Si5383/84 Reference Manual
Overview
This Reference Manual is intended to provide system, PCB design, signal integrity,
and software engineers the necessary technical information to successfully use the
Si5383/84 devices in end applications. The official device specifications can be found in
the Si5383/84 data sheet.
The Si5383/84 combines the industry's smallest footprint and lowest power network
synchronizer clock with unmatched frequency synthesis flexibility and ultra-low jitter.
The three independent DSPLLs are individually configurable as a SyncE PLL or a gener-
al-purpose PLL for processor/FPGA clocking, and support digitally controlled oscillator
(DCO) mode for IEEE 1588 (PTP) clock steering applications. In addition, locking to
a 1 pps input frequency is available on DSPLL D. The DCO mode provides precise
timing adjustment to 1 part per trillion (ppt). The Si5383/84 can also be used in legacy
SETS systems needing Stratum 3/3E compliance. The unique design of the Si5383/84
allows the device to accept a TCXO/OCXO with any frequency, and the reference clock
jitter does not degrade output performance. The Si5383/84 is configurable via a serial
interface with in-circuit programmable non-volatile memory so it always powers up into
a known configuration. Programming the Si5383/84 is easy with ClockBuilder Pro soft-
ware. Factory pre-programmed devices are also available.
Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com
1
Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021
RELATED DOCUMENTS
• Si5383/84 Data Sheet
• Si5383/84 Device Errata
• Si5383-EVB User Guide
• Si5383-EVB Schematics, BOM & Layout
• IBIS models
• To download support files, go to:
16. Accessing Design and Support
Collateral
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Si5383 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Skyworks Si5383

Summary of Contents for Skyworks Si5383

  • Page 1 Factory pre-programmed devices are also available. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 2: Table Of Contents

    ......40 Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 3 11.1.1 Si5383/84 Crystal Guidelines ..... . .67 11.1.2 Si5383/84 Output Clocks ......71 Skyworks Solutions, Inc.
  • Page 4 14.2 Indirect Memory Map ......77 14.3 Si5383/84 Register Map ......78 14.3.1 Page 0 Registers Si5383/84...

  • Page 5: Scope

    • SiOCXO1-EVB User Guide Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 6: Overview

    The Si5383/84 is well suited for both traditional and packet-based network timing solutions. The Si5383/84 contains three independent DSPLLs allowing for flexible single-chip timing architecture solutions. The Si5383 contains a single DSPLL D that can be configured for 1PPS applications to lock to a 1 Hz input, requiring no additional external circuitry. Each DSPLL contains a digitally controlled oscillator (DCO) for precise timing for IEEE 1588 (PTP) clock steering applications.

  • Page 7: Functional Description

    The Si5383/84 takes advantage of Skyworks' fourth-generation DSPLL technology to offer the industry’s most integrated and flexible jitter attenuating clock generator solution. The Si5383 offers three DSPLLs and the Si5384 offers one DSPLL. Each of the DSPLLs operate independently from each other and are controlled through a common serial interface. DSPLLs (A, C, and D) all have access to any of the three inputs (IN0 to IN2), after having been divided down by the input P dividers, which are either fractional or integer.

  • Page 8: Dspll

    Note: 1. Si5383 only. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 9: Fastlock

    0x02AC[19:0] FASTLOCK_DLY_ONSW_PLLC 0x02AF[19:0] FASTLOCK_DLY_ONSW_PLLD Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 10 Note: 1. Si5383 only. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 11: Smartlock Feature

    3.2.2 Smartlock Feature When operating in 1PPS input mode, the Si5383/84 offers the Smartlock feature to achieve fast locking to 1PPS inputs. The Smartlock feature locks to 1PPS inputs in two phases. During the first phase, large adjustments are made to eliminate the majority of the frequency and phase error.
  • Page 12 Must be set before PPS_EN. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 13 NormalLock mode. Must be set be- fore PPS_EN. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 14 Must be set before PPS_EN. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 15: Dividers Overview

    • 24-bit word where Value = 2 x (Word + 1), for example Word=3 gives an R value of 8 Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 16: Modes Of Operation

    Figure 4.1. Modes of Operation Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 17: Reset And Initialization

    VDD (1.8 V) and VDDA (3.3 V) pins. VDDOx supply is not required to write the flash memory. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 18: Changing Registers While Device In Operation

    Note, however, that this procedure affects all DSPLLs and outputs on the device. For assistance in changing only certain portions of the device without affecting the other outputs while the device is operating, please contact Skyworks technical support using the link on the last page of this document.

  • Page 19: Flash Update/Programming

    CBPro software is used to generate desired project files which include input/output frequency selection, output logic formats, loop BW values and a variety of associated PLL controls and alarm settings. The CBPro project file and Si5383 EVB can be tested to verify the Si5383/84 works as intended in the application.

  • Page 20: Upgrading Flash Firmware Image Using Skyworks Tools

    “Standalone,” and then either “Intel Hex” or “Binary” format. Additionally, Register File, Settings File, RegMap and MultiProject Register Settings, if applicable, can be saved in the Si5383 Export GUIs, as well as saving the Project File and design report (text) in the ClockBuilderPro GUI .
  • Page 21 --project pathname --outfile pathname Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 22: Upgrading Firmware Image Using I C Master Routine

    Codes. Details for step 2 -4 follows. 4.3.2.1 Place in Bootloader Mode The first step to updating the Firmware Image is to put the Si5383/84 in bootloader mode. This is a two-step write process to register 0x05: • 0x05, 0x57 •...

  • Page 23: Data Sequence To Write File

    The hex file provided from CBPro should be parsed out into separate “records” that will be sent one record at a time from the I2C master to the Si5383/84. This format is similar to that used by the Intel Hex file. The most important thing is to make sure the correct I2C Address is used.

  • Page 24: Bootloader Reply Response Codes

    4.4.1 Free Run Mode Once power is applied to the Si5383/84 and initialization is complete, all three DSPLLs will automatically enter freerun mode, generat- ing the frequencies determined by the NVM. The frequency accuracy and stability of the generated output clocks in freerun mode is entirely dependent on the reference clock (REF/REFb), while the external crystal at the XA/XB pins determines the jitter performance of the output clocks.

  • Page 25: Holdover Mode

    Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 26 Must be set before PPS_EN. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 27 Must be set before PPS_EN. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 28: Clock Inputs (In0, In1, In2, In3, In4)

    Figure 5.1. DSPLL Input Selection Crosspoint Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 29: Input Source Selection

    PLLD application or PPS mode is enabled then manual clock selection must be used Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 30 Note: 1. Si5383 only. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 31: Types Of Inputs

    Pulsed CMOS mode, the corresponding bit must be set in IN_PULSED_CMOS_EN 0x0949[7:4] for Reference, IN2, IN1 and IN0. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 32: Hitless Input Switching

    0x063A[1:0] HSW_MODE_PLLC HSW_MODE_PLLD 0x073A[1:0] Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 33: Glitchless Input Switching

    When ramped clock switching is enabled, the Si5383 will very briefly go into holdover and then immediately exit from holdover. This means that ramped switching will behave the same as an exit from holdover.

  • Page 34: Fault Monitoring

    XAXB_LOS is detected. This feature can be disabled such that the device will continue to produce output clocks when XAXB_LOS is detected. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 35 Indicates LOS status of the selected PPS signal. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 36: Oof Detection

    Figure 5.6. OOF Status Indicator Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 37: Lol Detection (Standard Input Mode)

    LOL is indicated when there’s more than 10 ppm frequency difference is shown in the figure below. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 38 The settings in the table above are handled by ClockBuilder Pro. Manual settings should be avoided. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 39: Lol Detection In Pps Mode

    0x5309[7:0] before reaquisition occurs Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 40: Interrupt Pin (Intrb)

    1. DSPLL A and C do not apply to the Si5384. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 41 If LOS[0] is high, then LOS_FLG[0] and the interrupt cannnot be cleared. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 42: Output Clocks

    Figure 6.1. DSPLL to Output Driver Crosspoint Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 43: Output Terminations

    Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 44: Support For 1 Hz Output (1Pps)

    Output 5 of the Si5383/84 can be configured to generate a 1PPS clock. This is done by cascading the R5 and R6 dividers, done internal to the Si5383/84 as shown in the figure below, and easily set when using CBPro. Output 6 is still usable in this case but is limited to a frequency of 33.5 MHz or less.

  • Page 45: Performance Guidelines For Outputs

    The jitter generation of the Si5383/84 is so low that crosstalk can become a significant portion of the final measured output jitter. Some of the crosstalk will come from the Si5383/84, and some will be introduced by the PCB.

  • Page 46: Differential Outputs

    Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 47: Differential Output Common Mode Voltage Selection

    OUT5_CM 0132[3:0] OUT6_CM 013C[3:0] Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 48: Recommended Settings For Differential Lvpecl, Lvds, Hcsl, And Cml

    6.4 LVCMOS Outputs Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 49: Lvcmos Output Terminations

    1. Use of the lowest impedance setting is recommended for all supply voltages for best edge rates. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 50: Lvcmos Output Signal Swing

    6.5 Output Enable/Disable The Si5383/84 OEb pin provides a convenient method of disabling or enabling the output drivers. When the OEb pin is held high, all outputs are disabled. When held low, the outputs are enabled. Outputs in the enabled state can be individually disabled through register control.

  • Page 51: Output Disable State Selection

    LOSXAXB con- dition. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 52: Synchronous/Asynchronous Output Selection

    0102[0] User Controllable BLE_LOW Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 53 Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 54: Output Buffer Voltage Selection

    0x0133 [5:4] OUT6_VDD_SEL 0x013D [5:4] Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 55: Digitally Controlled Oscillator (Dco) Mode

    DCO range. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 56: Frequency Increment/Decrement Using Pin Controls

    Figure 7.1. Controlling the DCO Mode by Serial Interface Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 57 00 when complete. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 58: Serial Interface

    Figure 8.1. I C Device Connectivity Configurations If the serial interface is not used, pull pins SDA and SCL low. Note that the Si5383/84 is not I C failsafe upon loss of power. Applications that require failsafe operation should isolate the device from a shared I C bus.

  • Page 59: I 2 C Interface

    C Configuration The 7-bit slave device address of the Si5383/84 consists of a 5-bit fixed address plus two pins that are selectable for the last two bits as shown below. When generating an OPN, the upper 5-bits are configurable and there is even an option to create a 7-bit fixed address for applications that do not desire the A1/A0 flexibility.
  • Page 60 Figure 8.5. I C Read Operation Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 61: Field Programming

    9. Field Programming To simplify design and software development of systems using the Si5383/84, a field programmer is available in addition to the evaluation board. The ClockBuilder Pro Field Programmer supports both “in-system” programming (for devices already mounted on a PCB), as well as “in-socket”...

  • Page 62: Recommended Crystals And External Oscillators

    Figure 10.1. External Reference Connections Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 63: Performance Of External References

    Figure 10.2. XAXB Crystal Resonator and External Reference Clock Connections Although the Si5383/84 can accept an external clock signal on its XA/XB pins, for best possible jitter performance, it is strongly recommended that an approved crystal be used. There is essentially no jitter attenuation from the XA/XB pins to the output clocks and ony the best XOs will avoid a jitter penalty compared to using an approved crystal.

  • Page 64: Recommended Oscillators For The Ref / Refb Inputs

    The following registers can be used to control and make adjustments for the external reference source used. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 65: Xaxb_Freq_Offset Frequency Offset Register

    XAXB_FREQ_OFFSET is modi- fied. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 66: Crystal And Device Circuit Layout Recommendations

    • Layer 6: Low speed CMOS and ground The following figure shows the top layer layout of the Si5383/84 device mounted on the top PCB layer. The crystal area is outlined with the white box around it. In this case, the top layer is flooded with ground. Note that this layout has a resistor in series with each pin of the crystal.

  • Page 67: Si5383/84 Crystal Guidelines

    0.05 inches away. The Si5383/84 should have all layers underneath the ground shield removed.
  • Page 68 The figure below shows layer 4, is the power plane with the power routed to the clock output power pins. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 69 The figure below is the bottom layer of the board as a ground plane. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 70 Figure 11.6. Ground Plane (Layer 6) Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 71: Si5383/84 Output Clocks

    Figure 11.8. Bottom Layer Ground Flooded (Layer 3) Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 72: Power Management

    Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 73: Base Vs. Factory Preprogrammed Devices

    (see Section ). Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 74: Register Map

    14. Register Map Si5383/84 registers reside in both direct memory space and indirect memory space. Direct registers are accessed by the host via the I2C interface as detailed in Section 8.1. Indirect registers are accessed by the host via a bridge function implemented by the direct registers.
  • Page 75 8. Read data3 (0x44) from RD_DATA3 (0x36) Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 76 Write with 0 and ignore on reads Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 77: Indirect Memory Map

    Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 78: Si5383/84 Register Map

    14.3 Si5383/84 Register Map Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 79: Registers Si5383/84

    B and stored as Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 80 1 if the clock input [Ref, 2 1 0] is currently OOF. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 81 These are sticky flag versions of 0x000C. They are cleared by writing zero to the bit that has been set. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 82 Si<Part Num Base><Grade>-<Device Revision><OPN ID>-<Temp Grade><Package ID> Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 83 ClockBuilder Pro project file. Si5383A-B-GM. Applies to a “base” or “blank” OPN device. Base devices are factory pre-programmed to a specific base part type (e.g., Si5383 but exclude any user-defined frequency plan or other user-defined operating characteristics selected in ClockBuilder Pro.
  • Page 84 1: A rising edge will cause an fre- quency increment. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 85 This is the LOS_VAL_TIME. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 86 ClockBuilder Pro calculates the correct LOS register clear threshold value for Input 1, given a particular frequency plan. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 87 0x0044 OOF3_DIV_SEL 0x0045 OOFXO_DIV_SEL Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 88 255 = 510 ppm Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 89 (1+ value) x 1000 ppm Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 90 OOF2_RATIO_REF 0x0065 25:24 OOF2_RATIO_REF Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 91 OOF needs a frequency reference. ClockBuilder Pro provides the OOF register values for a particular frequency plan. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 92 Note: 1. Si5383 only. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 93 1. Selects the measurement time in a slow LOL detection window. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 94 Values are in ppm. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 95 The following are the thresholds for the value that is placed in the four bits for DSPLLs. ClockBuilder Pro sets these values. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 96 Note: 1. Si5383 only. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 97 1. Standard Input Mode Only Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 98 1. Extension length added to fast-lock timer value. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 99: Registers Si5383/84

    0x012B OUT5_OE 0x0130 OUT6_OE Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 100 0x012C OUT5_DIS_STATE 0x0131 OUT6_DIS_STATE Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 101 3: DSPLL D 0x0133 OUT6_MUX_SEL Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 102 10: 2.5V 11: Reserved Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 103 10: 2.5V 11: Reserved Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 104 1: All drivers powered down. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 105: Registers Si5383/84

    32-bit Integer Number 0x020E-0x0211 Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 106 Registers while Device in Operation are followed. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 107 1. FINC or FDEC step size value. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 108 DESIGN_ID6:0x 00 DESIGN_ID7: 0x00 Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 109 ClockBuilder Pro project file. Si5383B-D-GM Applies to a "base" or "non-custom" OPN device. Base devices are factory pre-programmed to a specific base part type (e.g., Si5383 but exclude any user-defined frequency plan or other user-defined operating characteristics selected in ClockBuilder Pro).
  • Page 110 Note: 1. Si5383 only. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 111 Note: 1. Si5383 only. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 112 0x02B9 LC_FLG 1: Alarm Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 113 Calculated by CBPro. (IN4) Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 114: Registers Si5383/84

    0x0320 23:16 0x0321 31:24 Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 115 FINC/FDEC masks. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 116 44-bit Integer Number 0x033B-0x0340 Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 117: Registers Si5383

    The loop Bandwidth values are calculated by ClockBuilder Pro and written into these registers. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 118 The loop MA divider denominator values are calculated by ClockBuilder Pro for a particular frequency plan annd are written into these registers. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 119 See also registers 0x0415–0x041F. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 120 The ramp rate is selected when using CBPro. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 121 Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 122 IN2 Input 2 applies to LOS alarm 0x0437[2], OOF alarm 0x0437[6] Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 123 3: Same as 0 Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 124 HSW_FINE_PM_LEN_P Calculated by CBPro. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 125 Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 126 Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 127: Registers Si5383/84

    M_NUM_PLLB 0x051B 55:48 M_NUM_PLLB Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 128 Managed by CBPro. N_PLLB Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 129 Bits 7:1 of this register have no function and can be written to any value. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 130 Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 131: Registers Si5383

    Fastback BWs for PLL C. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 132 1: To disable FINC/FDEC updates. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 133 1: Holdover Enabled. Standard setting. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 134 1. Holdover exit ramp optimzation. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 135 1: To mask LOS from the clock se- lection logic Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 136 3: For priority 3 4-7: Reserved Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 137 Caclulated in CBPro Y_PLLC Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 138 Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 139 Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 140: Registers Si5383/84

    Fastlock BWs for PLL D. (Standard Input mode) Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 141 1. Bypass digital hold exit ramping when there is no valid history. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 142 See also Registers 0x0716-0x0720. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 143 Standard setting. (Standard Input mode) Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 144 1. Holdover exit ramp optimzation. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 145 1: To mask LOS from the clock se- lection logic Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 146 4: For priority 4 5-7: Reserved Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 147 HSW_FINE_PM_LEN_P Calculated by CBPro. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 148 Holdover (Standard Input mode) Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 149 IN3/IN4 not selected by ONFIG2_CMOS_PLLD 11: Reserved Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 150: Registers Si5383/84

    • Input 3 (Reference) corresponds to IN_EN 0x0949[3] Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 151: Page A Registers Si5383/84

    Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 152: Page B Registers Si5383/84

    When a DSPLL is in DCO mode, its corresponding clock disable bit should be cleared. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 153 Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 154: Page D Registers Si5383/84

    15:8 0x0D1F 23:16 0x0D20 Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 155: Registers Si5383/84, 1 Pps Mode

    Firmware Build Number 0x5307 Firmware Build Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 156 0x530C 0x530D 0x530E 0x530F Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 157: Pps Loop Registers Si5383/84

    Write 0 to this bit to clear. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 158 Write a 0 to this bit to clear Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 159 1 = External LOS Asserted Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 160 01h = 2 polls FFh= 256 polls Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 161 15:8 LOL_CLR_THR 0x534F LOL_CLR_THR Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 162 15:8 PD_ADJ 0x5363 PD_ADJ Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 163 SLA_FP_VAL_CNT Calculated by CBPro. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 164 SLA_PP6_NCYC Calculated by CBPro. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 165 SLA_RL2_NF Calculated by CBPro. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 166 SLA_RL4_NI Calculated by CBPro. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 167 SLB_PP2_NCYC Calculated by CBPro Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 168 15:8 SLB_PE_THR 0x53B3 SLB_PE_THR Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 169 SLB_RL3_NI Calculated by CBPro Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 170 10 and 11: Normal Mode Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 171 Calculated by CBPro based on val- ue of selected. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 172: Phase Readout Registers Si5383/84, 1Pps Mode

    11: IN3 and IN4 selected Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 173 1. Bit 31 is set when the value was previously read (indicates "stale" information being returned). Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 174 Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 175 Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 176: Custom Differential Amplitude Controls

    See also (xref) for additional information on the OUTx_FORMAT, OUTx_AMPL, and OUTx_CM controls. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...

  • Page 177: Accessing Design And Support Collateral

    The Si5383/84 is currently available to restricted customers only. To access the support documentation, contact Skyworks Support. Skyworks Solutions, Inc. • Phone [781] 376-3000 • Fax [781] 376-3100 • sales@skyworksinc.com • www.skyworksinc.com Rev. 1.0 • Skyworks Proprietary Information • Products and Product Information are Subject to Change Without Notice • December 9, 2021...
  • Page 178 Information in this document is provided in connection with Skyworks Solutions, Inc. (“Skyworks”) products or services. These materials, including the information contained herein, are provided by Skyworks as a service to its customers and may be used for informational purposes only by the customer.

This manual is also suitable for:

Si5384

Table of Contents
