Summary of Contents for Young Electric Mate
- Page 2 Parts 0 15 0 17 0 18...
-
Page 3: Parts List
Parts List Requied Tools（Not included） Part# Description Name Imperial Metric Rotating Group Monkey Wrench 12’’ 300mm Bottom Fixing Bracket Open Wrench 7/16’’ 11mm M16x85 Hexagon Bolt Open Wrench 11/16’’ 17mm M16 Lock Nut Beam Assembly Front Wheel Holder M10*20 Hex Bolt M10*120 Outer Hex Bolt M10 Lock Nut Middle Support Tube... - Page 4 figure to eliminate the gap between the Bottom fixing bracket (2) STEP1 and the Rotating Group(1). Note: Do not overtighten the bolts to prevent Bottom Fixing Bracket (2) and Rotating Group (1) components from rotating easily. Align the Bottom Fixing Bracket(2) with the hole of the Rotating Group (1), insert the M16*85 Outer Hexagon Bolt (3), and then screw on the M16 Lock Nut (4).
- Page 5 STEP2 STEP3 Align the holes from Front Wheel Holder (6) and Beam Assembly Place the components assembled in steps 2 above into the (5). Then fix them with M10*20 Hex Bolt (7). Bottom Fixing Bracket (2), align the holes, install 4pc M10*120 Outer Hexagon Bolt (8) and 4pc M10 Lock Nut (9), and tighten the bolts.
- Page 6 STEP4 STEP5 50Nm Insert Middle Support Tube (10) into the base of Bottom Fixing Install the adjustable Connecting Block (12) to the Middle Bracket (2), then fix them with M10x60 Bolt (11) and M10 Lock Support Tube (10), then tighten the knob from the Connecting Nut (9).
- Page 7 STEP6 The diameter of lock beam should be less than 7mm. The lock is not included. 2" Align the holes of the folding tube with the holes on the vehicle’s 2’’ hitch receiver, then connect the two parts as shown below. Place an M16 Shockproof Bolt (16), through the φ16 Spring Washer (17), φ16 Flat Washer (18) and the aligned holes.
-
Page 8: Folding Steps
Folding Steps ∶ · ∴ ∷... - Page 9 Bike Installation Instructions Snap the front tire of the ebike into the fixed frame, place the rear tire in the beam, and then use the ratchet wheel straps to fix the front wheel, rear wheel, and seat tube of the bicycle as shown in the figure below. It should place the first bike or a bike to the side which is close to the vehicle.
- Page 10 How to Adjust the Wheel Cradle 1.Pull the cam gear 2.Turn in counterclockwise 3.Slide it 4.Until it against the tire 5.Turn it tighten by clockwise 6.Press it down...
-
Page 11: Technical Specifications
Not intended for use with mopeds, motorcycles or 3 wheels bikes Universal sized up to 5'' wide tire Model Name YOUNG ELECTRIC Mate Description 2'' Hitch 2-Bike Rack Material Aluminum & Steel Maximum Weight Capacity 200lbs Applicable Vehicles... - Page 12 ⚠ WARNINGS ⚠ Do not overload beyond the bike rack’s weight capacity of 200lbs. Do not carry more than 2 bikes on the carrier. The bike rack is not intended for transporting humans or animals. If you are planning to load only one bike, it is recommended to place it in the position closest to the vehicle. ...
-
Page 13: Get Support
Young Electric) is a purchaser’s exclusive remedy under this Young Electric Warranty Policy warranty. Young Electric is committed to providing our customers with a quality shopping experience, for the products we sell, we provide Young Electric shall not be liable for any direct, indirect,...
