Nitecore ND02, NT02, NM02, NG02, NF02, NE02, NA02 Manual

Table of Contents

Contents

1 Features
2 Specifications
3 Accessories
4 Technical Data
5 Charging Function
6 Operating Instructions
7 Power Indication
8 ATR (Advanced Temperature Regulation)
9 Documents / Resources
- 9.1 Download manual

Features

USB Rechargeable Ultra Compact 21700 Flashlight
Utilizes 4 x CREE XP-G3 S3 LEDs, with a maximum output of 2,700 lumens
Maximum peak beam intensity of 5,400cd and maximum throw of 147 meters
Utilizes a total reflective optic lens for uniform and soft light
Built-in 1 x 4,000mAh 21700 rechargeable Li-ion battery
Built-in Li-ion battery charging circuit
High efficiency constant circuit provides stable output up to 310 hours
The metal tail switch controls 5 brightness levels
A power indicator on the tail indicates the remaining battery power
Incorporated Advanced Temperature Regulation (ATR) module (Patent No. ZL201510534543.6)
Constructed from aero grade aluminum alloy
HA III military grade hard-anodized finish
Waterproof in accordance with IPX8 (2 meters submersible)
Impact resistant to 1 meter
Tail stand capability

Specifications

Length: 123.4mm (4.86")
Head Diameter: 34mm (1.34")
Tail Diameter: 28.5mm (1.12")
Weight: 172.5g (6.08oz)

Accessories

Clip, Lanyard, Holster, USB Charging Cable

Technical Data

	TURBO	HIGH	MID	LOW	ULTRALOW
Brightness	Approx. 2,700 Lumens	Approx. 1,250 Lumens	Approx. 240 Lumens	Approx. 75 Lumens	Approx. 5 Lumens
Runtime	*Approx. 45min	Approx. 2h 15min	Approx. 9h	Approx. 26h	Approx. 310h
Beam Distance	Approx. 147m	Approx. 95m	Approx. 40m	Approx. 22m	Approx. 5m
Peak Beam Intensity	Approx. 5,400cd	Approx. 2,250cd	Approx. 400cd	Approx. 124cd	Approx. 7cd
Impact Resistance	1m
Water Resistance	IPX8, 2m (Waterproof and Submersible)

Note: The stated data is measured using the built-in battery (1 x 4,000mAh 21700 Li-ion battery) under laboratory conditions. The data may vary in real world use due to different battery usage or environmental conditions.
* The runtime for TURBO mode is tested without the temperature regulation.

Charging Function

The flashlight is equipped with an intelligent charging system. Please charge the product before the first use.
Connect to the external power: As illustrated, use the USB cable to connect an external power supply (e.g. a USB adapter, a computer or other USB charging devices) to the USB port located on the tail to begin the charging process.
Charging Function
Charging Indicator: When the charging status is normal, the blue indicator will flash slowly. When the battery is fully charged, the indicator will become steadily turned on.

The ULTRALOW, LOW and MID Level is still available when the flashlight is being charged.
Power Input: DC 5V/2A
The charging time is approx. 4 hours.
The standby time is approx. 12 months when the flashlight is fully charged.

Operating Instructions

On / Off
On: When the light is off, long press the Tail Switch to access ULTRALOW Level.
Off: When the light is on, long press the Tail Switch to turn off the light.

Brightness Levels
When the light is on, short press the Tail Switch to cycle through the following brightness levels: ULTRALOW – LOW – MID – HIGH – TURBO.

Direct Access to TURBO
When the light is off, keep pressing the Tail Switch for over 3 seconds to directly access TURBO after accessing ULTRALOW.

Power Indication

When the light is off, short press the Tail Switch and the power indicator will flash to indicate the remaining power of the batteries:

Flashing three times indicates that the power is above 50%;
Flashing twice indicates that the power is below 50%;
Flashing once indicates that the power is below 10%.
Note: When the light is on and the power level is close to 50%, the power indicator will flash every 2 seconds to inform the user. The flashlight should be recharged when the power indicator flashes quickly and continuously and the output appears to be dim or the flashlight becomes unresponsive due to low power.

ATR (Advanced Temperature Regulation)

The integrated ATR technology regulates the output of the flashlight according to the working condition and ambient environment to maintain the optimal performance.

Please charge the battery before the first use.
Please recharge the product every 3 months when left unused for a prolonged time.
DO NOT direct the beam towards naked eyes.
DO NOT disassemble, modify or reconstruct the product, otherwise the warranty will be nullified, and the product might be damaged.
The battery is built-in and non replaceable.
