Model Number
138A05
Performance
Measurement Range(for ±5V output)
Useful Overrange(for ± 10V output)
Sensitivity(± 15 %)
Maximum Pressure
Resolution
Resonant Frequency
Rise Time(Reflected)
Low Frequency Response(- 5 %)
Non-Linearity
Environmental
Temperature Range(Operating)
Maximum Shock
Electrical
Output Polarity(Positive Pressure)
Discharge Time Constant(at room temp)
Excitation Voltage
Constant Current Excitation
Output Impedance
Output Bias Voltage
Physical
Sensing Element
Housing Material
Electrical Connector 10-32 Coaxial Jack
Weight
[4]
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change specifications without notice.
®
ICP is a registered trademark of PCB Piezotronics, Inc.
ICP® PRESSURE SENSOR
EN GLISH SI
5,000 psi 34,475 kPa
10,000 psi 68,950 kPa
1.0 mV/psi 0.15 mV/kPa
50,000 psi 344,750 kPa
0.1 psi 0.7 kPa
≥ 1,000 kHz ≥ 1,000 kHz
≤ 1.5 µ sec ≤ 1.5 µ sec
1.7 Hz 1.7 Hz
≤ 2.0 % FS ≤ 2.0 % FS
-10 to +100 °F -23 to +37.8 °C
20,000 g pk 196,140 m/s² pk
Positive Positive
≥ 0.3 sec ≥ 0.3 sec
20 to 30 VDC 20 to 30 VDC
2 to 20 mA 2 to 20 mA
≤ 100 Ohm ≤ 100 Ohm
8 to 14 VDC 8 to 14 VDC
Tourmaline Tourmaline
Stainless Steel Stainless Steel
10-32 Coaxial Jack
0.75 oz 21.0 gm
Optional versions have identical specifications and accessories as listed for the standard model except
where noted below. More than one option may be used.
[1]
- Negative Output Polarity
N
W - Water Resistant Cable
[2]
[3]
N OTES:
[1]For +10 volt output, minimum 24 VDC supply voltage required. Negative 10 volt output may be
limited by output bias.
[2]Typical.
[3]Zero-based, least-squares, straight line method.
[4]See PCB Declaration of Conformance PS023 for details.
Entered: ND Engineer: RPF
Date: 10/07/2021 Date: 10/07/2021 Date: 10/07/2021 Date: 10/07/2021 138-1050-80
3425 Walden Avenue, Depew, NY 14043
Revision: L
ECN #: 52121
OPTION AL VERSION S
Sales: MV Approved: BAM Spec Number:
Phone: 716-684-0001
Fax: 716-684-0987
E-Mail: info@pcb.com
