- Page 1 DS-3WF03C User Manual DS-3WF03C User Manual...
- Page 2 INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA OR DOCUMENTATION, IN CONNECTION WITH THE USE OF THIS PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS.
- Page 3 DS-3WF03C User Manual Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
- Page 4 DS-3WF03C User Manual Applicable Models This manual is applicable to switches below: DS-3WF03C (product series). Symbol Conventions The symbols that may be found in this document are defined as follows. Symbol Description Provides additional information to emphasize or supplement important points of the main text. Indicates a potentially hazardous situation, which if not avoided, could result in equipment damage, data loss, performance degradation, or unexpected results.
-
Page 5: Table Of Contents
DS-3WF03C User Manual Catalog Chapter 1 Introduction ....................... 5 1.1 Overview ..........................5 1.2 Packing List ..........................5 1.3 Appearance ..........................5 1.3.1 Front Panel ........................5 Chapter 2 Installation ......................... 8 Chapter 3 Quick Configuration ....................10 3.1 Log in ............................10 3.2 Wizard ............................ -
Page 6: Chapter 1 Introduction
DS-3WF03C User Manual Chapter 1 Introduction 1.1 Overview DS-3WF03C wireless bridge can be applied in industries, such as wireless video surveillance, railway, transportation, power and other industries, wireless video/data transmission, wireless coverage, carrier wireless backbone network construction, Wi-Fi wireless coverage, rural information construction, and wireless network coverage. - Page 7 DS-3WF03C User Manual Front Panel of DS-3WF03C Figure 1-1 DS-3WF03C Front Panel Indicator Indicators are used to monitor the status of the DS-3WF03C. See the following table for the description of the indicators. Figure 1-2 Indicators...
- Page 8 DS-3WF03C User Manual Table 1-2 Indicator Description Indicator Description Power indicator. If the green light is steady on, it indicates that the power is on. Network connection light. The light indicates there is one IPC or other network device connects to the LAN port of PoE adapter. Blinking means sending data.
-
Page 9: Chapter 2 Installation
DS-3WF03C User Manual Chapter 2 Installation Step 1 Select the unobstructed high point around the device to ensure that the devices are aligned and there is no obstruction in the middle. Fix the device as shown in the figure below. Attach the back of the device to the pole, use the hoop to pass through the hoop hole on the back of the device, tighten the hoop, and fix the device on the pole. - Page 10 DS-3WF03C User Manual Figure 2-2 Power on the device Step 3 The schematic diagram of the installation of the device is as follows. Figure 2-3 Finish installation...
-
Page 11: Chapter 3 Quick Configuration
DS-3WF03C User Manual Chapter 3 Quick Configuration This chapter describes how to configure the device quickly. 3.1 Log in To log in the device, user needs to configure the TCP/IP of your computer first as the following steps: Step 1 Use a network cable to connect the computer to the LAN interface of the device or PoE power supply to prepare the device. - Page 12 DS-3WF03C User Manual Step 3 Double-click Internet Protocol Version 4 (TCP/IPv4). As shown below. Figure 3-3 Internet Protocol Version 4 (TCP/IPv4) Step 4 Configure the IP address of the computer to be the unused 192.168.1.X address in the LAN. X is any integer other than 36 in 2 to 253. The subnet mask is 255.255.255.0. Click "OK" as shown below.
-
Page 13: Wizard
DS-3WF03C User Manual Make sure that the IP address of the computer is inconsistent with the default IP address of the device. On the same network segment, use a browser to log in to the device, open a browser, and enter the default IP address of the device in the address bar: 192.168.1.36. - Page 14 DS-3WF03C User Manual Figure 3-6 Wizard – Network Step 2 Go to the “Wireless” page. The device can modify the wireless parameters such as network name, frequency, and key through this page. The default wireless mode of the device is the Station. The default network name of the device is Wireless.
-
Page 15: Chapter 4 Status
DS-3WF03C User Manual Chapter 4 Status Status shows the current configuration and real-time monitoring of the device. This page is divided into 2 parts: Status and Monitor. 4.1 Status The status page is shown in the following Figures： Figure 4-1 Status-Station Figure 4-2 Status-AP All the configurations in Status page is shown in Table 4-1. - Page 16 DS-3WF03C User Manual communication protocol WAN IP WAN IP address Distance The distance between two associated devices WAN MAC MAC of the WAN port CCQ/Noise Floor CCQ: Client link quality, the general recommended value of 90% or more, when the CCQ shows less than 90%, the user may consider to take the appropriate method to improve...
-
Page 17: Monitor
DS-3WF03C User Manual 4.2 Monitor The Monitor page is shown below: Figure 4-3 Monitor Throughput: The figure here monitors the real-time throughput of the ETH0 port (the LAN port of the PoE power supply) and the ETH1 port (the LAN port of the device). Interfaces: Device interface MAC address, MTU, IP, RX Bytes, RX Errors, TX Bytes, and TX Errors. -
Page 18: Chapter 5 Tdma
DS-3WF03C User Manual Chapter 5 TDMA Currently, most of the outdoor bridge products are developed based on 802.11 protocols, however, it has the limitations of short-distance, hidden node problems, and poor point-to-multi-point performance. VTrans technology utilizes a series of advanced technologies such as TDMA, 20 M/40 MHz bandwidth support, intelligent rate control, Auto ACK Time-out Adjust, having the advantage of long transmission range, high date rate and robust transmission. -
Page 19: Chapter 6 Wireless
DS-3WF03C User Manual Chapter 6 Wireless Wireless is shown in the following figure: Figure 6-1 Wireless-AP Figure 6-2 Wireless-Station Wireless Mode: There are totally 4 wireless modes, including: Station, Access Point, WDS Station, and WDS Access Point. - Page 20 DS-3WF03C User Manual Access Point: Access point. Station: A client device that can be connected to an AP. WDS Station: Use WDS feature to link multiple APs in a network, all associated stations from any AP can communicate with each other like in ad-hoc mode. WDS station means this device is a station in WDS mode.
-
Page 21: Chapter 7 Network
DS-3WF03C User Manual Chapter 7 Network 7.1 Bridge mode In Bridge mode, there is no WAN port. The LAN port of the PoE adaptor, and the LAN port of the device can all be the LAN port, and the user can choose one of them to use as LAN port. Figure 7-1 Bridge mode 7.2 Management The IP address of the device can be modified, and the management of the device can be... -
Page 22: Ip Aliases Settings
DS-3WF03C User Manual The firewall is enabled, the default rule of the firewall is Accept, the destination of the IP address filtering is Deny, the interface eth0, the IP type IP, the source IP/mask 192.168.1.100/32, and other values are null. 2. - Page 23 DS-3WF03C User Manual Ingress traffic entering ath0, control the input rate Egress traffic exiting ath0, control the output rate The relationship of rate and burst for ingress: Set burst to 0, the rate of ingress is unlimited ...
-
Page 24: Vlan Settings
DS-3WF03C User Manual 7.7 VLAN Settings The VLAN function allows user to create multiple virtual local area network. As show below, we add a VLAN on port ath0. The VLAN ID is 10. The range of VLAN ID is 2~4094. Each VLAN ID represents a different VLAN. -
Page 25: Chapter 8 Advanced
DS-3WF03C User Manual Chapter 8 Advanced The Advanced pages are shown below. Figure 8-1 Advanced-STA Figure 8-2 Advanced-AP Auto ACK-Timeout Adjust: It is suggested to enable this function, so that the distance between 2 DS-3WF03C devices can be detected and all the related parameters can be optimized to achieve the best link quality. - Page 26 DS-3WF03C User Manual When the equipment is found by wireless way, please keep multicast support enabled. Client Isolation: Enable this feature can make connection with an access point, the WDS access points equipment cannot communicate with each other, even though the client IP duplicate nor of communication have any impact (only the access point page is displayed).
-
Page 27: Chapter 9 System
DS-3WF03C User Manual Chapter 9 System System page is shown in Figure 9-1, and it is divided into the following 4 parts: Configuration Management, Firmware Configuration, Device Setting, and Accounts Information. Figure 9-1 System Backup configuration: When clicking Download button, the current configuration can be backed up to a file. -
Page 28: Chapter 10 Tools
DS-3WF03C User Manual Chapter 10 Tools The Tools page is shown in Figure 10-1. Figure 10-1 Tools... - Page 29 DS-3WF03C User Manual Ping IP: User can input the destination IP address of another device, and click Ping button. If that destination device is successfully connected to the DS-3WF03C device, the result shows Alive, otherwise shows Not Alive. Time to Reboot: Timing restart equipment. NTP: If this NTP server is set, and the DS-3WF03C device can access to this NTP server.
- Page 30 DS-3WF03C User Manual Figure 10-2 Antenna Calibration 5G When the bar graph shows the signal strength is higher than 60, said the signal strength is poor, it is recommended that users adjust the equipment to ensure that the two devices antenna angle is the best.
-
Page 31: Chapter 11 Logout
DS-3WF03C User Manual Chapter 11 Logout When you click logout button, the web will quit and return to the login web. Figure 11-1 Logout... - Page 32 DS-3WF03C User Manual...
