Summary of Contents for DOD FS580+
- Page 1 FS580+ User Manual...
-
Page 3: Safety Instructions
Safety instructions About the product • For your safety, please do not watch the video or operate the product while driving. To install and set up this product, please park your car in a safe place first. • Please read this User's Manual before operating the product. •... - Page 4 Other Description Product Upgrade Please go to the DOD website to download the latest software. When downloading the latest software, please check the system version first (if the host's current software version is higher than the version released on the official website, it is recommended not to change the software).
- Page 5 Buttons and screen display * Button functions and screen displays vary by model A. Subnet switching / WiFi F. Rear lens connection port B. Microphone / Downward G. Power port C. Confirmation / Playback H. Memory Card D. Upward / Recording I.
- Page 6 Mode Button Description Switch on/off Short press: Lock file Long press: capture in video Short press: Go to playback Press and hold: Switch to record on/off Short press: Go to setting menu Press and hold: Switch on/off recording Short press: switch the front and back lens display screen Long press: Switch WiFi on/off Switch on/off...
-
Page 7: Installation
Installation Installation location and alignment *Drawings are for reference only, subject to the real thing Cleaning windshields Installation Find a suitable location on the car, not blocking the driver's view and safety, install the bracket and hang the machine. Adjust the lens angle Adjust the angle of the lens by adjusting the angle of elevation of the main unit to make sure it is level with the ground. - Page 8 Connected Power Before connecting the power, please be sure to first connect the host and rear lens USB cable installation is complete, finally connect the car charging power to the car to reduce the host and rear lens damage chance. NOTE: Please use the original car charger to avoid damage caused by non-compliance with the specifications.
- Page 9 Please scan the QR code link to APP store to download the latest version of "DOD Dashcam" APP to your smart device. Android Note: DOD Dashcam APP supports version iOS7 or above Android4.5 or above. As each model varies, it is recommended to update your smart device to the latest version.
- Page 10 Link Description 1. Press the Wi-Fi switch on the machine → Open AP mode → Use your phone or tablet to connect to the machine Wi-Fi and enter the password → After the connection is completed, you can start the operation. Preset password: 12345678 00:02:13 SSID...
- Page 11 ● ● Switching front and rear camera display File Browse ● ● Capture the moment Turn on/off recording ● ● Cell phone brightness adjustment Settings ● Google Map ● Turn on/off recording *Need to turn on the ● Return to Link Control page phone GPS function...
-
Page 12: Function Setting Menu
Function Setting Menu ※ The menu varies depending on the model, so please refer to the update instructions released with the firmware for adding, deleting or changing features. Press [ ] once to enter the function setting Function Options Preset value 1440P30 4KP30 / 1600P30 / 1440P60 / 1440P30 / Single front... -
Page 13: Product Specifications
Product Specifications Front: 3840x2160@30fps Recording Resolution Rear: 1920x1080@30fps Light-sensitive element SONY STARVIS CMOS Sensor Wide angle lens 140° Aperture f/1.7 Video format MP4 / TS Compressed Format H.264 / H.265 EV value Independent adjustment of front and rear lenses WiFi 2.4G support Battery Jin Danyong... - Page 14 1. Please keep the invoice and warranty card. 2. If the invoice or warranty card for the camera is missing, please provide the device's serial number to DOD customer service so that the warranty can be fulfilled. The product is not included inside the warranty：...
-
Page 15: Guarantee Certificate
Date of Purchase ／ ／ DOD authorized distributor Copyright ©2023 DOD Tech Co., Ltd. All Rights Reserved Under the copyright laws, this manual may not be copied, in any way, shape, or form, without the written consent of DOD Tech Co., Ltd.
