- Page 1 Manual Angle 1.4 Hp 4 1/2” grinder Power Disc Applies for: Code Model 100902 ESMA-45110 ESMA-45110 Read this manual thoroughly CAUTION before using the tool.
-
Page 2: Table Of Contents
Manual before Parts using the tool. Assembly Keep this manual for future references. Start Up The illustrations in this manual are for reference Maintenance only. They might be different from the real tool. Notes Authorized Service Centers Warranty Policy ESMA-45110 ENGLISH... -
Page 3: Technical Data
Technical Data ESMA-45110 Code 100902 Description Angle grinder Discs 4 1/2” Voltage 127 V Frequency 60 Hz Current 8.3 A Power 1.4 Hp Speed 6 000 RPM - 12000 RPM Duty cycle 30 minutes work per 15 minutes idle. Maximum 3 hours per day. -
Page 4: General Power Tool Safety Warnings
General power tool safety warnings WARNING! Read carefully all safety warnings and instructions listed below. Failure to comply with any of these warnings may result in electric shock, fire and / or severe damage. Save all warnings and instructions for future references. -
Page 5: Safety Warnings For Angle Grinders
Safety warnings for angle grinders This power tool is intended to function as a cutting tool. Read all safety warnings, instructions and specifications provided. WARNING Select the right disc • Wear safety glasses, gloves and an apron when using the tool. CAUTION •... - Page 6 Safety warnings for angle grinders DANGER KICKBACK (Sharp Recoil) d) Discs should be used only for their recommended applications. For example: do not grind with the side of Kickback (sharp recoil) is a sudden reaction when a a cut-off wheel.Abrasive discs are used for perfect rotating wheel, backrest, brush, or other accessory gets grinding.
-
Page 7: Parts
Parts Axis Protective Speed Lock Guard Control Handle Guard Bracket Axis ” abrasive Lock Nut Lock disc included model ABT-386 Wrench (Included) Auxiliary Handle Protective Guard Outer Disc Flange Speed Control Inner Flange Power Supply Cord Auxiliary Handle Assembling Orifice Guard Bracket Switch... -
Page 8: Start Up
Assembly Auxiliary Handle Assembly • For a safer operation use the auxiliary handle. Fit it into any of the two mounting orifices. Use the one that make your job easier. Start Up The angle grinder is a manual power tool. It is used to grind and cut steel, pipes, and angles in iron, bricks, tiles, stone and/or ceramic pieces. -
Page 9: Maintenance
Start Up Useful Tips • To prevent damaging the disc work using the disc into the right position. • Press onto the work piece using less force than the tool’s weight to avoid overload and damaging the motor and disc. •... -
Page 10: Notes
Notes ENGLISH... -
Page 11: Authorized Service Centers
In the event of any problem contacting a Authorized Service Center, please see our webpage www.truper.com to get an updated list, or call our toll-free numbers 800 690-6990 or 800 0187-8737 to get information about the nearest Service Center. DE TODO PARA LA CONSTRUCCIÓN FIX FERRETERÍAS... -
Page 12: Warranty Policy
. Transportation costs resulting from compliance of this warranty will be covered by For questions or comments, call 800-690-6990. Made in China. Imported by Truper S.A. de C.V. Parque Industrial 1, Jilotepec, Edo. de Méx. C.P. 54240 Stamp of the business.
