- Page 1 WINDOW TYPE ROOM AIR CONDITIONER Owner’s Manual Owner’s Manual & Installation Manual Casements CD-81R01 CD-101R01 IMPORTANT NOTE: Before using your air conditioner, please read this manual carefully and keep it for future reference. www.marsdelivers.com...
- Page 2 CONTENTS Safety precautions Installation instructions What is in the box Before you get start Installation overview Installation operation Operation instructions 21-22 Get to know your AC Care and cleaning 23-24 Troubleshooting...
- Page 3 Safety Precautions Must read the warning message. Inside you will find many helpful hints on how to use and maintain To prevent injury to the user or other people and property your air conditioner properly. Just a little preventive care on your damage, the following instructions must be followed.
- Page 4 CAUTION unless they have been given super vision or instruction Hold the plug by the head of the power plug when taking concerning use of the appliance by a person responsible for it out. It may cause electric shock and damage. Turn o the their safety.
- Page 5 WARNING Electrical Information For Your Safety The complete electical rating of your new room air conditioner Do not store or use gasoline or other flammable vapors and is stated on the serial plate. Refer to the rating when checking liquids in the vicinity of this or any other appliance. the electrical requirements.
- Page 6 What is in the Box. Package content Installation kit contents: Hardware Qty. Hardware Qty. 9 or 10 Platform or 11 or 17 Support brace Window locking bracket Adjustment bolt Hex flange nut - 1/4 Plastic window panel Track seal Side channel Side channel seal Window sash seal Panel frame/seal assembly...
- Page 7 Before you get start Preparations before installation The installation must be Installing your We recommend We’re here if you need us, n u a carried out in strict AC should take doing this with please contact your local accordance with the about 60 minutes.
- Page 8 Step Attach support brace. The sliding window What you need.
- Page 9 Attach support brace. 8-11/16″ Platform Assembly HEX FLANGE NUT NOTE 6mm(1/4″) If you are planning to use a siding- protection board (see Step 5) on the outside of your house, hold board in place when testing assembly in window. If any sash stop protrudes more than 1 ″from the side window jambs, the 8-11/16″measurement must be increased accordingly.
- Page 10 Attach support brace. Measure from here About 3° to 4° Put platform tab against inside of track Inside wall of house Siding-protection board Securely attach a siding-protection Adjust platform assembly. board to the outdoor side of window. Adjust the platform assembly so that the air conditioning Place platform assembly,with platform tab against inside of window Angle is about 3°...
- Page 11 Step Install the panel frame and window panel. What you need.
- Page 12 Install the panel frame and window panel. Towards the back of the unit Top view Measure distance and subtract remain 20-5/8″. horizontal Fastening side channels Ensure your unit is Measure height of Fasten side channels. level on the window. window opening. Level platform assembly from Measure height of window opening Fasten side channels to the sides of...
- Page 13 Install the panel frame and window panel. Front Retaining Screw NOTICE: DO NOT push or pull air direction louvers. To remove front(Prepare for the installation of Window). 1. Remove the two front retaining screws from the front frame. 2. Gently pull the front out and lift up to release it from the case. 3.
- Page 14 Step Place AC in window opening. What you need.
- Page 15 Place AC in window opening. Measure the the plastic inner height window panel of the panel frame to the the R1 Panel frame top of the unit. hardware Plastic window Cut o the excess panel of the plastic window panel according to the measured length.
- Page 16 Place AC in window opening. Sash seal Front Retaining Window Screw locking bracket the foam seal Install the window To replace the front. strip/sash seal. locking bracket. Stu the foam seal strip/sash seal Use the window locking bracket to lock First reconnect the coupler plugs,make the the inner window sash to the base of the Exhaust control positioned through the front in...
- Page 17 Installation for di erent window types. Vinyl-Clad window & casement window NOTE Illustrations in this manual are for explanatory purposes. The actual shape of your indoor unit may be slightly di erent. The actual shape shall prevail. For casement window: to avoid crank handle and window clearance problems, the unit can be installed in a stationary sash section.
- Page 18 Attach support brace(For vinyl-clad window). Attach support brace to platform. Platform support bracket, support bracket and track seal must be As shown on the side. Use adjustment bolt and hex flange nut to complete centered with the centerline of assembly. Choose slot and adjustment bolt hole locations that will create a the 8-11/16 ″marked window jamb.
- Page 19 Casement window Attach support brace. What you need. Attach support brace (For casement window). Attach support brace to platform. Platform support bracket and track seal must be centered with the Use the adjustment bolt and hex flange nut to complete the assembly. centerline of the marked window jamb.
- Page 20 Attach support brace (For casement window). Center platform assembly on the window. Screw the platform assembly to the window jamb through the pilot hole you drilled in Step 2. Use a 3/4″self-threading screw. Measure from here About 3° to 4° Adjust platform assembly.
- Page 21 Get to know your AC. AC unit overview Feature Power key selection Display Levers Air Direction Filter pull Front Intake Grille handle (The filter is behind this) Rear Condenser Screw holes Vents in front panel Get to know your AC. Electronic control operating instructions Clean Timer...
- Page 22 Get to know your AC. Electronic control operating instructions Clean Timer Check Sleep Filter Exhaust Energy Timer Saver Timer Timer closed open Follow Auto High Auto Cool Mode Temp. Temp. The indicator light beside will be illuminated During this function, the display will show the actual 7.
- Page 23 Cleaning & maintenance How to clean & maintenance your AC. Air Filter & Cabinet Cleaning The air filter should be checked at least once Be sure to unplug the air conditioner to prevent shock or fire hazard. The cabinet a month to see if cleaning is necessary. and front may be dusted with an oil-free Trapped particles in the filter can build up cloth or washed with a cloth dampened in...
- Page 24 Problem Solving Problem Solution Dirty air filter- air restricted. Clean air filter. Refer to Care and Cleaning section. Temperature is set too High, set temperature to a Lower setting. Air conditioner cooling, but room Air directional louvers positioned improperly. Position louvers for better air distribution. is too warm- NO ice forming on Front of units is blocked by drapes, blinds, furniture, etc.
- Page 25 LIMITED EXPRESS WARRANTY REMEDY PROVIDED BY THE LIMITED EXPRESS WARRANTY Congratulations on purchasing your new HVAC equipment. It’s been designed for long life and reliable service, and is backed The sole remedy under the Limited Warranty is replacement of the by one of the strongest warranties in the industry.
- Page 26 This Page Left Intentionally Blank...
- Page 27 This Page Left Intentionally Blank...
- Page 28 1900 Wellworth Ave., Jackson, MI 49203 • Ph. 517-787-2100 • www.marsdelivers.com 1/2023...
