MSW TIGER MOTH 500 Installation

TIGER MOTH 500 HEADLIGHT
Thank you for your purchase! At MSW
accessories makes a good bike ride great. Tiger Moth 500 is MSW's handy
USB rechargeable headlight. Keep it on your bike mounted to the handlebars,
or easily remove it for safe storage in a commuter backpack or bag. Be seen
on your rides!
WARNING: Cycling can be dangerous. Bicycle products should be
installed and serviced by a professional mechanic. Never modify your bicycle
or accessories. Read and follow all product instructions and warnings
including information on the manufacturer's website. Inspect your bicycle
before every ride. Always wear a helmet. For more information, please visit
www.mswbike.com/safety

COMPATIBILITY AND INTENDED USE

WARNING: Ensure that the Tiger Moth 500 Headlight is placed an
adequate distance away from any rotating components of the bicycle
or bicycle wheels and is not obstructed by any components, accessories,
or cargo.

COMPONENTS

Light
USB cable

INSTALLATION

Install the bracket onto your handlebar.
Ø18~48mm
≤Ø23mm ≤Ø23mm
360° ROTATABLE BRACKET
360°
360°
≤Ø23mm
360°
360°
A
6400 WEST 105TH STREET // BLOOMINGTON, MN 55438 // 1-855-883-6563 // WWW.MSWBIKE.COM
196351 5/19 | 85-001108_INST_A
we believe having essential
®
Ø18~48mm
Ø18~48mm
Ø18~48mm
≥Ø23mm ≥Ø23mm
≥Ø23mm
A
Ø18~48mm

TO SWITCH MODES

Press the button on the top of the light.
Press
Light
Sensor
1.5
seconds
Constant
4.5 hrs
Off
MODE MEMORY FUNCTION: When you turn the light on, it lights up in the last
lighting mode you used.
NOTE: Upon full discharge, the light will enter Protected Mode and automatically
restore to factory default settings. The light will be in Low Mode when charged
and turned back on.
IN DARK ENVIRONMENTS
such as at night or in tunnels
A
2~8 hrs
CONSTANT OUTPUT
A
A

BATTERY LEVEL INDICATOR

3-level check function shows actual remaining power level.
Normal Mode
Green: 100–50%
Orange: 49–25%
Red: 24–0%
AUTO Mode
Blue: 100–25%
Alternately flash red and blue: 24–0%
≤Ø23mm
Power OFF: Double click to show the remaining capacity.

LOW BATTERY INDICATOR

Less than 25% battery remaining
In constant mode: circular flashing
In flashing mode: pulsed constant lighting

CHARGING

1. Open the rubber cover at the bottom of the light.
2. Plug in provided Micro USB cable then plug into USB port. The light will
alert you when fully charged.
3. Indicator will show charging status with different colors.
Red: 0–24%
Orange: 25–49%
Green: 50–100%
Light OFF: Fully Charged
Open
≤Ø23mm
≤Ø23mm
≤Ø23mm
A
≤Ø23mm
Boost Super Bright Pulsating
2 hrs 1 hrs 20 hrs
IN BRIGHT ENVIRONMENTS
such as during daytime, dawn, or dusk
to further enhance rider visibility
FLASHING OUTPUT
≥Ø23mm
Micro USB
360° 360°
≥Ø23mm
≥Ø23mm
≥Ø23mm
Daytime
Flashing
8 hrs
