potatoes and poultry.
COMBINATION 2: Microwaves the food for36% of the total time and grills it for 64%. Use this program for fish, potatoes, and 'au gratin' dishes.
Setting a combi -grill program
Example: To set a Com 2 cooking program taking 20 minutes:
You can combine cooking processes in a two stage programme. There are two main uses for this process.
After the first stage, the buzzer will sound once and the next stage will automatically start.
If you are defrosting, this must be the first process.
You can use multi-cooking with combi -cooking so you can defrost, microwave and grill all in one. The Auto-Cook menu cannot be used in multi-cooking.
Example: Defrost the food for 20 minutes, then cook at 50% microwave power for 10 minutes.
The defrost cycle will commence. When the defrost cycle has ended the oven will move on to the cooking process.
You can preset the time at which the cooking process starts.
Example: Cook food at 50% power for 10 min starting at21:20
The display reverts to clock time: When the preset time comes the buzzer sounds twice and the oven will begin the programme.
When Time Delayed coking is preset:
NOTES ON TIME DELAYED COOKING:
You can use a single program, a multistage program or an Auto-cook menu. You cannot use Express cooking.
Do not use raw or frozen fish products or foods which may deteriorate during the waiting period.
Do not use time-delayed cooking with a defrost programme. The clock must be set!
Please read this section together with the Safety Guide.
Hints for reheating food
Is it cooked?
Hints for defrosting
Steam: Steam is a natural product of microwave cooking. It escapes from the vents in the appliance. These vents should never be blocked. Steam may condense in and around the oven during cooking and should be dried off after use.
Smoke: If during cooking, smoke starts to come from the oven do NOT open the oven door! Immediately switch off at the mains, unplug the oven and wait for the smoke to completely subside and the oven to fully cool down before removing the food. Before you use your microwave oven again, consult a service technician and have the oven tested.
Testing Your Oven: Place a cup of water in the oven and heat it on full power for 2 minutes. If the water gets hot the oven is working.
Dim Oven Light: During low power microwave cooking the oven light may appear to dim slightly. This is normal and not a cause for concern.
If the oven fails to work or will not respond to commands: Unplug the oven and inspect the plug fuse. If this is intact, leave the oven for 30 minutes and then plug the oven in again. The oven should now work normally.
These steps should be taken after every use.
If the oven fails to operate:
If none of the above rectifies the situation, contact the Tesco helpline. Do not try to adjust or repair the oven yourself.
APPROXIMATE COOKING TIMES FOR FISH ON FULL POWER
Item | Weight | Cooking time | Standing time |
Cod fillets | 450g | 3-4 minutes | 4-10 minutes |
Cod steaks | 225g | 3-4 minutes | 4-10 minutes |
Haddock fillets | 225g | 3-4 minutes | 4-10 minutes |
Kipper fillets | 450g | 3-4 minutes | 4-6 minutes |
Plaice fillets | 225g | 3-4 minutes | 6-8 minutes |
Trout (2 fish, gutted but whole) turn fish over half way through | 3-5.5 minutes | 4-6 minutes |
The times given above are approximate and should be adjusted to suit portion sizes and individual taste. The average cooking time for fish is around 3.5 minutes per 450 g (1 lb). The fish should be lightly covered during the standing period. Temperature of the fish should reach 70º C. The fish should be opaque and flake easily.
APPROXIMATE COOKING TIMES FOR FRESH VEGETABLES (ON FULL POWER)
Item | Weight | Added water | Cooking Time |
Aubergines (peeled and diced) | 450g | 30-40 ml | 4.5-5.5 minutes |
Broccoli (trimmed and sliced into spears) | 225g | 50 ml | 3.5-4.5 minutes |
Brussels Sprouts (peeled) | 225g | 50 ml | 5.5-7.5 minutes |
Carrots (diced) | 225g | 30 ml | 5.5-7.5 minutes |
Cauliflower (in florets) | 450g | 50-60 ml | 7-9 minutes |
Courgettes (diced or sliced) | 450g | 10 ml | 5.5-7.5 minutes |
Peas (removed from pods) | 225g | 40-50 ml | 4.5-5.5 minutes |
Potatoes, jacket ( 2, scrubbed and pierced all round) | 225g | None | 7-9 minutes |
Potatoes, (in 40mm pieces) | 450 g | 40-50 ml | 6-7 minutes |
Spinach (shredded) | 225g | None | 3.5-5.5 minutes |
The times given above are approximate and should be adjusted to suit quantities, portion sizes and individual taste. The average cooking time for vegetables is around 5.5 minutes per 450 g (1 lb). When adding salt, mix it with the water or add it after cooking.
To cook vegetables: Mix them with the water in a ceramic curved bottomed bowl and cover lightly. After cooking leave the vegetables to stand for 2-3 minutes before straining (if necessary) and serving.
Your Tesco appliance is covered by a warranty for 12 months from the date of purchase. If a fault develops during this period, please contact the TESCO electrical help line on 0845 456 6767. Please have your original purchase receipt with you when you call. This warranty in no way affects your consumer rights.
Mains Supply: | 230V-240V~, 50 Hz: 1200-1270W |
Microwave Output: | 750-800 Watts |
Grill Input Power: | 950-1000 Watts |
Dimensions: | 258mm(H)×440mm(W)×293mm(D) |
Oven Capacity: | 20 Litres |
Microwave Frequency; | 2,450 Mhz |
Net Weight: | 11.3kg |
UK: Waste electrical products /batteries should not be disposed of with household waste. Separate disposal facilities exist, for your nearest facilities.
See www.recycle-more.co.uk or in-store for details.
ROI: Produced after 13th August 2005. Waste electrical products/batteries should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local Authority or retailer for recycling advice.
Here you can download full pdf version of manual, it may contain additional safety instructions, warranty information, FCC rules, etc.
Advertisement
Need help?
Do you have a question about the MG2011 and is the answer not in the manual?
Questions and answers
