DUAL ACTION AIRBRUSH KIT
Stock Number M676
On occasion, after printing of our literature is completed, our manufacturers may make changes and/or modifications to merchandise which will not be reflected in this manual. Although
we strive to maintain complete and accurate information, it is possible in some instances, that the product may differ slightly from printed specifications. Illustrations are intended for
reference only. Actual merchandise may vary. Wilmar is not responsible for typographical errors.
OWNERS MANUAL
Please read these instructions carefully and retain them for future use.
Advertisement
Related Manuals for Performance Tool M676
Summary of Contents for Performance Tool M676
- Page 1 DUAL ACTION AIRBRUSH KIT Stock Number M676 OWNERS MANUAL Please read these instructions carefully and retain them for future use. On occasion, after printing of our literature is completed, our manufacturers may make changes and/or modifications to merchandise which will not be reflected in this manual. Although we strive to maintain complete and accurate information, it is possible in some instances, that the product may differ slightly from printed specifications.
-
Page 2: Specifications
SPECIFICATIONS Air Pressure: ........10 - 35 P.S.I. Avg. Air Consumption (CFM): ......1 Spray Pattern: ......1/16 - 1-1/4 in. Fluid Inlet (NPS): ........1/8 in. Nozzle Size: ........... 0.35 MM Air Inlet (NPS): ........... 1/4 in. Cup Capacity: ....5 cc, 3/4 & 1-5/16 oz Specifications are subject to change without notice IMPORTANT SAFETY INFORMATION WARNING! -
Page 3: Care And Maintenance
CARE & MAINTENANCE Warning! To achieve the best results when spraying always clean the air brush of any paint deposits, dirt or other contaminants. Thoroughly clean the air brush immediately after each use. To protect the precision machined internal parts and passages. -
Page 4: Replacement Parts List
REPLACEMENT PARTS LIST REPLACEMENT PARTS LIST Description Qty. Description Qty. Protective Cap Needle Adjusting Sleeve Air Cap Needle Nozzle Needle Chucking Net O-Ring Needle Cover Gun Body O-Ring Adjustment Screw Valve Body Finger Trigger Valve Rod Rocker O-Ring Needle Chucking Guide Spring Spring Valve Screw... -
Page 5: Troubleshooting
REPLACEMENT PARTS LIST Description Qty. Description Qty. 1/4 NPT x M5-45 Adapter Metal Hanger Air Line Assembly 3/4 oz. Paint Jar 5 cc Metal Paint Cup 1-5/16 oz. Mixing Jar 7 mm Wrench Call Customer service for replacement parts: 1-800-497-0552 TROUBLESHOOTING periodic adjustments are necessary to maintain a peak Your spray gun was constructed with quality materials and... - Page 6 90 days from the date of purchase, provided that product is returned to place of purchase immediately after discovery of defect. After 90 days and up to one year from date of purchase, PERFORMANCE TOOL® will replace at no charge any parts which our examination shall disclose to be defective and under warranty.
