Brinly FDK-10BH Kit Instructions

180º dump conversion kit 10p cart
Hide thumbs

Advertisement

Quick Links

Download this manual
K I T I N S T R U C T I O N S
1 8 0 º D U M P C O N V E R S I O N K I T
1 0 P C A R T
F D K - 1 0 B H
Compatible with 10P Cart Models:
PCT-100BH, PCT-101BH & PCT-100JD
Visit us on the web!
www.brinly.com
English Manual
Call Customer Service, Toll-Free: 877-728-8224
Important: This manual contains information for the safety
of persons and property. Read it carefully before
assembly and operation of the equipment!
1
English, Spanish &
French Manual
1018671-B

Advertisement

loading
Need help?

Need help?

Do you have a question about the FDK-10BH and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Brinly FDK-10BH

Summary of Contents for Brinly FDK-10BH

  • Page 1 PCT-100BH, PCT-101BH & PCT-100JD Call Customer Service, Toll-Free: 877-728-8224 Important: This manual contains information for the safety Visit us on the web! of persons and property. Read it carefully before www.brinly.com assembly and operation of the equipment! English Manual 1018671-B...

  • Page 2: Table Of Contents

    INDRODUCTION ================================================================================================ CONGRATULATIONS on the purchase of your new Brinly-Hardy Roger 180º Dump Kit! This accessory has been designed, engineered and manufactured to give you the best possible dependability and performance. Should you experience any problem you cannot easily remedy, please do not hesitate to contact our knowledgeable customer service department toll-free at 1-877-728-8224.

  • Page 3: Hardware Identifier

    HARDWARE IDENTIFIER ================================================================================================ TEAR OUT THIS PAGE Illustrations on this page are to-scale for identification of hardware during assembly. Tear out this page for quick reference. Simply lay the hardware directly on top of the illustrations below to verify you’re using the correct parts. Exterior circumferences of the washers can Bushing: Hex Head vary.

  • Page 4: Part List

    - - - - - - - - - - - - - - - - - - - - - - - Please contact our Customer Service department: • 1/2” Wrench Call, Toll-Free: 877-728-8224 • 9/16” Wrench & Ratchet • Flathead Screwdriver Chat online: www.brinly.com • Drill (5/16" Bit included with kit) • Gloves Email: customerservice@brinly.com English Manual 1018671-B...

  • Page 5: Assembly

    STEP 1 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - BRINLY.COM An assembly video and Tear out the Hardware Identifier additional info for this kit is (page 3) for a faster assembly time.
  • Page 6 ASSEMBLY ================================================================================================ STEP 3-A - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Find this hardware: - x4 Round Head Screws (20) 5/16”...
  • Page 7 ASSEMBLY ================================================================================================ STEP 3-B (Drilling) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Find the provided Drill Bit (23). Using the remaining circular holes of the rocker plate (1) as a template, drill four...
  • Page 8 ASSEMBLY ================================================================================================ STEP 4 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Find this hardware: - x4 Screws; Round Head (20) - 5/16” x 1" - x4 Washer;...
  • Page 9 ASSEMBLY ================================================================================================ STEP 5-A (Continued) - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Beneath the cart A-frame, start to add two 5/16"...
  • Page 10 ASSEMBLY ================================================================================================ STEP 5-C - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Aligning the Pivot Arms Temporarily slide the rocker base (1) into the slots of the pivot arms (2) and (3).
  • Page 11 ASSEMBLY ================================================================================================ STEP 6 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Find this hardware: - x4 Screw;...
  • Page 12 ASSEMBLY ================================================================================================ STEP 7 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1.
  • Page 13 ASSEMBLY ================================================================================================ STEP 8-B - - - - - - - - - - - - - - - - - - - - - - - - Find this hardware: - x2 Bolt; Hex Head (19) 3/8" x 1 1/4" - x2 Washer;...
  • Page 14 ASSEMBLY ================================================================================================ STEP 10 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Align the bed of the cart with the rest of the assembly as illustrated here.
  • Page 15 ASSEMBLY ================================================================================================ STEP 11 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Rotate the cart bed to its' transport position by lifting it slowly back toward the A-Frame and tow bar.

  • Page 16: Operation

    OPERATION ================================================================================================ • Before dumping cart, park machine safely. • Before backing up, make sure the area is clear of bystanders, especially children. CAUTION: • Make sure cart is installed to the towing machine. Avoid injury! • Keep hands, feet and other body parts away from unloading areas and locking points to prevent injury from hauled materials or the cart itself.
  • Page 17 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Brinly-Hardy Company • 3230 Industrial Parkway • Jeffersonville, IN 47130 • (877) 728-8224...

  • Page 18: Warranty

    Hardy Co. During the period of the warranty, the exclusive remedy is repair or replacement of the product as set forth above. Brinly-Hardy Company • 3230 Industrial Parkway • Jeffersonville, IN 47130 • (877) 728-8224 • brinly.com English Manual 1018671-B...
