MSW TIGER MOTH 300 Installation

TIGER MOTH 300 HEADLIGHT
Thank you for your purchase! At MSW
accessories makes a good bike ride great. Tiger Moth 300 is MSW's handy
USB rechargeable light set. Keep it on your bike mounted to the handlebars,
or easily remove it for safe storage in a commuter backpack or bag. Be seen
on your rides!
WARNING: Cycling can be dangerous. Bicycle products should be
installed and serviced by a professional mechanic. Never modify your bicycle
or accessories. Read and follow all product instructions and warnings
including information on the manufacturer's website. Inspect your bicycle
before every ride. Always wear a helmet. For more information, please visit
www.mswbike.com/safety
COMPATIBILITY AND INTENDED USE
WARNING: Ensure that the Tiger Moth 300 Headlight is placed an
adequate distance away from any rotating components of the bicycle
or bicycle wheels and is not obstructed by any components, accessories,
or cargo.
COMPONENTS
Light
USB cable
INSTALLATION
Install the bracket onto your handlebar.
Ø18~48mm
≤Ø23mm
360° ROTATABLE BRACKET
360° 360°
6400 WEST 105TH STREET // BLOOMINGTON, MN 55438 // 1-855-883-6563 // WWW.MSWBIKE.COM
196351 5/19 | 85-001107_INST_A
we believe having essential
®
≥Ø23mm
TO SWITCH MODES
Press the button on the top of the light.
seconds
Off
Press
MODE MEMORY FUNCTION: When you turn the light
on, it lights up in the last lighting mode you used.
PROGRAMMABLE LUMINANCE MODE, 1~8 HRS
Press and hold the switch for 3 seconds to activate the
Programmable Luminance mode.
The light will automatically cycle from low to high
output. Press the button on the desired output to set it.
BATTERY CAPACITY INDICATOR
TURN ON: The indicator will show the remaining capacity with different colors.
Green: 100–50%
Orange: 49–25%
Red: 24–0%
TURN OFF: Double click to show the remaining capacity.
LOW BATTERY INDICATOR
Less than 25% battery remaining
In constant mode: circular flashing
In flashing mode: pulsed constant lighting
CHARGING
1. Open the rubber cover at the bottom of the light.
2. Plug in provided micro USB cable then plug into USB port.
Red: 0–24%
Orange: 25–49%
Green: 50–100%
Light OFF: Fully Charged
Open
1.5
Constant Boost Super Bright
8 hrs 4 hrs 2 hrs
Pulsating
Daytime Flashing
3.5 hrs 8 hrs
