English Add the bar and chain oil........8 Description......... 4 Install the battery pack........8 Intended use............4 Remove the battery pack........8 Residual risks.............4 10 Operation........... 8 Overview............4 10.1 Examine the chain oil........8 General power tool safety 10.2 Hold the machine..........8 warnings..........
English DESCRIPTION Guide bar cover Chain Front handle guard / 10 Guide bar INTENDED USE chain brake 11 Wrench Front handle 12 Rear handle This chainsaw is designed for cutting branches, trunks, logs Lock out button 13 Chain tension screw and beams of a diameter determined by the cutting length of Trigger the guide bar.
English • Remove any adjusting key or wrench before turning • When battery pack is not in use, keep it away from the power tool on. A wrench or a key left attached to a other metal objects like paper clips, coins, keys, nails, rotating part of the power tool may result in personal screws, or other small metal objects that can make a injury.
English SYMBOLS ON THE PRODUCT will reduce the likelihood of accidental contact with the moving saw chain. Some of the following symbols may be used on this product. • Follow instructions for lubricating, chain tensioning Please study them and learn their meaning. Proper and changing accessories.
English PROPOSITION 65 SYM- SIGNAL MEANING WARNING CAUTION Indicates a potentially hazard- This product contains a chemical known to the state of ous situation, which, if not California to cause cancer, birth defects or other avoided, may result in minor reproductive harm.
English ADD THE BAR AND CHAIN OIL 1. Align the lift ribs on the battery pack with the grooves in the battery compartment. Examine the amount of oil in the machine. If the oil level is 2. Push the battery pack into the battery compartment until low, add the bar and chain oil as follows.
English 10.3 START THE MACHINE 10.6 FELL A TREE 1. Press the lock-out button (4). 2. Press the trigger (5) while you hold the lock-out button. 3. Release the lock-out button. Recommendation that the first-time user should, as a IMPORTANT minimum practice, start cutting logs on a saw-horse or cradle.
English It is important to make sure your footing is secure and your CAUTION weight is evenly distributed. If possible, lift the log and hold The level notching cut helps prevent pinching of the it with branches, logs or chock. Obey the instructions below: saw chain or the guide bar when you make the second notch.
English 3. Put the chain drive links (21) into the bar groove (20). 4. Put the chain cutters (22) in the direction of the chain operation. When the log is on a slope, 1. Stand on the uphill side. 2. Control the chain saw completely. 3.
English NOTE NOTE If you start the chain saw with a new chain, have a test for During normal saw operation, the temperature of the chain 2-3 minutes. A new chain gets longer after the first use, increases. The drive links of a correctly tensioned warm examine the tension and tighten the chain if necessary.
English 11.4 GUIDE BAR MAINTENANCE 4. File all the cutters to the specified angles and the same length. NOTE During the process, • Keep the file flat with the surface to be sharpened. NOTE • Use the midpoint of the file bar. Make sure that it is turned over periodically to keep •...
English TROUBLESHOOTING Problem Possible cause Solution The motor runs Sharpen or replace Problem Possible cause Solution The chain is blunt. and the chain ro- the saw chain. tates, but the chain The guide bar and The chain is too Adjust the chain Turn the chain does not cut.
(3) years against defects in materials, parts or workmanship. Greenworks, at its own discretion will repair or replace any and all parts found to be defective, through normal use, free of charge to the customer.
English EXPLODED VIEW Part No. Description Part No. Description R0201007-00 Bar / Chain / Scabbard RB333101075A Bucking Spikes RB339022028A Chain Brake Kit RB311031063 Tensioner Kit RB339012028A Sprocket Kit R0201008-00 Sprocket Cover Assembly RB311051734F Oil Cap Assembly R0201009-00 Bar Pad Cover RB341022029 Chain Brake Handle 10 RB341032029...
Page 17
Español Descripción........18 Instalación........22 Uso previsto............. 18 Desembalaje de la máquina......22 Riesgos residuales..........18 Adición del aceite para barras y cadenas..22 Perspectiva general.......... 18 Instalación de la batería........23 Advertencias generales de Retirada de la batería........23 10 Funcionamiento....... 23 seguridad para herramientas 10.1 Examen del aceite de la cadena.......
Español DESCRIPCIÓN USO PREVISTO Esta motosierra se ha diseñado para cortar ramas, troncos, leños y vigas de un diámetro determinado por la longitud de corte de la barra de guía. Se ha diseñado únicamente para cortar madera. Para su uso únicamente en una aplicación doméstica en 13 15 exteriores por adultos.
Español SEGURIDAD ELÉCTRICA • Desconecte el enchufe de la fuente de alimentación o la batería de la herramienta eléctrica antes de realizar • No exponga las herramientas eléctricas a la lluvia ni a ajustes, cambiar accesorios o almacenar herramientas condiciones de humedad.Si penetra agua en una eléctricas.
Español SERVICIO la motosierra reducirá la posibilidad de contacto accidental con la cadena de la sierra en movimiento. • Solicite a un técnico de reparación cualificado que • Siga las instrucciones para lubricar, tensar la cadena y realice las tareas de servicio de su herramienta cambiar accesorios.
Español altura del calibrador de profundidad, puede aumentar el SÍMBO- INDICACIÓN SIGNIFICADO retroceso. ADVERTEN- Indica una situación de peli- SÍMBOLOS EN EL PRODUCTO gro potencial que, de no evita- rse, podría provocar lesiones En el producto pueden utilizarse algunos de los siguientes graves o incluso la muerte.
Español AVISO AVISO Si la batería se agrieta o se rompe, con o sin fugas, no la No instale la batería hasta que no haya montado todas las recargue ni la utilice. Deséchela y sustitúyala por una piezas. batería nueva. ¡NO INTENTE REPARARLA! Para evitar lesiones y riesgos de incendio, explosión o descarga DESEMBALAJE DE LA MÁQUINA eléctrica, y para evitar daños al medio ambiente:...
Español 10.1 EXAMEN DEL ACEITE DE LA 4. Ponga la tapa del aceite. CADENA 5. Apriete la tapa del aceite. 6. El depósito de aceite entero durará aproximadamente NOTA 20-40 minutos. No utilice la máquina si no tiene suficiente aceite para IMPORTANTE cadenas.
Español 10.5 ACCIONAMIENTO DEL FRENO • El usuario no se encuentre en la zona peligrosa (24), por ejemplo, en el lado cuesta abajo de la zona. DE LA CADENA • Las vías de evacuación (25) que se extienden hacia atrás AVISO y en diagonal detrás de la dirección de tala (23) estén despejadas.
Español 10.7 DESRAMADO DE UN ÁRBOL Desramar es quitar las ramas de un árbol caído. 1. Conserve las ramas inferiores más grandes para mantener el tronco levantado del suelo (31). Cuando el tronco se sostenga en dos extremos (37), 2. Retire las ramas pequeñas (30) de un corte. 1.
Español AVISO Retire la batería de la máquina antes de realizar tareas de mantenimiento. 11.1 SUSTITUCIÓN DE LA BARRA DE GUÍA Y LA CADENA 1. Retire las tuercas de la cubierta de la cadena con la llave. 16 17 2. Retire la cubierta de la cadena. 9.
Español 3. Gire el tornillo de ajuste de la cadena en sentido horario para aumentar la tensión de la cadena. 4. Gire el tornillo de ajuste de la cadena en sentido antihorario para disminuir la tensión de la cadena. 3. Afile la placa superior, la placa lateral y el calibrador de profundidad con una lima plana.
Español 11.4 MANTENIMIENTO DE LA BARRA • Lejos de productos que puedan producir corrosión, como sustancias químicas para jardín y sales para DE GUÍA descongelación. SOLUCIÓN DE PROBLEMAS Problema Posible causa Solución La barra de guía y La cadena está de- Ajuste la tensión la cadena se cal- masiado tensa.
Español Problema Posible causa Solución Problema Posible causa Solución El motor funciona, La cadena está de- Ajuste la tensión La máquina no se Tire del freno de la El freno de la ca- pero la cadena no masiado tensa. de la cadena. pone en marcha.
(3) años contra defectos de material, piezas o mano de obra. Greenworks, a su propia discreción, reparará o reemplazará todas y cada una de las piezas que se encuentren defectuosas, en base a un uso normal, sin costo alguno para el cliente.
Español VISTA DESPIEZADA Nº Nº pieza Cant. Descripción Nº Nº pieza Cant. Descripción R0201007-00 Barra / Cadena / Vaina RB333101075A Dientes RB339022028A Kit de freno de cadena RB311031063 Kit de tensor RB339012028A Kit de piñón R0201008-00 Conjunto de cubierta de pi- ñón RB311051734F Conjunto de tapa de aceite...
