Felix™-8720 Accu-Fit
User Guide
The answer to diffi cult one-on-one conversations
especially in noisy environments.
Hear conversations easily whether you're talking with family and
friends or trying to listen to your favorite TV program.
My eartip style & size:
an IntriCon company
My tubing size:
1-800-221-2099
My battery size: 312 (brown tab)
MEDICAL GRADE HEARING AID
PROVEN QUALITY
Doctor Designed • Audiologist Approved
100% Digital American-made technology
Advertisement
Table of Contents
Related Manuals for IntriCon HearingHelp Express Felix-8720 Accu-Fit
Summary of Contents for IntriCon HearingHelp Express Felix-8720 Accu-Fit
- Page 1 Hear conversations easily whether you’re talking with family and friends or trying to listen to your favorite TV program. My eartip style & size: an IntriCon company My tubing size: 1-800-221-2099 My battery size: 312 (brown tab)
-
Page 2: Table Of Contents
Where relationships begin with Value & Service and thrive on Quality and Trust. an IntriCon company Congratulations on your choice of the Felix™-8720 Accu-Fit hearing aid. I’m pleased and delighted to make this available to you... And I believe you’ll be pleased too. You’ll enjoy all the benefits the Felix™-8720 Accu-Fit has to offer, especially knowing how little you paid. -
Page 3: Parts Identified
Parts Identified Accu-Fit Felix-8720 Get to know your Battery Size: 312 (brown tab) 1. Microphone and Receiver 5. Slim-tube (pg. 5) 6. Open Dome Eartip 2. Program Button (pg. 8) 7. Sure-lock (pg. 7) 3. Volume Control (pg. 8) Serial number is located on 4. -
Page 4: How To Insert Battery (Felix-8720)
Inserting the Battery 1. Remove the brown colored tab from the flat, (+) positive side of the size 312 battery. Wait one minute for battery to reach full power before using (or testing) battery. 2. Open battery holder gently, using your fingernail or thumbnail. -
Page 5: Tubing Choices / Removing & Attaching
Slim Tube Choices You can try your Felix-8720 right away just as it is. We’ve selected the slim-tubing that works the best for most people and encourage you to try this size first. You will find size 1A Left and Right slim-tubing inside the green case, attached to the bag your Felix-8720 is in. -
Page 6: Eartip Choices / Removing & Attaching
Eartip Choices Eartip Choices: There are four different styles of eartips available. We have attached to the tubing the size we feel works best for most people: Tulip Dome You will find this inside the black case, attached to the tubing and stapled to the bag your Felix-8720 is in. -
Page 7: Which Is Left And Right
Which is left and right How to tell your right Felix-8720 from your left Felix-8720: Felix-8720 hearing aids can be used in either ear by selecting a right slim-tubing or a left slim-tubing. Each slim-tubing is preformed to “point” into either the right or left ear. Right slim-tubing has red lettering on it and left slim-tubing has blue lettering (printed near the eartip). -
Page 8: Volume Control / Program Settings
Adjusting the Volume Control Volume Control: Your Felix-8720 is equipped with a push button Your Felix-8720 is equipped with a push button control (located above the battery holder compartment). This button (located above the battery holder compartment). This button allows you to select your listening volume. Increase the volume: With your fingertip repeatedly press the With your fingertip repeatedly press the volume control button. -
Page 9: Getting Started
Accu-Fit Felix-8720 Using your with the Companion Microphone with the Companion Microphone Getting Started Charging the Companion Microphone The Companion Microphone (Mic) has a rechargeable battery. Charge your Companion Mic before using. To charge the Companion Mic, plug the charging cable into the Micro USB charging port and then plug the 2-prong end into a power outlet. -
Page 10: Turning On & Off Companion Mic
Turning Companion Mic On To turn the Companion Mic On: Press and hold down the Power Button for up to two seconds - until you see the LED light sequence as Power shown below for Power On. Button To turn the Companion Mic Off: Press and hold down the Power Button for up to two seconds - until you see the LED light sequence as... -
Page 11: Companion Mic Group/Single Switch
Group/Single Switch The Companion Mic can be used for picking up the voice from one person (one speaker) or used as a microphone to pick up multiple voices at one time. Group/Single Switch One Speaker – Slide the Group/Single Switch into the position that shows a single speaker Narrow end up towards speaker’s... -
Page 12: Care & Cleaning
Care and Cleaning We’ve done what we can to protect your Felix-8720 from moisture and earwax but a little regular cleaning by you will go a long way towards trouble-free use. Without regular cleaning, wax and moisture can build up and prevent your Felix-8720 from working properly. -
Page 13: Helpful Tips
IMPORTANT CARE INSTRUCTIONS BEGINNING THE DAY: After showering, apply all lotions, creams, hairspray, perfume and cologne BEFORE putting on your Felix-8720s. Water and such sprays can damage hearing aids. And please remember, your hearing aids are sensitive and don’t like extreme heat or cold. Never place your Felix-8720 in water. -
Page 14: Service Plans
Protect your hearing investment Protection Plan – worry-free hearing aid repairs or replacements! (call for pricing) • Get PROTECTED - Water, droppage, step on it - you name it! We will fix or replace it free of charge for one year (loss or theft are not covered). •... -
Page 15: Troubleshooting/Service
Troubleshooting your Felix-8720 If your hearing aid is: WHISTLING (FEEDBACK) 1. Your Felix-8720 may briefly whistle when a hand, 4. Try a different size eartip (pg. 6) or call customer hat or other object is near it or when inserting and service for other options. -
Page 16: Additional Information
Precautions: A hearing aid is a precision electronic device and medical evaluation from a licensed physician. as such, it requires the care in use and handling that you would Federal law permits a fully informed adult to sign a waiver afford any fine piece of equipment. -
Page 17: Technical Data
Felix-8720 Technical Information Maximum SSPL90 122.3 dB HFA SSPL90 111.3 dB HFA full-on gain 39.8 dB Reference test gain 33.8 dB Frequency range 200 Hz to 5890.2 Hz Equivalent input noise 29.5 dB SPL Total harmonic distortion 500 Hz: .6%, 800 Hz: .2%, 1600 Hz: .3% Attack time (msec) Release time (msec) Induction coil sensitivity (at 31.6 mA/m) HFA... -
Page 18: Accessories
Helpful Accessories Battery Care Kit – Worry-free hearing aid battery use. Worry-free hearing aid battery use. Battery Care Kit includes: • Digital Keychain Battery Tester – Small enough to go with Small enough to go with you anywhere. Takes the guesswork out of battery testing. •... - Page 19 Helpful Accessories PerfectDry Lux The PerfectDry Lux dehumidifier provides 30 minute rapid drying time. Also provides UV-C disinfection which destroy 99% of microorganisms which are often responsible for itchiness, allergies, and other irritations of the ear canal. Includes USB power supply. PerfectDry Lux, item #88745 $90.00 Easy-to-use cleaning tools...
-
Page 20: Warranty
Express for this warranty to condition. Ship insured mail. apply. Ship insured mail. Questions, call toll-free: 1-800-221-2099 an IntriCon company 1-800-221-2099 • HearingHelp.com 1714 Sycamore Rd • DeKalb, IL 60115 *409190726* © Hearing Help Express®, Inc.
