- Page 1 PNEUMATIC COIL ROOFING NAILER 5 Year Limited Warranty READ ALL INSTRUCTIONS BEFORE FIRST USE. KEEP THIS MANUAL FOR FUTURE REFERENCE. KEEP AWAY FROM CHILDREN. WEAR CSA APPROVED WEAR EAR WEAR A EYE PROTECTION PROTECTION FACE MASK...
-
Page 2: Product Specifications
PRODUCT SPECIFICATIONS PNEUMATIC COIL ROOFING NAILER Maximum working pressure 120 PSI Air inlet size 1/4" NPT Activation mode contact actuation Round Head Roofing Nails 3/4” to 1-3/4” Fastener Type Long, flat wire welded Magazine Capacity 120pcs Magazine angle 15° Working pressure 70-110 PSI Recommended hose 1/4"... -
Page 3: Table Of Contents
1282 309 PNEUMATIC COIL ROOFING NAILER TABLE OF CONTENTS Product Specifications ................... 1 Table of Contents ................... 2 Safety Guidelines ..................3-6 Symbols ....................... 7 Tool Specific Warnings .................. 8 ............. 9 Know Your Pneumatic Coil Roofing Nailer ............... 10-14 Assembly and Operating ................... -
Page 4: Safety Guidelines
SAFETY GUIDELINES WARNING: This manual contains information that relates to PROTECTING PERSONAL SAFETY and PREVENTING EQUIPMENT PROBLEMS. It is very important to read this manual carefully and understand it thoroughly before using the product. The symbols listed below are used to indicate this information. DANGER! Potential hazard that will result in serious injury or loss of life. -
Page 5: Symbols
1282 309 PNEUMATIC COIL ROOFING NAILER SYMBOL MEANING • Risk of inhalation: Never directly inhale the air produced by the compressor. • Risk of bursting: Do not adjust the pressure switch or safety valve for any reason. They have been pre-set at the factory for this compressor’s maximum pressure Tampering with the... - Page 6 WARNING! • Do not allow unskilled or untrained individuals to operate the air tool. • Do not use the tool for any task other than that it is designed to perform. • Locate the compressor in a well-ventilated area for cooling, and a minimum of 12”...
- Page 7 1282 309 PNEUMATIC COIL ROOFING NAILER CAUTION! • Disconnect tool from the air supply and turn o the compressor before performing any maintenance or changing accessories, when clearing a jammed fastener, when the tool is not in use, when it is being handed to another person, and when it is left unattended.
-
Page 9: Tool Specific Warnings
1282 309 PNEUMATIC COIL ROOFING NAILER TOOL SPECIFIC WARNINGS DANGER Potential hazard that will result in serious injury or death. • Do not disconnect or reconnect the air hose with the tool pressed or with a fastener in the guide. The tool may fire when it is reconnected to the air supply. -
Page 10: Know Your Pneumatic Coil Roofing Nailer
KNOW YOUR PNEUMATIC COIL ROOFING NAILER Exhaust vent Air quick coupler Trigger Depth adjustment wheel Coil Magazine Canister latch Guide base... -
Page 11: Assembly And Operating
1282 309 PNEUMATIC COIL ROOFING NAILER ASSEMBLY AND OPERATING Acceptable Fasteners WARNING: The use of any other types of fasteners will cause the tool to jam. Failure to comply could lead to serious injury or loss of life. Nail length: ¾-1-3/4”; Magazine capacity: 120pcs Description / Features •... - Page 12 Air Compressor 1 1/2–2 HP 2 1/2 HP 3+ HP Size & Power Light duty and Light duty and Light duty and 4 - 5 Gallons intermittent use intermittent use intermittent use Light duty and Medium duty and Medium duty and 6 - 11 Gallons intermittent use intermittent use...
- Page 13 1282 309 PNEUMATIC COIL ROOFING NAILER PREPARING THE TOOL FOR USE Please read and observe these operating instruction before using the tool. Basic safety measures should always be strictly followed to protect against damage to the equipment and personal injury to the user or other people working in the vicinity of operation.
- Page 14 fig C fig D Insert a strip of nails into the coil magazine. Ensure the points of the nails are facing down. Be sure to insert the heads of the nails into the channel. Close the coil magazine and push close the magazine latch (1) until it locks into place. The tool is now ready for use (fig C).
- Page 15 1282 309 PNEUMATIC COIL ROOFING NAILER WARNING: Avoid triggering the fastener driving tool if the magazine is empty. Any defective or improperly functioning fastener driving tool must immediately be disconnected from the compressed air supply and passed to a specialist for inspection.
-
Page 16: Maintenance
MAINTENANCE Note: Do not store the tool anywhere temperatures will fall below freezing. DANGER! Disconnect the tool from the air compressor before maintenance/service, adjusting, cleaning jams, reloading, and when it is not in use. Repairs must be performed by a qualified service technician only. - Page 17 1282 309 PNEUMATIC COIL ROOFING NAILER SYMPTOM POSSIBLE SOLUTIONS Blade driving 1. Worn bumper 1. Replace bumper fastener too deep. 2. Air pressure is too high. 2. Adjust the air pressure. Tool does not 1. Inadequate air supply. 1. Verify adequate air supply.
-
Page 18: Exploded View
EXPLODED VIEW... -
Page 19: Parts List
1282 309 PNEUMATIC COIL ROOFING NAILER PARTS LIST WARNING: When servicing, use only original equipment replacement parts. The use of any other parts may create a safety hazard or cause damage to the tool. Any attempt to repair or replace electrical parts on this tool may create a safety hazard unless repairs are performed by a qualified technician. - Page 20 Key # Part # Part Name Quantity 03.04.02.155 Guard 03.04.08.199 Nose 03.04.17.144 Nose guard 03.04.05.023 Bolt M5x25 03.04.36.295 Safety shelf spring 03.04.05.372 Bolt M5x16 03.04.05.738-01 Nut M5 03.04.39.04.058 Safety shelf assembly 03.04.19.236 Washer d=5 Gun body grip 03.04.29.230 End cover washer 03.04.07.152 03.04.11.097-03 End cover...
- Page 21 1282 309 PNEUMATIC COIL ROOFING NAILER Key # Part # Part Name Quantity 03.04.05.403 Bolt M5x10 03.04.24.032 Feeder spring Feeder 03.04.33.018 Feeder pin 03.04.31.135 Feeder case 03.04.29.222 03.04.29.223 Movable cover case 03.04.31.136 Movable cover pin 03.04.29.180 Adjust knob 03.04.36.296 Adjust spring 03.04.05.736...
- Page 22 Key # Part # Part Name Quantity 03.04.32.164 Guide base 03.04.05.404 Bolt M5x14 03.04.17.148 Shingle guide 03.04.05.408 Bolt M5x22...
-
Page 23: Warranty
WARRANTY BENCHMARK WARRANTY If this Benchmark tool fails due to a defect in material or workmanship within five years from the date of purchase, return it to any Home Hardware store with the original bill of sale for exchange. 3-year warranty for the battery and charger. This warranty does not include expendable parts including but not limited to blades, brushes, belts, light bulbs. - Page 24 PNEUMATIC COIL ROOFING NAILER *5 year limited warranty on tool 1282 309 BENCHMARK TOOLS CANADA Made in China ST. JACOBS, ONTARIO N0B 2N0 © 2021 Home Hardware Stores Limited CUSTOMER SERVICE/TECH SUPPORT 1-866-349-8665 * This Benchmark product carries a five (5) year LIMITED warranty against defects in workmanship and materials.
