WMF coffeemachines

WMF 1200 F planning information

Optional feet

(60mm/

100 mm

(incl. Cover cap)

(Optional: jug tray right side / thermos container and vending unit not combinable)

With automatic post brewing function

Optional feet

(60mm/

100 mm

http://www.wmf-kaffeemaschinen.de/fachplaner

WMF Group GmbH | Eberhardstraße 35 | 73312 Geislingen (Steige)

Optional: vending unit

Coin Checker 105 mm

Optional: jug tray and

thermos container 2.4L

Jug tray and thermos

container 2,4 liters

Optional: pipe for grounds

disposal 70 x 120 x 250

mm (extension with

second pipe possible)

Optional: cut-out 60x80 mm for lines and hoses

(water, waste water, power) 3kW min. Ø 50

Optional: cut-out for

grounds through counter

On site

(Angle valve)

3x1,5mm

Length 1m

On site

Page 1 (water, waste water, power) 3kW min. Ø 50 Jug tray and thermos container 2,4 liters Optional: cut-out for grounds through counter Optional feet (60mm/ 100 mm On site (Angle valve) 3x1,5mm Length 1m On site http://www.wmf-kaffeemaschinen.de/fachplaner WMF Group GmbH | Eberhardstraße 35 | 73312 Geislingen (Steige)
Page 2 For operating, service, and safety reasons the machine should be installed with a clearance from Clearance the building or non-WMF components of not less than 50 mm at the sides and 60 mm at the back. A minimum working space of 800 mm in front of the coffee machine is recommended.
Page 3 For connection from below through the counter a cut-out must be made in the hatched area on-site according to drawing (see top view). For drinking water with carbonate hardness above 5°dKH (carbonate hardness), a WMF water filter should be fitted upstream.
Page 4 For more information as the instruction manual , safety data sheets and certificates , see: http://www.servicecenter.wmf.de/ All information refers to coffee machines/ equipment as standard version. Individual solutions can differ from the standard version. http://www.wmf-kaffeemaschinen.de/fachplaner WMF Group GmbH | Eberhardstraße 35 | 73312 Geislingen (Steige)
