Page 1
Call Customer Service, Toll-Free: 877-728-8224 Important: This manual contains information for the safety Visit us on the web! of persons and property. Read it carefully before www.brinly.com assembly and operation of the equipment! English Manual 1020337EN-A...
INTRODUCTION AND SAFETY ================================================================================================== CONGRATULATIONS on your new Brinly-Hardy purchase! This accessory has been designed, engineered and manufactured to give you the best possible dependability and performance. Should you experience any problem you cannot easily remedy, please do not hesitate to contact our knowledgeable customer service department toll-free at 1-877-728-8224.
Page 3
SAFETY ================================================================================================== WARNING AVOID INJURY FROM EXPLOSION • Do not place gas container in cart when filling RIDERS CAN FALL OFF AND BE KILLED • No riders in cart B-7084 GENERAL SAFETY NOTES ( Operation ) Caution should be taken when towing and/or using any attachment. This attachment combined with the weight distribution, turning radius, and speed of towing vehicle can result in severe injury or death to operator, damage to towing vehicle, and/or attachment if not used properly.
Page 4
Please call our Customer Service Department, Toll Free: 877-728-8224 • Do not carry passengers. or customerservice@brinly.com • Do not let anyone, especially children, ride in/on this attachment, the towing vehicle or hitch bracket. • Riders are subject to injury such as being struck by foreign object and/or being thrown off during sudden starts, stops and turns.
Page 5
PART LIST ================================================================================================== Ref. Part # Description Qty. 1020336SER Cart Bed; Poly RPC-10BH-A 1020374 Draw Bar; Poly Cart B-4261 Axle, 3/4" x 34-3/4" B-4599-10 Axle Support 1008575 Wheel; Pneumatic 1018697-10 Right Pivot Arm 1018698-10 Left Pivot Arm 1019851 INNER PACK #1...
Page 8
HARDWARE IDENTIFIER ================================================================================================== DO NOT RETURN PRODUCT IF YOU ARE MISSING PARTS. Illustrations on this page Please Call: 1 (877) 728-8224 are to scale for faster identification of hardware during assembly. Hardware Skin Pack Z-1737 Contents of this page can be found in: Washer: Lock 5/16”...
Page 9
HARDWARE IDENTIFIER ================================================================================================== DO NOT RETURN PRODUCT IF YOU ARE MISSING PARTS. Illustrations on this page Please Call: 1 (877) 728-8224 are to scale for faster identification of hardware during assembly. Hardware Bag 1020338 Contents of this page can be found in: Nut: Hex Head Washer: Lock 5/16”...
NOTE: There will be a few extra /unnecessary pieces of hardware in the skinpack. - Scan this QR code or visit our website for additional info and videos: brinly.com Step 1 Install Lock Bracket Skin Pack Panel 2 1.
Page 11
ASSEMBLY ================================================================================================== Step 2-A 1. Align the cart foot pedal (3) through slot in drawbar (4) with the notch in the foot pedal oriented towards the raised tongue on the drawbar. See illustration. 2. While holding the foot pedal (3) in place, flip the drawbar (4) over.
Page 12
ASSEMBLY ================================================================================================== Step 2-C Skin Pack Panel 3 Continue running the 3/8 x 3-3/4 in. bolt (28) through the foot pedal (3). Between the foot pedal (3) and drawbar, add one 3/8 in. keps nut (27) to the bolt (28) as illustrated. Finally, run the end of the bolt (28) through the other side of the drawbar (4).
Page 13
ASSEMBLY ================================================================================================== Step 3 Skin Pack Panel 4 Hook one end of the latch spring (31) through the small hole at the base of the foot pedal (3). Hook the other end of the latch spring (31) through the drawbar (4) as illustrated. Step 4 Install Clevis Skin Pack Panel 5...
Page 14
ASSEMBLY ================================================================================================== Step 5 1. Align and start running the axle (6) through the first three slots of the Axle Support (7). 2. Center the drawbar (4) as illustrated here. 3. Continue to run the axle (6) through the rest of the Axle Support (7).
Page 15
ASSEMBLY ================================================================================================== Step 7-B 1. Align holes of the Right Pivot Arm (9) with the Axle support (7) as illustrated here. NOTE: Hook of the Pivot Arm (9) will face Right toward center of the cart. Pivot Axle Hardware Bag Support 2.
Page 16
ASSEMBLY ================================================================================================== Step 7-D 1. Temporarily slide the rocker base (11) into the slots of the pivot arms (9) and (10). See Illustration. Step 7-E 1. Tighten the four 5/16” nuts (37) from Steps 7-B and 7-C. 2. Remove the rocker base (11) from the assembly (this will be used on step 9-B, page 17).
Page 17
ASSEMBLY ================================================================================================== Step 9-B Skin Pack Panel 1 1. Add a Flat Washer (22) to four of the 5/16" Screws (29) and align the Rocker Base (11) as illustrated. From the inside of the cart bed, run these screws through the cart and rocker.
Page 18
ASSEMBLY ================================================================================================== Step 10-B 1. Lift the Motion Bracket (13) up and over the first set of extended arms of the Base Plate (11). 2. Align the two holes of these two parts as illustrated. Step 10-C Hardware Bag 1. Slide the two 3/8” bushings (40) in place as illustrated.
Page 19
ASSEMBLY ================================================================================================== Step 11 Hardware Bag 1. Align the Rocker Handle (14) with the square holes of the Rocker Motion Bracket (13) as illustrated here. 2. Add last two 5/16" x 1" Carriage Bolts (37) from beneath the Rocker Motion Bracket (13), through the handle (14) and secure in place with a 5/16 in.
Page 20
ASSEMBLY ================================================================================================== Step 13-A 1. Slide the pivot arms (9) and (10) into the slots of the rear pivot brackets (15). See Illustration. Step 13-B Hardware Bag 1. Attach both Pivot Arms (9 and 10) to the Pivot Brackets (15) with a 3” Hex Head Bolt (39) and 3/8”...
USE AND CARE ================================================================================================== MODEL: R P C - 1 0 B H - A R O G E R P O L Y C A R T SPECIFICATIONS INSTALLING CAUTION: Avoid injury! Before installing cart, make sure the Cart Bed Capacity . . . 10 cu ft dump levers are locked in place.
Page 22
USE AND CARE ================================================================================================== UNLOADING ROGER CART CAUTION: Avoid injury! • Before dumping cart, park machine safely. • Before backing up, make sure the area is clear of bystanders, especially children. • Make sure cart is installed to the towing machine. •...
Page 23
USE AND CARE ================================================================================================== UNLOADING ROGER CART , continued Step 3. Unloading Cart Pull the lever (14) labeled “Pull” and continue to guide the range of motion, flipping the bed of the cart toward an 180º unload. Step 4. Returning Cart to Transport Step 5.
Page 24
USE AND CARE ================================================================================================== MAINTENANCE DETERMINING WEIGHT FOR CART • The key to years of trouble- free service is to keep your CAUTION: Avoid injury! Cart clean and dry. Excessive towed load can cause loss of traction • After the first 30 minutes of and loss of control on slopes.
Page 25
D.I.Y. DIRECTIONS FOR CUSTOM-BUILT SIDE STAKES SAFETY NOTES: • Read and follow the operating instructions for your machine and your Brinly Poly Cart. • Do not load material higher than the top of the stake side rails. • Do not use the stake side rails to increase the weight capacity of your cart.
Page 26
USE AND CARE 8” 8” 13-1/2” ================================================================================================== 13-1/2” 3-3/4” 3-3/4” DIY: DIRECTIONS FOR CUSTOM-BUILT SIDE STAKES, Continued 9/32 Diameter 9/32 Diameter 2” 2” Step 1. Step 2. Drill two 9/32" holes in each 13-1/2" side Drill two 9/32" holes in each of the stake (1), located as illustrated here.
Customer Service department: replace a regular cotter pin for an extra-strong, In North America and Canada call convenient upgrade. Toll-Free: 877-728-8224 Chat online: www.brinly.com - Diameter: 1/2” Email: customerservice@brinly.com - Pin Length: 3” ONLINE: BRINLY.COM...
MANUFACTURER’S LIMITED WARRANTY CARTS The limited warranty set forth below is given by Brinly-Hardy Company with respect to new merchandise purchased and used in the United States (its possessions and territories) and Canada. Brinly-Hardy Company warrants the products listed below against to use this product.
