PCB Piezotronics ICP 208C04 Installation And Operating Manual page 17

4
PCB Piezotronics Inc. claims proprietary rights in
the information disclosed hereon. Neither it nor any
reproduction thereof will be disclosed to others
without the written consent of PCB Piezotronics Inc.
B
.625 [15.88] HEX
.10 [2.6]
3 2X
16 [0.4]
 [  ]
.625 .001 15.88 .03
3
16 [0.4]
7 ADD CABLE FOR WATER RESISTANT OPTION
A
6 MOUNTING TORQUE ON .625 [15.88] HEX, 16-20 IN-LBS [181-226 Ncm]
5.) COMPRESSIVE FORCE ON CELL YIELDS POSITIVE OUTPUT VOLTAGE
DRILL PERPENDICULAR TO MOUNTING SURFACE TO WITHIN ±1°
4
3 THESE SURFACES GROUND FLAT AND PARALLEL TO WITHIN .001 [0.03] TIR
2 MOUNTING SURFACE TO BE FLAT TO WITHIN .001 [0.03] TIR WITH A MIN SURFACE FINISH OF 125 [3.2]
1.) CASE MATERIAL-STAINLESS STEEL
4
3
[

2X 10-32 UNF - 2B .17 10-32 UNF - 2B
     
.210 .024 5.33

.330 [8.38]
6 .54 [13.7]
KAPTON TAPE
 .500 [12.70]
MODEL 084A03
IMPACT CAP
MATERIAL: 17-4 PH H900
(SUPPLIED)

.498 [12.65]
ELECTRICAL CONNECTOR
COAXIAL 10-32 UNF-2A
3
]

4.2
.61
.28 [7.0]
STANDARD MOUNTING
HOLE PREPERATION
INTEGRAL SEALED CABLE 7
Ø.159 [4.04]
10-32 UNF - 2B
.31 [7.8]
UNLESS OTHERWISE SPECIFIED TOLERANCES ARE:
DIMENSIONS IN INCHES
DECIMALS XX ±.01
XXX ±.005
ANGLES  2 DEGREES
FILLETS AND RADII
.003 - .005
2
REV
F UPDATED DRAWING PER MAIN ASSEMBLY UPDATE
MODEL 081B05
MOUNTING STUD
10-32 UNF - 2A
.33 [8.3]
TYPICAL BOTH ENDS
(2 SUPPLIED)
2
METRIC MOUNTING
4
HOLE PREPERATION

.23 [5.8] MIN Ø.199 [5.05]
 .15 [3.8] MIN
M6 X 1.00-6H
DRAWN CHECKED
DIMENSIONS IN MILLIMETERS
KRM 7/20/18 KRM 7/20/18
[ IN BRACKETS ]
TITLE
DECIMALS X ± 0.3
XX ± 0.13
INSTALLATION DRAWING
ANGLES  2 DEGREES
GENERAL PURPOSE
FORCE SENSOR
FILLETS AND RADII
0.07 - 0.13
2
1
REVISIONS
DESCRIPTION DIN
48247
MODEL M081A62
MOUNTING STUD
B
10-32 UNF - 2A BY
M6 X 1.00 - 6g
TYPICAL BOTH ENDS
(2 SUPPLIED)
2
4
 .30 [7.6] MIN

.25 [6.4] MIN
A
ENGINEER A
DRK 7/20/18
3425 WALDEN AVE. DEPEW, NY 14043
(716) 684-0001 E-MAIL: sales@pcb.com
DWG. NO.
CODE
8561
IDENT. NO.
52681
SCALE: 2.5X SHEET 1 OF 1
