Table Of Contents - Terex Genie Z331815M-101 Operator's Manual

Operator's Manual
TEREX Global GmbH
Bleicheplatz 2
8200 Schaffhausen
Switzerland
Technical Assistance Service
Telephone: +39 075 9418129
+39 075 9418175
e-mail: UMB.Service@terex.com
II
Contents
Introduction .......................................................... 1
Symbol and Hazard Pictorials Definitions............ 5
General Safety..................................................... 7
Personal Safety ................................................. 11
Work Area Safety .............................................. 12
Legend............................................................... 19
Controls ............................................................. 20
Inspections ........................................................ 25
Operating Instructions ....................................... 37
Transport and Lifting Instuctions ....................... 43
Maintenance ...................................................... 46
Specifications .................................................... 48
Copyright © 2018 by Terex Corporation
First Edition: Second Printing, August 2018
Genie and "Z" are registered trademarks of Terex South
Dakota, Inc. in the U.S.A. and many other countries.
These machines comply with
ANSI/SIA 92.5
CAN B.354.4
Z-33/18
First Edition • Second Printing
Part No. 1257144GT
