EarMate®-4220 Crystal
User Guide
•
100% Digital
•
Feedback Cancellation
•
Noise Reduction
•
Fingertip Volume Control
an IntriCon company
My eartip size:
1-800-221-2099
My battery size: 10 (yellow tab)
MEDICAL GRADE HEARING AID
PROVEN QUALITY
Doctor Designed • Audiologist Approved
100% Digital American-Made Technology
Advertisement
Table of Contents
Related Manuals for IntriCon Hearing Help Express EarMate-4220 Crystal
Summary of Contents for IntriCon Hearing Help Express EarMate-4220 Crystal
- Page 1 100% Digital • Feedback Cancellation • Noise Reduction • Fingertip Volume Control an IntriCon company My eartip size: 1-800-221-2099 My battery size: 10 (yellow tab) MEDICAL GRADE HEARING AID PROVEN QUALITY Doctor Designed • Audiologist Approved 100% Digital American-Made Technology...
-
Page 2: Table Of Contents
Where relationships begin with Value & Service and thrive on Quality and Trust. an IntriCon company Congratulations on your choice of the EarMate®-4220 Crystal hearing aid. I’m pleased and delighted to make this available to you... And I believe you’ll be pleased too. You’ll enjoy all the benefits the EarMate®-4220 Crystal has to offer, especially knowing how little you paid. -
Page 3: Parts Identified
Parts Identified Get to know your EarMate-4220 Crystal Battery Size: 10 (yellow tab) 1. Sound opening 4. Volume wheel 5. Micro handle (pullout knob) 2. Eartip 6. Microphone 3. Right or Left indicator 7. Battery holder RED = Right Ear Serial number is located on BLUE = Left Ear the outer casing of hearing aid... -
Page 4: Fit And Eartip Information
Fit and Eartip Information Getting the best fit possible is one of the most important steps with any hearing aid. Your EarMate-4220 comes with three small medium large sizes of soft eartips. The medium size small #84225 eartip has already been attached. CALL FOR medium #84227... -
Page 5: How To Insert Battery
Inserting the Battery IMPORTANT: The battery holder for the left and right EarMate-4220 open in opposite directions. Left Aid Right Aid 1. Hold the EarMate-4220 so the volume control is EarMate-4220 left above the battery holder. Next, using a fingernail gently pull the battery holder to the side. -
Page 6: Inserting & Removing Earmate-4220
Inserting and Removing 1. Hold the EarMate-4220 by the Micro handle with the volume control above the battery holder. 2. Push the EarMate-4220 into your ear canal until it fits securely in place. You may need to rotate it slightly for a good fit. -
Page 7: Talking On The Telephone
Talking on the telephone You can use your EarMate-4220 while talking on the telephone. Hold the handset slightly away from your ear and/or hold it at a slight angle to prevent feedback. This may take a little practice. Note: Your EarMate-4220 may feedback (squeal) if it is set too high, a hand or object is near it, or when inserting and removing it. -
Page 8: Care & Cleaning
Care and Cleaning Open the battery holder when not wearing your EarMate-4220. Any moisture inside your hearing aid can then evaporate, extending the life of your EarMate-4220. Always clean your EarMate-4220 at the beginning of each day prior to using it. Without regular cleaning, wax can build up and prevent your EarMate-4220 from working properly. -
Page 9: Helpful Tips
IMPORTANT CARE INSTRUCTIONS BEGINNING THE DAY: After showering, apply all lotions, creams, hairspray, perfume and cologne BEFORE putting on your EarMate-4220s. Water and such sprays can damage hearing aids. And please remember, your hearing aids are sensitive and don’t like extreme heat or cold. Never place your EarMate-4220 in water. -
Page 10: Service Plans
Protect your hearing investment Protection Plan – worry-free hearing aid repairs or replacements! (call for pricing) • Get PROTECTED - Water, droppage, step on it - you name it! We will fix or replace it free of charge for one year (loss or theft are not covered). •... -
Page 11: Troubleshooting/Service
Troubleshooting your EarMate If your hearing aid is: WEAK, DISTORTED, DEAD 1. Test to be sure the EarMate is turned 4. Clean your EarMate thoroughly (pg. 8). on (pg. 3). 5. If your EarMate goes dead periodically, but comes on after 2. -
Page 12: Technical Data / Additional Info
EarMate-4220 Technical Information Maximum SSPL90 110.1 dB HFA SSPL90 106.7 dB HFA full-on gain 39.3 dB Reference test gain 29.3 dB Frequency range 200 Hz to 5793.7 Hz Total harmonic distortion 500 Hz: 1.4%, 800 Hz: .9%, 1600 Hz: .8% Equivalent input noise 23.9 dB Attack time (msec) - Page 13 Precautions: A hearing aid is a precision electronic device and medical evaluation from a licensed physician. as such, it requires the care in use and handling that you would Federal law permits a fully informed adult to sign a waiver afford any fine piece of equipment.
-
Page 14: Accessories
Helpful Accessories PerfectDry Lux The PerfectDry Lux dehumidifier provides 30 minute rapid drying time. Also provides UV-C disinfection which destroy 99% of microorganisms which are often responsible for itchiness, allergies, and other irritations of the ear canal. Includes USB power supply. PerfectDry Lux, item #88745 $90.00 Protect your hearing aid... - Page 15 Helpful Accessories Premium hearing aid batteries for less! You always get: Best battery value Home delivery Fresh! Fresh! Fresh! FREE shipping Your EarMate-4220 uses a size 10 (yellow tab) zinc-air battery. Battery Care Kit – Worry-free hearing aid battery use. Worry-free hearing aid battery use.
-
Page 16: Warranty
Express for this warranty to condition. Ship insured mail. apply. Ship insured mail. Questions, call toll-free: 1-800-221-2099 an IntriCon company 1-800-221-2099 • HearingHelp.com 1714 Sycamore Rd • DeKalb, IL 60115 *349190701* © Hearing Help Express®, Inc.
