Here you can search Vidor to find the beta SAMD21 core for the board. Click on its box and
click on the install button. On the bottom bar of the window you can follow the download
and install procedure, including the installation of the proper driver, needed by the
operating system to use the board. For more information about cores, see the guide on
installing additional Arduino cores.
Now that the SAMD beta Core is installed, you can connect the board to the computer
using a standard USB cable. The very first time your computer may go through the new
hardware installation process.
Drivers
On Windows, drivers are needed to allow the board communication. These drivers will be
installed automatically when adding the core.
On MacOSX and Linux no driver is needed.
Select your board type and port
From Tools select the Board Arduino MKR Vidor 4000
2/8
